APRILIA PEGASO 650 - 2009 User manual

PEGASO
650
+
FACTORY

PEGASO 650
PEGASO
650
TOTAL FUN
In the world of motorcycling, one name is guaranteed to evoke ideas of agility, versatility, style,
technology, quick and easy travel to new horizons, and unrivalled riding satisfaction.
That name is Pegaso 650. Aprilia’s rst ever ‘big bike’ is still the reference point for total usability
and eclectic personality. Urban ghter, street motard, or simply an amazing commuter,
the Pegaso 650 is whatever you want it to be. Around town, on the motorway, or in the hills,
the Pegaso 650 has just one ambition: to give you nothing but sheer, total fun.
ORIGINAL STYLE
You can see at a glance that the Pegaso 650 is not made to sit on its side stand! Its design is
a perfect blend of modern, aggressive, sports styling. Its sleek, streamlined looks, exclusive
components and mean graphics are perfect for tackling the most diverse riding conditions in
quiet, relaxed condence. But the great thing about the Pegaso 650 is its ergonomics.
One minute on its impressively comfortable and low seat (seat height only 780 mm) is enough
to create total unity between man and machine. The Pegaso’s great seating position means
unrivalled comfort for both the passenger too.
PEGASO 650
PLATINUM GREY

PEGASO 650
PEGASO
650
ADVANCED TECHNOLOGY
The Pegaso 650 is so versatile, exciting and fun to ride because it incorporates the very latest motorcycle
technology. Its engine is a Euro 3 single cylinder with electronic fuel injection, four valve head and dry sump
lubrication system for instant response and excellent sports performance. A lightweight but rigid frame and robust
suspension deliver sensational handling and total control. Race-inspired alloy wheels, generous road-going tyres
and a powerful braking system mean light weight with plenty of grip and active safety. No other motorcycle can
compare. The Pegaso 650 is special in every component, and in every situation.
UNIQUE PERSONALITY
For leisure or commuting, alone or with a partner, all week long or on weekend trips, only the Pegaso 650 can give
you such amazing satisfaction. Even city centre trafc becomes a source of pleasure thanks to an exceptional
steering angle that makes the Pegaso 650 the most easy to manoeuvre and agile bike in its class. The Pegaso 650
loves change too: ring roads, coast road and mountain roads, morning and evening … riding them is always an
exhilarating experience. And tomorrow even more fun is coming your way on the Pegaso 650.
PEGASO 650
BRIO YELLOW

PEGASO 650 FACTORY
PEGASO
650
FACTORY
TRUE GRIT
“Factory” is a legendary name that evokes the ultimate in Aprilia technology and racing spirit.
The Pegaso 650 Factory is an exclusive, prestigious, and enviable motorcycle, designed for the rider who
demands the best in every way. The Factory has been made as light as possible to make the most of the
Pegaso’s powerful Euro 3 engine and renowned handling. Generous use of carbon bre parts like mudguards
and side guards confer a unique level of prestige. The Factory is more high-tech and aggressive in every
detail, from its special graphics to its twin taper aluminium handlebars and motard style, gold coloured,
lightweight alloy, spoked wheels. On a Pegaso 650 Factory, fun is taken to the next level!
EXCLUSIVE EMOTIONS
A road bike with all the characteristics of a supermotard, the Pegaso 650 Factory carries you into a world of
new emotions. The riding position features a higher seat for greater control over the front end and an instant
feeling of control not only in everyday riding but even in the most challenging situations. A braking system
with four-piston radial calipers of the sort used on racing motards adds to the fun and provides further proof
that the Pegaso 650 Factory beats any rival even in safety.
PEGASO 650 FACTORY
APRILIA BLACK

04
03
01 02
05
04
PEGASO 650 + FACTORY
PEGASO
EQUIPMENT
INNOVATION IS STANDARD
As you could expect from Aprilia, the Pegaso 650 boasts a unique level of equipment for its class.
For a start there are two storage compartments. One is located in the top of the fuel tank and features an
electric release switch on the handlebars so that it can be opened without having to remove the ignition
key. The other, located under the seat, provides the biggest storage capacity found on any motorcycle of
this kind. Then there are twin headlights, integrated in the self-supporting nose fairing to deliver maximum
grit and protection with minimum weight.
The innovative instruments feature a rened, sporting design and a joystick on the handlebar control
block for quick and easy access and operation. An analog rev counter is complemented by a large,
multifunctional digital display (01) complete with on-board computer providing all the information you could
possibly need, immobiliser with programmable PIN code (02), analog rev counter (03), digital speedometer
(04), customisable gear change threshold, top speed, engine diagnostics with “Service Code”, odometer
with two trip counters, timer, clock, hazard warning function, battery level, and 6 warning lights and
indicators (05) for warning, turn, main beam, fuel reserve*, neutral, and side stand down.
* Only available on the Factory.

040302
PEGASOEXTRA
07
PEGASO 650 FACTORY
05
08
06
01
INFINITE POSSIBILITIES
The Pegaso 650 can be equipped with a wide range of accessories
to make it even more versatile for all trips, long and short alike, and to
match your needs whatever the situation.
• Carbon bre body parts.
• Adjustable front brake lever*.
• Luggage rack.
01. Adjustable full windshield.
02. High seat for taller riders*.
03. Street Case II, 47 litre top box with optional
backrest.
04. Semi-rigid lockable panniers in high-tech
textile, expandable from 25 to 34 litres.
05. Carbon bre hand guards.
06. Aprilia “Street Legal” slip-on titanium
silencers by Akrapovic.
07. Aprilia electronic anti-theft system.
08. Tank cover and removable 14 litre tank bag
in high-tech textile, complete with rain hood.
* Standard on the Pegaso 650 Factory.

Engine Single cylinder four stroke with light alloy cylinder.
Liquid cooling with three way pressurised circuit.
Single overhead cam with chain timing drive; four valves.
Anti-vibration counter-shaft. Euro 3.
Fuel Unleaded petrol.
Bore x stroke 100 x 84 mm.
Displacement 660 cc.
Compression ratio 10:1.
Max. power at crank 48 HP (35 kW) at 6,000 rpm.
Max. torque at crank 6.01 kgm (59 Nm) at 5,000 rpm.
Fuel system Integrated electronic engine management system.
Electronic fuel injection. Throttle body: 44 mm.
Ignition Electronic.
Starting Electric.
Alternator 290 W.
Lubrication Dry sump with oil pump.
Gearbox 5 speed. Ratios:
1
st 12/30, 2nd 16/26, 3rd 20/23, 4th 22/20, 5th 26/20.
Clutch Cable operated multi-plate wet clutch.
Primary drive Spur gears.
Transmission ratio: 36/75.
Final drive Chain.
Transmission ratio: 15/44.
Frame Steel, open cradle, single spar frame.
Front suspension 45 mm fork.
Wheel travel 140 mm.
Rear suspension High strength steel swingarm. Aprilia Progressive System (APS)
rising rate linkages. Sachs hydraulic monoshock with adjustable
rebound and preload.
Wheel travel 130 mm.
Brakes Front: Brembo with 320 mm stainless steel floating disc.
Caliper with four opposed pistons.
Rear: 240 mm stainless steel disc, floating caliper.
Pegaso Factory - Front: FTE with 320 mm stainless steel floating
disc. Four piston radial caliper and radial master cylinder.
Wheels Light alloy, Y spokes.
Front: 3.50 x 17”.
Rear: 4.50 x 17”.
Pegaso Factory – Spoked wheels with gold anodised rim.
Tyres Front: 100/90-19.Rear: 130/80-17.
Dimensions Overall length: 2232 mm. Overall width: 820 mm.
Ground clearance: 270 mm. Seat height: 820 mm.
Wheelbase: 1510 mm.
Fuel tank Capacity 16 litres, 3.5 litre reserve.
Pegaso 650 and Factory are both available in restricted 25 kW versions.
Pegaso 650
Platinum Grey
Pegaso 650
Brio Yellow
Pegaso 650 Factory
Aprilia Black
MINEDIVINE Photography: Milagro Still Life: Studio Pointer Testi: Daniele Varelli Printed in Italy 03/2008
Drive safely always wearing a helmet and protective clothing. Observe the laws of the road and respect the environment. Carefully read the owners’ handbook. Photographs, technical data, specifications
and colours shown in this brochure refer to the Italian market version and may be subject to change without prior notice. Ask your official Aprilia dealers for full details. In order to maintain your machine
in a safe and efficient manner, always demand official Aprilia Spare Parts, which are guaranteed by Aprilia Quality Service in respect of current legislation. E & O E. Aprilia offers Aprilia Road Assistance, a
call centre available 24 hours a day for information and road rescue.
E. & O.E. Aprilia reserves the right to change colour/specification without prior notice.
Concessionair
Pegaso 650 and Factory are ecological vehicle with communitarian homologation Euro 3, in the respect of the acoustic and atmospheric pollution limits.
