AQUASYSTEM APPQO600 -i User manual

Ver0.2
AIR VACUUM CLEANER for Open Pail can
Instruction Manual
■ APPQO600 -i
■ APPQO600S -i
1・・・・・・・・・・・・・ For Safety
1 ～ 3・・・・・・・・ Before use
4・・・・・・・・・・・・・ Use conditions/How to use/Attention
5・・・・・・・・・・・・・ Trouble shooting
6・・・・・・・・・・・・・ Maintenance/Specifications
7 ～ 8・・・・・・・・ External dimensions
9・・・・・・・・・・・・・ Assurance/After service
APPQO600-i APPQO600S-i

1
Caution
Danger
Waring
Danger
For Safety
 This manual contains safety and operating instructions, which will help
you to use the device correctly and safely. Please read it carefully before
using the device. Using the device in a wrong way may cause malfunction
of the equipment and human injuries.
 Keep this manual in safe place, as you may need it in the future.
Refer to it whenever necessary.
Before use
★Check the instruction manual of the liquid you are using
and use it correctly.
For the liquid to be used, read the instruction manual of the
liquid carefully and use it correctly.
★Take appropriate measures when contacting the liquid used.
If you are exposed to liquid (accidentally swallowed, touched
skin, etc.), follow the instruction manual of the liquid and take
appropriate measures or consult a doctor.
★Operate in a fire-free area
Please refrain from using it in liquids and places where there
is a risk of explosion, as there is a risk of ignition due to static
electricity.
Indicates the content that may result in death or
serious injury if mishandled.
Indicates the contents that may cause injury or
property damage if handled improperly.
Indicates a risk of death or serious injury if handled
improperly.

2
Waring
★Operate in a safe place.
Do not touch it with infants and children. Use in a place
where safety can be ensured.
Do not leave the cleaner while driving.
★Seek medical attention.
If you feel unwell during use, seek medical advice
immediately.
★Wear protective clothing.
Please wear protective clothing according to the liquid
instruction manual.
★Never disassemble, repair or modify.
Under normal circumstances, no one other than a repair
technician should disassemble, repair, or modify the
product. It is not covered by the warranty.
････････････････････････････････････････････････････････････････････････････････････
････････････････････････････････････････････････････････････････････････････････････
････････････････････････････････････････････････････････････････････････････････････
････････････････････････････････････････････････････････････････････････････････････
････････････････････････････････････････････････････････････････････････････････････
★Use new liquid.
When replacing liquids, wipe old liquid completely and wash
it before treating new liquid. Mixing liquids may cause
chemical reaction.
････････････････････････････････････････････････････････････････････････････････････
★Liquid temperature
The usable liquid temperature is 0 to 60 °C.
････････････････････････････････････････････････････････････････････････････････････

3
････････････････････････････････････････････････････････････････････････････････････
★Request for inspection and repair.
In case the product accidentally stops its operation, or
anything abnormal is found, immediately stop the operation,
and contact sales shops or service shops to inspect and/or
repair. If such a product is continuously operated, it may
cause any kind of accident or injuries.
････････････････････････････････････････････････････････････････････････････････
★Do not give a shock to products.
It may not operate normally, or cause malfunction or liquid
leakage.
･･････････････････････････････････････････････････････････････････････････････
★Drain liquid inside the cleaner after use.
Residual liquid may cause rust preventing enough
performance.
★Remove the moisture in the compressed air.
When treat the liquid that hate moisture, remove with a filter.
(Optional item)
★When the handling person is changed, attach this manual to
the product.
★If this manual is lost, ask for with us or your dealer.
★Those who sell or install our products, ensure to pass this
manual to the person in actual use.
★Use a compressor with more than 5 HP. (0.4-0.6MPa)
★When a tank is almost full, the liquid mixing with the
discharge air blow out from an exhaust port.
★Use an air hose with size of more than 3/8.
If the hose is thinner, the pressure will drop.
Caution

4
Use conditions
1. Used for JIS standard 20L open pail cans.
2. Compressor：5HP（3.75KW）
3. Supply air pressure：0.4～0.6MPa.
4. Acceptable viscosity：Under 3,000cP.
How to use
① Place the cleaner on a pail can so that the edge of the pail can fits
perfectly in the groove of rubber packing on the back of cleaner.
② Connect the air hose with the air valve closed.
③ When the air valve is opened, start to suck liquid / powder from the
tip nozzle.
④ In case of liquid collection, inhalation will stop automatically when
the can is full (about 17L).（*Except to S type model）
⑤ Close the air valve after use.
⑥ Remove the air hose.
⑦ Remove the cleaner from pail can.
*Necessary to use filter for powder inhalation.
【Attention】
① S type model does not include an oil stopper.
The inhalation does not stop even if the can is full. Please watch out
the volume of inside pail can. If you continue inhaling when the can
is full, the liquid will spurt out as mist from the ejector. If you need
the automatic stop function, purchase and install the optional oil
stopper.
② For powder inhalation, attach a filter surely. If the filter is not
attached, the sucked powder may spurt out from the ejector.
(Excluding S type model)In addition, the acoustic material of the
silencer may get wet or clogged, and leads to power depression.
③ Supply air pressure
Under 0.4MPa, the suction power is weak and it may not perform well.
Over 0.6MPa, the pail may be crushed.
Ensure to use with proper range of supply air pressure.

5
If the below Case Happens …
1. Do not inhale
● Is a compressor working?
● Is an air hose firmly connected?
● Is an air valve opened?
● Is a pail can deformed or crushed?
● Is a pail can full with collected materials/liquid?
● Is a filter clogged?
2. Low inhalation
● Is an air hose specified size? (More than 3/8)
● Is the air pressure low? (0.4-0.6Mpa)
● Is air leaking from the can?
(The cleaner should fit on a pail can perfectly. Are there any scratches
or dents on the pail?)
● Is the hose or suction port clogged with collected material?
● Is the air valve fully open?
● Is the hose or nozzle damaged?
● Is the viscosity of the liquid too high?
● Is the acoustic material of the silencer clogged?
● Is air leaking from swivel?
● Is the compressor HP sufficient? (3.75KW)
For other problems, please contact our service center, or sales shop sold
the product without disassembling it.

6
Maintenance
For the Filter
1. Remove the S-shaped spring band and the filter. (Be careful not
to cut your hands) We recommend to clean by air blow, detergent should
be done depending on the degree of dirt.
2. The suction power is affected by clogging of the filter.
For the Acoustic Material
1. Remove the four tapping screws and silencer. We recommend cleaning
by air blow should be done depending on the degree of dirt.
2. The suction power is affected by clogging of the acoustic material.
Specifications
Model Salvaged
material
Acceptable
Viscosity
(ｃＰ)
Air
Consumption
(L/min)
Sucking
Volume
(L/min)
Pump
Head
(m)
Material Noise
(dB)
Body
Nozzle
Packing Hose
APPQO600-i
APPQO600S-i
Oil, Cutting oil,
Garbage,
Chips(Over100
μ/Under1ｃｍ）
3,000 475 90 2 AL NBR PVC 85

7
External Dimensions
APPQO600 -i

8
APPQO600S -i

9
Assurance・After Service
Thank you for choosing our product. Our product is produced strictly under
our regulations and quality control. However, if any of the Defects, related
with our production processes, is found, our assurance Covers, according to
the below limitation.
1. To repair
To order the parts or request for repair, prepare to inform us Part No., Serial No., the
purchased date with the receipt and then contact the purchased shop.
2. Within 6 months after the purchased date, if the below case* happens, we will repair
it at free of charge.
Despite of regular maintenance and/or inspection specified in manual, if the trouble
or damage happens due to the defect of our design or assembling, within warranty
period.
* However, we are not responsible for all and any expenses or other damages related
with the above trouble and/or damage due to the defect of the product.
* When the free repair is taken care, if the part replacement is judged necessary by
us, as the consumables, the expenses for such replaced parts shall be borne by the
user.
3. If the assurance period of 6 months is over, or the above assurance condition does not
meet even within the assurance period of 6 months, the repairing expenses shall not
be covered by us, but borne by the user.
4. In any case, delivery cost both to us and from us shall be borne by the user/customers.
5. Exemption range (even within the warranty period, you will be charged if the
following applies)
①Failure caused by incorrect handling (use in different from the instruction manual).
②Failure due to repair, disassembly, or modification outside of our company.
③Failure due to improper storage / maintenance.
④No document certifying the date of purchase (delivery note, invoice, etc.)
⑤Parts which is worn out by used frequently.
For any questions or request about after-sales service of repairs during the warranty
period, please contact the below, our distributors or our agents.
《Customer Service》
AQUASYSTEM Co., Ltd.
1190 SUGOSHI-CHO, HIKONE-SHI,
SHIGA, 522-0058, JAPAN
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
