Aquatic Adventures Aqua-Cycle AC6 Quick guide

Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 12 For assistance contact us at 800-970-2688
Aquatic Adventures International, Inc.
5348 Vegas Dr.
Las Vegas NV 89108
800-970-2688 Toll Free
(888-970-0467 Fax)
www.aquatic-adventures.com
Email: [e-mail]
Made in the U.S.A.
Rev 6/18/2014
Send us some photos and interesting experiences
of you with your Aqua-Cycle Water Trike. With
your permission, we will add them to our website.
Send to [e-mail]
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 1For assistance contact us at 800-970-2688
ASSEMBLY INSTRUCTIONS
This section will guide you through the assembly process. The second half of this
booklet covers maintenance to keep your Aqua-Cycle Water Trike in tiptop shape.
Please read all assembly instructions before you begin.
NEED HELP? Give us a call. It is better to get your questions answered rather
than hope what you are doing is correct. Your Aqua-Cycle Water Trike will last for
many years if assembled correctly.
These instructions are in the order that works best for quick assembly. Complete
each step before going to the next. As you start each new step re-read all the in-
structions for that section before proceeding.
If you have several Aqua-Cycle Water Trikes to assemble, do them one at a time. It
is much better to assemble and check out each one before proceeding to the next
one. Assembly line work does not give the best results nor is it any faster.
ECO-FRIENDLY—We do not market recreation products that have been chemically
“brightened”. Our manufacturing processes meet the three-fold criteria of biodegradability,
zero (net) environmental impact and full scope reuse/renewability. We have long been con-
cerned with protecting both our customers and the ecosystems in which customers enjoy our
products. This policy is based upon our continuing commitment to responsible, earth friend-
ly business practices.
NOTES AND CAUTIONS
SAFETY—Never allow an Aqua-Cycle Water Trike to be operated without the
fork guard and belt guard properly installed for the protection and safety of your
users.
ANTI-SEIZE COMPOUND—Included with the assembly parts is a small quantity
of anti-seize compound. Put a small dab along the full length of the thread before
screwing on the nut. As the nut is turned the compound will be spread around the
thread to keep the nut from seizing up (galling) on the bolt. Galling is a common
problem with stainless steel lock nuts and bolts unless anti-seize compound is used.
If the nut and bolt seize up there is no way to separate them. Cutting, grinding or
twisting the bolt apart is the only solution. It is very important to use this com-
pound.
REAR WHEELS—Do not over-tighten the nuts and bolts when mounting the rear
wheels onto the axle. Follow the directions carefully. Tightening the wheel bolts
and nuts is not like tightening the lug nuts on a car wheel—do not over-tighten.
FRONT WHEEL—Carefully tighten the hex nuts against the front wheel bushings
on the front axle. Do not force the bushings into the center tube by over-tightening.
PEDAL SCREWS—Do not over-tighten the pedal screws. Forcing the pedal

Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 2 For assistance contact us at 800-970-2688
screws tight on new pedals can create stress in the plastic and shorten their life.
NOTES ABOUT FUTURE MAINTENANCE
Aqua-Cycle Water Trikes are extremely rugged and will last for many years, but
periodic maintenance is necessary. Aqua-Cycle maintenance tips are located in the
second half of this booklet. If you have any questions concerning the care and
maintenance of your Aqua-Cycle, please call our office.
Your Aqua-Cycle bearings should be replaced every 200 hours of use. Keep a
spare Bearing Replacement Kit on hand for each Aqua-Cycle. Proper replacement
of the bearings will help you avoid expensive repairs.
Using the bearings beyond 200 hours, due to wear on the bearings, causes
stress damage to the rear axle and pedal crank. The stress damage accumulates
with every rotation and will eventually result in a broken rear axle and/or pedal
crank. Changing the bearings will stop the stress damage, but will not undo the
damage done as a result of not replacing the bearings as recommended.
CHECK LIST OF UNASSEMBLED PARTS
(per Aqua-Cycle)
Rec'd Per AC Description
_____ 1Front wheel (matching color)
_____ 2Rear wheels (matching color)
_____ 2Rear Wheel hubs with cogs (stubs)
_____ 2Rear Wheel hubs without cogs
_____ 1Seat
_____ 1Frame (preassembled with belt guard, pedal crank and rear axle)
_____ 1Fork guard with 2 top and 2 bottom pieces, 12 screws and
washers
_____ 1Fork with fork pin, 2 bolts and nuts, 4 washers, 2 fork bushings,
and front axle (shipped attached to the Aqua-Cycle frame)
_____ 1Front axle, two lock nuts, two hex nuts, and two bushings
(preassembled on Aqua-Cycle fork)
_____ 10 Pedal halves and 20 screws (includes 1 spare pedal and screws)
_____ 9½" x 4" wheel bolts (includes 1 spare wheel bolt)
_____ 9½" lock nuts (includes 1 spare lock nut)
_____ 9½" flat washers (includes 1 spare flat washer)
_____ 5Seat straps (includes 1 spare seat strap)
_____ 1Anti-seize compound
_____ 7Wheel plugs (2 per wheel plus 1 spare)
Spare parts are included above in case you need them during assembly. Plan ahead
by keeping on hand a spare set of all bearings, wheel plugs, seat straps, folk bush-
ings and a belt for each Aqua-Cycle. So you can make repairs when needed.
TOOLS TO HAVE READY DURING ASSEMBLY
You do not need many tools to assemble an Aqua-Cycle, but having the right tools
will make the process much easier and assembly faster. If repairs are necessary,
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 11For assistance contact us at 800-970-2688
SAFETY INFORMATION PLATE
A Safety Information plate is attached to the center tube of the frame in a position
for each rider to see. Be sure each Aqua-Cycle Water Trike has a Safety Infor-
mation Plate attached to the frame center tube about 9” down from the neck and
that it is readable. Contact our office if you need a new safety information plate.
CAUTION PLATE
The red CAUTION plate at the back of the Aqua-Cycle frame is a reminder that
safety information should be shared with the riders, that the bearings should be re-
placed as recommended and that the Aqua-Cycle Water Trike should not be operat-
ed without the fork guard and belt guard properly installed. Be sure the CAUTION
plate is attached and readable. Contact our office if you need a new CAUTION
plate.
FORK GUARD
The fork guard covers the turning mechanism of the Aqua-Cycle Water Trike. It
protects against hands and fingers getting into the turning mechanism where they
can be severely injured.
Never allow an Aqua-Cycle Water Trike to be used without the fork guard
properly installed.
BELT GUARD
The belt guard covers the pedal crank gear, axle gear and belt drive system. It pro-
tects against stray fingers and toes getting into that area.
Never allow the Aqua-Cycle Water Trike to be used without the belt guard
properly installed.
Have a wonderful time with your Aqua-Cycle Water Trike.

Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 10 For assistance contact us at 800-970-2688
squeezes and crushes the wheel center area. The nuts should be snug, but not tight.
After the rear wheel is reinstalled on the axle, let the new caulking dry and cure for
at least 24 hours before putting the Aqua-Cycle in the water.
WHEEL PLUGS
Be sure each wheel has wheel plugs and that they are tight in the wheels. A loose
plug will allow the wheel to take on water. Clear GE Silicone II caulking can be
put on a loose wheel plug to seal it.
If you need a temporary replacement for a wheel plug, use a standard 3/4” PVC,
galvanized or brass pipe plug (3/4” NPT) available from a hardware store.
BELT
Look for strands or fibers coming from the sides of the belt. Cut these off with a
sharp knife. If not trimmed, they can snag on the gears and be stripped out of the
belt, ruining it.
BELT TENSION
If a clicking or snapping sound is heard when the Aqua-Cycle is pedaled, most like-
ly the bearings have not been replaced recently or the frame has been bent or twist-
ed. First replace all bearings with new ones to correct the problem.
If the problem still exists remove the rear bearings and re-drill the bearing mount
holes to adjust the rear bearings farther away from the pedal crank bearings.
We have a belt tensioner kit that can be installed if no other solution works, to keep
the belt the proper tension during pedaling. However, the belt tensioner kit is not a
an alternative for replacing the pedal crank and rear axle bearings. The belt ten-
sioner kit should be used as a last resort and does not solve all problems.
PEDALS
Check that all screws are tight and none are missing. Look for weathering and
cracks in the pedals. Cracks indicate that the pedal will soon break. Replace bro-
ken, weathered or cracked pedals before the season begins for the comfort and safe-
ty of your riders..
SEAT STRAPS
Check that the seat straps are tight and that they do not show signs of weathering
and cracking, which is an indication that they will soon break. Refer to the Assem-
bly Instructions for how to replace the seat straps in the rear legs.
FRONT AND REAR BEARING BRACKETS
Inspect the welds. Look for small cracks in the welds which could allow a bearing
bracket to break loose from the frame.
TAR ON WHEELS
When you see tar or oil on a wheel, get it off quickly. Tar and oil will penetrate
into the wheel. The longer it is left on the wheel, the deeper will be the stain left
behind. Use gasoline or Bug and Tar Remover (sold in automotive stores) to re-
move the tar.
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 3For assistance contact us at 800-970-2688
these same tools will be used for repair and maintenance. Good quality tools will
make assembly easier.
1Hammer—most any type will be fine
1 Philips head #2 screwdriver
1 10" Vise Grips—square jaw
11/2" Drive socket wrench—preferred 15” or longer handle
11/2” Drive extension rod 8” to 12” long
11/2” Drive x 1/2” socket six point
11/2” Drive x 3/4" DEEP socket six point
11/2” Open end wrench
13/4” Open end wrench
1 Can of WD-40 or silicone spray lubricant
PREPARATION OF TOOLS AND PARTS
Locate the seat box that matches the serial number of the frame you are about to
assemble. Unpack from the seat box the seat, black wheel hubs, white plastic fork
guard, assembly parts box and spare parts box. The assembly parts box contains all
of the needed bolts, nuts, washers, screws, pedals, fork guard screws and seat
straps. You should not need the spare parts at this time. Next remove the fork from
the frame. Keep the white plastic fork guard and parts in the plastic bag for now.
Note how the front axle is installed on the fork. That is how you will reassemble it
into the front wheel. Now remove the axle from the fork, but leave the parts on the
axle.
Check that the tools listed are close by. The 1/2” Drive socket wrench, 1/2” socket
and 1/2” open end wrench are used for the fork assembly. The 1/2” Drive socket
wrench, socket extension, 3/4" socket, 3/4” open end wrench and Vise Grips are for
the rear and front wheel assembly. The Philips screwdriver is for assembly of the
white plastic fork guard and pedals. The hammer is just in case you need it.
LET'S GET STARTED WITH ASSEMBLY
To begin assembly, place the frame right side up as it will be when assembled. In
this position the frame will be resting on the black belt guard and aluminum steps,
with the neck pointing up.
SEAT ATTACHMENT
The seat is held in place by four nylon straps inserted through holes in the seat legs
and tightened around the frame.
Attach the rear legs first. The rear legs of the seat allow for two positions. We will
use the seat’s forward-most position (the back notch on the rear legs). Note that
there is a hole in the front of the rear seat leg, one in the back of the leg, and one on
each side of the middle ridge (we will call them front-middle and back-middle).
Ignore the holes directly above where the seat would set on the frame because you
will only use the back and front-middle holes.
Place the seat on the frame in the forward-most position and push a strap into the

Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 4 For assistance contact us at 800-970-2688
front-middle hole toward the back. Take a second strap, push it through the back
hole and aim it to hit and slide under the first strap. The first strap should guide the
second strap out of the front-middle hole. Now remove the first strap and leave the
second strap in place, but unattached for the moment. Repeat this process for the
other rear seat leg.
For each front seat leg, push a strap into the outside hole and through the inside
hole.
Once all four straps are through the proper holes bring each of them around the
frame and through the strap buckles. Tighten and double the excess back through
the loop buckle. Looping the excess part of the strap through the buckle adds addi-
tional strength to the locking mechanism.
Last, push the loose end of each strap into the nearest seat leg hole to keep it out of
the way.
FORK ASSEMBLY
Before removing the fork pin from the fork, mark the bottom of the pin with an
arrow pointing toward the front of the fork. This will help you get the pin back into
proper position so the bolt holes will match up. Remove the two bolts, fork pin,
and fork bushings from the fork.
Insert the two plastic bushings into the frame neck tube. You may need to use a
rubber mallet or hammer to gently tap them all the way into the tube.
Place the fork onto the neck tube. Slide the fork pin (with the arrow on the bottom)
into the top of the fork, and through the upper fork bushing, neck tube, lower bush-
ing and fork lower hole. Be sure that the arrow you put on the bottom of the fork
pin is pointing to the front of the fork.
Match up the bolt holes in the fork pin with those in the fork. Re-install the two
bolts, nuts and washers (one washer at the bolt head and one at the nut) to hold the
fork pin in place, and tighten.
FORK GUARD
For each Aqua-Cycle Water Trike there is a fork guard in a plastic bag which has
been uniquely fitted to it. The number on the bag matches the serial number on the
Aqua-Cycle (8th and 9th digits are most important). Matching the correct fork
guard to each Aqua-Cycle will make assembly easier.
The fork guard covers the turning mechanism. It is attached by Philips-head screws
and washers. The holes are predrilled. Wrap the guard (barrel) around the fork
with the wings snug to the frame. Install two screws with washers to secure the
wings. Install two screws into the top gussets (neck tube support brackets).
Match the numbers on the top and bottom covers to the numbers on the fork (1-2, 3
-4, 5-6 and 7-8). Install each with the screws and washers where pre-drilled.
Never allow the Aqua-Cycle to be used without the fork guard installed.
REAR WHEEL ASSEMBLY AND HUBS
With the seat and fork attached, flip the Aqua-Cycle frame upside down so it rests
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 9For assistance contact us at 800-970-2688
FRONT WHEEL
Inspect the front wheel for cracks along the center seam. Check that the wheel
plugs are properly installed into the front wheel.
Check that the wheel is centered between the two fork legs without risk of rubbing
on the legs. If off-center, add stainless steel washers between the fork leg and the
hex nut.
FRONT WHEEL BUSHINGS
Be sure these are in good shape and have not been forced into the center tube by
overtightening.
FRONT WHEEL AXLE
Check that the hex nuts are tight against the wheel bushings and the fork legs are
tight against the hex nuts. Check that the outside lock nuts are tight against the fork
leg.
PEDAL CRANK
Inspect pedal crank the gear, bolts, nuts and washers. Be sure everything is tight
and that there is no damage to the gear. A worn or cracked gear will damage the
belt in a very short time.
Check that the pedal crank lock collars are properly installed on each end of the
pedal crank. These keep the pedal crank gear aligned with the rear axle gear, hold
it centered in the belt channel and provide extra strength to the frame.
REAR AXLE
Inspect the rear axle gear, bolts, nuts, and washers. Be sure everything is tight and
that the gear is not cracked or damaged. Even slight damage can ruin the belt in a
short time. Check that the gear plate is smooth and does not rub harshly on the side
of the belt.
Check the axle lock collars, that they are tight against the side axle bearings to keep
the axle gear in alignment with the pedal crank gear. If misaligned, the belt can be
severely damaged.
REAR WHEEL
Water getting into the rear wheels is an indication of cracks in the axle mounting
area. Remove the wheel from the rear axle, remove the wheel hubs and inspect the
center areas of the wheels. Look for hairline cracks or damage around the bolt
mounting holes.
If damage is found or suspected, clean off all sand, salt, dirt and oil, and remove
any loose plastic. Scuff and scar the surfaces on the wheel where repair is desired
and on the adjacent wheel hub surfaces. Put clear GE Silicone II Caulking around
each bolt hole, known cracks and the axle hole.
Apply the caulking like tooth paste. Don't spread it around. When the wheel is
reinstalled, the caulking will spread out to cover the surfaces.
Cracks in the rear wheel are usually caused by over-tightening the bolts, which

Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 8 For assistance contact us at 800-970-2688
can be repaired before they become major. Check all bolts and nuts to be sure they
are tight. Be sure that all pedal screws are tight. Inspect the wheels for visible
cracks or missing wheel plugs. Check that the seat straps are tight. Inspect the
aluminum welds for cracks or signs of fatigue.
SEASONAL MAINTENANCE & INSPECTION
Before each season replace all bearings, bushings, pedals and seat straps. Check all
the other parts to be sure that they will make it through the season. Remember that
an Aqua-Cycle Water Trike out-of-service can cost you many times more in lost
revenue than the cost of the replacement part. It also can be bad public relations
and endanger your customers should something break during rental.
BEARINGS
The Aqua-Cycle Water Trike is designed to transfer wear and stress to the bearings.
Bearings are far less expensive than replacing a broken axle or pedal crank. Aqua-
Cycle Water Trike bearings should be replaced after every 200 hours of use.
If you do not replace the bearings as needed, slight bowing occurs in the rear axle
and pedal crank. With each rotation, reverse stress fatigues the metal. This fatigue
accumulates and will eventually cause the rear axle and pedal crank to break in
half, requiring replacement. Welding the two halves back together is seldom satis-
factory.
Do not rely on your ability to see when the bearings are worn and need replace-
ment. By the time the wear in the bearings is visible, irreversible damage has al-
ready been done to the rear axle and pedal crank.
Protect your Aqua-Cycle investment and the safety of your customers by re-
placing all bearings every 200 hours of use and at the start of each season.
FORK
Remove the fork guard and inspect the fork welds, especially the welds below the
lower of the two cross bars, looking for small cracks in the front and back of the
fork legs. These cracks most commonly start on the front as a result of customers
riding the Aqua-Cycle Water Trike in waves and hitting the shore or playing
"bumper cycle." Catch a crack and have it repaired before it develops into a full
break. Reinstall the fork guard when inspection and maintenance are completed.
Never allow the Aqua-Cycle to be used without the fork guard properly installed.
FORK BUSHINGS
The bushings in the fork turning mechanism and the fork pin should be checked for
excessive wear. Be sure there is enough shoulder left on the bushings so the fork
does not rub directly against the neck tube. Replace if necessary.
NECK
Inspect the welds around the neck where the fork attaches to the frame and check
the gussets that strengthen the neck tube attachment. Look for small cracks in the
welds, which are an indication of a potential break.
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 5For assistance contact us at 800-970-2688
on the handle bar and the top edge of the seat back.
Prepare the eight ½" x 4" bolts for assembly by putting a bead of anti-seize com-
pound along one side of the threads.
Wheel Hubs. There are two different hubs per wheel. The hub with cogs (stubs)
goes in the outer center of the wheel (side of the wheel with fins) and the other
(plain) hub goes on the wheel next to the axle plate.
Rear Wheel Installation. Have someone help you install the rear wheels—it will
make the process much easier.
Put the plain hub onto the rear axle in such a way that it will nest into the wheel.
Lift the rear wheel onto the axle with the fins away from the seat—so they will not
splash water on the riders. Put the cogged hub into the wheel and turn the wheel
and plain hub so the bolt holes align with those in the axle plate.
Insert a ½” x 4" bolt (with anti-seize compound on the thread) and a washer into
each of the bolt holes in the cogged hub and wheel. Push the bolts through the
holes in the plain hub and axle plate. Screw a lock nut onto each bolt, but only
hand tighten.
Be sure the bolt head and washer are on the outside side (side with fins) of the
wheel and the lock nut (without a washer) is against the axle mounting plate.
Warning about the next step, do not over-tighten the 4" bolts! Tightening them
too much will mash the center of the wheel and create hairline cracks in the plastic.
Water can seep into the wheel through these cracks as it rotates and that damage
will continue to expand.
Gently tighten the four nuts, turning one a few turns and then another and anoth-
er—working your way around the wheel several times. Normal tightening is to the
point where two or three threads are showing beyond the edge of the nut, but not so
far that the center of the wheel is squeezed together, mashing and cracking the
wheel center area. This is not like tightening lug nuts on a car wheel, where you
have a metal wheel against a metal plate. The plastic wheel can easily be damaged
by too much force. If a wheel bolt or washer is still loose then tighten the nut a
little at a time until secure.
Repeat this process for the other rear wheel.
Each wheel has two threaded holes near the outside edge. These are for the wheel
plugs. Be sure to install two wheel plugs in each wheel.
If you temporarily need a wheel plug, get a standard 3/4” NPT pipe plug from a
hardware store, whether PVC, brass or galvanized.
FRONT WHEEL ASSEMBLY
Front Axle. This is a ½" by 25" stainless steel rod threaded at each end. It is
shipped complete with two wheel bushings, two hex nuts, and two lock nuts. Dis-
assemble these parts and place them near the front wheel and fork.
Note the difference between the 1/2" hex nuts and the 1/2" lock nuts. The lock nuts
have a nylon insert in the end and the hex nuts do not.

Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 6 For assistance contact us at 800-970-2688
Slide the axle through the center tube to be sure the passage is clear. Sometimes
during manufacturing plastic gets into the center tube. Excess plastic can be forced
out using the front axle as a pusher. DO NOT strike the threaded end of the axle
with a hammer because you will damage the threads.
Insert one front wheel bushing into each end of the tube. Slide the axle through the
bushings so equal thread extends out each side. Screw a ½" hex nut (not a lock nut)
onto each end of the axle. Snug them up against the bushings. Snug, but not tight.
The hex nuts serve to keep the bushings in place. If you over tighten the hex nuts
the shoulder of the bushings will be forced into the tube, damaging it.
Attach the front wheel onto the fork by spreading the fork legs and putting the axle
through the holes in the legs.
Secure the axle with a ½" lock nut per side. With a ½" wrench holding the hex nut
use another wrench to tighten the ½" lock nut against the fork leg forcing the leg
tight against the ½" hex nut. Repeat on the other side.
When finished, each hex nut should be tight against the bushing, but not forcing it
into the tube, the fork leg should be tight against the hex nut, and the lock nut
should be very tight against the fork leg. The wheel should turn freely on the fork.
PEDALS
Install four pedals (eight identical halves) on the pedal crank. If the pedals are hard
to rotate, loosen the screws slightly for the first few days of use while the pedals
wear to match the pedal crank. After a few days tighten them.
LUBRICATION
Lubricate the fork pin with WD-40 or silicone spray lubricant. This should also be
done once a week during heavy use or anytime a squeak develops in the steering.
The pedal crank and rear axle bearings have been greased prior to shipment.
Grease them once a week during normal rental periods. Some of the grease fittings
are covered by the plastic belt guard. It has access holes over these fittings for
greasing. A good quality marine grease is best and can be purchased from a marine
supply.
BELT TENSION
The Aqua-Cycle Water Trike is shipped with the belt slightly tighter than neces-
sary. Within the first week of use the bearings will wear just enough to be easier to
pedal.
Remember to replace the bearings every 200 hours of use to avoid damage to the
pedal crank and rear axle that accumulates with worn bearings. If you hear a pop-
ping or snapping sound as you pedal, probably it is time to replace the bearings.
If the bearings are relatively new and you cannot find any cause for the popping
sound, we have a belt tension kit that can be added to the Aqua-Cycle Water Trike
to help keep the belt the proper tension during pedaling.
Aqua-Cycle Water Trikes—AC6
Assembly Instructions and Maintenance
Page 7For assistance contact us at 800-970-2688
MAINTENANCE
A well maintained Aqua-Cycle Water Trike will last for many years.
If your Aqua-Cycle Water Trike is for personal use, refer to this guide only as need-
ed. Rental operators should follow these lubrication and maintenance guidelines
every week to keep their equipment properly maintained for customer safety and
the least amount of maintenance down time.
NEVER allow Aqua-Cycle Water Trikes to be used without the fork guard and
belt guard properly installed for the safety of the users and protection of the equip-
ment. If you have a question please call our office.
NEED HELP OR PARTS?
Give us a call. We can ship most parts within 24 hours. If you need them
“yesterday”, we can ship air freight, Federal Express, United Parcel Service or
however you instruct us. Payment can be by check, Visa, MasterCard, PayPal,
Western Union or bank wire.
When you call to order parts or for help with a replacement part, have the 12 digit
identification number of the specific Aqua-Cycle Water Trike involved so we can
quickly determine which series of parts you need or give instructions for making
the replacement.
WEEKLY MAINTENANCE & INSPECTION
BEARINGS
The grease fittings on the pedal crank and rear axle bearings only take a moment to
lubricate and will keep your Aqua-Cycle Water Trike running smooth. Some of the
fittings are covered by the plastic belt guard. These fittings are greased through
access holes in the belt guard or by temporarily removing the belt guard. Never
operate the Aqua-Cycle with the belt guard removed.
To grease the Aqua-Cycle Water Trike, flip it over so it is resting on the handle bar
and top of the seat back. This way the wheels are free to turn and you have easy
access to the grease fittings.
Use a high-quality marine grease. Force enough grease into the bearings so a little
comes out the sides. Rotate the pedal crank and rear axle to spread the grease in-
side the bearings before turning the Aqua-Cycle Water Trike right side up. Wipe
off any excess so it does not collect dirt or sand, or get grease on a rider.
FRONT FORK
The top and bottom of the fork pin should be sprayed with WD-40 or silicone spray
lubricant. Turn the fork while spraying so the lubricant runs down the pin and is
spread from side to side. Lubricating the fork pin keeps wear to a minimum and the
fork from squeaking.
SAFETY INSPECTION
When lubricating your Aqua-Cycle Water Trike, check for potential problems that
