AquaViva AVM-FI7RW User manual

INVERTER SWIMMING POOL HEAT PUMP
Aquaviva MODEL
USER MANUAL
EN PL Ua RU
For models up to the 2023 production year

READ THIS MANUAL CAREFULLY BEFORE OPERATING THE UNIT. DO NOT
THROW IT AWAY.
BEFORE OPERATING THE UNIT, ENSURE THE INSTALLATION HAS BEEN
CARRIED OUT IN ACCORDANCE WITH THESE INSTRUCTIONS. IF IN DOUBT
CONSULT YOUR LOCAL DEALER.
!
2

INTRODUCTION ............................................................................................................................
SAFETY RULES .............................................................................................................................
GENERAL INFORMATION.............................................................................................................
DEVICE PARAMETERS..................................................................................................................
SYSTEM SPECIFICATION..............................................................................................................
1. SPECIFICATION..........................................................................................................................
2. UNIT DIMENSIONS......................................................................................................................
3. EXPLOSION VIEW........................................................................................................................
INSTALLATION INSTRUCTIONS...................................................................................................
RUNNING TEST..............................................................................................................................
1. INSPECTION BEFORE RUNNING TEST..................................................................................
2. CONTROL FUNCTION DESCRIPTION........................................................................................
3. FAULT CODE AND SOLUTION.................................................................................................
4. WIFI SETTINGS..........................................................................................................................
CONSERVATION.............................................................................................................................
ENVIRONMENTAL INFORMATION...............................................................................................
DISPOSAL REQUIREMENTS........................................................................................................
CONTENTS
3
4
5
6
13
16
16
19
20
21
24
24
24
26
29
34
35
35

4
INTRODUCTION
This manual includes the necessary information to safely install and maintain your Heat Pump.
Please read this manual carefully before you operate the unit.
The Heat Pump
The swimming pool heat pump is one of the most economical ways of heating your swimming
pool efficiently. Using the free renewable energy from the air,it is over 4/5 time more efficient
than traditional heating.The swimming pool heat pump extends your swimming season and gives
you comfort at high level.You could enjoy swimming not only in summer,but also in
spring,autumn and even winter time.
●ECO Friendly
The Heat Pump uses R32 Refrigerant which is ozone friendly dramatically
reducing Carbon Emissions.
●Titanium heat exchanger
The advanced titanium heat exchanger guarantees a longer life span, free of
corrosion. It can be used with all types of water treatment including chlorine,
iodine, bromine and salt water.
●Multiple functions
-Cooling and heating functions available
-Auto operation, Auto-restart, Auto defrost
-Auto timer on/off:no human attendance is required
-Wide ambient working range: -10°C to 45°C.
●Reliable operation
The Heat Pump has several built in safety features, which include insufficient
water flow protection, high/low pressure protection, overload protection,
compressor protection.
●Self-diagnosis
When there is malfunction,the swimming pool heat pump will make self-
diagnosis by displaying error code on the control panel.To identify the
problem,please refer to ERROR CODES pages in this manual.

5
SAFETY INSTRUCTIONS
To prevent injury to the user, other people or damage to property, the following
instructions must be followed.
Install the unit only when it complies with local regulations, by-laws and standards.
Check the main voltage and frequency. This unit must be earthed and have a supply
voltage of 220 ~240 V / ~/ 1Ph.
The following safety precautions should always be taken into account:
Ɣ Be sure to read the following WARNING before installing the unit.
Ɣ After reading these instructions retain for future reference.
! WARN
Incorrect installation could cause injury due to fire, electric shock or water damage. If
in doubt consult your local dealer or a qualified installer.
Securing the Unit.
The unit should be located on a solid, level, horizontal surface and securely fixed.
Ensure free air-flow to all sides of the unit.
Electrical Connections.
Ensure the correct sized Circuit Breakers, isolators and cables are used. All terminals
should be tightly secured and not prone to stress.
This unit must be earthed.
Materials.
To prevent fire, electric shock and other hazards all materials should be suitable for the
specific use of this unit.
Never use an extension cable to connect the unit to the electric power supply.
If there is no suitable earthed supply available, have one installed by a qualified
electrician.
Do not move/repair the unit yourself.
Before carrying out any maintenance, service or repair work, the product must be
isolated from the mains electrical supply. To prevent possible injury, only qualified
engineers should carry out these works.

FOREWORD
WARNING
Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacturer.The appliance shall be stored in a room without
continuously operating ignition sources (for example: open flames, an operating gas appliance
or an operating electric heater.
Do not pierce or burn.
BE AWARE THAT REFRIGERANTS MAY NOT CONTAIN AN ODOUR
Initial safety checks shall include:
●that capacitors are discharged: this shall be done in a safe manner to avoid
possibility of sparking;
●that no live electrical components and wiring are exposed while charging, recovering
or purging the system;
●that there is continuity of earth bonding.
Checks to the area
Prior to beginning work on systems containing flammable refrigerants, safety checks are
necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system,the
following precautions shall be completed prior to conducting work on the system.
Work procedure
Work shall be undertaken under a controlled procedure so as to minimise the risk of a flammable
gas or vapour being present while the work is being performed.
General work area
All maintenance staff and others working in the local area shall be instructed on the nature of
work being carried out. Work in confined spaces shall be avoided.
Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during work, to
ensure the technician is aware of potentially flammable atmospheres. Ensure that the leak
detection equipment being used is suitable for use with flammable refrigerants, i.e. nonsparking,
adequately sealed or intrinsically safe.
Presence of fire extinguisher
If any hot work is to be conducted on the refrigerating equipment or any associated parts,
appropriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO2
fire extinguisher adjacent to the charging area.
6
!

No ignition sources
No person carrying out work in relation to a refrigeration system which involves exposing any
pipe work that contains or has contained flammable refrigerant shall use any sources of ignition
in such a manner that it may lead to the risk of fire or explosion. All possible ignition sources,
including cigarette smoking, should be kept sufficiently far away from the site of installation,
repairing, removing and disposal, during which flammable refrigerant can possibly be released to
the surrounding space. Prior to work taking place, the area around the
equipment is to be surveyed to make sure that there are no flammable hazards or ignition risks.
“No Smoking” signs shall be displayed.
Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking into the
system or conducting any hot work. A degree of ventilation shall continue during the period that
the work is carried out. The ventilation should safely disperse any released refrigerant and
preferably expel it externally into the atmosphere.
Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit for the purpose and to the
correct specification. At all times the manufacturer’s maintenance and service guidelines shall be
followed. If in doubt consult the manufacturer’s technical department for assistance
The following checks shall be applied to installations using flammable refrigerants:
●the charge size is in accordance with the room size within which the refrigerant containing
parts are installed;
●the ventilation machinery and outlets are operating adequately and are not obstructed;
●if an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the
presence of refrigerant;
●marking to the equipment continues to be visible and legible. Markings and signs that are
illegible shall be corrected;
●refrigeration pipe or components are installed in a position where they are unlikely to be
exposed to any substance which may corrode refrigerant containing components, unless the
components are constructed of materials which are inherently resistant to being corroded or
are suitably protected against being so corroded.
7

8
Repairs to sealed components
DD.5.1 During repairs to sealed components, all electrical supplies shall be disconnected from the
equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely
necessary to have an electrical supply to equipment during servicing, then a permanently
operating form of leak detection shall be located at the most critical point to warn of a potentially
hazardous situation.
DD.5.2 Particular attention shall be paid to the following to ensure that by working on electrical
components, the casing is not altered in such a way that the level of protection is affected. This
shall include damage to cables, excessive number of connections, terminals not made to original
specification, damage to seals, incorrect fitting of glands, etc.
Ensure that the apparatus is mounted securely.
Ensure that seals or sealing materials have not degraded to the point that they no longer serve
the purpose of preventing the ingress of flammable atmospheres. Replacement parts shall be in
accordance with the manufacturer’s specifications.
Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this
will not exceed the permissible voltage and current permitted for the equipment in use.
Intrinsically safe components are the only types that can be worked on while live in the presence
of a flammable atmosphere. The test apparatus shall be at the correct rating.
Replace components only with parts specified by the manufacturer. Other parts may result in the
ignition of refrigerant in the atmosphere from a leak.
NOTE :
The use of silicon sealant can inhibit the effectiveness of some types of leak
detection equipment.
Intrinsically safe components do not have to be isolated prior to working on them.
Cabling
Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp
edges or any other adverse environmental effects. The check shall also take into account the
effects of aging or continual vibration from sources such as compressors or fans.
Detection of flammable refrigerants
Under no circumstances shall potential sources of ignition be used in the searching for or
detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall
not be used.
!

9
Leak detection methods
The following leak detection methods are deemed acceptable for systems containing flammable
refrigerants.
Electronic leak detectors shall be used to detect flammable refrigerants, but the sensitivity may not
be adequate, or may need re-calibration. (Detection equipment shall be calibrated in a refrigerant-
free area.) Ensure that the detector is not a potential source of ignition and is suitable for the
refrigerant used. Leak detection equipment shall be set at a percentage of the LFL of the
refrigerant and shall be calibrated to the refrigerant employed and the appropriate percentage of
gas (25 % maximum) is confirmed.
Leak detection fluids are suitable for use with most refrigerants but the use of detergents
containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the
copper pipe-work.
If a leak is suspected, all naked flames shall be removed/extinguished.
If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered
from the system, or isolated (by means of shut off valves) in a part of the system remote from the
leak. Oxygen free nitrogen (OFN) shall then be purged through the system both before and during
the brazing process.
Removal and evacuation
When breaking into the refrigerant circuit to make repairs – or for any other purpose –
conventional procedures shall be used. However, it is important that best practice is followed
since flammability is a consideration. The following procedure shall be adhered to:
•remove refrigerant;
•purge the circuit with inert gas;
•evacuate;
•purge again with inert gas;
•open the circuit by cutting or brazing.
The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall
be “flushed” with OFN to render the unit safe. This process may need to be repeated several
times. Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to
fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down
to a vacuum. This process shall be repeated until no refrigerant is within the system. When the
final OFN charge is used, the system shall be vented down to atmospheric pressure to enable
work to take place. This operation is absolutely vital if brazing operations on the pipework are
to take place.
Ensure that the outlet for the vacuum pump is not close to any ignition sources and there is
ventilation available.

10
Charging procedures
In addition to conventional charging procedures, the following requirements shall be followed.
•Ensure that contamination of different refrigerants does not occur when using charging
equipment. Hoses or lines shall be as short as possible to minimise the amount of refrigerant
contained in them. Cylinders shall be kept upright.
•Ensure that the refrigeration system is earthed prior to charging the system with refrigerant.
•Label the system when charging is complete (if not already).
•Extreme care shall be taken not to overfill the refrigeration system. Prior to recharging the
system it shall be pressure tested with OFN. The system shall be leak tested on completion
of charging but prior to commissioning. A follow up leak test shall be carried out prior to
leaving the site.
Decommissioning
Before carrying out this procedure, it is essential that the technician is completely familiar with
the equipment and all its detail. It is recommended good practice that all refrigerants are
recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken
in case analysis is required prior to re-use of reclaimed refrigerant. It is essential that electrical
power is available before the task is commenced.
a) Become familiar with the equipment and its operation.
b) Isolate system electrically.
c) Before attempting the procedure ensure that:
●mechanical handling equipment is available, if required, for handling refrigerant cylinders;
●all personal protective equipment is available and being used correctly;
●the recovery process is supervised at all times by a competent person;
●recovery equipment and cylinders conform to the appropriate standards.
d) Pump down refrigerant system, if possible.
e) If a vacuum is not possible, make a manifold so that refrigerant can be removed from
various parts of the system.
f) Make sure that cylinder is situated on the scales before recovery takes place.
g) Start the recovery machine and operate in accordance with manufacturer's instructions.
h) Do not overfill cylinders. (No more than 80% volume liquid charge).
i) Do not exceed the maximum working pressure of the cylinder, even temporarily.
j) When the cylinders have been filled correctly and the process completed, make sure that the
cylinders and the equipment are removed from site promptly and all isolation valves on the
equipment are closed off.
k) Recovered refrigerant shall not be charged into another refrigeration system unless it has
been cleaned and checked.

11
Labelling
Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant.
The label shall be dated and signed. Ensure that there are labels on the equipment stating the
equipment contains flammable refrigerant.
Recovery
When removing refrigerant from a system, either for servicing or decommissioning, it is
recommended good practice that all refrigerants are removed safely. When transferring
refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are
employed. Ensure that the correct number of cylinders for holding the total system charge are
available. All cylinders to be used are designated for the recovered refrigerant and labelled for
that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete
with pressure relief valve and associated shut-off valves in good working order. Empty recovery
cylinders are evacuated and, if possible, cooled before recovery occurs.
The recovery equipment shall be in good working order with a set of instructions concerning the
equipment that is at hand and shall be suitable for the recovery of flammable refrigerants.
In addition, a set of calibrated weighing scales shall be available and in good working order.
Hoses shall be complete with leak-free disconnect couplings and in good condition. Before using
the recovery machine, check that it is in satisfactory working order, has been properly maintained
and that any associated electrical components are sealed to prevent ignition in the event of a
refrigerant release. Consult manufacturer if in doubt.
The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery
cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery
units and especially not in cylinders.
If compressors or compressor oils are to be removed, ensure that they have been evacuated to
an acceptable level to make certain that flammable refrigerant does not remain within the
lubricant. The evacuation process shall be carried out prior to returning the compressor to the
suppliers. Only electric heating to the compressor body shall be employed to accelerate this
process. When oil is drained from a system, it shall be carried out safely.

This symbol shows that a service personnel
should be handling this equipment with
reference to the installation manual.
CAUTION
The symbol shows that this appliance uses a low
burning velocity material.Please keep away from fire
source.
The symbol shows that this appliance uses a
flammable refrigerant.
If the refrigerant is leaked and exposed to an external
ignition source, there is a risk of fire.
Symbol Description
12
The symbol description of the device
Meaning
WARNING
WARNING
This symbol shows that the operation
manual should be read carefully.
CAUTION
This symbol shows that information is available
such as the operating manual or installation
manual.
CAUTION

13
Unit Parameters
1. Appearance
2. Statement
To keep users under safe working condition and property safety, please follow the
instructions below.
•Wrong operation may result in injury or damage;
•Please install the unit in compliance with local laws, regulations and standards;
•Confirm power voltage and frequency;
•The unit is only used with grounding sockets;
•Independent switch must be offered with the unit.
3. The following safety factors need to be considered:
•Please read the following warnings before installation;
•Be sure to check the details that need attention, including safety factors;
•After reading the installation instructions, be sure to save them for future reference.
►Warning! Make sure that the unit is installed safely and reliably.
•If the unit is not secure or not installed, it may cause damage. The minimum support
weight required for installation is 21g/mm2.
•If the unit was installed in a closed area or limited space, please consider the size of
room and ventilation to prevent suffocation caused by refrigerant leakage.
►Use a specific wire and fasten it to terminal block so that the connection will prevent
pressure from being applied to parts.
►Wrong wiring will cause fire.
Please connect power wire accurately according to wiring diagram on the manual to avoid
burnout of the unit or fire.

14
►Be sure to use correct material during installing
Wrong parts or wrong materials may result in fire, electric shock, or falling of the unit.
►Install on the ground safely, please read installation instructions.
Improper installation may result in fire, electric shock, falling of the unit, or water leaking.
►Use professional tools for doing electrical work.
If power supply capacity is insufficient or circuit is not completed, it may cause fire or
electric shock.
►The unit must have grounding device.
If power supply does not have grounding device, be sure not to connect the unit.
►The unit should be only removed and repaired by professional technician.
Improper movement or maintenance of the unit may cause water leakage, electric shock, or
fire. Please find a professional technician to do.
►Don't unplug or plug power during operation.It may cause fire or electric shock.
►Don't touch or operate the unit when your hands are wet. It may cause fire or
electric shock.
►Don't place heaters or other electrical appliances near the power wire.It may cause
fire or electric shock.
►The water must not be poured directly from the unit. Do not let water to permeate
into the electrical components.
4. Warning
►Do not install the unit in a location where there may be flammable gas.
►If there is flammable gas around the unit, it will cause explosion.
According to the instruction to carry out drainage system and pipeline work. If drainage
system or pipeline is defective, water leakage will occur. And it should be disposed
immediately to prevent other household products from getting wet and damage.

!
15
►Do not clean the unit while power is on. Turn off power before cleaning the unit. If not
it may result in injury from a high-speed fan or electric shock.
►Stop operating the unit once there is a problem or an fault code.
Please turn off power and stop running the unit. Otherwise it may cause electric shock or fire.
►Be careful when the unit is not packed or not installed. Pay attention to sharp edges and fins
of heat exchanger.
►After installation or repair, please confirm refrigerant is not leaking.
If refrigerant is not enough, the unit will not work properly.
►The installation of external unit must be flat and firm.
Avoid abnormal vibration and noise.
►Don’t put your fingers into fan and evaporator.
High speed running fan will result in serious injury.
This device is not designed for people who is physically or mentally weak (including children)
and who does not have experience and knowledge of heating and cooling system. Unless it
is used under direction and supervision of professional technician, or has received training
on the using of this unit. Children must use it under supervision of an adult to ensure that
they use the unit safely. If power wire is damaged, it must be replaced by a professional
technician to avoid danger.

Heating capacity (kW)
Ambient Temperature: (DB/WB) 27°C/24.3°C; Water Inlet/Outlet Temperature: 26°C/28°C.
Parameter
AVM-FI7RW AVM-FI9RW AVM-FI11RW
Model
1.5~7.21 1.8~9.48 2.8~11.51
Power input (kW)
0.09~1.09 0.11~1.44 0.17~1.74
16
SYSTEM SPECIFICATION
COP 16~6.6 16.4~6.6 16.5~6.6
Heating capacity (kW)
7.2 9.5 11.5
COP 6.6 6.6 6.6
Boost mode
Heating capacity (kW)
5.8 7.8 9.1
COP 9.03 9.02 9.32
Smart mode
Heating capacity (kW)
2.8 3.5 5.5
COP 14.2 14.2 13.8
Silent mode
Heating capacity (kW)
Ambient Temperature: (DB/WB) 15°C/12°C; Water Inlet Temperature: 26°C.
1.3~5.42 1.51~7.89 2.2~8.21
Power input (kW)
0.16~1.06 0.18~1.52 0.27~1.61
COP 8.1~5.1 8.3~5.2 8.1~5.1
Heating capacity (kW)
5.4 7.9 8.23
COP 5.1 5.2 5.1
Boost mode
Heating capacity (kW)
4.3 6.1 6.58
COP 6.23 6.22 6.19
Smart mode
Heating capacity (kW)
2.4 2.5 4.37
COP 7.55 7.58 7.53
Silent mode
220-240V/50Hz
1.61 1.75 2.3
7.32 7.96 10.5
5~40
-10~43
15~30 20~40 25~50
R32
MITSUBISHI ELECTRIC ( DC inverter)
Hydrophilic fin exchanger
Titanium tube heat exchanger
3.1 4.1 4.9
895×355×608 981×400×660
50
42 45 50
32~45 33~47 33~47
0.6/0.1
0.6/0.1
65TS/25A/250VAC
Power supply
Max power input (kW)
Max current(A)
Heating water temperature range (°С)
Running ambient temperature range (°С)
Advised swimming pool size (m³)
Refrigerant
Compressor
Air side heat exchanger
Water side heat exchanger
Water flow (m3/h)
Net dimension LxWxH (mm)
Water pipe connection (mm)
Net weight (kg)
Noise level (dB (А))
Max./Min. Water operating pressure (Mpa)
Max./Min. Water inlet pressure (Mpa)
Fuse specification

17
Heating capacity (kW)
Ambient Temperature: (DB/WB) 27°C/24.3°C; Water Inlet/Outlet Temperature: 26°C/28°C.
Parameter
AVM-FI15RW AVM-FI18RW AVM-FI21RW
Model
3.48~15.3 4.34~18.1 4.72~21.21
Power input (kW)
0.22~2.53 0.27~2.81 0.29~3.26
COP 15.9~6.5 16.1~6.4 16.2~6.5
Heating capacity (kW)
15.3 18.1 21.21
COP 6.5 6.4 6.5
Boost mode
Heating capacity (kW)
11.55 14.01 17.1
COP 9.18 9 9.35
Smart mode
Heating capacity (kW)
7.35 8.7 10.2
COP 13.6 13.2 13.1
Silent mode
Heating capacity (kW)
Ambient Temperature: (DB/WB) 15°C/12°C; Water Inlet Temperature: 26°C.
2.96~11.14 3.44~13.35 3.51~14.21
Power input (kW)
0.36~2.19 0.41~2.61 0.43~2.78
COP 8.3~5.1 8.3~5.1 8.1~5.1
Heating capacity (kW)
11.15 13.33 14.2
COP 5.1 5.1 5.1
Boost mode
Heating capacity (kW)
8.65 10.55 11.2
COP 6.2 6.16 6.2
Smart mode
Heating capacity (kW)
5.55 6.72 7.5
COP 7.55 7.54 7.5
Silent mode
220-240V/50Hz
3.2 3.9 4.1
14.5 15.9 7.3
5~40
-10~43
30~60 35~70 45~80
R32
MITSUBISHI ELECTRIC ( DC inverter）
Hydrophilic fin exchanger
Titanium tube heat exchanger
6.6 7.7 9.1
981×400×660 1100×403×770
50
53 60 88
34~48 34~48 35~50
0.6/0.1
0.6/0.1
65TS/30A/250VAC
Power supply
Max power input (kW)
Max current (A)
Heating water temperature range (°С)
Running ambient temperature range (°С)
Advised swimming pool size (m³)
Refrigerant
Compressor
Air side heat exchanger
Water side heat exchanger
Water flow (m3/h)
Net dimension LxWxH (mm)
Inlet (mm)
Net weight (kg)
Noise level dB(A)
Max./Min. Water operating pressure (Mpa)
Max./Min. Water inlet pressure (Mpa)
Fuse specification
380-415V/50Hz
65TS/5A/250VAC
50
Outlet (mm)
Water pipe
connection

18
Heating capacity (kW)
Ambient Temperature: (DB/WB) 27°C/24.3°C; Water Inlet/Outlet Temperature: 26°C/28°C.
Parameter Model
Power input (kW)
COP
Heating capacity (kW)
COP
Boost mode
Heating capacity (kW)
COP
Smart mode
Heating capacity (kW)
COP
Silent mode
Heating capacity (kW)
Ambient Temperature: (DB/WB) 15°C/12°C; Water Inlet Temperature: 26°C.
Power input (kW)
COP
Heating capacity (kW)
COP
Boost mode
Heating capacity (kW)
COP
Smart mode
Heating capacity (kW)
COP
Silent mode
380-415V/50Hz
MITSUBISHI ELECTRIC ( DC inverter)
Hydrophilic fin exchanger
Titanium tube heat exchanger
1130×485×775
AVM-FI25RW
5.05~25.28
0.31~3.89
16.2~6.5
25.3
6.5
20.36
8.9
12.3
13.6
3.81~17.08
0.48~3.35
8~5.1
17.1
5.1
13.5
6.21
8.3
7.52
4.5
8.5
55~90
10.8
95
35~52
65TS/20A/250VAC
Power supply
Max power input (kW)
Max current (A)
Heating water temperature range (°С)
Running ambient temperature range (°С)
Advised swimming pool size (m³)
Refrigerant
Compressor
Air side heat exchanger
Water side heat exchanger
Water flow (m3/h)
Net dimension LxWxH (mm)
Inlet (mm)
Net weight (kg)
Noise level (dB (А))
Max./Min. Water operating pressure (Mpa)
Max./Min. Water inlet pressure (Mpa)
Fuse specification
AVM-FI28RW
5.4~28.06
0.33~4.32
16.3~6.51
28.1
6.51
22.61
8.92
13.91
13.5
4.04~18.49
0.49~3.56
8.2~5.2
18.5
5.2
14.63
6.18
9.31
7.53
5.4
10.2
15~40
-10~43
65~100
R32
12
50
98
36~52
0.6/0.1
0.6/0.1
50
Outlet (mm)
Water pipe
connection

The technical specification of our heat pumps is provided for information purpose
only. We reserve the right to make change without notice in advance.
1. Noise at 1 m, at 4 m and at 10 m in accordance with Directives EN ISO 3741 and EN ISO 354
2. Calculate according to an in-ground private swimming pool covered with bubble
Unit Dimensions
19
A
B
C
D
E
F
G
1100
403
770
680
655
390
110
AVM-FI7RW
AVM-FI9RW
AVM-FI11RW
AVM-FI15RW
AVM-FI18RW
AVM-FI210RW
Size
Model
895
355
608
591
330
280
74
981
400
660
666
345
380
73
B
A
C
E
D
F
G
WATER OUTLET
WATER INLET
Air outlet
Puwer
input
1100
403
770
680
655
470
110
AVM-FI25RW
AVM-FI28RW

22
21
20
19
18
17
16
15
14
13
12
11109
6
7
8
4
5
1
2
3
20
Explosion View
The top
Electrical box cover
Electrical box
The left panel
Pillar
Motor Support
Fan Motor
Fan Blade
Front Plate
Middle Plate
Chassis
№
1
2
3
4
5
6
7
8
9
10
11
Name
Right plate
Rubber loop
Handle
Wire Controller
Wiring box
Inductor
Titanium heat exchanger
EEV component
Hydrophilic finned heat exchanger
The rear panel
Environmental probe holder
№
12
13
14
15
16
17
18
19
20
21
22
Name
