Aquapure CS Series User manual

At a Glance:
• Luxury water at an affordable price
• Proprietary brass water softening valve with motorized piston
helps provide reliable and durable performance
• Compliant to California AB1953
Applications:
• Hard Water
• Moderate Soluable Metals
• Semi-transparentfiberglassmediatankallowsformedialevelcheckwithoutdisas-
sembly.
Product Benefits:
• Extremely easy to set proprietary brass water softening valve
• Full 3/4” porting with 1” bypass for superior water flow characteristics
• Cycle programmability to meet your exact water quality conditions
• Uses as little as 30 gallons of water during regeneration
• Semi-transparent fiberglass threaded media tank allows for media level check
without disassembly.
• Superior performance brine tank with salt shelf that provides virtually
trouble-free operation
• CSM Series denotes metered initiated models that help to save salt and water by
regenerating only when needed, based on total gallon flow versus time.
Models:
CS1001/CS1501/CS2001/
CSM1001/CSM1501/CSM2001
Water Softeners
Product Dimensions:
Model No.
Media Tank Brine Tank Minimum Space Requirements
D x H W x D x H Width Height Depth
ABC
CS1001/CSM1001 8” x 44”
(21 cm x 112 cm)
15” x 15” x 34”
(38 cm x 38 cm x 87 cm)
33”
(84 cm)
53”
(135 cm)
15”
(38 cm)
CS1501/CSM1501 10” x 44”
(26 cm x 112 cm)
15” x 1 5” x 34”
(38 cm x 38 cm x 87 cm)
35”
(89 cm)
53”
(135 cm)
15”
(38 cm)
CS2001/CSM2001 10” x 54”
(26 cm x 137.2 cm)
15” x 15” x 34”
(38 cm x 38 cm x 87 cm)
35”
(89 cm)
63”
(160 cm)
15”
(38 cm)
Spec #
Quantity
CS/CSM Series

Specifications:
Category
Model
CS1001/CSM1001 CS1501/CSM1501 CS2001/CSM2001
Media
cu ft (cu m) 1.0 (0.03) 1.5 (0.04) 2.0 (0.06)
Salt
Dosage*
lbs. (kg)
4.0 (1.8)
6.0 (2.7)
15.0 (6.8)
6.0 (2.7)
9.0 (4.1)
24.0 (10.9)
8.0 (3.6)
12.0 (5.4)
24.0 (10.9)
Softening
Capacity**
(grains)
16,300
18,600
30,000
24,150
27,900
45,000
34,100
37,200
54,000
Flow Rates:
Service
Backwash
7.5
1.5
9.0
2.4
9.0
2.4
* Salt Dosage: Top row indicates salt efficient setting, second row indicates factory setting and
third row indicates maximum setting with the supplied brine tank.
** Softening Capacity: Top row indicates salt efficient setting, second row indicates factory salt
setting and third row indicates maximum salt setting with the supplied brine tank.
NOTE: Certified NSF/ANSI Standard 372 compliant to California AB1953.
Maximum Operating Temperature: 110°F (43.3°C), Electrical Requirements: 110/120V, 60Hz
Operating Pressure: 20 - 125 psi (138 - 862 kPa) Pipe Size: 1” NPT
WARNING To reduce the risk associated with the ingestion of contaminants:
Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after the system.
CAUTION
To reduce the risk associated with property damage due to water leakage:
• Read and follow Use Instructions before installation and use of this system.
3M Purification Inc. recommends regularly scheduled maintenance in order for the
product to perform as advertised.
Spec #
Quantity
Model Number
Part Number
3M Purification Inc.
400 Research Parkway
Meriden, CT 06450 U.S.A.
Toll Free: 1.800.222.7880
Worldwide: 203.237.5541
Fax: [phone]
www.aquapure.com • www.3Mpurification.com
3M is a trademark of 3M Company.
Aqua-Pure is a trademark of 3M Company used under license.
All other trademarks are the property of their respective owners.
© 2012 3M Company. All rights reserved.
70-0202-7532-0 REV 0312
Distributed by:
CAUTION: These diagrams shown are for reference
purposes only. Read installation and operation manual
prior to installing the unit.
WELL INSTALLATION
PUBLIC WATER SUPPLY INSTALLATION
Typical Installation:
WATER
SOFTENER
BACKWASH
FILTER
SOFT WATER
TANK
SWITCH
PRESSURE
PRESSURE
TREATED WATER
TREATED
WELL
WATER
RAW
CHECK VALVE
BRINE
TANK
WASTE DRAIN WASTE DRAIN
WATER
RAW
METER
HIGH DEMAND
OR OTHER
LAWN SPRINKLERS
WATER FOR
BRINE
TANK
WASTE DRAIN WASTE DRAIN
WATER
SOFTENER
BACKWASH
FILTER
SOFT WATER
TREATED WATER
TREATED
Limited Warranty:
3M Purification Inc. warrants this Product to be free from defects in material and workmanship during normal use for the warranty period set forth below. The warranty period commences from the
date of purchase. This warranty does not cover failures resulting from abuse, misuse, alteration or damage not caused by 3M Purification Inc. or failure to follow installaation and use instructions.
No warranty is given as to the service life of any filter cartridge, membrane, or media as it will vary with local water conditions and water consumption. 3M PURIFICATION INC.MAKES NO OTHER
WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICU-
LAR PURPOSE OR ANY IMPLIED WARRANTY OR CONDITION ARISING OUT OF A COURSE OF DEALING, CUSTOMER OR USAGE OF TRADE. If the Product is found defective within the warranty
period, your exclusive remedy and 3M Purification Inc.’s sole obligation shall be, at 3M Purification Inc.’s option, to replace or repair the Product or refund the purchase price of the Product. This
warranty does not cover labor. The remedy stated in this paragraph is Customer’s sole remedy and 3M Purification Inc.’s exclusive obligation.
Warranty Period:
• One (1) year on the entire product unit
• Five (5) years on the media tank only (does not include internal component parts)
• Five (5) years on the control valve
• Five (5) years on salt storage container and components*
Limitation of Liability: 3M Purification Inc. will not be liable for any loss or damage arising from this 3M Purification Inc. product, whether direct, indirect, special, incidental, or consequential,
regardless of the legal theory asserted, including warranty, contract, negligence or strict liability. Some states and countries do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
*water softeners only
