HT SOLAR-02 User manual

Rel. 4.00 - 22/11/22 1
SOLAR-02
USER
MANUAL
SOLAR-02
USER
MANUAL
ENVIRONMENTAL
PARAMETER
DATA LOGGER
Rel. 4.00 - 21/11/22

Rel. 4.00 - 22/11/2218
SOLAR-02
EN 1 

2.1. Preliminary instructions 20
2.2. During use 21
2.3. After use 21
 
3.1. Initial inspections 21
3.2. Power supply 21
3.3. Storage 21
4 
4.1. Description of controls 22
4.2.Description of function keys 22
4.3. Conditions when turning on 22
5 
5.1. General 23
5.2. Programming THE remote unit SOLAR-02 23
5.2.1. Setting the values of sensor 1 (PYRA or MONO) 24
5.2.2.Setting the values of sensor 2 (MULTI) 24
5.2.3.Setting the values of sensor 3 24
5.3. Using the SOLAR-02 in independent mode 25
5.4. Using the inclinometer function 25
5.5. Using the SOLAR-02 with master instrument type “M-USB” 25
5.5.1. Preliminary check 25
5.5.2.Use of the unit 26
5.6. Using the SOLAR-02 with master instrument type “M-RF” 26
5.6.1. Preliminary check 26
5.6.2. Use of the unit 27
6 
6.1.General information 28
6.2. Replacing the batteries 28
6.3. Cleaning 28
6.4. End of life 28
7 
7.1. Technical specications 29
7.2. General characteristics 29
7.3. Environmental conditions 29
7.4. Accessories 29
 
8.1. Warranty conditions 30
8.2. Service 30
INDICE

Rel. 4.00 - 22/11/22 19
SOLAR-02 EN
INTRODUCTION
1
ATTENZIONE
The remote unit SOLAR-02 has been designed to measure irradiation [W/
m2] and temperature [°C] by means of appropriate probes connected
to it. It can also be used in combination with a MASTER instrument to
carry out the above-mentioned measurements for testing/recording the
eciency of single-phase and three-phase photovoltaic installations.
The unit SOLAR-02 can be connected to the following accessories and MASTER
instruments:
For the sake of brevity, in this manual, the master instruments and the
accessories are indicated with the acronym given in column “Acronym” of the
previous Table 1
The unit SOLAR-02 has the following functions:
• Real-time display of irradiation and temperature values of PV module cells
and environment
• Connection with a irradiation sensor type Irr-P or reference cell type Irr-S2
• Connection to master unit via USB connection (M-USB) or radio frequency
connection (M-RF)
• Synchronization with master unit M-USB or M-RF when starting testing/
recording.
• Measurement of the tilting angle of PV panels
• The remote unit SOLAR-02 is a measuring instrument capable of using
radio frequency for data transfer. For internal reasons it was been adopted
a 2.4GHz harmonized frequency band. The above said radio based device is
built under Class 1 according to the Agreement stipulated among EEC and
EFTA countries, as dened by ERC/REC 70-03 protocols
• About a WiFi portable devices the European standards dictate
maximum radiated transmit power of 100mW EIRP and frequency range
2.400÷2.4835GHz. In France these types of equipment must be restricted to
the 2.4465÷2.4835GHz frequency range and must be restricted to indoor use
CAUTION
DESCRIPTION ACRONYM HT MODEL
Pyranometer Irr-P HT303, HT 303N
Irradiation sensor with 2 silicon cells Irr-S2 HT304, HT304N
Temperature sensor Tmp PT300N
Master instrument - USB connection M-USB SOLAR300, SOLAR300N
Master instrument - RF connection M-RF
SOLAR I-V, SOLAR I-Vw,
SOLAR I-Ve,I-V400,I-
V400w,I-V500w, PVCHECK,
PVCHECKs
TABLE 1:
LISTOF MASTER INSTRUMENTS
AND ACCESSORIES

Rel. 4.00 - 22/11/2220
SOLAR-02
The instrument was designed in compliance with the requirements of
R&TTE Directive as well as of harmonized directives for electronic measuring
instruments. Before and during measurements, carefully observe the following
instructions:
• Do not perform any measurement in humid environments, in the presence of
gas or explosive or inammable material or in dusty areas.
• Avoid any contact with the circuit to be tested if no measurements are being
carried out.
• Avoid any contact with exposed metal parts, with unused measuring leads,
circuits, etc.
• Do not perform any measurement when anomalies are found in the instrument,
such as deformations, breaks, substance leaks, no display view, etc.
• Only use HT original accessories.
• Only use HT original accessories.
In accordance with the recommendations of the European Council 1995/519/
EC and the standard EN62311, the instrument can be used safely while you are
holding it in your hands. Under this circumstance power levels with 2.4GHz
transmission are thoroughly covered as per the basic restrictions for human
exposure to RF according to the above mentioned European rules
Warning: observe the instructions reported in the manual. An improper use
could damage the instrument or its components
PRECAUTIONS AND
SAFETY MEASURES

CAUTION
CAUTION
• This instrument has been designed for use in the environmental conditions
specied in § 7.3
• We recommend following the usual safety rules to protect yourself from
dangerous voltages and currents and to protect the instrument against
improper use
• Do not apply any voltage to the instrument’s inputs
• Only the accessories supplied with the instrument guarantee safety
standards. They must be in good conditions and replaced, if necessary, with
identical models
• Do not subject the input connectors of the instrument to strong mechanical
stress
• Check that the batteries are correctly inserted
PRELIMINARY INSTRUCTIONS

CAUTION
The RF connection of remote unit SOLAR-02 is normally disabled for default.
For use of this unit with the Master meter “M-RF” (see Table 1) is necessary
to activate the RF connection (see § 5.6.1)

Rel. 4.00 - 22/11/22 21
SOLAR-02
INITIAL INSPECTIONS

Before shipment, the instrument’s electronics and mechanics have been
inspected. All possible precautions have been taken in order for the
instrument to be delivered without damage. However, we recommend
generally inspecting the instrument in order to detect any damage suered
during transport. Should you detect any anomalies, immediately contact
the forwarding agent. Moreover, we recommend checking that the package
contains all parts listed in § 0. Should you nd any discrepancy, please
contact the dealer. Should it become necessary to return the instrument,
please follow the instructions reported in § 8
POWER SUPPLY

The instrument is supplied by 4 x 1,5V batteries type IEC LR03 AAA. When
batteries are almost at, the symbol “ ” appears on the display. To replace
the batteries, see § 6.2
STORAGE

In order to guarantee precise measurements, after a long storage period,
in extreme environmental conditions, wait for the instrument to return to
normal conditions (see § 7.3)
PREPARATION FOR USE

We recommend carefully reading the following recommendations and
instructions:
DURING USE

CAUTION
• Failure to observe the warnings and/or instructions may damage the
instrument and/or its components or generate a danger for the operator.
• The symbol « » indicates that the batteries are at. Stop testing and
replace the batteries according to the procedure described in § 6.2
• When the instrument is connected to the circuit being tested, never touch
any lead, even if unused.
When measurements are completed, turn o the instrument by pressing and
holding the ON/OFF key for some seconds. If the instrument is not to be
used for a long time, remove the batteries and follow the instructions given
in § 7.3
AFTER USE

EN

Rel. 4.00 - 22/11/2222
SOLAR-02
DESCRIPTION OF THE
REMOTE UNIT SOLAR-02
4
DESCRIPTION OF CONTROLS
4.1
DESCRIPTION OF FUNCTION KEYS

This key has a double function of turning ON/OFF the unit and of returning
to the previous screen (ESC)
The SET key allows a rapid selection of the sensitivity of the solarimeter/
reference solar cell in use
This key has a double function of increasing (▲), which can be
used when programming, and of passing from the display of the
environmental temperature Te to the display of the tilting angle (FUNC).
The ▼key is used when programming the unit to set the parameter values,
CONDITIONS WHEN TURNING ON

1. Press the /ESC key to turn on the instrument
2.After the initial screen, where all display symbols appear, the screen beside,
relevant to the loaded rmware version (FW, e.g. 4.01), is displayed by the
unit for a few seconds
3.The screen beside is displayed in order to show that no probe is connected.
From this moment on it is possible to use the unit
4.Press and hold the /ESC key for a few seconds to turn o the unit
CAPTION:
1. LCD display
2. /ESC key
3. SET key
4. PYRA/CELL input
5. TEMP input
6. ▼ arrow key
7. FUNC/▲ key
8. USB port for connection to
master instrument M-USB

Rel. 4.00 - 22/11/22 23
SOLAR-02 EN
USING THE REMOTE
UNIT SOLAR-02
5
GENERAL
5.1
The remote unit SOLAR-02 can be used in the following modes:
1. Independent operation without connection to any master instrument
for measuring in real time the values of irradiation, cell temperature and
environmental temperature on PV installations. To this purpose, the unit
accepts, as inputs:
For irradiation measurement (expressed in W/m2 - PYRA/CELL input):
• Solarimeter probe with thermobattery type Irr-P (see Table 1)
• Double reference silicon cell type  (see Table 1)
For module and environmental temperature measurement (expressed in °C – TEMP
input)
• Temperature probe type Tmp (see Table 1)
2. Operation for testing/recording synchronized with a master instrument for
measuring and saving irradiation and temperature values of cells:
• Connection via USB cable C2007 → Master instrument type M-USB (see
Table 1)
• Connection with radio frequency (RF) → Master instrument type M-RF (see
Table 1)
According with settings receveid by MASTER instrument, SOLAR-02 display a
Tc value:
• Measured by the temperature probe “Tmp” (see Table 1)
• Calcuted using NOCT (set in MASTER instrument), Irradiance and
Environment Temperature measured by SOLAR-02 according to relationship
where:
Tamb= Environment Temperature
Gp= Irradiance measured
NOCT= Normal Operating Cell Temperature
Tcel =Tenv + (NOCT - 20) x Gp
800
CAUTION
The presence of “K” symbol on the left of “Tc” temperature value, indicates
that the Cell temperature (Tc) value displayed is not a measured
value buti s a calculated value according with previous relationship.
When the SOLAR-02 is switched on (before connection to MASTER
instrument) the Tc value is the measured value.


In order to obtain correct irradiation measurement results, it is necessary to carry
out a correct preliminary setting of the sensitivity values of the probes connected
to the PYRA/CELL input of the unit. The set values will be read and considered by
the master instruments upon testing/recording and will be kept by the SOLAR-02
even when the unit is turned o, until they are modied.
The unit SOLAR-02 allows setting the parameters of max 3 irradiation sensors.
In detail:
• The use of a sensor type  requires setting the sensitivity (K) expressed in
mV/kW*m or in µV/W*m and the parameter Alpha expressed in %/°C for the
various types of silicon (monocrystalline, polycristalline, etc.)
• The use of a sensor type Irr-P → requires setting the sensitivity (K) expressed
in mV/kW*m or in µV/W*m. The parameter Alpha expressed in %/°C is
ignored.V/W*m-2. The parameter Alpha expressed in %/°C is ignored.

Rel. 4.00 - 22/11/2224
SOLAR-02


1. Press and hold the SET key while turning on the instrument by means of the
/ESC key. The unit shows the screen beside.
2. Use the arrow keys ▲and ▼to set the correct K sensitivity value reported on
the (front or rear) label, located on the sensor itself.
3. Press the SET key to conrm the value.
4. With sensor type Irr-P, press the ESC key to exit the programming mode,
saving the changes made. In case a sensor type Irr-S2 is used, it is necessary
to set the parameter “Alpha” instead.
5. Use the arrow keys ▲and ▼to set the value of Te (Alpha) corresponding to
the value of sensitivity K previously set.
6. Press the SET key to conrm the value and go on setting sensor 2.
1. Use the arrow keys ▲and ▼to set the correct K sensitivity value reported
on the (front or rear) label, located on the sensor itself.
2. Press the SET key to conrm the value.
3. Use the arrow keys ▲and ▼to set the value of Te (Alpha) corresponding to
the value of sensitivity K previously set.
4. Press the SET key to conrm the value.




1. With sensor type Irr-S2, press the ESC key to exit the programming mode,
saving the changes made.
2. Use the arrow keys ▲and ▼ to set the correct K sensitivity value reported
on the (front or rear) label, located on the sensor itself.
3. Press the SET key to conrm the value.
4. Use the arrow keys ▲and ▼to set the value of Te (Alpha) corresponding
to the value of sensitivity K previously set.
5. Press the SET key to conrm the value.

Rel. 4.00 - 22/11/22 25
SOLAR-02 EN


1. Turn on the instrument by pressing the /ESC key.
2.Press the SET key. The unit shows the screen beside in which the K value of
the currently set sensor is selected.
3.Use the arrow keys ▲and ▼to select the desired type of sensor considering
the unit programming (see § 0)
4.Conrm selection with the SET key to go back to the measuring mode
5.Position the irradiation measuring probe type “Irr-P” or “Irr-S2” (see Table 1)
on the modules’ surface and connect the relevant output lead to the PYRA/
CELL input of the unit SOLAR-02
6.Fasten the temperature probe type Tmp with adhesive tape (see Table 1) on
the rear side of the modules and connect the relevant output lead to the
TEMP input of the unit SOLAR-02
7. Read on the display, in real time, as shown in the gure beside, the values of:
• Irradiation on the main display, expressed in W/m²
• Tc = temperature of cells expressed in °C
• Te = temperature of environment expressed in °C
USING THE INCLINOMETER FUNCTION
5.4
"

5.5
PRELIMINARY CHECK
5.5.1
1. Turn on the unit by pressing the /ESC key. The display shows the following
screen
2.Press the FUNC/▲key to activate the inclinometer mode of the unit
SOLAR-02 instead of the measurement of temperature Te as shown on the
screen beside
3.Fasten the unit on the module’s surface, if necessary by means of the two
magnets available on the rear side
4.Wait for a few seconds
5.Read, in real time, the value (expressed in °) of the tilting angle against the
horizontal plane of the object to be tested
For the denitions of the instrument types, see Table 1. For the use, functions
and activation of a testing/recording on the master instrument, please see
the user manual of the master instrument itself.
For the “M-USB” master instruments the enable of internal RF module is NOT
necessary. Check that the parameter which enable/disable the RF module
should be corrected set at the rst usage of the unit in the herewith way:
By press and hold the FUNC/▲key while switching on the meter by /ESC
key. The message “rFOFF” is displayed for a few seconds. If the message “rFON”
is displayed switch o the unit and repeat the operation. Afterwards the
initial screen is displayed by the meter. The setting of “RF” parameter is
maintained also during the replace of batteries

Rel. 4.00 - 22/11/2226
SOLAR-02
1. Switch on the unit and press the SET key. The unit shows the screen beside
in which sensor 1 is selected
2.Use the arrow keys ▲and ▼to select the desired type of sensor considering
the unit programming (see § 5.2)
3.Conrm selection with the SET key to go back to the measuring mode
4.Connect the unit SOLAR-02 to the master instrument by means of the USB
cable. The symbol “USB” is shown on the display while the unit is detected
by the master instrument
5.By activating a testing/recording on the master instrument, the unit
SOLAR-02 waits for the synchronization, showing the message “HoLd” on
the display and the indication of the waiting time necessary before being
able to activate the testing procedures (see example in the screen beside)
6.Once the waiting phase (HOLD) has ended, the message “Recording…” will
be displayed. It is now possible to disconnect the USB cable from the unit
SOLAR-02 and take the unit near the PV modules. Possible hyphens “- - -”
indicate that no irradiation and temperature probes are connected to the
unit SOLAR-02 yet
7. Place the Irradiance probe (Irr-P or Irr-S2 – see Table 1) parallel to PV
modules surface and connect the output connector to SOLAR-02 PYRA/
CELL input
8.Using a tape x the temperature probe (Tmp – see Table 1) on the backside
of the module and connect the output connector to SOLAR-02 TEMP input
9. Upon reaching an irradiation value higher that the threshold set by the
MASTER instrument, the unit SOLAR-02 shows the message “READY” on
the display
10. Disconnect the irradiation and temperature probes, connect the unit
to the master instrument again by means of the USB cable
11. Upon detecting the control to stop testing/recording from the master
instrument, the unit stops working, shows on the display the message
“SEnd” and sends the data to the master instrument to determine the nal
result of the testing
PRELIMINARY CHECK
5.6.1

5.6
USE OF THE UNIT

For the denitions of the instrument types, see Table 1. For the use, functions
and activation of a testing/recording on the master instrument, please see
the user manual of the master instrument itself.
For the “M-RF” master instruments the enable of internal RF module IS
NECESSARY. Check that the parameter which enable/disable the RF module
should be corrected set at the rst usage of the unit in the herewith way:
By press and hold the FUNC/▲key while switching on the meter by /ESC
key. The message “rFON“ is displayed for a few seconds. If the message “rFOFF“is
displayed switch o the unit and repeat the operation. Afterwards the initial
screen is displayed by the meter. The setting of “RF” parameter is maintained
also during the replace of batteries

Rel. 4.00 - 22/11/22 27
SOLAR-02
1. Switch on and approach the unit SOLAR-02 to the master instrument (max
distance 1m). The symbol “ ”:
• Is blinking approx 30s at display while searching a M-RF master unit
• Is xed at display when a M-RF master unit is found
• Disappears from display if no M-RF master unit is found within approx 30s.
Press the ▼key for re-start a new search of a “M-RF” master unit
2.Press the SET key. The unit shows the screen beside in which sensor 1 is
selected.
3.Use the arrow keys ▲and ▼to select the desired type of sensor considering
the unit programming (see § 5.2)
4.Conrm selection with the SET key to go back to the measuring mode
5.With operative RF connection, by activating a testing/recording on the
master instrument, the unit SOLAR-02 waits for the synchronization,
showing the message “HoLd” on the display and the indication of the time
during which it is necessary to keep the unit SOLAR-02 near the master
instrument before being able to activate the testing procedures
6.Once the waiting phase (HOLD) has ended, the message “Recording…” will
be displayed. It is now possible to take the unit SOLAR-02 away from the
master instrument and take it near the PV modules. Possible hyphens “- - -”
indicate that no irradiation and temperature probes are connected to the
unit SOLAR-02 yet
7. Place the Irradiance probe (Irr-P or Irr-S2 – see Table 1) parallel to PV
modules surface and connect the output connector to SOLAR-02 PYRA/
CELL input
8.Using a tape x the temperature probe (Tmp – see Table 1) on the backside
of the module and connect the output connector to SOLAR-02 TEMP input
9.Upon reaching an irradiation value higher that the threshold set by the
MASTER instrument, the unit SOLAR-02 shows the message “READY” on
the display
10. Disconnect the irradiation and temperature probes and
take the unit again near the master instrument in order to activate the RF
connection
11. Approach the unit SOLAR-02 to the master instrument (max distance 1m):
• If the “ ” symbol is blinking at display wait for the reciprocal detection of
both units and after this the symbol is x at display
• If the “ ” is missed at display press the ▼key for restart a new search of a
“M-RF” master unit
12.Upon detecting the control to stop testing/recording from the master
instrument, the unit stops working, shows on the display the message
“SEnd” and sends the data to the master instrument
USE OF THE UNIT

EN

Rel. 4.00 - 22/11/2228
SOLAR-02
GENERAL INFORMATION
6.1
1. Whether in use or in storage, please do not exceed the specications to
avoid any possible damage or danger during use.
2.Do not keep this instrument at high temperatures and/or humidity or
expose it to direct sunlight.
3.For long-term storage, remove the battery to avoid leakage of battery uid
that can damage the internal components.
BATTERY REPLACEMENT

When battery is low, the symbol " " is displayed to require replacement.
Please proceed as follows:
1. Remove the battery cover (see Fig. 1 – part 8) by unscrewing the fastening
screw;
2.Remove the battery;
3.Replace the battery with a new one of the same type respecting the
polarity;
4.Restore the battery cover back into place;
5.Use the appropriate battery disposal methods for your area.
CLEANING

Use a soft dry cloth to clean the instrument. Never use wet clothes, solvents
or water, etc.
END OF LIFE
6.4
CAUTION: this symbol indicates that the equipment and its accessories
shall be subject to a separate collection and correct disposal.
MAINTENANCE
6

Rel. 4.00 - 22/11/22 29
SOLAR-02
TECHNICAL
SPECIFICATIONS
7
TECHNICAL SPECIFICATIONS
7.1
Accuracy is referred to reference conditions: 23°C, <80%RH
• ISO calibration report • User manual
GENERAL CHARATERISTICS
 
RANGE [W/M2]RESOLUTION [W/M²]ACCURACY
0 ÷ 1400 1 + INT (100 * 0.1/K) ± [1.0%reading + INT(1000 * 0.1/K) dgt]
PROBE SENSITIVITY RANGE [mV] RESOLUTION
[mV] ACCURACY
K<10 15.00÷0.00 0.01 ± (1.0%reading+0.1mV)
K≥10 65.00÷0.00 0.02
IRRADIATION – PYRA/CELL INPUT
TEMPERATURE – TEMP INPUT (MEASURED
WITH “TMP” TEMPERATURE PROBE – SEE
TABLE 1)
Display: 4 LCD (2000 dots), decimal comma and point
Power supply
Batteries:
Duration of batteries:
Auto Power OFF:
4x1,5V alkaline type AAA LR03
approx. 480 hours
after 5 minutes of idleness (not in rec. oper.)

Frequency range:
R&TTE category:
Max transmission power:
2.400 ÷2.4835GHz
Class 1
30 ÷ W
Input connectors
USB port:
PYRA/CELL and TEMP inputs:
USB 2.0
type Hypertac
Internal memory
Autonomy: approx. 1.5 hours (@ PI master = 5s)
Mechanical characteristics
Dimensions (L x W x H): 120x 65 x 35mm (5 x 3 x 1in)
Weight (batteries included): 215g (8ounces)
Reference temperature: 23°C ±5°C ; (73°F ±41°F)
Operating temperature: 0°C ÷ 40°C; (32°F ÷ 104°F)
Relative operating humidity: <80%RH
Storage temperature: -10°C ÷ 60°C; (14°F ÷ 140°F)
Storage humidity: <80%RH
ENVIRONMETAL CONDITIONS
 
ACCESSORIES
7.4

HT declares (see Declaration of Conformity) that the instrument is complying with


(WEEE) directive
K = sensibilità della sonda per misura di irraggiamento utilizzata (espressa in mV/kW/m2o in uV/W/m2)
RANGE [°C] RESOLUTION [°C] ACCURACY
-20.0 ÷ 99.9 0.1 ± (1.0%reading + 1°C)
TILTING ANGLE RANGE [°C] RESOLUTION [°C] ACCURACY
0 ÷ 90 1± (1.0%reading + 1°)
EN

Rel. 4.00 - 22/11/2230
SOLAR-02
WARRANTY CONDITIONS

This instrument is guaranteed against material or production defects, in
accordance with our general sales conditions. During the warranty period,
the manufacturer reserves the right to decide either to repair or replace the
product. Should you need, for any reason, to return the instrument for repair
or replacement, please take prior agreements with the local distributor from
whom the instrument was bought. Do not forget to enclose a report describing
the reasons for returning (detected fault). Onlt use original packaging. Any
damage occurred during transport due to non-original packaging will be
charged to the customer. The manufacturer will not be held responsible for
any harm to people or damage to property.
The warranty does not apply to:
• Accessories and batteries (not covered by warranty).
• Repairs made necessary by improper use (including adaptation to
particular applications not foreseen in the instructions manual) or improper
combination with incompatible accessories or equipment.
• Repairs made necessary by improper shipping material causing damages
during transport.
• Repairs made necessary by previous attempts for repair carried out by
non-skilled or unauthorized personnel.
• Instruments for whatever reason modied by the customer himself without
explicit authorization of our Technical Department.
The contents of this manual may not be reproduced in any form whatsoever
without the manufacturer’s authorization.
Our products are patented and our logotypes registered. We reserve
          
improvements or developments which might be necessary.


Should the instrument not work properly, before contacting your distributor,
please make sure that the battery is correctly installed and working, check
the accessories and replace them if necessary. Make sure that your operating
procedure corresponds to the one described in this manual. Should you need,
for any reason, to return the instrument for repair or replacement, please take
prior agreements with the local distributor from whom the instrument was
bought. Do not forget to enclose a report describing the reasons for returning
(detected fault). Only use original packaging. Any damage occurred during
transport due to non-original packaging will be charged to the customer.
The manufacturer will not be held responsible for any harm to people or
damage to property.
SERVICE


Rel. 4.00 - 22/11/22 31
SOLAR-02 EN

Rel. 4.00 - 22/11/2288
SOLAR-02
HT ITALIA S.R.L.
Via della Boaria, 40 48018 Faenza (RA) Italia
T+39 0546 621002 | F [phone]
[e-mail] | ht-instruments.com
WHERE
WE ARE
YAMUM0042HT1
