APRILIA 1115-2 Instruction manual

0-1
RSV mille
INTRODUCTION 0
GENERAL INFORMATION 1
SERVICE AND SETTING UP 2
ENGINE 3
FUEL SUPPLY SYSTEM 4
COOLING SYSTEM 5
ELECTRIC SYSTEM 6
CHASSIS 7
REPAIR INFORMATION 8
ANALYTICAL INDEX @
Release 00/2002-10 - 00
236mille U 
WORKSHOP manual
a rilia part# 8140688

INTRODUCTION
0
0-2
RSV mille
INTRODUCTION
4!",%/&#/.4%.43
50$!4%/&2%,%!3%
 ...................................................... 0-3-00
0.1.1 INFORMATION ON THE
UPDATING OF THE MANUAL ............... 0-3-00
0.1.2 UPDATED MANUAL GENERAL LIST ... 0-3-00
(/ 4/#/.35,44(%-!.5!, ..... 0-5-00
&/2% /2$ ............................................... 0-6-00
2%&%2%.#%-!.5!,3 ......................... 0-6-00
0.4.1 ENGINE SERVICE AND
REPAIR MANUALS ................................ 0-6-00
0.4.2 SPARE PARTS CATALOGUES ............ 0-6-00
0.4.3 SPECIAL TOOL MANUALS .................. 0-6-00
0.4.4 USE AND MAINTENANCE MANUALS . 0-6-00
3!&%49 !2.).'3 ............................... 0-7-00
0.5.1 PRECAUTIONS AND GENERAL
INFORMATIONS .................................... 0-7-00
0.5.2 BEFORE THE DISASSEMBLY OF THE
COMPONENTS ...................................... 0-7-00
0.5.3 DISASSEMBLING THE COMPONENTS 0-7-00
0.5.4 REASSEMBLING THE COMPONENTS 0-7-00
(/ 4/53%9/523%26)#%
!.$2%0!)2-!.5!, ........................... 0-8-00
0.6.1 ADVICE FOR CONSULTATION ............ 0-8-00
!""2%6)!4)/.339-"/,3
).)4)!,3 .................................................... 0-9-00
Release 00/2002-10
- 00

INTRODUCTION
0-3
RSV mille
50$!4%/&2%,%!3%
Date of the first edition ( elease 00) and of the following
eleases:
First edition ( elease 00) ............................october 2002
0.1.1 INFORMATION ON THE UPDATING OF THE
MANUAL
The manual must be u dated every time a new “Re-
lease” is received.
The manual consists of # 10 sections, for a total amount
of # 384 pages, as listed below.
NOTE For the nomenclature of the standard page of
the manual (and specifically for the definition of the page
number) see 0.2 (HOW TO CONSULT THE MANUAL).
Insert the ages of the last Release in the manual
and eliminate the corres onding obsolete ages
(even if belonging to a revious Release).
aWARNING
The failure to u date the manual and to eliminate
the obsolete ages makes it more difficult to con-
sult the manual and may lead to the erformance
of incorrect o erations on the vehicle, with serious
consequences for the safety of the vehicle and of
ersons and ro erty.
0.1.2 UPDATED MANUAL GENERAL LIST
age# Release
0 - 1 - 00 ............................... 00
0 - 2 - 00 ............................... 00
0 - 3 - 00 ............................... 00
0 - 4 - 00 ............................... 00
0 - 5 - 00 ............................... 00
0 - 6 - 00 ............................... 00
0 - 7 - 00 ............................... 00
0 - 8 - 00 ............................... 00
0 - 9 - 00 ............................... 00
0 - 10 - 00 ............................... 00
1 - 1 - 00 ............................... 00
1 - 2 - 00 ............................... 00
1 - 3 - 00 ............................... 00
1 - 4 - 00 ............................... 00
1 - 5 - 00 ............................... 00
1 - 6 - 00 ............................... 00
1 - 7 - 00 ............................... 00
1 - 8 - 00 ............................... 00
1 - 9 - 00 ............................... 00
1 - 10 - 00 ............................... 00
1 - 11 - 00 ............................... 00
1 - 12 - 00 ............................... 00
1 - 13 - 00 ............................... 00
1 - 14 - 00 ............................... 00
1 - 15 - 00 ............................... 00
1 - 16 - 00 ............................... 00
1 - 17 - 00 ............................... 00
1 - 18 - 00 ............................... 00
1 - 19 - 00 ............................... 00
1 - 20 - 00 ............................... 00
1 - 21 - 00 ............................... 00
1 - 22 - 00 ............................... 00
1 - 23 - 00 ............................... 00
1 - 24 - 00 ............................... 00
2 - 21 - 00 ................................ 00
2 - 22 - 00 ................................ 00
2 - 23 - 00 ................................ 00
2 - 24 - 00 ................................ 00
2 - 25 - 00 ................................ 00
2 - 26 - 00 ................................ 00
2 - 27 - 00 ................................ 00
2 - 28 - 00 ................................ 00
2 - 29 - 00 ................................ 00
2 - 30 - 00 ................................ 00
2 - 31 - 00 ................................ 00
2 - 32 - 00 ................................ 00
2 - 33 - 00 ................................ 00
2 - 34 - 00 ................................ 00
2 - 35 - 00 ................................ 00
2 - 36 - 00 ................................ 00
2 - 37 - 00 ................................ 00
2 - 38 - 00 ................................ 00
2 - 39 - 00 ................................ 00
2 - 40 - 00 ................................ 00
2 - 41 - 00 ................................ 00
2 - 42 - 00 ................................ 00
2 - 43 - 00 ................................ 00
2 - 44 - 00 ................................ 00
2 - 45 - 00 ................................ 00
2 - 46 - 00 ................................ 00
2 - 47 - 00 ................................ 00
2 - 48 - 00 ................................ 00
2 - 49 - 00 ................................ 00
2 - 50 - 00 ................................ 00
2 - 51 - 00 ................................ 00
2 - 52 - 00 ................................ 00
2 - 53 - 00 ................................ 00
2 - 54 - 00 ................................ 00
2 - 55 - 00 ................................ 00
2 - 56 - 00 ................................ 00
2 - 57 - 00 ................................ 00
2 - 58 - 00 ................................ 00
2 - 59 - 00 ................................ 00
2 - 60 - 00 ................................ 00
2 - 61 - 00 ................................ 00
2 - 62 - 00 ................................ 00
2 - 63 - 00 ................................ 00
2 - 64 - 00 ................................ 00
2 - 65 - 00 ................................ 00
2 - 66 - 00 ................................ 00
3 - 1 - 00 ................................ 00
3 - 2 - 00 ................................ 00
3 - 3 - 00 ................................ 00
3 - 4 - 00 ................................ 00
3 - 5 - 00 ................................ 00
3 - 6 - 00 ................................ 00
3 - 7 - 00 ................................ 00
3 - 8 - 00 ................................ 00
3 - 9 - 00 ................................ 00
3 - 10 - 00 ................................ 00
3 - 11 - 00 ................................ 00
3 - 12 - 00 ................................ 00
3 - 13 - 00 ................................ 00
3 - 14 - 00 ................................ 00
3 - 15 - 00 ................................ 00
3 - 16 - 00 ................................ 00
3 - 17 - 00 ................................ 00
3 - 18 - 00 ................................ 00
3 - 19 - 00 ................................ 00
3 - 20 - 00 ................................ 00
3 - 21 - 00 ................................ 00
3 - 22 - 00 ................................ 00
4 - 1 - 00 ................................ 00
4 - 2 - 00 ................................ 00
age# Release
Release 00/2002-10 - 00
1 - 25 - 00 ................................ 00
1 - 26 - 00 ................................ 00
1 - 27 - 00 ................................ 00
1 - 28 - 00 ................................ 00
1 - 29 - 00 ................................ 00
1 - 30 - 00 ................................ 00
1 - 31 - 00 ................................ 00
1 - 32 - 00 ................................ 00
1 - 33 - 00 ................................ 00
1 - 34 - 00 ................................ 00
1 - 35 - 00 ................................ 00
1 - 36 - 00 ................................ 00
1 - 37 - 00 ................................ 00
1 - 38 - 00 ................................ 00
2 - 1 - 00 ................................ 00
2 - 2 - 00 ................................ 00
2 - 3 - 00 ................................ 00
2 - 4 - 00 ................................ 00
2 - 5 - 00 ................................ 00
2 - 6 - 00 ................................ 00
2 - 7 - 00 ................................ 00
2 - 8 - 00 ................................ 00
2 - 9 - 00 ................................ 00
2 - 10 - 00 ................................ 00
2 - 11 - 00 ................................ 00
2 - 12 - 00 ................................ 00
2 - 13 - 00 ................................ 00
2 - 14 - 00 ................................ 00
2 - 15 - 00 ................................ 00
2 - 16 - 00 ................................ 00
2 - 17 - 00 ................................ 00
2 - 18 - 00 ................................ 00
2 - 19 - 00 ................................ 00
2 - 20 - 00 ................................ 00
age# Release
4 - 3 - 00 ............................... 00
4 - 4 - 00 ............................... 00
4 - 5 - 00 ............................... 00
4 - 6 - 00 ............................... 00
4 - 7 - 00 ............................... 00
4 - 8 - 00 ............................... 00
4 - 9 - 00 ............................... 00
4 - 10 - 00 ............................... 00
4 - 11 - 00 ............................... 00
4 - 12 - 00 ............................... 00
4 - 13 - 00 ............................... 00
4 - 14 - 00 ............................... 00
4 - 15 - 00 ............................... 00
4 - 16 - 00 ............................... 00
4 - 17 - 00 ............................... 00
4 - 18 - 00 ............................... 00
4 - 19 - 00 ............................... 00
4 - 20 - 00 ............................... 00
4 - 21 - 00 ............................... 00
4 - 22 - 00 ............................... 00
4 - 23 - 00 ............................... 00
4 - 24 - 00 ............................... 00
4 - 25 - 00 ............................... 00
4 - 26 - 00 ............................... 00
4 - 27 - 00 ............................... 00
4 - 28 - 00 ............................... 00
4 - 29 - 00 ............................... 00
4 - 30 - 00 ............................... 00
5 - 1 - 00 ............................... 00
5 - 2 - 00 ............................... 00
5 - 3 - 00 ............................... 00
5 - 4 - 00 ............................... 00
5 - 5 - 00 ............................... 00
5 - 6 - 00 ............................... 00
5 - 7 - 00 ............................... 00
5 - 8 - 00 ............................... 00
5 - 9 - 00 ............................... 00
5 - 10 - 00 ............................... 00
5 - 11 - 00 ............................... 00
5 - 12 - 00 ............................... 00
5 - 13 - 00 ............................... 00
5 - 14 - 00 ............................... 00
6 - 1 - 00 ............................... 00
6 - 2 - 00 ............................... 00
6 - 3 - 00 ............................... 00
6 - 4 - 00 ............................... 00
6 - 5 - 00 ............................... 00
6 - 6 - 00 ............................... 00
6 - 7 - 00 ............................... 00
6 - 8 - 00 ............................... 00
6 - 9 - 00 ............................... 00
6 - 10 - 00 ............................... 00
6 - 11 - 00 ............................... 00
6 - 12 - 00 ............................... 00
6 - 13 - 00 ............................... 00
6 - 14 - 00 ............................... 00
6 - 15 - 00 ............................... 00
6 - 16 - 00 ............................... 00
6 - 17 - 00 ............................... 00
6 - 18 - 00 ............................... 00
6 - 19 - 00 ............................... 00
6 - 20 - 00 ............................... 00
6 - 21 - 00 ............................... 00
6 - 22 - 00 ............................... 00
6 - 23 - 00 ............................... 00
6 - 24 - 00 ............................... 00
6 - 25 - 00 ............................... 00
6 - 26 - 00 ............................... 00
6 - 27 - 00 ............................... 00
6 - 28 - 00 ............................... 00
age# Release
Follow ã

INTRODUCTION
0-4
RSV mille
6 - 29 - 00 ................................ 00
6 - 30 - 00 ................................ 00
6 - 31 - 00 ................................ 00
6 - 32 - 00 ................................ 00
6 - 33 - 00 ................................ 00
6 - 34 - 00 ................................ 00
6 - 35 - 00 ................................ 00
6 - 36 - 00 ................................ 00
6 - 37 - 00 ................................ 00
6 - 38 - 00 ................................ 00
6 - 39 - 00 ................................ 00
6 - 40 - 00 ................................ 00
6 - 41 - 00 ................................ 00
6 - 42 - 00 ................................ 00
6 - 43 - 00 ................................ 00
6 - 44 - 00 ................................ 00
6 - 45 - 00 ................................ 00
6 - 46 - 00 ................................ 00
6 - 47 - 00 ................................ 00
6 - 48 - 00 ................................ 00
6 - 49 - 00 ................................ 00
6 - 50 - 00 ................................ 00
6 - 51 - 00 ................................ 00
6 - 52 - 00 ................................ 00
6 - 53 - 00 ................................ 00
6 - 54 - 00 ................................ 00
7 - 1 - 00 ................................ 00
7 - 2 - 00 ................................ 00
7 - 3 - 00 ................................ 00
7 - 4 - 00 ................................ 00
7 - 5 - 00 ................................ 00
7 - 6 - 00 ................................ 00
7 - 7 - 00 ................................ 00
7 - 8 - 00 ................................ 00
7 - 9 - 00 ................................ 00
7 - 10 - 00 ................................ 00
7 - 11 - 00 ................................ 00
7 - 12 - 00 ................................ 00
7 - 13 - 00 ................................ 00
7 - 14 - 00 ................................ 00
7 - 15 - 00 ................................ 00
7 - 16 - 00 ................................ 00
7 - 17 - 00 ................................ 00
7 - 18 - 00 ................................ 00
7 - 19 - 00 ................................ 00
7 - 20 - 00 ................................ 00
7 - 21 - 00 ................................ 00
7 - 22 - 00 ................................ 00
7 - 23 - 00 ................................ 00
7 - 24 - 00 ................................ 00
7 - 25 - 00 ................................ 00
7 - 26 - 00 ................................ 00
7 - 27 - 00 ................................ 00
7 - 28 - 00 ................................ 00
7 - 29 - 00 ................................ 00
7 - 30 - 00 ................................ 00
7 - 31 - 00 ................................ 00
7 - 32 - 00 ................................ 00
7 - 33 - 00 ................................ 00
7 - 34 - 00 ................................ 00
7 - 35 - 00 ................................ 00
7 - 36 - 00 ................................ 00
7 - 37 - 00 ................................ 00
7 - 38 - 00 ................................ 00
7 - 39 - 00 ................................ 00
7 - 40 - 00 ................................ 00
7 - 41 - 00 ................................ 00
7 - 42 - 00 ................................ 00
7 - 43 - 00 ................................ 00
7 - 44 - 00 ................................ 00
age# Release
Release 00/2002-10
- 00
7 - 45 - 00 ............................... 00
7 - 46 - 00 ............................... 00
7 - 47 - 00 ............................... 00
7 - 48 - 00 ............................... 00
7 - 49 - 00 ............................... 00
7 - 50 - 00 ............................... 00
7 - 51 - 00 ............................... 00
7 - 52 - 00 ............................... 00
7 - 53 - 00 ............................... 00
7 - 54 - 00 ............................... 00
7 - 55 - 00 ............................... 00
7 - 56 - 00 ............................... 00
7 - 57 - 00 ............................... 00
7 - 58 - 00 ............................... 00
7 - 59 - 00 ............................... 00
7 - 60 - 00 ............................... 00
7 - 61 - 00 ............................... 00
7 - 62 - 00 ............................... 00
7 - 63 - 00 ............................... 00
7 - 64 - 00 ............................... 00
7 - 65 - 00 ............................... 00
7 - 66 - 00 ............................... 00
7 - 67 - 00 ............................... 00
7 - 68 - 00 ............................... 00
7 - 69 - 00 ............................... 00
7 - 70 - 00 ............................... 00
7 - 71 - 00 ............................... 00
7 - 72 - 00 ............................... 00
7 - 73 - 00 ............................... 00
7 - 74 - 00 ............................... 00
7 - 75 - 00 ............................... 00
7 - 76 - 00 ............................... 00
7 - 77 - 00 ............................... 00
7 - 78 - 00 ............................... 00
7 - 79 - 00 ............................... 00
7 - 80 - 00 ............................... 00
7 - 81 - 00 ............................... 00
7 - 82 - 00 ............................... 00
7 - 83 - 00 ............................... 00
7 - 84 - 00 ............................... 00
7 - 85 - 00 ............................... 00
7 - 86 - 00 ............................... 00
7 - 87 - 00 ............................... 00
7 - 88 - 00 ............................... 00
7 - 89 - 00 ............................... 00
7 - 90 - 00 ............................... 00
7 - 91 - 00 ............................... 00
7 - 92 - 00 ............................... 00
7 - 93 - 00 ............................... 00
7 - 94 - 00 ............................... 00
7 - 95 - 00 ............................... 00
7 - 96 - 00 ............................... 00
7 - 97 - 00 ............................... 00
7 - 98 - 00 ............................... 00
7 - 99 - 00 ............................... 00
7 - 100
- 00 ............................... 00
7 - 101
- 00 ............................... 00
7 - 102
- 00 ............................... 00
7 - 103
- 00 ............................... 00
7 - 104
- 00 ............................... 00
7 - 105
- 00 ............................... 00
7 - 106
- 00 ............................... 00
7 - 107
- 00 ............................... 00
7 - 108
- 00 ............................... 00
7 - 109
- 00 ............................... 00
7 - 110
- 00 ............................... 00
7 - 111
- 00 ............................... 00
7 - 112
- 00 ............................... 00
7 - 113
- 00 ............................... 00
7 - 114
- 00 ............................... 00
age# Release
8 - 1 - 00 ................................ 00
8 - 2 - 00 ................................ 00
8 - 3 - 00 ................................ 00
8 - 4 - 00 ................................ 00
8 - 5 - 00 ................................ 00
8 - 6 - 00 ................................ 00
8 - 7 - 00 ................................ 00
8 - 8 - 00 ................................ 00
8 - 9 - 00 ................................ 00
8 - 10 - 00 ................................ 00
8 - 11 - 00 ................................ 00
8 - 12 - 00 ................................ 00
8 - 13 - 00 ................................ 00
8 - 14 - 00 ................................ 00
8 - 15 - 00 ................................ 00
8 - 16 - 00 ................................ 00
8 - 17 - 00 ................................ 00
8 - 18 - 00 ................................ 00
8 - 19 - 00 ................................ 00
8 - 20 - 00 ................................ 00
8 - 21 - 00 ................................ 00
8 - 22 - 00 ................................ 00
8 - 23 - 00 ................................ 00
8 - 24 - 00 ................................ 00
Å- 1 - 00 ................................ 00
Å- 2 - 00 ................................ 00
Å- 3 - 00 ................................ 00
Å- 4 - 00 ................................ 00
Å- 5 - 00 ................................ 00
Å- 6 - 00 ................................ 00
Å- 7 - 00 ................................ 00
Å- 8 - 00 ................................ 00
Å- 9 - 00 ................................ 00
Å- 10 - 00 ................................ 00
Å- 11 - 00 ................................ 00
Å- 12 - 00 ................................ 00
age# Release
Follow ã

INTRODUCTION
0-5
RSV mille
 (/ 4/#/.35,44(%-!.5!,
1) Vehicle (or engine) model
2) Section
3) elease consecutive number (“00” indicates the first
edition)
4) Year and month of publication of the elease
5) Section number
6) Section page consecutive number
7) Updated page consecutive number
8) Chapter title (numbered consecutively)
9) Paragraph title (numbered consecutively)
10) Description of the operation (always preceded by a
rhombus)
11) Description of the operation: the star means that the
operation must be repeated on the other side of the
vehicle
Release 00/2002-10 - 00

INTRODUCTION
0-6
RSV mille
 &/2% /2$
– This manual supplies the main information for normal
servicing procedures.
– In the future, the information and illustrations that make
up this manual will be updated by means of “ eleases”,
see 0.1 (UPDATE OF ELEASE 00/2002-10).
– This publication is intended for the a rilia Dealers and
their qualified engineers; many notions were voluntarily
omitted, because they were considered superfluous.
Since it is not possible to include complete mechanical
information in this publication, the persons using this
manual must have a basic mechanical training and a
basic knowledge of the procedures regarding motor ve-
hicles repair systems.
Without this knowledge, the repair or servicing of the
vehicle may be ineffective or even dangerous.
The manual does not describe all the procedures for
the repair and servicing of the vehicle in detail, there-
fore it is important to be particularly careful, in order to
avoid any damage to components and persons.
In order to grant its customers more and more satisfac-
tion in the use of the vehicle, a rilia s. .a. will keep
improving its products and the relevant documenta-
tion.
The main technical modifications and the modifica-
tions in the vehicle repair procedures are communicat-
ed to all a rilia Outlets and Branches the world over.
These modifications will be described in the succes-
sive editions of this manual.
In case of need or doubts regarding the repair and in-
spection procedures, contact the Technical After-
Sales Dpt., which can give you the information re-
quired and also inform you about any updates and
technical modifications made to the vehicle.
a rilia s. .a. reserves the right to modify its models at any
time, without prejudice to the main characteristics here
described.
All rights as to electronic storage, reproduction and total
or partial adaptation, with any means, are reserved for all
Countries.
The mention to products or services supplied by third par-
ties is made only for information purposes and it isn’t bind-
ing in any case.
a rilia takes no responsibility as to the performance or
use of said products.
For further information, see 0.4 ( EFE ENCE MANU-
ALS).
First edition: october 2002
Prodotto e stampato da:
editing division
Soave (VE ONA) - Italia
tel. [phone]
fax [phone]
E-mail: custome[email protected]
www.stp.it
per conto di:
a rilia s. .a.
Technical After-Sales De artment - Technical Documentation De artment
via G. Galilei, 1 - 30033 Noale (VE) - Italia
tel.[phone]
fax [phone]
www.aprilia.com
www.serviceaprilia.com
 2%&%2%.#%-!.5!,3
0.4.1 ENGINE SERVICE AND REPAIR MANUALS
0.4.2 SPARE PARTS CATALOGUES
0.4.3 SPECIAL TOOL MANUALS
0.4.4 USE AND MAINTENANCE MANUALS
APRILIA art# (countries)
8140582 (1051-1) I
8140584 (1053-1) f
8140585 (1054-1) d
8140583 (1052-1) E
8140586 (1055-1) U
8140587 (1056-1) u
APRILIA art# (countries)
390W IU
390Y IU
3901 IU
APRILIA art# (countries)
8202278 IfdEU
APRILIA art# (countries)
models 1998 - 1999
8102623 Ifd
8102857 pEU
8102858 ODF
8102859 GJU
8104128 A
8104099 u
models 2000
8104089 Ifd
8104142 pEU
8104143 ODF
8104141 GJU
8104164 A
8104171 u
ò
8104152 Ifd
8104269 pEU
8104267 ODF
8104268 GJU
8104270 A
8104264 u
Release 00/2002-10
- 00

INTRODUCTION
0-7
RSV mille
 3!&%49 !2.).'3
The following precautionary warnings are used through-
out this manual in order to convey the following messag-
es:
Safety warning. When you find this symbol on
the vehicle or in the manual, be careful to the o-
tential risk of ersonal injury. Non-com liance with
the indications given in the messages receded by
this symbol may result in grave risks for your and oth-
er eo le’s safety and for the vehicle!
aWARNING
Indicates a otential hazard which may result in seri-
ous injury or even death.
aCAUTION
Indicates a otential hazard which may result in
minor ersonal injury or damage to the vehicle.
NOTE The word “NOTE” in this manual precedes im-
portant information or instructions.
0.5.1 PRECAUTIONS AND GENERAL INFORMA-
TIONS
Follow with care these recommendations when repairing,
disassembling and reassembling the vehicle.
aWARNING
The use of naked flames is forbidden for any ty e of
o eration.
Before beginning any maintenance o eration or any
ins ection of the vehicle, sto the engine, extract the
key from the ignition block, wait until the engine and
the exhaust system have cooled down and if ossible
lift the vehicle by means of the ro er equi ment, on
firm and flat ground.
Kee away from the red-hot arts of the engine and
of the exhaust system, in order to avoid burns.
aWARNING
Do not hold any mechanical iece or other arts of
the vehicle with your mouth: the com onents are not
edible and some of them are noxious or even toxic.
If not ex ressly indicated otherwise, for the reassem-
bly of the units re eat the disassembly o erations in
reverse order.
Any reference to o erations from other cha ters
must be inter reted logically in order to avoid com-
onents being removed unnecessarily.
Do not use olishing astes on matt aints.
Never use fuel as a solvent for cleaning the vehicle.
Do not use alcohol, etrol or solvents to clean the
rubber and lastic arts and the saddle: use only wa-
ter and mild soa .
Disconnect the negative cable (–) from the battery
when electric welding.
When two or more ersons are working together,
make sure that each is working in safe conditions.
Carefully read 1.2 (INSTRUCTIONS FOR USE OF FU-
EL, LUBRICANTS, COOLANT AND OTHER COMPO-
NENTS).
0.5.2 BEFORE THE DISASSEMBLY OF THE
COMPONENTS
– emove any dirt, mud, dust and foreign matters from
the vehicle before disassembling the components.
– Use, when necessary, the special tools designed for
this vehicle.
0.5.3 DISASSEMBLING THE COMPONENTS
– Do not loosen and/or tighten the screws and nuts using
pliers or other tools: instead, always use the proper
spanner.
– Before disconnecting the joints (pipes, cables, etc.),
mark the positions on all of them and mark them with
different distinguishing signs.
Each piece must be marked clearly, in order not to
have problems during installation.
– Clean and wash carefully any disassembled parts with
low inflammability detergents.
– Keep the parts that are used in pairs together, since
they have adapted to each other following the normal
wear.
Some components must be used together or replaced
completely.
– Keep away from heat sources.
0.5.4 REASSEMBLING THE COMPONENTS
aCAUTION
Never use a seeger ring twice. When a seeger ring is
removed, it must be re laced with a new one. When
assembling a new seeger ring be careful not to
stretch its ends more than strictly necessary to ut it
on the shaft.
After installing a seeger ring, make sure that it is
com letely and firmly inserted in its seat.
Do not use com ressed air to clean the bearings.
NOTE The bearings must rotate freely, without halting
a/o noise otherwise they must be replaced.
– Use only original a rilia SPA E PA TS.
– Use the recommended lubricants.
– Whenever possible, lubricate the parts before reas-
sembly.
– When tightening screws and nuts, begin with those
having greater diameters or with inner ones, proceed-
ing diagonally.
Tighten screws or nuts in successive passages before
applying driving torque.
– Always replace lock nuts, seals, sealing rings, snap
rings, O-rings, split pins and screws, whenever the
thread appears damaged, with new ones.
– Before the assembly, clean all the connection surfaces,
the oil seal edges and the gaskets.
Apply a thin layer of lithium-based grease on the oil
seal edges.
Put back the oil seals and the bearings with the mark or
serial number facing towards the outside (visible side).
Follow ã
a
Release 00/2002-10 - 00

INTRODUCTION
0-8
RSV mille
Follow ã
– When installing the bearings, lubricate them abundant-
ly.
– Make sure that each component has been reassem-
bled correctly.
– After a repair or periodic maintenance operation, carry
out the preliminary checks and test the vehicle in a pri-
vate area or, in any case, in a low-traffic area.
(/ 4/53%9/523%26)#%!.$2%0!)2
-!.5!,
0.6.1 ADVICE FOR CONSULTATION
– This manual is divided into section and chapters, each
one of which corresponds to a category of main com-
ponents.
To consult them, see the sections’ index, see page 0-1.
– If not expressly indicated otherwise, for the reassembly
of the units repeat the disassembly operations in re-
verse order.
– The terms “right” and “left” are referred to the rider
seated on the vehicle in the normal riding position.
– For normal maintenance operations and for the use of
the vehicle, consult the “USE AND MAINTENANCE”
manual.
The o erations receded by this symbol must
be re eated on the o osite side of the vehi-
cle.
In this manual the various versions are indicated by the
following symbols:
òframe # ZD4RP............(and in any case from model 2001)
eautomatic light switching version (Automatic Switch-on
Device)
mo tional
ocatalytic version
VERSION:
IItaly GGreece MMalaysia
UUnited King-
dom OHolland cChile
aAustria YSwitzerland HCroatia
pPortugal DDenmark AAustralia
FFinland JJa an uUnited States
of America
BBelgium SSinga ore ÄBrazil
dGermany sSlovenia RSouth Africa
fFrance iIsrael nNew Zealand
ES ain South Korea CCanada
★
Release 00/2002-10
- 00

INTRODUCTION
0-9
RSV mille
!""2%6)!4)/.339-"/,3).)4)!,3
#= number
<= is less than
>= is greater than
≤= is equal to or less than
≥= is equal to or greater than
~= approximately
∞= infinity
°C = degrees Celsius (centigrade)
°F = degrees Fahrenheit
±= plus or minus
a.c. = alternating current
A= ampère
Ah = ampere per hour
API = American Petroleum Institute
HV = high voltage
AV/DC = AntiVibration Double Countershaft
bar = unit of pressure (1 bar = 100 kPa)
d.c. = direct current
cm#= cubic centimetres
CO = carbon monoxide
CPU = Central Processing Unit
DIN = German industrial normative (Deutsche
Industrie Norm)
DOHC = Double Overhead Camshaft
ECU = Engine Control Unit
r m = revolutions per minute
HC = unburnt hydrocarbons
ISC = idle speed control
ISO = International Standardization Organization
kg = kilograms
kgm = kilograms per metre (1 kgm = 10 Nm)
km = kilometres
km/h = kilometres an hour
kΩ= kilo-ohms
kPa = kiloPascal (1 kPa = 0.01 bar)
KS = clutch side (Kupplungseite)
kW = kilowatt
L= litres
LAP = lap (race course)
LED = Light Emitting Diode
LEFT
SIDE = left side
m/s = metres an second
MAX = maximum
mbar = millibar (1mbar = 0.1 kPa)
mi = mile
MIN = minimum
MPH = miles per hour
MS = flywheel side (Magnetoseite)
MΩ= megaohm
N.A. = not available (Not Available)
N.O.M.M. = “Motor” method octane number
N.O.R.M. = “ esearch” method octane number
Nm = newton per meter (1 Nm = 0.1 kgm)
Ω= ohm
PICK-UP = pick-up
BDC = bottom dead centre
TDC = top dead centre
PPC = Pneumatic Power Clutch
RIGHT
SIDE = right side
SAE = Society of Automotive Engineers
TEST = diagnostics test
T.B.E.I. = convex socket head
T.C.E.I. = hexagonal socket head
T.E. = hex-head
T.P. = flat head
TSI = Twin Spark Ignition
UPSIDE-
DOWN = upside-down rods
V= volt
W= watt
Ø= diameter
Release 00/2002-10 - 00

NOTES
THIS PAGE HAS BEEN INTENTIONALLY LEFT EMPTY
INTRODUCTION
0-10
RSV mille
Release 00/2002-10
- 00

RSV mille
1-1
GENERAL INFORMATION 1
Release 00/2002-10 - 00

GENERAL INFORMATION
1
1-2
RSV mille
GENERAL INFORMATION
4!",%/&#/.4%.43
0/3)4)/./&4(%3%2)!,
.5-"%23 .................................................. 1-3-00
1.1.1 FRAME NUMBER .................................... 1-3-00
1.1.2 ENGINE NUMBER ................................... 1-3-00
).3425#4)/.3&/253%/&
&5%,,5"2)#!.43#//,!.4!.$
/4(%2#/-0/.%.43 .......................... 1-4-00
1.2.1 FUEL ........................................................ 1-4-00
1.2.2 ENGINE OIL ............................................ 1-4-00
1.2.3 FORK OIL ................................................ 1-4-00
1.2.4 BRAKE FLUID ......................................... 1-5-00
1.2.5 COOLANT ............................................... 1-5-00
1.2.6 CLUTCH FLUID ....................................... 1-6-00
1.2.7 CARBON MONOXIDE ............................. 1-6-00
1.2.8 HOT COMPONENTS ............................... 1-6-00
25..).').25,%3 ............................... 1-7-00
30!2%0!243 .......................................... 1-7-00
4%#(.)#!,30%#)&)#!4)/.3 ............ 1-8-00
,5"2)#!.4#(!24 .............................. 1-12-00
1.6.1 LUBRICANT CHART (for models
u to 2001) ............................................ 1-12-00
1.6.2 LUBRICANT CHART ò ..................... 1-13-00
30%#)!,4//,3m .............................. 1-14-00
1.7.1 SUPPORT STANDS .............................. 1-14-00
1.7.2 FRAME TOOLS ..................................... 1-15-00
1.7.3 FORK TOOLS ....................................... 1-15-00
1.7.4 ENGINE TOOLS .................................... 1-16-00
1.7.5 MISCELLANEOUS TOOLS ................... 1-18-00
1.7.6 TOOLS USED FOR OTHER
a rilia VEHICLES ................................. 1-20-00
0/3)4)/.).'4(%6%()#,%/.
4(%3500/2434!.$ ......................... 1-21-00
1.8.1 ASSEMBLING THE PINS FOR THE
REAR SUPPORT STAND m ............... 1-21-00
1.8.2 POSITIONING THE VEHICLE ON
THE REAR SUPPORT STAND m ...... 1-21-00
1.8.3 POSITIONING THE VEHICLE ON THE
FRONT SUPPORT STAND m ............ 1-21-00
1.8.4 POSITIONING THE VEHICLE ON THE
CENTRE SUPPORT STAND m .......... 1-22-00
#/.35-!",%3 ..................................... 1-23-00
1.9.1 PRODUCT PROPERTIES ..................... 1-23-00
1.9.2 USE OF CONSUMABLES ..................... 1-25-00
&!34%.).'%,%-%.43 .................... 1-28-00
1.10.1 JOINTS WITH HOSE CLAMPS
AND SCREW CLAMPS ....................... 1-28-00
1.10.2 GENERAL SPECIFICATIONS OF
THE DRIVING TORQUES ................... 1-29-00
1.10.3 DRIVING TORQUES ........................... 1-30-00
- 00 Release 00/2002-10
).3425#4)/.3&/2!00,9).'
42!.3&%23 ........................................... 1-36-00

GENERAL INFORMATION
1-3
RSV mille
 0/3)4)/./&4(%3%2)!,.5-"%23
These numbers are necessary for the registration of the
vehicle.
Do not alter the identification numbers if you do not want
to incur severe penal and administrative sanctions. In
particular, the alteration of the frame number results in
the immediate invalidity of the guarantee.
1.1.1 FRAME NUMBER
The frame number is stamped on the right side of the
steering column.
1.1.2 ENGINE NUMBER
The engine number is stamped on the rear part of the en-
gine, near the pinion.
Release 00/2002-10 - 00

GENERAL INFORMATION
1-4
RSV mille
 ).3425#4)/.3&/253%/&&5%,
,5"2)#!.43#//,!.4!.$/4(%2
#/-0/.%.43
1.2.1 FUEL
aWARNING
The fuel used for internal combustion engines is ex-
tremely inflammable and in articular conditions it
can become ex losive.
It is im ortant to carry out the refuelling and the
maintenance o erations in a well-ventilated area,
with the engine off.
Do not smoke while refuelling or near fuel va ours, in
any case avoid any contact with naked flames,
s arks and any other heat source to revent the fuel
from catching fire or from ex loding.
Further, revent fuel from flowing out of the fuel filler,
as it could catch fire when getting in contact with the
red-hot surfaces of the engine.
In case some fuel has accidentally been s ilt, make
sure that the area has com letely dried and before
starting the vehicle verify that there is no fuel inside
the fuel filler neck.
Since etrol ex ands under the heat of the sun and
due to the effects of sun radiation.
Never fill the tank to the brim.
Screw the lug u carefully after refuelling.
Avoid any contact of the fuel with the skin and the in-
halation of va ours; do not swallow fuel or our it
from a rece tacle into another by means of a tube.
DO NOT DISPOSE OF FUEL IN THE ENVIRONMENT.
KEEP AWAY FROM CHILDREN.
Use only premium grade unleaded petrol, min. O.N. 95
(N.O. .M.) and 85 (N.O.M.M.).
1.2.2 ENGINE OIL
aWARNING
Engine oil may cause serious damage to the skin if
handled daily and for long eriods.
Wash your hands carefully after use.
Do not dis ose of the oil in the environment.
Deliver it to or have it collected by the nearest oil sal-
vage center or by the su lier.
In case any maintenance o eration has to be carried
out, it is advisable to use latex gloves.
For the maintenance intervals, see 2.1.1 (REGULAR
SERVICE INTERVALS CHART).
For the lubricant ty es, see 1.6 (LUBRICANT CHART).
1.2.3 FORK OIL
aWARNING
Fork oil may cause serious damage to the skin if han-
dled daily and for long eriods.
Wash your hands carefully after use.
Do not dis ose of the oil in the environment.
Deliver it to or have it collected by the nearest oil sal-
vage center or by the su lier.
In case any maintenance o eration has to be carried
out, it is advisable to use latex gloves.
By changing the dam er settings and/or the viscosity
of the oil contained in them, the sus ension re-
s onse may be altered artially.
Standard oil viscosity: SAE 20 W.
The viscosity ratings which can be chosen based on
the ty e of fork stiffness desired (SAE 5W soft, 20W
stiff).
The two roducts can be used in different ercentag-
es until the desired res onse is obtained.
v F.A. is that your viscosity alters little with changes
in tem erature and their dam ing res onse therefore
remains constant.
For the maintenance intervals, see 2.1.1 (REGULAR
SERVICE INTERVALS CHART).
For the lubricant ty es, see 1.6 (LUBRICANT CHART).
- 00 Release 00/2002-10

GENERAL INFORMATION
1-5
RSV mille
1.2.4 BRAKE FLUID
NOTE This vehicle is provided with front and rear disc
brakes, with separate hydraulic circuits. The following in-
formation refers to a single braking system, but is valid for
both.
aWARNING
If the brake fluid gets in contact with the skin or the
eyes, it can cause serious irritations.
Carefully wash the arts of your body that get in con-
tact with the liquid. Consult a doctor or an oculist if
the liquid gets in contact with your eyes.
DO NOT DISPOSE OF THE FLUID IN THE ENVIRON-
MENT.
KEEP AWAY FROM CHILDREN.
When using the brake fluid, take care not to s ill it on
the lastic or ainted arts, since it can damage
them.
For the maintenance intervals, see 2.1.1 (REGULAR
SERVICE INTERVALS CHART).
For the lubricant ty es, see 1.6 (LUBRICANT CHART).
aCAUTION
To avoid serious damage to the braking system, do
not use fluids other than the recommended ones nor
mix different fluids for to ing u .
Do not use brake fluid taken from old or already
o ened containers.
Sudden variations in clearance or an elastic resist-
ance in the brake levers may be due to trouble in the
hydraulic circuits.
Make sure that the brake discs and the friction ads
are com letely free of grease or oil, es ecially after
maintenance or checking o erations.
Check that the brake cables are neither twisted nor
worn out.
Prevent water or dust from accidentally getting into
the circuit.
In case maintenance o erations are to be erformed
on the hydraulic circuit, it is advisable to use latex
gloves.
1.2.5 COOLANT
aWARNING
The coolant is noxious: do not swallow it; if the cool-
ant gets in contact with the skin or the eyes, it can
cause serious irritations. If the coolant gets in con-
tact with your skin or eyes, rinse with lenty of water
and consult a doctor.
If it is swallowed, induce vomit, rinse mouth and
throat with lenty of water and consult a doctor with-
out delay.
DO NOT DISPOSE OF THE FLUID IN THE ENVIRON-
MENT.
KEEP AWAY FROM CHILDREN.
Be careful not to s ill the coolant on the red-hot arts
of the engine: it may catch fire and send out invisible
flames.
In case any maintenance o eration should be re-
quired, it is advisable to use latex gloves.
Do not use the vehicle if the coolant is below the min-
imum rescribed level.
For the maintenance intervals, see 2.1.1 ( EGULA
SE VICE INTE VALS CHA T).
The coolant is composed of 50% water and 50% anti-
freeze. This mixture is ideal for most running tempera-
tures and ensures good protection against corrosion.
It is advisable to keep the same mixture in the hot season
as well, since in this way losses due to evaporation are
reduced and it is not necessary to top up so frequently.
The mineral salt deposits left in the radiator by evaporat-
ed water are thus lessened and the efficiency of the cool-
ing system remains unaltered.
If the outdoor temperature is below 0°, check th cooling
circuit frequently and inf necessary increase the anti-
freeze concentration (up to maximum 60%).
For the cooling solution use distilled water, in order not to
damage the engine.
For the lubricant ty es, see 1.6 (LUBRICANT CHART).
On the basis of the desired freezing temperature of the
coolant mixture, add to the water the percentage of cool-
ant indicated in the following table:
NOTE The characteristics of the various antifreeze liq-
uids are different. Be sure to read the label on the product
to learn the degree of protection it guarantees.
aCAUTION
Use only antifreeze and anticorrosive without nitrite,
ensuring rotection at -35 °C at least.
Freezing oint °C Coolant of the volume
%
-20 35
-30 45
-40 55
Release 00/2002-10 - 00

GENERAL INFORMATION
1-6
RSV mille
1.2.6 CLUTCH FLUID
NOTE This vehicle is provided with hydraulic clutch
control.
aWARNING
If the clutch fluid gets in contact with the skin or the
eyes, it can cause serious irritations.
Carefully wash the arts of your body that get in con-
tact with the liquid. Consult a doctor or an oculist if
the liquid gets in contact with your eyes.
DO NOT DISPOSE OF THE FLUID IN THE ENVIRON-
MENT.
KEEP AWAY FROM CHILDREN.
When using the clutch fluid, take care not to s ill it on
the lastic and ainted arts, since it damages them.
For the maintenance intervals, see 2.1.1 (REGULAR
SERVICE INTERVALS CHART).
For the lubricant ty es, see 1.6 (LUBRICANT CHART).
aCAUTION
To avoid serious damage to the system, do not use
fluids other than the recommended ones nor mix dif-
ferent fluids for to ing u .
Do not use clutch fluid taken from old or already
o ened containers.
Sudden variations in clearance or an elastic resist-
ance in the clutch levers may be due to trouble in the
hydraulic circuits.
Check that the clutch hoses are not twisted or worn.
Prevent water or dust from accidentally getting into
the circuit.
In case maintenance o erations are to be erformed
on the hydraulic circuit, it is advisable to use latex
gloves.
1.2.7 CARBON MONOXIDE
If it is necessary to let the engine run in order to carry out
some work, make sure that the area in which you are op-
erating is properly ventilated.
Never run the engine in enclosed spaces.
If it is necessary to work indoors, use an exhaust evacua-
tion system.
aWARNING
The exhaust fumes contain carbon monoxide, a oi-
sonous gas that can cause loss of consciousness
and even death.
un the engine in an open area or, if it is necessary to
work indoors, use an exhaust evacuation system.
1.2.8 HOT COMPONENTS
aWARNING
The engine and the com onents of the exhaust sys-
tem become very hot and remain hot for some time
after the engine has been sto ed.
Before handling these com onents, wear insulating
gloves or wait until the engine and the exhaust sys-
tem have cooled down.
- 00 Release 00/2002-10

GENERAL INFORMATION
1-7
RSV mille
 25..).').25,%3
The running-in of the engine is essential to ensure its du-
ration and correct functioning.
If possible, drive on hilly roads and/or roads with many
bends, so that the engine, the suspensions and the
brakes undergo a more effective running-in.
During running-in, change speed.
In this way the components are first “loaded” and then
“relieved” and the engine parts can thus cool down.
Even if it is important to stress the engine components
during running-in, take care not to exceed.
aCAUTION
Only after the first 1500 km (937 mi) of running-in is it
ossible to obtain the best erformance.
Keep to the following indications:
◆Do not open the throttle completely if the speed is low,
both during and after the running-in.
◆During the first 100 km (62 mi) put on the brakes with
caution, avoiding sharp and prolonged brakings.
This ensures a correct bedding-in of the pads on the
brake disc.
◆During the first 1000 km (625 mi) never exceed 6000
rpm. (see table).
aCAUTION
After the first 1000 km (625 mi) erform the checking
o erations indicated in the “after running-in” col-
umn, see 2.1.1 (REGULAR SERVICE INTERVALS
CHART) in order to avoid injuring yourself or others
a/o damaging the vehicle.
◆Between the first 1000 km (625 mi) and 1500 km (937
mi) drive more briskly, change speed and use the max-
imum acceleration only for a few seconds, in order to
ensure better coupling of the components; never ex-
ceed 7500 rpm (see table).
◆After the first 1500 km (937 mi) you can expect better
performance from the engine, however, without ex-
ceeding the maximum allowed (10500 rpm).
 30!2%0!243
For any replacement, use a rilia Genuine Spare Parts
only, see 0.4.2 (SPA E PA TS CATALOGUES).
a rilia Genuine Spare Parts are high-quality parts, ex-
pressly designed and manufactured for a rilia vehicles.
aCAUTION
Failure to use APRILIA Genuine S are Parts may re-
sult in incorrect erformance and damages.
Engine maximum r m recommended
Mileage km (mi) r m
0 – 1000 (0 – 625) 6000
1000 – 1500 (625 – 937) 7500
over 1500 (937) 10500
Release 00/2002-10 - 00

GENERAL INFORMATION
1-8
RSV mille
 4%#(.)#!,30%#)&)#!4)/.3
DIMENSIONS
Max. length 2080 mm
òMax. length 2070 mm
Max. length (with number plate-holder extension) m2140 mm
Max. width 720 mm
òMax. width 725 mm
Max. height (front part of the fairing included) 1170 mm
Seat height 820 mm
Distance between centres 1415 mm
Min. ground clearance 130 mm
Weight ready for starting (fuel and fluid included) 221 kg
ENGINE
Model V990
Type 60° longitudinal V-type, two-cylinder, 4-stroke, with 4
valves per cylinder, DOHC.
Number of cylinders 2
Total displacement 997.62 cm#
Max. rated power (to driving shaft) 86.5 kW at 9250 rpm
ò Max. rated power (to driving shaft) 92 kW at 9250 rpm
Bore/stroke 97 mm/67.5 mm
Compression ratio 11.8 ± 0.4 : 1
Average piston speed 22.5 m/s at 10000 rpm
Camshaft during intake stroke 259°, valve lifting= 10.6 mm
òCamshaft during intake stroke 262°, valve lifting= 11.4 mm
Camshaft during exhaust stroke 259°, valve lifting= 10.6 mm
Valve advance (with valve clearance 1mm) opening during
intake stroke
closing during intake
stroke
opening during exhaust
stroke
closing during exhaust
stroke
20° before TDC
59° after BDC
64° before TDC
15° after BDC
òValve advance (with valve clearance 1mm) opening during
intake stroke
closing during intake
stroke
opening during exhaust
stroke
closing during exhaust
stroke
25° before TDC
58° after BDC
64° before TDC
15° after BDC
Valve clearance during intake stroke 0.12 – 0.17 mm
Valve clearance during exhaust stroke 0.23 – 0.28 mm
Diameter of the inlet valve plate 36.0 mm
Diameter of the exhaust valve plate 31.0 mm
# Engine revolutions at minimum rpm 1250 ± 100 rpm
# Engine revolutions at peak rpm 10250 ± 100 rpm
Ignition electronically controlled
Starting electric
Spark advance Variable according to speed and load
Starter motor gear ratio i= 49/9 * 30/11 * 64/30 = 31.677
Clutch multidisc in oil bath, with hydraulic control on the left
side of the handlebar and PPC device
- # 9 lined discs; thick 3.5 mm
- # 9 internal discs; thick 1.5 mm
Follow
ã
- 00 Release 00/2002-10

GENERAL INFORMATION
1-9
RSV mille
Follow
ã
ENGINE
Transmission Mechanical, 6 gears with foot control on the left side of
the engine
Lubrication system dry pan with separate oil tank, # 2 trochoidal pumps
and cooling radiator
Lubrication pressure min 500 kPa (5 bar)
at max 80 °C (176 °F) and 6000 rpm
Air cleaner with dry filter cartridge
Cooling liquid-cooled
Coolant pump gear ratio iwp= 28/27 * 28/28 = 1.037
Coolant pump delivery (with thermal expansion valve open) 90 L /min and 9000 rpm
Thermal expansion valve opening start temperature 75 ± 2 °C (149 ± 5 °F)
Engine dry weight ~ 65 kg
CAPACITY
Fuel (reserve included) 20 L
òFuel (reserve included) 18 L
Fuel reserve 4.5 ± 1 L
Engine oil oil change 3700 cm#
oil and oil filter change 3900 cm#
Fork oil (per rod) 520 ± 2.5 cm#
Coolant 2.5 L(50% water + 50% antifreeze with ethylene glycol)
Seats 2
Vehicle max. load (driver + passenger + luggage) 182 kg
òVehicle max. load (driver + passenger + luggage) 180 kg
DRIVE
GEA ATIOS atio Primary Secondary Final ratio Total ratio
1a31/60 = 1: 1.935 14/35 = 1: 2.500 17/42 = 1: 2.470 11.948
2a16/28 = 1: 1.750 8.368
3a19/26 = 1: 1.368 6.543
4a22/24 = 1: 1.090 5.216
5a23/22 = 1: 0.956 4.573
6a27/23 = 1: 0.851 4.073
# sprocket teeth 17
Drive chain Endless type (with no connection link) with sealed links,
model 525, dimensions 5/8" x 5/16"
FUEL SUPPLY SYSTEM
Type electronic injection
Choke Ø 51 mm
FUEL SUPPLY
Type indirect injection (MULTIPOINT)
Fuel premium grade unleaded petrol, min. O.N. 95
(N.O. .M.) and 85 (N.O.M.M.).
FRAME
Type two-beam frame with light alloy cast elements and
extruded elements
Steering inclination angle 25°
Fore stroke 97 mm
òFore stroke 99 mm (with front tyre 120/70)
Follow
ã
Release 00/2002-10 - 00
