Applent Instruments AT4610 User manual

User’s Guide
Rev.A7
AT4610/AT4710
Data Logger
~@
Applent Instruments Ltd.
Address: Dangnan Industrial Zone,
Changzhou, Jiangsu, China (PRC)
Post Code: 213014
Tel: [phone]
Fax: [phone]
Sales Email: [e-mail]
Tech Email: [e-mail]
http://www.applent.com

2
AT4610/AT4710 User’s Guide
Safety Summary
Warning Dangerous:
The following general safety precautions must be observed during all phases of operation, service, and repair of this
instrument. Failure to comply with these precautions or with specific WARNINGS elsewhere in this manual may
impair the protection provided by the equipment. In addition it violates safety standards of design, manufacture, and
intended use of the instrument.
Disclaimer
The Applent Instruments assumes no liability for the customer's failure to
comply with these requirements.
Ground
The Instrument
To avoid electric shock hazard, the instrument chassis and cabinet must be
connected to a safety earth ground by the supplied power cable with earth
blade.
DO NOT
Operate In An Explosive
Atmosphere
Do not operate the instrument in the presence of inflammable gasses or
fumes. Operation of any electrical instrument in such
an environment
constitutes a definite safety hazard.
Keep away
from live circuit
Operating personnel must not remove instrument covers. Component
replacement and internal adjustments must be made by qualified
maintenance personnel. Do not replace components with the power cable
connected. Under certain conditions, dangerous voltages may exist even
with the power cable removed. To avoid injuries, always disconnect power
and discharge circuits before touching them.
Operations not
included in the manual are
forbidden The protection measurements will be failure while beyond the scope.
Waste Electrical and Electronic Equipment (WEEE) order 2002/96/EC
Do not leave in the trash can

3
Unpacking and Preparation
CERTIFIACTION, LIMITED & LIMITATION OF LIABILITY
Applent Instruments, Inc. (shortened form Applent) certifies that this product met its published specifications at the
time of shipment from the factory. Applent further certifies that its calibration measurements are traceable to the
People’s Republic of China National Institute of Standards and Technology, to the extent allowed by the Institution’s
calibration facility or by the calibration facilities of other International Standards Organization members.
This Applent instrument product is warranted against defects in material and workmanship for a period corresponding
to the individual warranty periods of its component products. The warranty period is 1 year and begins on the date
of shipment. During the warranty period, Applent will, at its option, either repair or replace products that prove to be
defective. This warranty extends only to the original buyer or end-user customer of a Applent authorized reseller, and
does not apply to fuses, disposable batteries or to any product which, in Applent’s opinion, has been misused, altered,
neglected or damaged by accident or abnormal conditions of operation or handling.
For warranty service or repair, this product must be returned to a service facility designated by Applent. The buyer
shall prepay shipping charges to Applent and the Buyer shall pay all shipping charges, duties, and taxes for products
returned to Applent from another country.
Applent warrants that its software and firmware designated by Applent for use with an instrument will execute its
programming instruction when properly installed on that instrument. Applent doesnot warrant that the operation of the
instrument, or software, or firmware, will be uninterrupted or error free.
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by the Buyer,
Buyer-supplied software or interfacing, unauthorized modification or misuse, operation outside the environmental
specifications for the product, or improper site preparation or maintenance.
THIS WARRANTY IS BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. APPLENT SHALL NOT BE LIABLE
FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING
LOSS OF DATA, WHETHER ARISING FROM BREACH OF WARRANTY OR BASED ON CONTRACT, TORT,
RELIANCE OR ANY OTHER THEORY.
People’s Republic of China
Jiangsu Province
Changzhou Applent Instruments Inc.
May. 2014
Rev.C0

4
AT4610/AT4710 User’s Guide
Contents
Safety Summary .....................................................................................................................................................2
CERTIFIACTION, LIMITED & LIMITATION OF LIABILITY .........................................................................3
Contents..................................................................................................................................................................4
Figure Contents.......................................................................................................................................................7
Table Contents........................................................................................................................................................7
1. Unpacking and Preparation.....................................................................................................................................9
1.1 Packing List............................................................................................................................................9
1.2 Power Requirement ................................................................................................................................9
1.3 Operation Environment...........................................................................................................................9
1.4 Cleaning................................................................................................................................................10
1.5 Instrument Handle ................................................................................................................................10
2. Overview ..............................................................................................................................................................11
2.1 Introduction...........................................................................................................................................11
2.2 Main Specification................................................................................................................................12
2.2.1 Parameters.....................................................................................................................................12
2.2.2 Measurement Range .....................................................................................................................12
2.2.3 Sampling Rate...............................................................................................................................12
2.2.4 Basic Accuracy .............................................................................................................................12
2.2.5 Resolution.....................................................................................................................................12
2.2.6 Comparator...................................................................................................................................13
2.2.7 Interface........................................................................................................................................13
3. Startup...................................................................................................................................................................14
3.1 Front Panel............................................................................................................................................14
3.1.1 Front panel description .................................................................................................................14
3.2 Rear Panel.............................................................................................................................................14
3.3 Display Layout......................................................................................................................................15
3.4 Power up...............................................................................................................................................16
3.4.1 Power on/off .................................................................................................................................16
3.4.2 Instrument Version........................................................................................................................16
3.5 How to Connect....................................................................................................................................16
3.5.1 Connection of Voltage...................................................................................................................17
3.5.2 Connection of Thermocouple .......................................................................................................17
3.5.3 Connection of 3-wire RTD ...........................................................................................................17
3.5.4 Connection of Resistance and 4-wire RTD...................................................................................18
4. <SETUP> Page.....................................................................................................................................................19
4.1 Channel [Color] Setup..........................................................................................................................19
4.2 Channel [ON/OFF]...............................................................................................................................20
4.3 Input [Type]..........................................................................................................................................20
4.4 [Range] Setting.....................................................................................................................................20
4.5 Graph [Lower Limit] [Upper Limit].....................................................................................................22
4.6 [Auto Save] Setting Value.....................................................................................................................23
5. <SYSTEM CONFIG>Page ..................................................................................................................................24
5.1 Date/Time .............................................................................................................................................24
5.2 Change System [Language]..................................................................................................................25
5.3 [DATALOG] Group..............................................................................................................................25
5.3.1 File Type for [Real-time Saving]..................................................................................................25
5.3.2 Media............................................................................................................................................26
5.3.3 File Name Prefix...........................................................................................................................26
5.3.4 Split Files......................................................................................................................................27
5.3.5 X-axis Display ..............................................................................................................................27
5.3.6 Start Prompt Dialog Box...............................................................................................................28
5.4 [FONT] Group......................................................................................................................................28
5.4.1 Value Font.....................................................................................................................................29
5.4.2 Value Color...................................................................................................................................29
5.5 [MEASUREMENT] Group..................................................................................................................29
5.5.1 Cold Junction Compensation........................................................................................................29

5
5.5.2 Open-Circuit Detection.................................................................................................................29
5.5.3 Digital Filter..................................................................................................................................29
5.6 Local Network Connection...................................................................................................................30
5.7 WIRELESS LAN Connection ..............................................................................................................30
5.8 Remote Control Setting ........................................................................................................................30
5.8.1 RS-232 Baud Rate ........................................................................................................................30
5.8.2 RS-232 Configuration...................................................................................................................30
5.8.3 Command Handshake...................................................................................................................31
6. <COMPARATOR SET> Page..............................................................................................................................32
6.1 Turn on/off Comparator [COMP].........................................................................................................32
6.2 Comparator [Upper/Lower] Limit Setting............................................................................................33
6.3 Display Comparative Result.................................................................................................................33
6.3.1 Display Comparative Result on <MEAS DISPLAY> page..........................................................34
6.3.2 Display Comparative Results on <DATA LOG> Page.................................................................34
7. <File> Page...........................................................................................................................................................36
7.1 Target [Media] ......................................................................................................................................36
7.2 [Auto Save] Setting...............................................................................................................................37
7.3 Saving Files into Internal Disk .............................................................................................................37
7.4 Load File from Internal Disk................................................................................................................38
7.5 Delete File.............................................................................................................................................38
7.6 Access External Media .........................................................................................................................39
8. <MEAS DISPLAY> Page ....................................................................................................................................40
8.1 <MEAS DISPLAY> Page ....................................................................................................................40
8.2 Sampling Rate.......................................................................................................................................40
8.3 Trigger ..................................................................................................................................................41
9. <DATA LOG> Page..............................................................................................................................................42
9.1 Setting Sampling Rate ..........................................................................................................................42
9.2 Horizontal Axis Gridding Setting .........................................................................................................43
9.3 Curve Display.......................................................................................................................................44
9.4 Start Logging Data................................................................................................................................45
9.5 Auto-Save Data to External Disk..........................................................................................................45
9.5.1 Rules of File Creating...................................................................................................................46
9.5.2 File Path........................................................................................................................................46
9.5.3 Comma-Separated Values File (CSV)...........................................................................................46
9.5.4 Binary File Format (BIN).............................................................................................................47
9.6 Manual-Save Data to External Disk .....................................................................................................48
9.7 Browse Historical Data.........................................................................................................................49
9.8 Cursor Setting.......................................................................................................................................50
9.9 Channel Display....................................................................................................................................50
10. Remote Control.............................................................................................................................................52
10.1 RS-232C ...............................................................................................................................................52
10.1.1 RS232C Connection .....................................................................................................................52
10.2 USB-232 Interface................................................................................................................................53
10.3 Ethernet Interface..................................................................................................................................53
10.4 WIRELESS LAN Ethernet Interface....................................................................................................54
10.5 SCPI Language.....................................................................................................................................55
10.6 Handshake Protocol..............................................................................................................................55
10.7 Handshake Identification Code.............................................................................................................55
11. SCPI Command Reference...........................................................................................................................57
11.1 Terminator.............................................................................................................................................57
11.1.1 Terminator Rules...........................................................................................................................57
11.1.2 Notation Conventions and Definitions..........................................................................................57
11.1.3 Command Structure......................................................................................................................58
11.2 Header and Parameters .........................................................................................................................58
11.2.1 Header...........................................................................................................................................58
11.2.2 Parameter......................................................................................................................................58
11.2.3 Separator.......................................................................................................................................59
11.3 Command Reference ............................................................................................................................59

6
AT4610/AT4710 User’s Guide
11.4 DISPLAY SUBSYSTEM .........................................................................................................................59
11.4.1 DISPlay:PAGE..............................................................................................................................60
11.4.2 DISP:LINE ...................................................................................................................................60
11.5 SETUP SUBSYSTEM..........................................................................................................................60
11.5.1 SETUP:CH?..................................................................................................................................61
11.5.2 SETUP:CH:EN.............................................................................................................................61
11.5.3 SETUP:CH:TYPE ........................................................................................................................61
11.5.4 SETUP:CH:RANGE.....................................................................................................................61
11.5.5 SETUP:CH:LIMIT .......................................................................................................................61
11.6 SYSTEM CONFIG SUBSYSTEM ......................................................................................................62
11.6.1 SYST:LOG:FEXT ........................................................................................................................62
11.6.2 SYST:LOG:MEDIA .....................................................................................................................62
11.6.3 SYST:LOG:FILE..........................................................................................................................62
11.6.4 SYST:LOG:SPLIT........................................................................................................................63
11.6.5 SYST:LOG:XDISP.......................................................................................................................63
11.6.6 SYST:LOG:MSG..........................................................................................................................63
11.6.7 SYST:CJC.....................................................................................................................................64
11.6.8 SYST:OCD...................................................................................................................................64
11.6.9 SYST:FILTER ..............................................................................................................................64
11.6.10 SYST:RESULT:FONT..................................................................................................................64
11.6.11 SYST:RESULT:COLOR...............................................................................................................64
11.7 COMPARATOR SET SUBSYSTEM...................................................................................................64
11.7.1 COMP:EN.....................................................................................................................................65
11.7.2 COMP:CH:EN..............................................................................................................................65
11.7.3 COMP:CH ....................................................................................................................................65
11.8 FILE SUBSYSTEM .............................................................................................................................65
11.8.1 FILE:SAVE...................................................................................................................................66
11.8.2 FILE?............................................................................................................................................66
11.9 MEAS SUBSYSTEM...........................................................................................................................66
11.9.1 MEAS:RATE................................................................................................................................66
11.9.2 MEAS:FETCH?............................................................................................................................66
11.10 LOG SUBSYSTEM..............................................................................................................................67
11.10.1 LOG:STATE .................................................................................................................................67
11.10.2 LOG:RATE...................................................................................................................................67
11.10.3 LOG:DIV......................................................................................................................................67
11.10.4 LOG:DISP ....................................................................................................................................68
11.10.5 LOG:FETCH?...............................................................................................................................68
11.11 IDN? .....................................................................................................................................................69
11.12 KEYLOCK Command..........................................................................................................................69
11.13 Setting System TIME............................................................................................................................69
11.14 ERR: SHAKE Command......................................................................................................................69
12. Specifications and Calibration......................................................................................................................70
12.1 Calibration Environment.......................................................................................................................70
12.1.1 Test Environment..........................................................................................................................70
12.1.2 Instrument Conditions...................................................................................................................70
12.2 Technical Specifications .......................................................................................................................70
12.2.1 DC Voltage....................................................................................................................................70
12.2.2 DC Resistance...............................................................................................................................71
12.3 Temperature..........................................................................................................................................71
12.3.1 Thermocouple...............................................................................................................................71
12.3.2 PT100 RTD...................................................................................................................................73
12.3.3 Cu50 Copper RTD........................................................................................................................73
12.4 General Specifications..........................................................................................................................74
12.5 Environmental Requirement.................................................................................................................75
12.6 Dimension.............................................................................................................................................76

7
Figure Contents
Figure 1-1 A handle kit is attached to the AT4610/AT4710..................................................................................10
Figure 3-1 Front panel..........................................................................................................................................14
Figure 3-2 Rear panel ...........................................................................................................................................14
Figure 3-3 Display layout.....................................................................................................................................15
Figure 3-4 Instrument’s version............................................................................................................................16
Figure 3-5 Test input terminal on rear panel.........................................................................................................16
Figure 3-6 Connection of voltage.........................................................................................................................17
Figure 3-7 Connection of thermocouple...............................................................................................................17
Figure 3-8 Connection of 3-wire RTD..................................................................................................................17
Figure 3-9 Connection of resistance and 4-wire RTD ..........................................................................................18
Figure 4-1 <SETUP> Page...................................................................................................................................19
Figure 4-2 Setting lower limit and upper limit in <SETUP> page.......................................................................22
Figure 4-3 Upper limit and lower limit in <DATALOG> page ...........................................................................22
Figure 5-1 < SYSTEM CONFIG > Page..............................................................................................................24
Figure 5-2 Clock input box...................................................................................................................................25
Figure 5-3 Input filename.....................................................................................................................................26
Figure 5-4 Input time interval of split files...........................................................................................................27
Figure 5-5 Graph of when X axis is time..............................................................................................................27
Figure 5-6 Graph of when X axis is date..............................................................................................................28
Figure 5-7 Graph of when X axis is data pointer..................................................................................................28
Figure 5-8 Start prompt dialog box.......................................................................................................................28
Figure 6-1 <COMPARATOR SET> page,............................................................................................................32
Figure 6-2 the data of group 1 in <COMPARATOR SET> page..........................................................................34
Figure 6-3 Comparator display in <MEAS DISPLAY> page ..............................................................................34
Figure 6-4 Comparator display on <DATALOG> page........................................................................................34
Figure 7-1 <File> page.........................................................................................................................................36
Figure 8-1 <MEAS DISPLAY> page...................................................................................................................40
Figure 9-1 <DATA LOG> page............................................................................................................................42
Figure 9-2 Graph of 1s’s horizontal axis ..............................................................................................................44
Figure 9-3 Graph of 5s’s horizontal axis ..............................................................................................................44
Figure 9-4 Numeric display method.....................................................................................................................45
Figure 9-5 Waveform display method ..................................................................................................................45
Figure 9-6 Start prompt dialog box.......................................................................................................................45
Figure 9-7 An example of a BIN file....................................................................................................................48
Figure 9-8 Manual save to external disk...............................................................................................................48
Figure 9-9 Browse historical data.........................................................................................................................49
Figure 9-10 Cursor................................................................................................................................................50
Figure 9-11 Channel display.................................................................................................................................51
Figure 10-1 RS-232 connector on rear panel........................................................................................................53
Figure 11-1 Command Tree Example...................................................................................................................58
Figure 12-1 Connection of voltage.......................................................................................................................70
Figure 12-2 Connection of resistance...................................................................................................................71
Figure 12-3 Connection of thermocouple.............................................................................................................71
Figure 12-4 Connection of 3-wire RTD................................................................................................................73
Figure 12-5 Connection of 4-wire RTD................................................................................................................73
Figure 12-6 Dimension.........................................................................................................................................76
Table Contents
Table 2-1 Measurement range...............................................................................................................................12
Table 3-1 Front panel description.........................................................................................................................14
Table 3-2 Rear panel description..........................................................................................................................15
Table 4-1 Range limit of DC voltage (AT4610) ...................................................................................................20
Table 4-2 Range limit of K type thermocouple ....................................................................................................21

8
AT4610/AT4710 User’s Guide
Table 4-3 Range limit of J type thermocouple......................................................................................................21
Table 4-4 Range limit of E type thermocouple.....................................................................................................21
Table 4-5 Range limit of T type thermocouple.....................................................................................................21
Table 4-6 Range limit of N type thermocouple ....................................................................................................21
Table 4-7 Range limit of S type thermocouple.....................................................................................................21
Table 4-8 Range limit of W type thermocouple....................................................................................................21
Table 4-9 Range limit of R type thermocouple.....................................................................................................21
Table 4-10 Range limit of PT100 (RTD-3W/RTD-4W).......................................................................................22
Table 4-11 Range limit of resistance (AT4610)....................................................................................................22
Table 5-1 Identification code definition return by command handshake..............................................................31
Table 7-1 Target disk list.......................................................................................................................................36
Table 9-1 Sampling rate and internal buffer logging time....................................................................................43
Table 9-2 An example of a CSV file.....................................................................................................................46
Table 10-1 Common RS-232 signal......................................................................................................................52
Table 10-2 RS-232 Standard minimum subset .....................................................................................................52
Table 10-3 Identification code definition returned by command handshake........................................................55
Table 11-1 Multiplier Mnemonics ........................................................................................................................59
Table 11-2 DISPLAY subsystem tree ...................................................................................................................60
Table 11-3 SETUP system tree .......................................................................................................................60
Table 11-4 COMPARATOR subsystem tree......................................................................................................64
Table 11-5 FILE Subsystem tree...........................................................................................................................65
Table 11-6 MEAS subsystem tree.........................................................................................................................66
Table 11-7 LOG subsystem tree ...........................................................................................................................67
Table 12-1 DC voltage specifications...................................................................................................................71
Table 12-2 DC resistance specifications...............................................................................................................71
Table 12-3 Specifications for thermocouple TC-K...............................................................................................72
Table 12-4 Specifications for thermocouple TC-J................................................................................................72
Table 12-5 Specifications for thermocouple TC-E ...............................................................................................72
Table 12-6 Specifications for thermocouple TC-T ...............................................................................................72
Table 12-7 Specifications for thermocouple TC-N...............................................................................................72
Table 12-8 Specifications for thermocouple TC-S ...............................................................................................73
Table 12-9 Specifications for thermocouple TC-B...............................................................................................73
Table 12-10 Specifications for thermocouple TC-R.............................................................................................73
Table 12-11 PT100 RTD (RTD-3W/RTD-4W) Specifications.............................................................................73
Table 12-12 Cu50 (3W) Copper RTD Specifications...........................................................................................73

9
Unpacking and Preparation
1.Unpacking and Preparation
&
&
&
This chapter describes:
Packing List
Power Requirements
Environmental Requirements
Cleaning
1.1 Packing List
After you receive the instrument, carry out checks during unpacking according to the following
procedures.
WARNING
If the external face of the instrument (such as the cover, front/rear panel, LCD screen, power switch, and port
connectors) appears to have been damaged during transport, do not turn on the power switch. Otherwise, you
may get an electrical shock.
Make sure that the packing box or shock-absorbing material used to package the instrument has
not been damaged.
Referring to <Packing List> in the packing box, check that all packaged items supplied with the
meter have been provided as per the specified optioned.
WARNING
If an abnormality is detected, contact the company and send the meter to your nearest Applent Instruments
sales or service office. For inspection by the transport company, save the packing box, shock-absorbing
material, and packaged items as you received them.
1.2 Power Requirement
Use AT46xx as per the following power supply conditions:
~Line: 100VAC~240VAC
Frequency: 50Hz/60Hz
WARNING
To prevent electrical shock, please connect to GND.
If users change power cord, please make sure reliable connection of GND.
1.3 Operation Environment
Ensure that the operation environment meets the following requirements.
Temperature：0°C～55°C,
Humidity ：@23°C＜70%RH

10
AT4610/AT4710 User’s Guide
1.4 Cleaning
To prevent electrical shock, disconnect the AT46xx/AT47xx power cable from the receptacle
before cleaning.
Use dry clothes slightly dipped in water to clean the case.
Do not attempt to clean the internal of the instrument.
WARNING
Don’t Use Organic Solvents (such as alcohol or gasoline) to clean the Instrument.
1.5 Instrument Handle
Figure 1-1Ahandle kit is attached to the AT4610/AT4710
1 Retracted 
3 Carrying Position

2 Extended
Remove Handle (Lift the handle perpendicular to the unit while pulling it in the direction of 1.
)

11
Overview
2.Overview
&
&
&
This chapter is organized as follows
Introduction
Main Specifications
2.1 Introduction
Thank you for purchasing AT4610/AT4710 Data Logger.
AT4610/AT4710 adopts high-performance ARM microprocessor and FPGA, it can record data
with real-time and high speed. It is 7 inches highlight true color LCD display screen, all touch
panel assist secondary function key to operate, it uses Applent ATOS Rev.7 operating system,
and it is more easy to use and more intelligent. Real-time display measured data and graph
brings you newer experience.
New design AT46/AT47 series data logger adopts real-time FPGA circuit, breaks the limitation
of sampling rate, coordinates high-efficient、high precise analog circuit, realize high precise and
super high sampling rate, the resolution of measured temperature reaches 0.01°C, sampling rate
of single channel <1ms, it only takes 10ms to complete measurement of 10 channels.
The AT4610/AT4710 can measure multiple channels’ signal, they include temperature
(-270°C~+2000°C), DCV (0.0005mV~100V) (AT4610 only), resistance (1mΩ~200Ω)
(AT4610 only) and so on. AT4610/AT4710 support various types of temperature sensors, they
include thermocouple K、J、E、T、N、S、B、R type, RTD: 3 wire and 4 wire PT100.
In order to apply to alive test, instrument adopts high voltage buffer circuit, MCU and IU can
withstand voltage 300VAC, allow MAX withstand voltage 300VDC for each channel.
There is 80MB high capacity data cache inside the instrument, used to real-time record, it can
save 5.5 hours’ data under 10ms sampling rate (AT4610 Only). Instrument supports four
USB2.0 host interface and one SD card interface.
The instrument configures comparator, and optional Handler (PLC) interface, output 10
channels NG signal.
Built-in LAN interface, RS-232C interface and USB232 interface, also have optional RS485
and Wireless LAN module.
The instrument adopts Applent enhanced PC remote control command, compatible with SCPI
(Standard Command for Programmable Instrument), and realize high-efficient remote control
and data acquisition function.
AT4610/AT4710 can be applied in many areas, they include fuel cell, electro bile battery,
lithium battery, acid battery pack’s develop and maintenance, LED and related circuit’s develop,
cars and their parts’ evaluation and measurement, daily maintenance of automatic equipment,
factory monitor, power device and other electronic components’measurement.

12
AT4610/AT4710 User’s Guide
Reference See complete technical specifications in chapter 12.
2.2 Main Specification
2.2.1 Parameters
Thermocouple graduation: K、J、E、T、N、S、B、R;
RTD graduation：3 wire or 4 wire PT100;
DC voltage (AT4610 only);
DC resistance (AT4610 only)
2.2.2 Measurement Range
Table 2-1 Measurement range
Input
Graduation
Measurement Range
TC
K
-270°C ~ 1300°C
J
-210°C ~ 1200°C
E
-270°C ~1000°C
T
-270°C ~ 400°C
N
-200°C ~ 1300°C
S
-50°C ~ 1700°C
B
250°C ~ 1800°C
R
-50°C ~ 1700°C
RTD
PT100
-100°C ~ 850°C
DCV(AT4610)
DCV
0.0005mV~100.000V
DCR(AT4610)
DCR
0.001Ω ~ 200.00Ω
2.2.3 Sampling Rate
AT4610 presets 19 kinds of sampling rate:
10ms, 20ms, 50ms, 100ms, 200ms,
500ms,1s, 2s, 5s, 10s, 20s, 30s,
1min, 2min, 5min, 10min, 20min, 30min and 1h
And AT4710 preset 14 kings of sampling rate:
500ms,
1s, 2s, 5s, 10s, 20s, 30s,
1min, 2min, 5min, 10min, 20min, 30min and 1h
2.2.4 Basic Accuracy
DC voltage: 0.1% (AT4610)
DC resistance: 0.1% (AT4610)
Thermocouple: ±0.6°C (K/J/E/T: 0~100°C)
PT100 RTD: ±0.6°C (-100~100°C)
2.2.5 Resolution
Temperature: 0.01°C
Resistance and voltage: Varying according to different range, please refer to “Specifications”
chapter.

13
Overview
2.2.6 Comparator
Individually setting Upper/Lower value for each channel and can be output via Handler.
2.2.7 Interface
RS-232 remote control (can communicate with host USB by USB-232 interface)
Supports MAX baud rate 115200bps, compatible with SCPI protocol, ASCII transmit.
Built-in 10M network card
Compatible with SCPI protocol, ASCII transmit.
USB host interface
Instrument built-in 4 groups USB interface, can externally connect USB-disk (U-disk or
USB HDD), support plug and play external USB mouse.
SD card interface
Support SD card storage
Handler interface
Support internal 5V and external MAX 35V power supply.
Input: trigger signal
Output: All sorting compare results’signal; high current drive output, direct drive relay.
Optional Wireless LAN interface
Applent’s USB Wireless LAN card is optional for the instrument.

14
AT4610/AT4710 User’s Guide
3.Startup
&
&
&
This chapter describes:
Front panel
Rear panel
Power up
Connect to device
3.1 Front Panel
3.1.1 Front panel description
Figure 3-1 Front panel
1
2
5
4
6
3
Table 3-1 Front panel description
No.
Description
1
USB disk interface
2
Power switch
3
LCD display screen with touch panel
4
Main function key:
Measurement and setup
5
Cursor keys
6
SD card slot
3.2 Rear Panel
Figure 3-2 Rear panel

15
Startup
1
2
3 4 5 6 7
8
Table 3-2 Rear panel description
No.
Description
1
Test input terminal
2
Power socket (100V-240VAC, 50Hz/60Hz)
3 Fuse holder (3A, 250V SB)
4
HANDLER interface
5
RS-232C interface and RS-485 interface(Optional)
6
LAN interface and USB host interface
7
USB slave interface
8
Reserve expanding input port
3.3 Display Layout
Figure 3-3 Display layout

16
AT4610/AT4710 User’s Guide
3.4 Power up
3.4.1 Power on/off
The power switch is tact switch with indicator light.
Press the power key for at least 2 seconds, release the power key after the buzzer beeps,
instrument will power up and power switch indicator will be turned on.
After the instrument is powered on, it will load Applent ATOS operating system, and this
process will take 10 seconds.
Then ATOS operating system will begin to perform AT4610/AT4710 procedure.
TIP
When instrument is in process of start or instrument’s procedure collapse or crash, press power switch or
about 4 seconds, then power will be forced to turn off.
3.4.2 Instrument Version
Figure 3-4 Instrument’s version
After finish loading ATOS operating system, the screen will display product model for a while
and its version.
In addition, on <SYSTEM CONFIG> page and <SETUP> page, instrument’s version is also
available.
You can also check instrument version by remote control’s command [idn?]
3.5 How to Connect
The input terminal on rear panel:
Figure 3-5 Test input terminal on rear panel
There are 10 groups of input, each input will AUTO configure 2 terminal, 3 terminal or 4
terminal according to input type.
Measuring voltage and thermocouple use 2 terminal, RTD uses 3 terminal or 4 terminal, and
resistance use 4 terminal.

17
Startup
3.5.1 Connection of Voltage
Figure 3-6 Connection of voltage
Please connect voltage source’s positive pole to input terminal’s positive pole, connect negative
pole to input terminal’s negative pole, as per the above figure, otherwise, instrument will
display negative value.
WARNING
The test terminal is limited to connect to DC voltage, connect to AC voltage will damage instrument.
Input voltage cannot exceed 120VDC.
3.5.2 Connection of Thermocouple
Instrument supports 8 types of thermocouple, connecting method for each type of thermocouple
is the same.
Figure 3-7 Connection of thermocouple
Please plug 2 terminals of thermocouple to positive and negative test terminal, generally
speaking, red wires is positive pole, black wire is negative pole.
WARNING
Instrument allows thermocouple to work with alive test, but ensure that the live voltage does not exceed
300VDC.
The MAX allowed voltage between input terminals is 300VDC.
If exceeding the above voltage, the input circuit of instrument will be damaged.
3.5.3 Connection of 3-wire RTD
Figure 3-8 Connection of 3-wire RTD

18
AT4610/AT4710 User’s Guide
In order to eliminate the effect of lead resistance, RTD usually use 3-wire to connect, please do
it as per the above figure.
3.5.4 Connection of Resistance and 4-wire RTD
Figure 3-9 Connection of resistance and 4-wire RTD
4 terminal method can efficiently eliminate the error caused by lead resistance.
AT4610/AT4710 can only use 4-wire to measure resistance, high precise RTD also use 4-wire
method to connect.
TIP
The instrument uses 4-wire connecting method to measure resistors.

19
<SETUP> Page
4. <SETUP> Page
&
&
&
This chapter describes all channels’ setting function
•Channel Color Setup
•Channel Turn on/off
•Input Type Setup
•Measuring Range Setup
•Graph Upper/Lower limit in <DATALOG> Page
Press [Setup] key or light touch page title, then light touch [SETUP] button in functional field,
instrument will enter <SETUP> Page.
All setup that is related to channel and <MEAS DISPLAY> Page and <DATALOG> Page is
operated in <SETUP> page.
On <SETUP> Page, the setting includes the following parameters:
Channel color setup
Channel turn on/off
Input type
Range
Curve graph lower limit value
Curve graph upper limit value
Figure 4-1 <SETUP> Page
4.1 Channel [Color] Setup
The graph color and measured data color for each channel can be set, there are 21 types of color
inside the instrument.
Steps of setting color:

20
AT4610/AT4710 User’s Guide
Step 1
Enter <SETUP> Page
Step 2
Touch screen
＆
click or use cursor to select [Channel Color] button;
Step 3
Touch screen function field at right side, click & select color.
TIP
The color for measured data is controlled by [Value Color] in [SYSTEM CONFIG] Page, it is only available when
it is set as Graph Color.
4.2 Channel [ON/OFF]
Users can independently turn off each channel, after turning off, all parameters at current
channel is set as unavailable.
4.3 Input [Type]
Each channel can individually set its input type, due to instrument supports various types of
inputs and each input type varies, DC-V and thermocouple (TC-K, TC-J, TC-E, TC-T, TC-N,
TC-S, TC-B, TC-W, TC-R) adopt 2 terminal method to test, 3-wire RTD adopts 3 terminal
method to test, 4-wire RTD and DC-R adopt 4 terminal method to test, after set input type,
please make sure input terminal is correct.
Steps of setting input type:
Step 1
Enter <SETUP> Page
Step 2
Touch screen & click or usecursor to select [Type] field;
Step 3
Touch screen function key field at right side, click
＆
select Input Type.
Function keys
Function
TC-K
Thermocouple
TC-J
Thermocouple
TC-E
Thermocouple
TC-T
Thermocouple
TC-N
Thermocouple
TC-S
Thermocouple
TC-B
Thermocouple
TC-W
Thermocouple
TC-R
Thermocouple
RTD-3W
3 wire PT100 RTD
RTD-4W
4 wire PT100 RTD
Cu50
Copper RTD
DC-V
DC Voltage (AT4610 only)
DC-R
DC Resistance (AT4610 only)
One key set
Set the rest channel’s type the same as this type
TIP
Due to the range and unit of temperature, voltage and resistance is different, the range of these input signal and
upper/lower limit value is independently saved in the internal disk, and they don’t affect each other.
4.4 [Range] Setting
Table 4-1 Range limit of DC voltage (AT4610)
