AquaLabo Ponsel CTZN User manual

1
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
CTZN NUMERICAL SENSOR
User manual

2
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
CONTENTS
1. GENERAL..............................................................................................................3
2. CHARACTERISTICS .............................................................................................4
2.1 Technical characteristics. ............................................................................................................................... 4
2.2 CE compliance................................................................................................................................................. 5
3. DESCRIPTION.......................................................................................................6
3.1 Product overview............................................................................................................................................. 6
3.2 Applications..................................................................................................................................................... 6
3.3 Construction and dimensions......................................................................................................................... 6
3.4 Communication............................................................................................................................................... 7
3.4.1 Modbus RTU registers. .............................................................................................................................. 7
3.4.2 SDI12 frame............................................................................................................................................... 8
4. INSTALLATION. ....................................................................................................8
4.1 Sensor installation option ............................................................................................................................... 8
4.1.1 Accessories for immersion installation. ..................................................................................................... 8
4.1.2 Accessories for PVC pipe-mounting........................................................................................................ 10
4.1.3 Accessories for stainless steel pipe-mounting.......................................................................................... 11
4.3 Electrical connections. .................................................................................................................................. 12
5. STARTUP AND MAINTENANCE........................................................................13
5.1 Initial startup................................................................................................................................................. 13
5.2 Calibration..................................................................................................................................................... 13

3
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
1. General
In order to maintain and ensure the good working order of the CTZN sensor, users must comply with
the safety precautions and warnings featured in this manual.
Assembly and activation:
- Assembly, electrical connection, activation, operation and maintenance of the measuring system
must only be carried out by specialist personnel authorized by the user of the facilities.
- Trained personnel must be familiar with and comply with the instructions in this manual.
- Make sure the power supply complies with the specifications before connecting the device.
- A clearly-labeled power switch must be installed near the device.
- Check all connections before turning the power on.
- Do not attempt to use damaged equipment: it may represent a hazard and should be labeled as
faulty.
- Repairs must only be carried out by the manufacturer or by AQUALABO’s after-sales service
department.
➢Marking on the body of the sensor:
The marking on the body of the sensor indicates the serial number of the sensor (for the traceability)
and the LOGO CE.
1
Datamatrix (contains the serial number)
2
Serial number CTZN sensor : SN-PCTZX-YYYY
X : version
YYYY : number
3
CE mark
1
2
3

4
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
2. Characteristics
2.1 Technical characteristics.
The technical characteristics can be modified without advance notice.
Measures
Measure principle
Inductive conductivity sensor regulated in temperature
Measure ranges conductivity
0,0 –100,0 mS/cm
Resolution
0,1
Measure ranges salinity
5-60 g/Kg
Working temperature
0 to 50 °C
Temperature compensation
With NTC or external measure
Accuracy T°C
0.5 °C range 0-40 °C
Response time
90% of the value in less than 30 seconds
Storage temperature
-10°C à + 60°C
Maximum refreshing time
Maximum < 1 seconde
Sensor
Dimensions
Diameter max. 62,4 mm, Lenght : 196 mm
Weight
700 g
Wetted Material
Body : EPDM, PVC, Stainless steel
Cable : polyurethane jacket
Steam gland : Polyamide
Maximum pressure
5 bars
Connection
9 armoured connectors, polyurethane jacket, bare-wires or
waterproof Fisher connector
Protection
IP68
Sensor cable
Standard : 3, 7 and 15 m (other length on request).
100 m Max. Up to 100 m with junction box.
Communication –Power supply
Signal interface
Modbus RTU RS-485 and SDI-12
Power requirements
5 to 28 volts, max 30 V
Electric Consumption
Automatic Standby < 50 µA , Heating time 100 mS
Average Modbus RS485/ Range 0-100 mS/cm
Vin 5V
Vin 12 V
Vin 24 V
1 measure/s
31 mA
15,5 mA
11,5 mA
Max current pulse 700 mA during 2 mS, 350 mA during 150 mS

5
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
2.2 CE compliance.
Pursuant to the article 11 of the directive 89 / 336 / EEC relative to the electromagnetic compatibility.
We declare that the digital sensor of the range DIGISENS sensor CTZN was tested and declared in
compliance with the European standards :
Standard tests : EN 61326-1 edition 2013
Emission - EMC EN 55022 Class B
Immunity - EN 61000-4-3 A
EN 61000-4-2 B
EN 61000-4-6 A
EN 61000-4-4 B
Shone disturbances : EN 55011B
Identification of the measurement process : composed of :
1- one probe
2- Ponsel’s cable.
EN 61000-4-5 Not concerned for sensors with a cable lower or equal to 30 M
Commercial name : DIGISENS range
Manufacturer:
AQUALABO
90 Rue du professeur P. Milliez
94506 CHAMPIGNY-SUR-MARNE
Responsible UE :
AQUALABO
90 Rue du professeur P. Milliez
94506 CHAMPIGNY-SUR-MARNE

6
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
3. Description.
3.1 Product overview
Inductive method :
A ring-type coil is excited at fixed intervals and the response is retrieved on a second coil, which is
linked to the excited coil. The connectivity between the coils (determined by the degree of conductivity)
takes place via the conducting solution.
Economic and successful technology that requiring not enough maintenance and not consumable.
The CTZN sensor offers the following advantages:
• Low operating costs due to reduced maintenance work (no electrolyte changes)
• Greater calibration intervals due to low drift behaviour
• No polarization voltage required • High measuring accuracy, even for low concentrations • Rapid
response times
The sensor features excellent interference immunity thanks to the integrated preamplifier and digital
signal processing. The measured value for conductivity is automatically compensated with the
temperature and transferred without interference to the connected display unit and controller via a
digital interface. The sensor also includes a log book containing the last ten successful calibrations in
the form of a ring buffer.
3.2 Applications
The compact and robust sensor is particularly well suited to the following typical areas of application:
•Urban wastewater treatment
•Industrial effluent treatment
•Surface water monitoring
•Sea water
•Fish farming
3.3 Construction and dimensions.
(1) NTC Temperature sensor
(2) EPDM Head of body
(3) PVC Sensor body with measurement electronics
(4) Cable bushing
(5) Securely connected connection cable
1
2
3
4
5

7
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
3.4 Communication.
3.4.1 Modbus RTU registers.
The link protocol must correspond to MODBUS RTU.
See document: -Modbus_over_serial_line_V1_02.pdf
-Modbus_Application_Protocol_V1_1a.pdf
-Modbus memory for PONSEL digital Sensors :
SENSOR_TramesCom_xxx_UK.xls
The Modbus memory plane is identical for each parameter of the Sensors.
The Modbus protocol for the Sensors allows you to measure the parameter (+ temperature) of the
Sensor and to calibrate the parameter (+ temperature). Furthermore, there are certain numbers of
functions such as: -Select the averaging value
-Read the Sensor description
-Return to default coefficients
-Modify the Sensor address
-Information on measures conducted (Out Of Specification
measures, measures in progress, etc.).
-Date and name of the operator who performed the calibration
-etc.
To have more information on the open PONSEL’s Modbus protocol please consult the last version of
the following documents :
- the pdf file : Modbus_SpecificationsVxxx-EN
- the excel file : Digital sensor Frame_XXX_UK
Dimensions –Version immersion /Inpipe PVC
installation
Dimensions –Version Inpipe Stainless steel
installation

8
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
3.4.2 SDI12 frame.
A list of SDI12 registers is available for network communication.
Please ask to our hotline service the documentation on SDI12 communication.
4. Installation.
4.1 Sensor installation option
For the installation of the sensors in condition of immersion or in-pipe insertion, we advise to use
accessories adapted and proposed by AQUALABO.
4.1.1 Accessories for immersion installation.
In immersion condition, it is necessary to maintain the sensor by the body and not to leave the sensor
suspended by the cable at the risk of damaging the sensor.
AQUALABO proposes a range or pole (long version) in order to install the sensor in open basins. It
can be positioned a considerable distance from the basin edge with the bracket suspended for
example.
Please note the following when planning your set-up:
• The fitting must be easily accessible to allow the sensor or the fitting itself to be maintained
and cleaned regularly
• Do not allow the fitting (and thus also the sensor) to swing against and hit the basin edge
• When working with systems involving pressure and/or temperature, ensure that the fitting
and sensor meet all relevant requirements
• The system designer must check that the materials in the fitting and sensor are suitable for
the measurement (chemical compatibility, for instance)
Material
PVC
Admissible temperature
0 to 60 °C
Pressure max.
5 bars

9
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
➢Long pole
The long poles are available in elbow version, for installations in aeration basin, and straight, for
applications in open channel. Every pole is equipped with an elbowed shutter and with waterproofness
joints. The lower part includes a nozzle which is adapted to the sensor what assures its mechanical
support.
➢Mounting accessories for pole.
The elements of fixation for the poles are flexible and specially studied to adapt themselves to the
different configurations of assembly.
- Elbowed pole with elbowed shutter
PF-ACC-C-00109
90° ELBOW LONG POLE FOR
CTZN SENSOR (2955 mm,
ELBOWED SHUTTER)
- Straight long pole with elbowed shutter
PF-ACC-C-00115
STRAIGHT LONG POLE FOR
CTZN SENSOR (2745 mm,
ELBOWED SHUTTER)
Elbowed
shutter
Vertical
axis
Connection
vertical pole/
horizontal axis
Connection
horizontal axis/
Pole
Horizontal
axis
- Pole kit fixation
NC-ACC-C-00009
POLE FIXATION KIT FOR
NUMERICAL SENSOR
(ON LOW WALL)
NC-ACC-C-00010
POLE FIXATION KIT FOR
NUMERICAL SENSOR
(ON LIFE LINE)
NC-ACC-C-00011
POLE FIXATION KIT FOR
NUMERICAL SENSOR
(ON VERTICAL AXIS)
PF-ACC-C-00272
VERTICAL AXIS FOR
NUMERICAL SENSOR POLE
(TO BE FIXED ON SOIL)

10
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
4.1.2 Accessories for PVC pipe-mounting.
Every system of assembly is delivered with an adapter (and the appropriate joints) and one T of
assembly (90 ° for CTZN sensor) to stick on a 90 mm diameter pipe. Its special design type ensures
the correct inflow to the sensor, thus preventing incorrect measurements.
Please note the following when planning your piping set-up:
• The fitting must be easily accessible to allow the sensor or the fitting itself to be maintained
and cleaned regularly
• We recommend bypass measurements. It must be possible to remove the sensor through
the use of shut-off valves
• When working with systems involving pressure and/or temperature, ensure that the fitting
and sensor meet all relevant requirements
• The system designer must check that the materials in the fitting and sensor are suitable for
the measurement (chemical compatibility, for instance)
Mounting system for CTZN sensor (PF-ACC-M-00001)
1 Unscrew the union nut (2) from the PVC flow fitting (3).
2 Guide the sensor cable through the union nut on the fitting.
3 Insert the sensor (1) into the fitting as far as the position shown in the middle image above.
4 Screw the union nut onto the fitting as far as the stop.
1
3
4
CTZN sensor
Union nut
Adapter
90 mm pipe diameter
2

11
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
4.1.3 Accessories for stainless steel pipe-mounting.
The accessories of assembly for stainless pipe are proposed with an adapter and its joints with or
without the systems of clamp / Nipple. The acceptable maximum pressure for the sensors is 5 bars.
The system of assembly can be delivered with or without stainless steel clamp.
The adapter is compatible with a 90 mm diameter external clamp.
Mounting system for CTZN sensor (PF-ACC-C-00350)
1 After welding the clamp (3) on the stainless steel pipe, remove the clamp from the system and
remove the PVC adapter (1).
2 Guide the sensor cable through the union nut on the adapter.
3 Reposition the adapter in the nipple (4).
1
2
3
4
(1) adapter
(2) CTZN sensor
(3) Clamp
(4) Nipple to weld

12
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
4.3 Electrical connections.
The sensor could deliver within version bare wire on 3, 7, 15 m or on other length (up to 100 m).
Power supply
Power requirements
5 to 12 volts for cable 0-15 m
7 to 12 volts for cable >15 m
Max. 13.2 V
Consumption
Standby 25 µA
Average RS485 (1 measure/ seconde) : 6,3 mA
Average SDI12 (1 measure/ seconde) : 9,2 mA
Current pulse : 500 mA
Protection against the inversions of polarity
Wiring diagram
Cable length up to 15m
1- Red
Power supply V+
2 - Blue
SDI-12
3 - Black
Power supply V-
4 - Green
B " RS-485 "
5 - White
A " RS-485 "
6 –
Green/yellow
Cable shield with
Power supply V-
Cable lenght 15 to 100 meters
Red
Purple
Yellow
Orange
pink
Power supply
V+
2 - Blue
SDI-12
3 - Black
Power supply
V-
4 - Green
B " RS-485 "
5 - White
A " RS-485 "
6 –
Green/yellow
Cable shield
with Power
supply V-

13
Version 1.0
Update: August 2018
AQUALABO
90 Rue du professeur P. Milliez
94506 Champigny-sur-Marne, FRANCE
Tel.: [phone]
5. Startup and maintenance.
5.1 Initial startup
Once the sensor is connected to your terminal, the sensor is settled in its accessory of assembly and
the parameterization has been carried out on the display unit, the sensor is ready for initial startup.
➢Note :
During the introduction of the sensor in measurement environment, wait for sensor’s temperature
stabilization before measure processing.
➢Started :
5.2 Calibration
The calibration of the conductivity sensor is a 2-step process:
- Step 1 (offset): Expose the sensor to the air to perform the first stage of the Calibration process. The
value for this first calibration standard is set to 0 0 μS/cm.
- Step 2 (gain): the sensor is placed in a buffer solution of known conductivity 12,88 mS/cm. Let
stabilize during 5 minutes.
5.3 Maintenance:
The sensor not being sensitive to the fouling, there is no particular maintenance to be planned.
However, assure hthat the central part of the sensor is not blocked.
AQUALABO Hotline
115 Rue Michel MARION
56850 CAUDAN
FRANCE
Tel.: [phone]
Email: [e-mail]
