arcelik 2495 CNMY User manual

2495 CNMY
2470 CEY
refrigerator

Please read this guide first!
Dear Customer,
We'd like you to achieve the optimal efficiency from our product, which has been manufactured in
modern facilities with meticulous quality controls.
For this purpose, please fully read the user guide before using the product and keep the guide as a
reference source. If you turn the product over to another person, provide this guide along with the
product.
User guide ensure the quick and safe use of the product.
• Please read the user guide before installing and operating the product.
• Always observe the applicable safety instructions.
• Keep the user guide within easy reach for future use.
• Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide clearly indicates any
variations of different models.
Symbols and Remarks
The following symbols are used in the user guide:
CImportant information and use-
ful tips.
ARisk of life and property.
BRisk of electric shock.
The product’s packaging is
made of recyclable materials,
in accordance with the National
Environment Legislation.

2 /26 EN Refrigerator / User Guide
1 Safety and environment instructions3
1.1. General safety. . . . . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning. . . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water fountain . . . . . . . . . 5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety. . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with WEEE Directive and Disposing
of the Waste Product . . . . . . . . . . . . . . . . . 6
1.5. Compliance with RoHS Directive . . . . . . . . . 6
1.6. Package information . . . . . . . . . . . . . . . . . . 6
2 Your Refrigerator 7
3 Installation 8
3.1. Right place for installation . . . . . . . . . . . . . . 8
3.2. Attaching the plastic wedges . . . . . . . . . . . . 8
3.3. Adjusting the stands . . . . . . . . . . . . . . . . . . 8
3.4. Power connection . . . . . . . . . . . . . . . . . . . . 9
3.5. Reversing the doors . . . . . . . . . . . . . . . . . 10
3.6. Reversing the doors . . . . . . . . . . . . . . . . . 11
4 Preparation 12
4.1. What to do for energy saving. . . . . . . . . . . 12
4.2. First Use . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Using the product 13
5.1. Temperature adjustment button . . . . . . . . . 13
5.2. Rapid freezing . . . . . . . . . . . . . . . . . . . . . 13
5.3. Vacation function . . . . . . . . . . . . . . . . . . . 14
5.4. Indicator panel . . . . . . . . . . . . . . . . . . . . . 15
5.5. Ice bucket. . . . . . . . . . . . . . . . . . . . . . . . . 18
5.6. Eggholder . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.7. Fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.8. Vegetable bin . . . . . . . . . . . . . . . . . . . . . . 18
5.9. Zero degree compartment. . . . . . . . . . . . . 18
5.10.Moving door rack. . . . . . . . . . . . . . . . . . . 19
5.11.Sliding storage box . . . . . . . . . . . . . . . . . 19
5.12.Moisture controlled vegetable bin . . . . . . . 20
5.13.Automatic ice machine . . . . . . . . . . . . . . 20
5.14.Freezing fresh food . . . . . . . . . . . . . . . . . 21
5.15.Recommendations for storing frozen foods 21
5.16.Deep freezer details . . . . . . . . . . . . . . . . . 22
5.17.Placing the food. . . . . . . . . . . . . . . . . . . . 22
5.18.Door open alert . . . . . . . . . . . . . . . . . . . . 22
5.19.Changing the opening direction of the door22
5.20.Interior light . . . . . . . . . . . . . . . . . . . . . . . 22
6 Maintenance and cleaning 23
6.1. Preventing malodour . . . . . . . . . . . . . . . . . 23
6.2. Protecting plastic surfaces . . . . . . . . . . . . 23
6.3. Door glass . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Troubleshooting 24
Table of Contents

3/26 EN
Refrigerator / User Guide
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all
types of product warranty.
1.1.General safety
• This product should not be
used by persons with physical,
sensory and mental disabilities,
without sufficient knowledge
and experience or by children.
The device can only be used by
such persons under supervision
and instruction of a person
responsible for their safety.
Children should not be allowed
to play with this device.
• In case of malfunction, unplug
the device.
• After unplugging, wait at least
5 minutes before plugging in
again.
• Unplug the product when not in
use.
• Do not touch the plug with wet
hands! Do not pull the cable to
plug off, always hold the plug.
• Wipe the power plug’s tip with
a dry cloth before plugging in.
• Do not plug in the refrigerator if
the socket is loose.
• Unplug the product during
installation, maintenance,
cleaning and repair.
• If the product will not be used
for a while, unplug the product
and remove any food inside.
• Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product
(electrical card box cover) (1) is
open.
1
1
• Do not use steam or steamed
cleaning materials for cleaning
the refrigerator and melting the
ice inside. Steam may contact
the electrified areas and cause
short circuit or electric shock!
• Do not wash the product by
spraying or pouring water on it!
Danger of electric shock!
1Safety and environment instructions

Safety and environment instructions
4 /26 EN Refrigerator / User Guide
• In case of malfunction, do
not use the product, as it
may cause electric shock.
Contact the authorized
service before doing
anything.
• Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
• If the product has LED
type lighting, contact the
authorized service for
replacing or in case of any
problem.
• Do not touch frozen food
with wet hands! It may
adhere to your hands!
• Do not place liquids in
bottles and cans into the
freezer compartment. They
may burst out!
• Place liquids in upright
position after tightly closing
the lid.
• Do not spray flammable
substances near the product,
as it may burn or explode.
• Do not keep flammable
materials and products with
flammable gas (sprays, etc.)
in the refrigerator.
• Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of
fire.
• Exposing the product to rain,
snow, sunlight and wind
will cause electrical danger.
When relocating the product,
do not pull by holding the
door handle. The handle may
come off.
• Take care to avoid trapping
any part of your hands or
body in any of the moving
parts inside the product.
• Do not step or lean on the
door, drawers and similar
parts of the refrigerator. This
will cause the product to fall
down and cause damage to
the parts.
• Take care not to trap the
power cable.

Safety and environment instructions
5/26EN
Refrigerator / User Guide
1.1.1 HC warning
If the product comprises a
cooling system using R600a
gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas
is flammable. If the cooling
system is damaged, keep the
product away from sources
of fire and ventilate the room
immediately.
CThe label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water fountain
• In order for the water system
inside the refrigerator to
operate properly, pressure
in the water mains must
be between 1-8 bars. A
pressure regulator must be
used if the pressure in the
water mains is higher than
5 bars. If the pressure in
the mains is higher than 8
bars, the refrigerator must
not be connected to the
mains. If you are not sure
about how to measure the
water pressure, ask for
professional help.
• Use drinking water only.
1.2.Intended use
• This product is designed for
home use. It is not intended
for commercial use.
• The product should be used
to store food and beverages
only.
• Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes
no responsibility for any
damage due to misuse or
mishandling.
• The product’s bench life is
10 years. The spare parts
necessary for the product to
function will be available for
this period.
1.3.Child safety
• Keep packaging materials
out of children’s reach.

Safety and environment instructions
6 /26 EN Refrigerator / User Guide
• Do not allow the children to
play with the product.
• If the product’s door
comprises a lock, keep the
key out of children’s reach.
1.4. Compliance with WEEE
Directive and Disposing
of the Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be
reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult your
local authorities to learn about these
collection centers.
1.5. Compliance with
RoHS Directive
• This product complies with EU WEEE
Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified
in the Directive.
1.6. Package information
• Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the
packaging materials together with the
domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.

7/26 EN
Refrigerator / User Guide
1. Cooler compartment door shelf
2. Bottle shelf
3. Adjustable legs
4. Deep freezer compartment
5. Quick freeze compartment
6. Vegetable bin
7. Zero degree compartment
8. Interior light
9. Cooler compartment glass shelf
10. Temperature adjustment button
11. Cooler compartment
12. Freezer compartment
2Your Refrigerator
C*optional: Pictures given in this manual are given as example figures and they may not be exactly
the same as your product. If your product does not comprise the relevant parts, the information
pertains to other models.
*1
*2
*4
*5
33
*6
*7
8
*10
11
12
*9

8 /26 EN Refrigerator / User Guide
3Installation
3.1. Right place for installation
Contact the Authorized Service for the product's
installation. To ready the product for installation,
see the information in the user guide and make
sure the electric and water utilities are as required.
If not, call an electrician and plumber to arrange
the utilities as necessary.
BWARNING: The manufacturer assumes
no responsibility for any damage caused
by the work carried out by unauthorized
persons.
BWARNING: The product’s power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
AWARNING: If the door span is too narrow
for the product to pass, remove the door
and turn the product sideways; if this does
not work, contact the authorized service.
•Placetheproductonaflatsurfacetoavoid
vibration.
•Placetheproductatleast30cmawayfromthe
heater, stove and similar sources of heat and at
least 5 cm away from electric ovens.
•Donotexposetheproducttodirectsunlightor
keep in damp environments.
•Theproductrequiresadequateaircirculationto
function efficiently.
•Iftheproductwillbeplacedinanalcove,
remember to leave at least 5 cm distance
between the product and the ceiling and the
walls.
•Donotinstalltheproductinenvironmentswith
temperatures below -5°C.
3.2. Attaching the plastic wedges
Use the plastic wedges in the provided with
the product to provide sufficient space for air
circulation between the product and the wall.
1. To attach the wedges, remove the screws on the
product and use the screws provided with the wedges.
2. Attach 2 plastic wedges on the ventilation cover as
shown in the figure.
3.3. Adjusting the stands
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.

Installation
9/26 EN
Refrigerator / User Guide
3.4. Power connection
AWARNING: Do not use extension or multi
sockets in power connection.
BWARNING: Damaged power cable must
be replaced by Authorized Service.
CWhen placing two coolers in adjacent
position, leave at least 4 cm distance
between the two units.
• Our firm will not assume responsibility for
any damages due to usage without earthing
and power connection in compliance with
national regulations.
• The power cable plug must be easily
accessible after installation.
• Connect the refrigerator to an earthed
socket with 220-240V/50 Hz voltage. The
plug must comprise a 10-16A fuse.
• Do not use multi-group plug with or without
extension cable between the wall socket
and the refrigerator.
