APRILIA 2010 RX 125 User manual

ENDURO MOTORCYCLE
SUPERMOTO MOTORCYCLE
SX 125
RX 125
RACING TECHNOLOGY AND EMOTIONS, MADE TO MEASURE FOR YOU. HAVING SEEN OFF ALL
COMERS IN THE SUPERMOTARD WORLD CHAMPIONSHIP, APRILIA IS PROUD TO PRESENT THE EXCITING
NEW SX 125. ADVANCED TECHNOLOGY, SENSATIONAL PERFORMANCE AND STUNNING LOOKS: HERE IS A
MOTARD THAT MAKES YOU DREAM OF THE RACETRACK EVERY TIME YOU RIDE. POWER, AGILITY, CONTROL:
WITH THE SX 125, AT LAST YOU CAN EXPERIENCE THE THRILLS YOU HAVE ALWAYS DREAMED OF.
THE MOTARD YOU’VE
BEEN WAITING FOR!
APRILIA’S WINNING SPIRIT, OFF-ROAD AND AROUND TOWN. ONE BIKE, TWO SOULS, UNIQUE
PERFORMANCE AND EXCITEMENT: THE RX 125. THE RESULT OF APRILIA’S UNBEATABLE EXPERIENCE IN
OFF ROAD RACING, AND DEDICATED TO RIDERS IN SEARCH OF SATISFACTION OFF ROAD AND IN TOWN,
THE RX 125 OFFERS EXCITING AGILITY AND CONTROL. LIVE THE THRILLS OF AN RX 125, EVERY DAY,
ON ALL TERRAINS.
THE RETURN OF AN
OFF ROAD LEGEND!

GEARBOX
6 speed.
Transmission ratios:
1st 10/30
2nd 14/29
3rd 17/27
4th 19/25
5th 21/23
6th 22/21
FUEL TANK
Capacity 10 litres
EVERYTHING ABOUT THE RX 125 EXPRESSES YOUR PASSION FOR ENDURO: ITS INNOVATIVE
TRELLIS FRAME, OFF ROAD RIDING POSITION, AND TOP LEVEL COMPONENTS GIVE YOU THE
VERY BEST, IN THE MUD AND ON THE ROAD. ON TOP OF THIS YOU GET APRILIA STYLE TOO.
REAR BRAKE
The rear brake features a reservoirincorporated
in the master cylinder and a 220 mm disc with
single piston floating caliper for super-safe
braking even over slippery surfaces
FORK
An oversized upside down fork with
40 mm stanchions and 260 mm of wheel travel
means maximum precision under all conditions
DIMENSIONS, RX
Overall length: 2255 mm
Overall width: 850 mm
Seat height: 925 mm
Wheelbase: 1480 mm
UNSTOPPABLE WHEELS
Spoked wheels withaluminium
alloy rims and classic enduro size.
Front: 1.6 x 21”.
Rear: 2.15 x 18”.
The right balancebetween strength
and flexibility off-road
Knobbly tyres:
Front: 90.90 x 21”.
Rear: 120/90 x 18”.
Ideal on all surfaces
MULTIFUNCTIONAL INSTRUMENTS
All the information you could possible need
is provided in a minimum of space
SLENDER LINES AND LED LIGHTS
The high luminosity LED rear light cluster
is ultra-compactand feature aggressive
colours and eye-catching graphics.
Stylistic and technical solutions reduce
weight and add aggression at the same
time
TWO-TONE NARROW RACING SEAT
The slender linesof the seat make the RX
superbly manoeuvrable even over the twistiest
routes. The dimensions of the seat allow you
to shift your body easily for perfect weight
distribution and control through bends
DIMENSIONS, SX
Overall length: 2165 mm
Overall width: 850 mm
Seat height: 870 mm
Wheelbase: 1480 mm
SX 125 and RX 125 are ecological vehicle with communitarian
homologation Euro 3, in the respect of the acoustic and
atmospheric pollution limits.
RACETRACK WHEELS
Spoked wheels with aluminium rims:
Front: 3.00 x 17”. Rear: 4.25 x 17”.
Perfect rigidity over urban roads
Tyres:
Front: 110.70 x 17”. Rear: 150/60 x 17”.
Unbeatable grip
TRELLIS FRAME
Made from high strength steel, the
lightweight frame gives amazing agility
and strength, with exceptional elasticity
to damp out rough surfaces and perfect
torsion for cornering control
DETACHABLE SEAT FRAME
The detachable seat frame is a technical
refinement designed to lighten racingbikes
quickly and simply: a sign of authentic racing
spirit
ROBUST SWINGARM
The steel swingarmgives
maximum strength under all
conditions of use,enhancing the
superbly balanced chassis
SINGLE CYLINDER 2-STROKE
Lightweight, reliable, and high-tech, with electronic ignition, electronically
controlled exhaust valve and liquid cooling, the engine delivers unrivalled
performance, with bags of torque as soon as you twist the throttle
POWER AND ECOLOGY
Though homologated to Euro 3 standards, the engine producesthe
maximum power permitted for a 125 cc, plus thesparkling 2-stroke
performance
REAR MONOSHOCK
Monoshock with spring preload adjustment
and piggy-back cylinder, derived from Aprilia’s
racing experience
PRIMARY DRIVE
Helical gears. Ratio: 19/63
FINAL DRIVE
Chain. Z 16 gearbox pinion, Z 45 rear wheel sprocket (11 kW);
Z 15 gearbox pinion, Z 45 rear wheel sprocket (16 kW).
KICK START
Racing emotion from the
word ‘go’!
CLUTCH
Multi-plate wet clutch.
“APRILIA RACING” GRAPHICS
An unmistakable winning look bound to cause envy!
FUEL
Unleaded petrol
THE SX 125 HAS ALL THE PERSONALITY AND TECHNOLOGY OF A GENUINE MOTARD: AGILE IN
CORNERING, INSTANT POWER ALWAYS ON TAP, AND EXTREME ROADHOLDING. AND APRILIA
QUALITY TOO: A NEW STANDARD FOR THE WORLD OF OFF ROAD RACING AND ON-ROAD
ENJOYMENT.
FRONT BRAKE
260 mm disc and two-piston
floating caliper for powerful yet
controllable braking in all situations
RX 125
ENDLESS
FUN!
SX 125
POWER
SLIDES HERE
WE COME!
SUPERMOTO MOTORCYCLE
ENDURO MOTORCYCLE
Aprilia ViaG.Galilei, 1 30033 Noale (VE) Italia tel. [phone] fax [phone] www.aprilia.com
Drive safely always wearing a helmet and protective clothing. Observe the laws of the road and respectthe environment. Carefully read the owners’ handbook. Photographs, technical data, specifications
and colors shown in this brochure refer to the Italian market version and may be subject to change without prior notice. Ask your official Aprilia dealers for full details. In order to maintain your machine in
a safe and efficient manner,always demand official Aprilia Spare Parts, which are guaranteed by Aprilia Quality Service in respect of current legislation.
