AQUA-REX WK1P Instruction sheet

This product is intended for use on plastic pipe up to
2½”diameter on re-circulating systems for swimming pools.
It may also be used to treat domestic water supplies on
pipe diameter up to 1” where it is exposed to wet or damp
conditions. It MUST NOT be used on pipe sizes of more
than one inch diameter except on re-circulating systems such
as pools.
The WK1P is fully waterproof so it can be left outside
exposed to rain and weather.
The antennas and power supply are directly wired into the
control box and cannot be removed from the unit. The circuit
board is fully encapsulated in epoxy resin.
There is a plastic sheath that can be heat shrunk onto the
power supply connection.
The power supply transformer is only rated for
internal use and must not be allowed to get wet.
It must be protected in the same way as a normal
home internal plug.
GENERAL
If this unit is to be used on domestic water services
to protect an externally mounted water heater
then refer to the instructions for the Aqua-Rex
WK1 which can be downloaded from the Technical
Library on our website www.aqua-rex.com.
The Aqua-Rex WK1P will substantially reduce the amount
of Calcium scale deposits that occur around the waterline
of pools. By removing the scale from the tiles or liner, any
staining that is retained by the scale will also disappear.
SILICA SCALE
Calcium scale and Silica scale look very similar and are
often confused with each other. The easiest way to tell them
apart is to test them with an acid such as vinegar or muriatic.
Calcium scale will bubble and will disappear. Silica won’t
react at all.
Aqua-Rex will NOT remove Silica scale. The scale around
the grout lines of tiles generally comes from behind the tile
and is mostly Silica. Aqua-Rex will not be effective on this
kind of scale either. High levels of Silica are found in a few
ground water supplies.
Aqua-Rex will reduce scale in a lter so the sand is free to
act more effectively and may require less backwashing. It
will help chlorine or other biocides to be more effective so
that the amount used can be reduced for the same effect.
PHOSPHATES
Aqua-Rex has shown to be effective at causing phosphates
to occulate and fall out of solution into the bottom of the
pool. The water will be clearer and any algae will have less
food so is less likely to cause a problem.
It may also help reduce dissolved solids by encouraging
them to precipitate into suspended solids which can then be
removed by the lter.
SALT GENERATOR
It will also help to keep the salt generator plates
clean.
LOCATION
The unit should be installed downstream of the circulation
pump and a multi cyclone lter, if tted, on a pipe that is
always full of water. If there is more than one pump serving
a separate pool or water feature then each pumped line
needs to be treated downstream of the pump. It will operate
on any type of pipe material, including corrugated and
plastic up to 2½” diameter.
It is a very simple installation but there are three basic
points that it is ESSENTIAL you follow.
1. The wires must be tight on the pipe and secured at both
ends by the plastic zip ties. Check from time to time that
they stay tight and don’t work loose with the vibration
of the pump.
2. Keep the box close to the pipe so there is the maximum
number of windings possible on the pipe. It is best to
secure the box to the pipe or just let it hang from the
aerials.
3. Install it on the discharge side of the pump. The unit is
most easily installed on a horizontal pipe but it can also
be located on a vertical pipe if required.
HOW TO INSTALL THE AQUA-REX WK1P

SECURING THE ANTENNAS
Once you have decided
where to locate the unit
you need to wrap the
antennas around the pipe.
It is normally easier to
start by putting a plastic
tyrap loosely around the
pipe. Feed the end of an
antenna wire through the
tyrap and secure it so that
there is the least amount
of antenna left between
the tyrap and the unit. The
shorter this length of antenna, the more you have available
to wrap round the pipe and the better the Aqua-Rex will
work.
It is perfectly acceptable to allow the unit to hang
below the pipe, suspended on tyraps or on its
antennas. It does not need to be attached to a wall
or hard surface.
Wind the remaining antenna around the pipe so that there
are at least 12 turns, more if possible. Secure the other end
of the antenna with another plastic tyrap. Repeat the process
with the second antenna. Start it off in the opposite direction
of the rst antenna winding as shown in the picture above.
It is important that the antennas are wrapped
around the pipe as tightly as possible. If they are
loose the process doesn’t work. Do not use tape to
secure the wires as the vibration from the owing
water will loosen the wires.
POWER SUPPLY
The Aqua-Rex requires a standard 120 volt outlet. If your
unit has a standard plug in transformer the power supply
will be 9 volts AC. Additional cable can be spliced into the
line between the transformer and its plug. If your unit has
a USB connection then extra cable can be spliced in by an
electrician or a USB extension cable can be purchased.
In both cases the connection can be protected by the
waterproof heat shrink sleeve provided. Both the
transformer and the USB power supply must be protected
from weather.
To protect the plug/socket from damp and rain, use the heat
shrink tube supplied. Slide the heat shrink sleeve over the
plug, connect it to the socket and use a hair dryer to shrink
it into place.
PLUG / TRANSFORMER UNIT
Plug in the transformer and switch on the power supply. The
LED on the unit will ash, indicating that the unit is powered
up and that the program is sequencing through the range
of frequencies.
HOW THE UNIT WORKS
Once the unit has been installed correctly on the pool
circulation system it will pass a radio signal into the water
which causes the calcium ions to precipitate in suspension in
the water instead of on the surface of the pool.
Existing scale will also be removed over a few weeks and
any staining will disappear with it. Some Silica scale may
re-appear but it should be considerably less than previously.
Silica scale that has been leached from behind the tiles will
not necessarily be reduced.
MAINTENANCE & TROUBLE SHOOTING
The Aqua-Rex needs no maintenance or servicing but do
check occasionally to see that the LED light is ashing and
that the wires are tight on the pipe. If the Aqua-Rex stops
working, check rst that the power supply to the transformer
is functioning by plugging another appliance or lamp into
the outlet and seeing if it works.
If the transformer is cold that means it has failed.
Contact us for a replacement.
If the unit still fails to work, or you are not happy
with the results, before you do anything else
contact us by email or phone.
Tel [phone]
[e-mail]
Please do not remove the unit before contacting
us. Very often the solution to the problem is very
simple to resolve over the telephone or by email.
AQUA-REX LLC
3301 SPRING MOUNTAIN RD STE 18, LAS VEGAS NV 89102
T: 1-877 640 2170 E: [email protected] www.aqua-rex.com
100 DAY MONEY BACK GUARANTEE
If, for any reason whatsoever, you are dissatised with
your Aqua-Rex product, you may return it at any time
during the rst 100 days after purchase and the purchase
price will be reimbursed in full. Simply return it to wherever
it was purchased, together with your full name and address
and proof of purchase, showing the price paid.
5 YEAR MANUFACTURER’S WARRANTY
Aqua-Rex LLC Guarantees that it will replace the WK1P
unit should it suffer from a manufacturing defect during
the rst ve years after the date of purchase. The unit
should be returned to the dealer properly boxed
and wrapped together with the invoice.
