Alyseum Q-MIXI User manual

Q-MIXI, Q-MIX & Q-MIXO – User’s manual © - Revision 2.0 - Page 1
ALYSEUM - Q-MIXI, Q-MIX & Q-MIXO - User manual V2.0
1 Introdu tion
On e upon a time, needed a ompa t audio mixer for my
personal Eurora k, in luding 4 inputs with LEVEL & PAN
ontrols and an adjustable stereo audio level output, all in
6HP maximum!
The hallenge of this new module was multiple:
● Strong fo us on ergonomi s in maximum 6HP.
● Pro audio omponents for ex ellent performan e.
● LINE IN & OUT onne tors on the rear panel, whi h
allows to add future extension modules.
● Large MASTER stereo output potentiometer.
● Quality apa itors on the audio path.
I made it and, following the positive omments from my
entourage, I said to myself "what about marketting it"?
I have sin e added a sub-mixer (Q-MIXI) and a balan ed
output module (Q-MIXO) with two independent
headphone outputs.
Depending on your use and needs, Q-MIXI, Q-MIX and Q-MIXO modules an be used in several ombinations:
● Individually
● In pairs (3 ombinations)
● All three together
Q-MIX, Q-MIXI and Q-MIXO use quality apa itors in the audio signal path.
No DC signal an pass through the modules.

Q-MIXI, Q-MIX & Q-MIXO – User’s manual © - Revision 2.0 - Page 2
2 Hardware
2.1 Pa kage Content
● Box ontain 1 Q-MIX or 1 Q-MIXI or 1 Q-MIXO module.
● One plasti bag ontaining:
o Two M3 s rews + M3 nylon washers
o One 10/16 pins power ribbon able.
● Warranty & user manual a ess ard.
2.2 Features & spe ifi ations
● High quality Audio OP-AMP type LME49720
● Power supply prote ted against reverse ribbon able insertion.
● Power onsumption (Full LED On):
o Q-MIXI: +12V= 20mA / -12V= 20mA
o Q-MIX: +12V= 27mA / -12V= 20mA
o Q-MIXO: +12V= 160mA / -12V= 20mA
● Front panel width: 30 mm (6HP)
● Modules Q-MIXI & Q-MIX maximum depth: 26 mm
● Module Q-MIXO maximum depth: 37mm
2.3 Installation
If you use only one of the modules, pla e it where you want a ording to your personal ergonomi s.
If you use 2 or 3 of these modules, it is important to pla e jointly the Q-MIXI on the left, the Q-MIX in the middle and
the Q-MIXO on the right.
This is important regarding the rear wiring (see the hapter 2.5)
Choose the installation lo ation of your unit arefully:
● Avoid pla ing it in dire t sunlight or lose to a sour e of heat.
● Avoid lo ations subje t to vibrations, ex essive dust, heat, old, moisture or rain.
Pro edure:
1. Only onne t the module to a Eurora k bus board powered by a spe ified A-100 power supply.
2. Swit h OFF and dis onne t the Eurora k ase from the main power supply by unplugging it from the wall
so ket!
3. Make absolutely ertain that the ribbon able has the right orientation by onne ting the indi ated red stripe
on the negative 12 Volt side of your Eurora k ase bus board.
4. Carefully pla e the module on an appropriately spa ed spot on your Eurora k and fasten it firmly in pla e with
the supplied s rews and nylon washers. Repla e any overs or blanking plates that you removed to install the
module and s rew them in firmly.
5. Re onne t the Eurora k ase power able ba k into the main power supply and swit h the ase power on.
6. If it doesn’t seem to be working as expe ted, immediately dis onne t the system from the main power supply
again. In this ase, double- he k the onne tions, making ompletely sure that the ribbon able is the right
way round where it onne ts to the module and the bu

Q-MIXI, Q-MIX & Q-MIXO – User’s manual © - Revision 2.0 - Page 3
2.4 Blo diagram
Q-MIXI
IN 5
LEVEL PAN
IN 6
LEVEL PAN
OUT L
O.A.
OUT R
O.A.
12V
12V
LINE OUT
LEVEL
IN 7
LEVEL
IN 8
(L)
(R)
(L)
(R)
NB: if you only have a mono signal for stereo inputs 7 and 8, use the left input, it will automati ally be onne ted to
the right input.
Q-MIX
IN 1
LEVEL PAN
IN 2
LEVEL PAN
IN 3
LEVEL PAN
IN 4
LEVEL PAN
LINE
O.A. OUT L
O.A.
O.A. OUT R
O.A.
12V
12V
PEAK
OUT
L
R
MASTER OUT
IN

Q-MIXI, Q-MIX & Q-MIXO – User’s manual © - Revision 2.0 - Page 4
Q-MIXO
IN L
IN R
OUT R
12V
12V
LINE IN
LEVEL
LEVEL
LEVEL
PHONES 1
P.A.
P.A.
PHONES 2
P.A.
P.A.
B.A.
B.A.
OUT L
V.U.
V.U.
BALANCED
NB: The rear wiring from the Q-MIX is automati ally ut off if you insert a sour e into the input ja ks.
2.5 Ba k Audio Wiring
Q-MIXI is equipped on its ba k side with a able in a white sheath. You an onne t it dire tly to the LINE IN so ket
(bottom) of the Q-MIX.
Q-MIXO is equipped on its ba k side with a able in a bla k sheath. You an onne t it dire tly to the LINE OUT so ket
(top) of the Q-MIX.
If you use Q-MIXI or Q-MIXO without the Q-MIX, please leave the ables un onne ted.
NB: It is not possible to realize a ba k audio wiring from the Q-MIXI to the Q-MIXO.

Q-MIXI, Q-MIX & Q-MIXO – User’s manual © - Revision 2.0 - Page 5
3 How to use
Well, is it ne essary to explain how to use the LEVEL, PAN and Master Out adjustements of these modules?
There is abundant literature on the subje t, and if you really have a question, do not hesitate to onta t me personally
at willi@alyseum. om
I would be pleased to answer you be ause you made the effort to read this user manual up to here :)
4 Mis ellaneous
4.1 Dis laimer
All rights reserved. Reprodu tion in whole or part of this do ument is prohibited without the express permission of
ALYSEUM.
© 2011-2099 ALYSEUM.
The information and spe ifi ations des ribed in this manual are subje t to hange without prior noti e.
Throughout this manual, trademarked names might be used. We state herein that we are using the name to the
benefit of the trademark owner, with no intention of infringement.
4.2 Warranty and repair
ALYSEUM warrants to you, the original pur haser, that ea h of its produ ts will be free from defe ts in materials and
workmanship for a period of two years following the date of pur hase.
This warranty does not apply to any produ ts whi h have been repaired or altered by other than ALYSEUM, or whi h
have been subje t to ESD, moisture, abuse, a ident, improper installation or use.
ALYSEUM assumes no liability as a onsequen e of su h events under the terms of this Warranty.
Please, onsult your dealer for more details or visit our support page on alyseum. om/support before any a tion.
