Aquatic HOTSOAK 53 ai6042ClHS User manual

99
SPECIFICATIONS:
The manufacturer accepts a 1/4” variance. There are variations on each tub and specifications are subject to change as we improve upon our product as required. The dimensions needed for site preparation
and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324
August 2008
Rough-In Plumbing
Measurements
21 1/4” 22”
41 3/4”
25”
59 1/2”
Two Person Bath
41 3/4”
38 1/2”
24 1/2”
HOTSOAK 53
HOTSOAK SERIES Model # ai6042ClHS
GENERAL SPECIFICATIONS:
Tub Size 59 1/2” x 41 3/4” x 25”
151 cm x 106 cm x 64 cm
Bathing Well 38 1/2” long
24 1/2” wide
22 3/4” interior depth
Shipping Weight 180 lbs. / 82 kg
Tub Weight Filled 863 lbs. / 391 kg
Tub Only Weight 114 lbs. / 52 kg
Gallons to Overow 90 gal. / 341 L
ELECTRICAL SPECIFICATIONS:
Pump 1/15 HP; 1.3 AMP; 110V
Heater 1.5 kW; 12.5 AMP; 110V
Requirements 20 AMP; 110V, separate circuit
required protected w/ Class A GFCI
This unit is not recommended for shower installations.
• Chromatherapy LED Lighting*
• Comfort Pillow - Oval or Rectangle
• Grab Bar
- White, Biscuit, Chrome, Polished Brass, Gold,
Polished Nickel, Satin Nickel or Oil Rubbed Bronze
• Lift & Turn Waste and Overow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel or Oil Rubbed Bronze
• Cable Drive Waste and Overow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel, Oil Rubbed Bronze or
Color Matched (Bone, White and Biscuit Only)
• Factory Installed Rigid ABS Tile Flange
• Optional Pump Location
• Color Matched Acrylic Skirt
• Premium Colors
All acrylic colors featured by Aquatic match the industry’s
leading xture manufacturers.
*This whirlpool will need to be hard wired to the breaker box.
Three outlets will be supplied on the whirlpool.
OPTIONAL EQUIPMENT:
Aquatic Quality Features:
- 1.5 kW Inline Maintenance Heater
- Run-Dry Pump with 20-Minute Timer
- 2 Circulation Portal Covers
- Bath-Side On/Off Electronic Button
- ”Quiet Pad”Anti-Vibration Pump Mount for Quiet Operation
- Color Matched Grab Bar
- 4 Arm Rests
- Slip Resistant Floor
- Pre-leveled ABS Support Base
- Heat-bent Rigid PVC Piping for Optimum Sanitary Conditions
- Durable, Easy to Clean, Lucite® Cast Acrylic Surface
- Available in 8 Standard No-Charge Colors
UL & IAPMO Listed, Factory Tested
Limited Lifetime Warranty
STANDARD EQUIPMENT:
Fax-On-Demand
Document #1228
5 1/8”
11 3/4”
4
32
1
