Apricum UIMip Operator's manual

Details, modifications and corrections may be subject to change without notice. Apricum gives no warranty for the accuracy of the document.
The reproduction, transmission and use of this document or its contents is not permitted without written authority. All rights reserved.
DOCUMENTATION
UIMip
TECHNICAL AND APPLICATION
DESCRIPTION
Authors: Manouchehr Ghahramanian Golzar, Peter Hauner
Last Modification: 2017-03-02
© 2001-2017 Apricum d.o.o.
Mažuranićeva 4, 21312 Podstrana, Hrvatska

UIMip - TAD
2 / 19 02.03.2017
1CONTENTS
1Contents ..............................................................................................................................2
2UIMip Product Description...............................................................................................3
3Apricum UIMip Highlights ...............................................................................................4
4Operational Description ....................................................................................................5
4.1 Normal Mode ...............................................................................................................5
4.1.1 Programming Button and Physical Address Assignment...................................................................5
4.1.2 Function Button and Factory Reset ....................................................................................................6
4.2 Boot Mode and Firmware Update................................................................................6
4.3 KNX Telegrams in the IP Network..............................................................................7
5Application Description.....................................................................................................7
6ETS-Parameters.................................................................................................................8
6.1 General.........................................................................................................................8
6.2 IP Configuration...........................................................................................................8
7Web Front-End.................................................................................................................10
7.1 Accessing the Device .................................................................................................10
7.1.1 Via the Windows Network with UPnP.............................................................................................10
7.1.2 Via the MAC Address......................................................................................................................10
7.1.3 Via the IP Address............................................................................................................................10
7.2 Device Info.................................................................................................................11
7.3 KNX...........................................................................................................................11
7.4 Update ........................................................................................................................12
7.5 Tunneling Addresses (Additional Physical Addresses).............................................14
8State of Delivery ...............................................................................................................15
9Technical Drawings..........................................................................................................15
10 Technical Data..................................................................................................................16
11 Legal Notice ......................................................................................................................17
12 FAQ ...................................................................................................................................18

UIMip - TAD
02.03.2017 3 / 19
2UIMip PRODUCT DESCRIPTION
The Apricum IP interface UIMip is a tunneling
1
device and connects a personal computer to
the KNX TP bus. The device uses no KNX communication objects for itself. With the ETS
or with another KNX compatible commissioning tool the UIMip can be used as
the programming interface. For this purpose the device provides up to four additional physical
addresses
2
that can be used for tunneling connections.
Four LEDs and two buttons are located on the front panel as illustrated below. The device
offers diagnostic features by displaying all operational states with combined LEDs
(see Operational Description). The LEDs indicate details concerning the bus state, traffic on
the KNX bus, error/faulty communication NACK, BUSY on the bus, etc.
Picture 1: Front view
1
Bus state LAN LED
2
Bus state KNX TP line
LED
3
Bus traffic LAN line LED
4
Bus traffic KNX TP line
LED
5
Programming LED
A
Ethernet connector
B
Function button
C
Program button
D
KNX connector
1
Information basics about tunnelling and device management: The presence of the Internet
Protocol (IP) has led to the definition of KNXnet/IP. KNXnet/IP provides the means
for point-to-point connections like “KNXnet/IP Tunneling” for ETS and/or between
a supervisory system and a KNX installation. The KNXnet/IP Device Management provides
configuring KNXnet/IP devices via the KNX network effectively. Additionally, with this
the time required for network configurations is reduced.
2
Please note that in this document the term “physical address” means the “physical address”
as well as the “individual address”. Both of these terms are used by the KNX organisation
interchangeably.In this document only the term “physical address” is used.

UIMip - TAD
4 / 19 02.03.2017
3APRICUM UIMip HIGHLIGHTS
The UIMip works without external power supply.
Picture 2: Connection diagram
The UIMip is one of the rare KNX IP interfaces on the market
that supports the extended frame format and long telegrams up to 240 bytes (APDU).
In combination with the Apricum line coupler “MECtp” long messages are made
possible (e.g. for energy metering applications).
With the ability to feature a tunneling protocol conversation, a connection point for the
ETS or other tools to enable commissioning and monitoring is provided (four parallel
connections are possible; one separate address for each connection). The ETS address
for tunneling is not necessarily the one which is already configured.
The great advantage of tunneling is using LAN as a fast medium to exchange telegrams
between the lines and/or areas.
The UIMip is featuring a high internal amount of communication buffers being capable
of smoothening peaks in the communication load course.
Using a high internal amount of communication buffers is suitable for networks with a
high bus load.
UPnP is available to discover the device in an IP network. In terms of topology, this is
only possible with a proper network installation. With the KNXnet/IP Search Request
the ETS can discover the device as communication interface.
The comfortable operation via a Web interface provides the option to modify a set
of tunneling addresses of the device and an opportunity to switch the “Program Mode”
on or off. Also the firmware can be updated via the Web Front-End.
The UIMip’s ETS database entries are available for the ETS3.0d and upward.
The UIMip supports KNXnet/IP, ARP, ICMP, IGMP, HTTP, UPnP discovery,
UDP/IP, TCP/IP, DHCP and AutoIP.

UIMip - TAD
02.03.2017 5 / 19
4OPERATIONAL DESCRIPTION
The UIMip features two different modes, the “Normal Mode” and the “Boot Mode”.
In this chapter it is explained how to assign the individual physical address to the device and
how to carry out a factory reset or a firmware update.
4.1 NORMAL MODE
According either to the factory default settings or the latest parameter settings downloaded
from the ETS (also other tools) in normal operating mode the UIMip operates
as it is supposed to and LEDs 1, 2 light green.
Green
Red
LED 1
Bus State LAN
On: LAN line OK
Off: LAN line error
N.A.
LED 2
Bus State KNX
On: KNX line OK
Off: KNX line error
N.A.
LED 3
Traffic LAN
Off
Blinking:
transmission error LAN line
LED 4
Traffic KNX
Blinking:
bus traffic KNX TP line
Blinking:
transmissionerrorKNX TPline
LED 5
Programming
N.A.
On: device in Boot Mode
Blinking: LAN line error
4.1.1PROGRAMMING BUTTON AND PHYSICAL ADDRESS ASSIGNMENT
To download the desired physical address or
a full ETS setting into the device, during the procedure
the programming button ( ) needs to be pressed.
(The programming button is used to put the device into
“Program Mode”). With the ETS the physical address can
be assigned to the device by setting the desired address in
the properties window of the ETS, starting the download
and pressing the programming button. After assignment
the device restarts itself. (A blinking red LED 5 indicates
that the Ethernet cable is not properly connected.)
To commission the device a PC with ETS and an interface
connection (IP, USB) to the databus is required. The
device is supplied with the individual physical address
15.15.255. The KNX product database entry (available for
ETS3 and higher) can be downloaded from our website or
the KNX Online Catalog App.
Picture 3: Properties window
C

UIMip - TAD
6 / 19 02.03.2017
4.1.2FUNCTION BUTTON AND FACTORY RESET
The function button ( ) is used to execute a factory reset of the UIMip.
The factory reset is carried out by pressing the button for about 15 seconds (LEDs 1, 2 light
orange). After release, pressing it again until all LEDs turn off resets all parameters
to factory default settings (incl. physical address). Subsequently, after the automatic restart
of the device LEDs 1, 2 light green again indicating the normal operation status.
1. Long press of the function button (≈ 15 s) in “Normal Mode”
2. Short press of the function button (≈3 s)
4.2 BOOT MODE AND FIRMWARE UPDATE
As described for the “Normal Mode” the same factory reset procedure applies when the device
is in “Boot Mode”. Additionally, the UIMip exits the “Boot Mode”afterwards.
1. Long press of the function button (≈ 15 s) in “Boot Mode”
2. Short press of the function button (≈3 s)
When operating in “Boot Mode”, it is possible to update the UIMip’s firmware.
For more detailed information concerning the update procedure please refer to the section
Update. In order to switch from “Normal Mode” to “Boot Mode” it is necessary to begin
the firmware update procedure and use the “Request Update” button in the Web Front-End:
1. Press the programming button in “Normal Mode”
2. Press the function button
3. Press the “Refresh” button in the Update tab of the Web front-end
4. Press the “Request Update” button
While being in “Boot Mode” LED 1, 2 and 5 have the states as described here:
LED 1 Bus State LAN
Keeps on lighting green
LED 2 Bus State KNX
Blinking green
LED 3 Traffic LAN
Blinking green
LED 5 Programming
Keeps on lighting red
In general, there are three options to switch from “Boot Mode” back to “Normal Mode”:
Update the firmware (if you have a new firmware available for your UIMip).
Cancel the update procedure and reset the application by pressing the “Abort” button.
Wait 10 minutes until the device switches to “Normal Mode” automatically by itself.
B

UIMip - TAD
02.03.2017 7 / 19
4.3 KNX TELEGRAMS IN THE IP NETWORK
The UIMip can be used as an interface in a network installation field. In accordance with the
KNXnet/IP protocol specification the UIMip sends telegrams from theKNX network to the
IP network and vice versa. If the IP address is changed from the IP sideit might happen that the
ETS does no longer recognize the device. Then the connection canno longer be established
(Tunneling uses IP addresses!).
Please note:
As a precaution, always run a restart or change the IP address from the TP side.
If there are problems with the IP address assignment please ask your administrator.
According to the topology, the additional physical addresses for tunnelling always
have to be assigned in the range of sub line addresses. For more information about
the additional tunneling addresses please refer to Tunneling Addresses (Additional
Physical Addresses).
5APPLICATION DESCRIPTION
The IP Interface is designed for use in 10/100 BaseT networks compliant to IEEE802.3.
The device features an AutoSensing function and sets the baud rate (10 Mbit or 100 Mbit)
automatically. The IP address of the device can be received from a DHCP server.
For this purpose the ETS automatic assignment setting of the IP address is required.
If no DHCP server is found with this setting, the device starts an AutoIP procedure and
autonomously assigns an IP address. The IP address which the device receives during
its start-up (via DHCP or AutoIP) is retained until the next start-up (e.g. due to
switching on/off or reprogramming). If the IP address of the UIMip is supposed
to have a fixed assignment, in the ETS a fixed IP address (as well as a subnet mask and
a standard gateway) can be set.

UIMip - TAD
8 / 19 02.03.2017
6ETS-PARAMETERS
All screen shots in this chapter represent the UIMip ´s data base entry in the ETS5.
6.1 GENERAL
Picture 4: General
ETS-Text
Selection
[Factory default]
Comment
Host name
UIM KNX IP Interface
[KNX IP Interface]
Field to enter the device name (30 signs max.)
providing an easy search of the device with
the ETS or any KNXnet/IP visualisation system.
Note: If the Host name is changed by an ETS4 download, a manual restart is recommended.
6.2 IP CONFIGURATION
Picture 5: IP configuration
ETS-Text
Selection
[Factory default]
Comment
DHCP
use
do not use
[use]
If DHCP is used, no parameterisation of the
IP parameters must be done.
If DHCP is not used, the IP parameters must be
set manually (see following picture and table).

UIMip - TAD
02.03.2017 9 / 19
Picture 6: Manual configuration of the IP address
ETS-Text
Selection
[Factory default]
Comment
DHCP configuration
use
do not use
[use]
If DHCP is not used, the following
IP parameters must be set manually.
IP address
0-255.0-255.0-255.0-255
[0.0.0.0]
IP Byte 1 to 4: manual input.
Net mask
0-255.0-255.0-255.0-255
[255.255.255.0]
NM Byte 1 to 4: manual input.
Gateway
0-255.0-255.0-255.0-255
[0.0.0.0]
GW Byte 1 to 4: manual input.
Note: The configuration of the IP connectivity (Host name, IP address, KNX multicast
address) is not updated automatically after an ETS download. To get these values
updated it is essential executing a manual device restart.

UIMip - TAD
10 / 19 02.03.2017
7WEB FRONT-END
7.1 ACCESSING THE DEVICE
To download the firmware into the device and/or to adjust the tunneling addresses please use
the Web front-end. Therefore, to access the device it has to be opened as a Microsoft Windows
(Version 7 or higher) UPnP network device. Alternatively, one can use either the IP address or
the MAC address as URL base in the web browser.
7.1.1VIA THE WINDOWS NETWORK WITH UPNP
Picture 7: UPnP network device
In the event that the network device is not visible a manual restart is recommended.
Then wait until the device gets visible in the list of network devices. If it is still not visible
make sure that the UPnP function of the network is enabled.
7.1.2VIA THE MAC ADDRESS
The MAC address is printed on a label of the UIMip housing. Use this MAC address
of the UIMip without brackets [ ] as described here:
http://knx-ipif-[XX][YY][ZZ]:8080/
Example:
[XX] = byte 4 of the MAC address
The MAC address is “D0-76-50-11-22-33”.
[YY] = byte 5 of the MAC address
Enter the URL
“http://knx-ipif-112233:8080/”
into the web browser´s address bar.
[ZZ] = byte 6 of the MAC address
7.1.3VIA THE IP ADDRESS
Example:
The UIMip has an IP address of “192.168.1.32”.
Enter the URL “http://192.168.1.32:8080/” into the web browser´s address bar.

UIMip - TAD
02.03.2017 11 / 19
7.2 DEVICE INFO
If the UIMip has been working in “Normal Mode”, the Device Info tab is the first tab you
might see when you reach the Web front-end. Here you get all general information about the
current settings of the device.
Picture 8: Device info
7.3 KNX
Under the KNX tab the “Program Mode”of the UIMip can be turned “On”or “Off”. This
function is similar to the programming button function. With this the regarded device
is easy to distinguish from other interfaces in the same IP network. It can also be noticed what
the particular device is currently processing (after a change in the settings, for example).
With the “Set” button (and the ETS) it is possible to set the Tunneling Addresses (Additional
Physical Addresses). Moreover, here the serial number of the device is visible.
Picture 9: KNX

UIMip - TAD
12 / 19 02.03.2017
7.4 UPDATE
Under the Update tab the firmware of the device can be updated. If the device is in “Normal
Mode”, proceed with following steps 1 to 5. If the device is already in “Boot Mode”, follow
the instructions shown in the Web front-end and continue with step 3 (refresh, request update).
Step 1:
Open the Update tab of the Web front-end.
Picture 10: Update
Step 2:
Either use the “Change Program Mode” function in the KNX tab or
press the programming button once.
Picture 11: Program mode
Step 3:
After the “Program Mode”is turned to “On” give a short key press to
the function button. Then the “refresh”button in the Update tab
needs to be pressed. Alternatively, refresh the browser.
Picture 12: Update authorized

UIMip - TAD
02.03.2017 13 / 19
Step 4:
Then the „request update“ button appears. Press it to select the update file
and enter “Boot Mode”.
Picture 13: Request update
Step 5:
The device now switches to “Boot Mode”. The update file can be selected
and uploaded. Pressing the „Abort“ button cancels the firmware update
procedure and the device exits the “Boot Mode”.
Picture 14: Select update file

UIMip - TAD
14 / 19 02.03.2017
7.5 TUNNELING ADDRESSES (ADDITIONAL PHYSICAL ADDRESSES)
According to the host’s physical address assignment (see Programming Button and Physical
Address Assignment) the first additional physical address of the UIMip can only be set with
the ETS. Please make sure: The additional physical addresses for tunneling and the host´s
physical address have to be different.
Step 1:
Open the Bus tab in the ETS and select the UIMip as the
“Current Interface”. In the “IP Tunneling” window the already assigned
host physical address can be read.
Picture 15: First additional physical address (tunnelling address)
Step 2:
Type the additional physical address into the “Individual Address” field.
Click on the “Test” button. If the green Ok appears, the first tunneling
address is already set. In this example it is set to “9.1.241”.
Step 3:
Now open the KNX tab of the Web front-end. Click on the “Set” button to
change the remaining three tunneling addresses basing on the first tunneling
address as follows.
Picture 16: Additional tunneling addresses

UIMip - TAD
02.03.2017 15 / 19
8STATE OF DELIVERY
With the following default factory settings the UIMip is delivered:
9TECHNICAL DRAWINGS
All dimensions shown here are specified in mm. The device width is 2 modules at 18 mm.
Picture 17: Dimension drawings
Marking/Design
UIMip
Physical address
15.15.255
Physical address for tunneling connections
15.15.241
15.15.242
15.15.243
15.15.244
IP configuration
IP address assignment
DHCP/AutoIP
IP routing multicast address
224.0.23.12

UIMip - TAD
16 / 19 02.03.2017
10 TECHNICAL DATA
Warning: device may not be connected to 230V!
Marking/Design
UIMip
Current consumption
< 40 mA
Connections
IP line: RJ45 socket for 100 Mbit and 10 Mbit BaseT,
IEEE 802.3 networks
KNX line: KNX bus WAGO connector (red/black),
screwless for single-core cable Ø 0,6…0,8 mm
Display elements
LED Bus state
LED “Program Mode”
LED Traffic
LED Error
Control elements
Function button, Program button
Mounting
35 mm top-hat rail (TH35) according to IEC60715
Protection type
IP20 according to IEC60529
Pollution degree
2 according to IEC60664-1
Protection class
III according to IEC61140
Overvoltage category
II according to IEC60664-1
Approbation
KNX-certified according to ISO/IEC14543-3
CE-Marking
According to low voltage and EMC guidelines
Compliance: EN50428, EN50581, EN61000-6, EN62479
Power supply
Safety extra low voltage, 21…30V DC (SELV)
Housing colour
Plastic PA66 housing grey
Dimensions
H = 90 mm, W = 36 mm (2 modules), D = 71 mm
Mounting depth = 64 mm
Weight
70 g
Device temperature
Working temperature: -5…45 °C
Storage temperature: -20…60 °C
Ambient humidity
5…93 %, non-condensing

UIMip - TAD
02.03.2017 17 / 19
11 LEGAL NOTICE
Lw IP is used in developing the UIMip.
Lw IP is licenced under the BSD licence.
Copyright (c) 2001-2004 Swedish Institute of Computer Science.
All rights reserved.
Providing that the following conditions are met redistribution and use in source and binary
forms, with or without modification, are permitted:
1. Redistributions of the source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
3. The name of the author may not be used to endorse or promote products derived from
this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE AUTHOR `` AS IS AND ANY EXPRESS OR
IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY
THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE
USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.

UIMip - TAD
18 / 19 02.03.2017
12 FAQ
Q: The firmware update process has finished successfully but the device doesn´t react now.
A: Turn the power off and on manually (dis-/reconnect bus line). Try to restart it this way.
Q: Is it Ok to connect and disconnect the Ethernet quickly?
A: No! You shouldn’t do this. To observe, the LAN status LED will light green for a few
seconds and then the device will reset.
Q: What does the programming LED show when the Ethernet cable is not connected?
A: As long as the Ethernet cable is not connected properly the programming LED blinks
red.
Q: I have disabled DHCP and assigned a correct IP configuration to the UIMip.
But I cannot reach the Web front-end anymore. Why?
A: Manually reset the UIMip and try again. For more information about changing
the configuration of the IP network please refer to IP Configuration.
Q: I tried to reach the Web front-end of my UIMip but I wasn’t successful.
What can I do?
A: Make sure the “http://...” matches your device IP along with the port address “8080”.
Or type the MAC address into the browser´s address bar in exactly the way as
explained (see Via the MAC Address). Then wait (for about 5-15 seconds), refresh your
browser and try again.
Q: Is it possible to reach the Web front-end when the device is already in “Boot Mode”?
A: Yes, it is. The Web front-end is accessible in both “Normal Mode” and “Boot Mode”
(see Update). In this case the Web front-end will look like illustrated next. You can use
the Update tab to update the firmware and/or to exit the “Boot Mode”.
Picture 18: Boot mode
Q: I was able to reach the Web front-end. But when I try to use its tabs or options again
my browser only shows a connection error to me. What can I do?
A: Refresh the browser window. The Web front-end will show up again.
