Archos Cesar MPM User manual

-1-
CESAR MPM
USER GUIDE
VER 1.0
100 831
Install Guide –English ......................................p. 2
Guide d'installation –Français .......................p. 15
Betriebsanleitung –Deutsch ..........................p. 28
Manual del usuario –Español ........................p. 42
Manual dell’ utilizzatore –Italiano ..................p. 56

-2-
Quick Start Guide
Contents
1. Overview.......................................................5
2. Install the Hardware......................................6
3. Install the Software Driver on PC :
A. PCMCIA Interface Installation...................7
B. USB Interface Installation .........................8
C. USB 2.0 Interface Installation ...................8
D. FireWire Interface Installation...................9
4. How to open and close the lid of the
CESAR Drive ..............................................10
5. Batteries......................................................11
6. CDR-CRDRW burning :
A. Install the Nero Burning ROM Software (PC)..12
B. Using CESAR with Nero .................................12
C. Reading and burning speed............................13
7. Customer Support.......................................14
CLASS 1 LASER PRODUCT
DANGERINVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.

-3-
Warranty and Limited Liability
This product is sold with a limited warranty and specific remedies are available
to the original purchaser in the event the product fails to conform to the limited
warranty. Manufacturer’s liability may be further limited in accordance with its
sales contact.
In general, the manufacturer shall not be responsible for product damages
caused by natural disasters, fire, static discharge, misuse, abuse, neglect,
improper handling or installation, unauthorised repair, alteration or accident.
In no event shall the manufacturer be liable for loss of data stored on disk
media.
MANUFACTURER SHALL NOT BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES. EVEN IF INFORMED OF
THE POSSIBILITY THEREOF IN ADVANCE.
Please see your sales contract for a complete statement of warranty rights,
remedies and limitation of liability.
Further, the warranty does not apply to:
•Damages or problems resulting from misuse, abuse, accident, alteration
or incorrect electrical current or voltage.
•Any product with a tampered-with or damaged warranty seal or serial
number label.
•Any product without a warranty or serial number label.
•Any batteries and all consumable items delivered with or in the
equipment..
Warnings and Safety Instructions
CAUTION
To prevent risks of electric shock, this unit must only be opened by qualified
service personnel.
Power off and disconnect the power supply cable before opening the unit.
WARNING
§To prevent fire or shock hazard, do not expose the unit to rain or
moisture.
§Use of this product is for personal use only. Copying CDs or downloading
music files for sale or other business purposes is or may be a violation of
copyright law.

-4-
FCC Warning Statement
FCC Compliance
This equipment has been tested and found to comply with the requirements
for a class B digital device pursuant to Part 15 of the FCC regulations. These
requirements are designed to provide reasonable protection against harmful
interference in a residential area. This equipment generates, uses and can
radiate radio frequency energy. If not installed and used in accordance with
the manufacturer’s instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular environment. If this equipment does cause harmful
interference, to radio or television reception which can be determined by
turning the equipment on and off. The user is advised to try to correct the
interference by one or more of the following methods :
•Reorient or relocate the receiving unit's antenna;
•Increase the distance between the equipment and the receiver;
•Connect the equipment to a different power outlet other than the one
where the receiver is connected;
•Consult a certified television or radio technician for assistance.
CAUTION : Any changes or modifications not expressly approved by the
manufacturer of this device will void the user's authority to
operate the equipment.
FCC Part 15 -Operation is subject to the following two conditions:
1. This device may not cause harmful interference;
2. This device must accept any interference received including interference
that may cause undesired operation.
Copyright Notice
Copyright ARCHOS © 2001 -All rights reserved.
This document may not, in whole or part, be copied, photocopied, reproduced,
translated or reduced to any electronic medium or machine-readable form
without prior consent, in writing, from ARCHOS. Windows 95, Windows 98,
Windows 98 SE, Windows Me, Windows 2000, Windows XP, Mac OS are
trademarks of Microsoft Corporation and Apple Inc. All rights reserved. All
brands and products names are registered trademarks and the property of
their respective owners. Specifications are subject to change without
notification. Errors and omissions excepted. Images and illustrations may not
always match contents.

-5-
1. Overview
Low Batteries
Drive Busy
Power On
Eject
Mechanical eject
LID
Swappable
Interface
AC/DC adapter
LINE OUT
Batteries
door
Batteries

-6-
2. Install the Hardware
NOTE: DO NOT try to open the lid of the CESAR until the drive is
fully installed into a computer. The lid may be locked and
CANNOT be opened at this stage.
NOTE : First use require 4 hours of Batteries charging.
•Plug in the power cable into the
Power Socket at the back of your
CESAR.
•Plug the AC/DC adpter into
anelectrical outlet.
•Verify that the green “ON” LED is turn
ON.
•After 4 hours of batteries charging,
connect the interface cable to the
connector at the back of the
CESAR drive.

-7-
3..Install the Software Driver on PC
Using CESAR for the first time requires a driver installation,
depending on the version of interface (PCMCIA, USB, USB2 or Fire
Wire). Each driver installation is different.
A. PCMCIA Interface Installation
NOTE : For the PCMCIA interface, default Windows driver
are used.
The floppy disk driver is not required for this installation.
Windows 95, Windows 98, Windows 98SE & ME :
•Turn on your system and wait for Windows to finish booting.
•Insert the PCMCIA card (Archos logo face up) into an open
PCMCIA slot in your notebook.
•A “New Hardware Found” window will guide you through
installation of driver. When prompted for driver disk,
uncheck all boxes. Then click Next.
•For Windows 98 (4.10.1998) choose “The updated driver
recommended” and click Next:
Windows 2000 :
•Turn on your computer and wait for Windows to finish
booting.
•Insert PCMCIA card (Archos logo face up) into an open
PCMCIA slot in your computer.
Follow steps listed below to complete installation:
1. Found new hardware wizard will pop up. System will install
ARC ATAPI,
PCMCIA IDE/ATAPI Controller,
ARCHOS SlimCDRW 8824 and
CD-ROM Drive using standard Windows drivers.
No driver files will be needed from Archos.
2. You must restart your computer before the new settings will take
effect.

-8-
B. USB Interface Installation
NOTE : using USB ports repeated on some peripherals
(such as keyboards).
May cause quick discharge.
Windows 98SE -Windows ME & Windows 2000 :
•Turn on your system and wait for Windows to finish booting.
•Insert the driver floppy disk into the floppy disk Drive
•Insert USB cable to an open USB port on your computer.
Follow steps listed below to complete installation:
•A “New Hardware Found” window will guide you through
installation of driver. When prompted for driver disk, Check
"Floppy disk drives” box, and uncheck all other boxes. Insert
Install Disk in floppy drive then click Next.
C. USB 2.0 Interface Installation
NOTE : using USB ports repeated on some peripherals
(such as keyboards).
May cause quick discharge.
Windows 98SE :
•Turn on your computer and wait until it has finished booting.
•Connect USB end of USB cable to a free USB port on your
computer
•A “New Hardware Found” window will guide you through
installation of driver. When prompted for driver disk, Check
"Floppy disk drives” box, and uncheck all ot

-9-
Windows ME & Windows 2000 :
No install disk is needed.
•Turn on your computer and wait until it has finished booting.
•Connect USB end of USB cable to a free USB port on your
computer
•A “New Hardware Found” window will guide you through
installation of driver. Microsoft “USB Mass storage” drivers will
be automatically installed.
D. FireWire Interface Installation
Windows 98SE, Windows ME & Windows 2000 :
No install disk is needed.
•Turn on your computer and wait until it has finished booting.
•Connect FireWire end of FireWire cable to a free FireWire port
on your computer
•A “New Hardware Found” window will guide you through
installation of driver. Microsoft “USB Mass storage” drivers will
be automatically installed.

-10 -
4. How to open and close the lid of the
CESAR Drive
NOTE: Due to the design of the CESAR unit, the cover of the
CESAR drive DOES NOT eject or open automatically like
a tray CDROM would.
OPEN :
•Press firmly on the Eject
button.
•The cover will unlock.
•Wait until the CDROM
stops spinning.
•Grasp the “TABS” on
both sides of the lid and
gently lift up.
CLOSE :
•With the lid open, insert the CDROM with printed label
facing up.
•Push down gently on the cover. It will lock automatically.
•The CESAR is now ready for use.

-11 -
5. Batteries
CESAR is designed to be used without external AC/DC adapter.
CESAR is equipped with 2 xLithium-Ion rechargeable batteries.
These batteries are required to be changed only when they can no
longer hold charge. Use ONLY ARCHOS Lithium-Ion rechargeable
batteries. To remove the batteries door, remove its 2 small screws
(see picture below).
WARNING !: -Insure enough charge level
before any CDR/W burning.
-Using USB ports repeated
on some peripherals (such as
keyboards), may cause
CESAR to not be able to draw
enough power from such
ports.
Batteries door
Batteries
Batteries door screws

-12 -
6. CDR-CDRW burning
A. Install the Nero Burning ROM Software
(PC)
NOTE: The CESAR drive will not operate if the cover is
NOT in the locked position after inserting a
CDROM media.
•Insert the ARCHOS setup CD into the CDROM drive.
•Close the cover and wait for the CDROM to spin up.
•Choose Nero installation. If the software installation
program does not start automatically, click Start, click
Run, and Browse to the asetup.exe file on the CD.
If you wish to use the CD-RW writer as a floppy drive, you can install
InCD Packet Writing by repeating the instructions above and by
choosing the InCD Packet Writing icon.
B. Using CESAR with Nero
In order to use the burning software, please refer to the user’s guide
available on CD-ROM in the folder \NERO\Nero55\Quickstart and
choose your language.

-13 -
C. Reading and burning speed
The maximum speed depends on the interface used (see the chart
below), as well as on the configuration of your computer, and notably
on the performance of the communication ports.
Interface Cable Write Rewrite Read Max Operating Systems
Supported
PC
USB 4X 4X 6X W98SE/ME/2000
USB 2.0 8X 8X 24X W98SE/ME/2000
16-BIT PCMCIA/
PC Card 8X 8X 12X W98/98SE/ME/2000
FireWire/IEEE 1394 8X 8X 24X W98SE/ME/2000

-14 -
7. Customer Support
If you need help with your CESAR drive, contact the place of
purchase.
If you need additional help you may contact Archos directly via
the Web or by phone.
USA-Canada-Asia Europe
Archos, Inc. Archos S.A.
15375 Barranca Parkway 12, rue Ampère
Suite J 101 91430 Igny -France
Irvine, CA 92618
Phone: [phone] Phone : [phone]
Fax : [phone]
technical-[email protected] support-[email protected]
http://www.archos.com

-15 -
Guide d’installation rapide
Table des matières
1. Vue d’ensemble.............................................18
2. Installation du matériel ..................................19
3. Installation des pilotes du périphérique
dans le PC :
A. Installation de l’Interface PCMCIA.............20
B. Installation de l’Interface USB...................22
C. Installation de l’Interface USB 2.0.............22
D. Installation de l’Interface FireWire.............24
4. Comment ouvrir et fermer le capot du lecteur
CESAR .........................................................24
5. Batteries........................................................25
6. Gravure de CDR-CRDRW :
A. Installation du logiciel...............................26
B. Nero Burning ROM(PC)
Utiliser CESAR avec Nero .......................26
C. Vitesse de lecture et de gravure ...............26
7. Support client ………….………… .................27
APPAREIL A LASER DE CLASSE 1
ATTENTION RADIATION DU FAISCEAU LASER INVISIBLE EN CAS
D’OUVERTURE. EVITER TOUTE EXPOSITION AUX RAYONS.

-16 -
Conformité FCC
Cet équipement a été testé et prouvé conforme aux exigences d’un appareil
numérique de classe B selon l’Article 15 du règlement FCC. Ces exigences
sont conçues pour fournir une protection suffisante contre toute interférence
nuisible dans une zone résidentielle. Cet équipement génère, utilise et peut
émettre de l’énergie à radiofréquence. S’il n’est pas installé et utilisé selon les
instructions du fabricant, il peut provoquer des interférences nuisibles avec les
communications radio. Cependant, il n’existe aucune garantie que ces
interférences ne puissent survenir dans un environnement particulier. Si cet
équipement occasionne des interférences nuisibles à la réception de radio ou
de télévision (déterminé par la mise sous et hors tension de l’appareil), il est
conseillé à l’utilisateur d’essayer de corriger l’interférence à l’aide de l’une des
méthodes suivantes :
•Réorienter ou replacer l’antenne de l’unité de réception ;
•Augmenter la distance entre l’équipement et le récepteur ;
•Connecter l’équipement à une prise électrique différente de celle du
récepteur ;
•Consulter un technicien certifié de radio ou télévision pour obtenir de
l’aide.
ATTENTION :tout changement ou modification non autorisée
expressément par le fabricant de cet appareil annulera
l’autorité de l’utilisateur à manipuler l’équipement.
Les articles de loi L44.5 et 44.6 du code de la Santé publique,
modifiés par l’article 2 de la loi du 28 mai 1996 imposent une
puissance acoustique maximale de 100 décibels. Le casque livré
(référence ARCHOS 100200) et l’appareil respectent la législation en
vigueur.(NF/EN 50332-1).
ATTENTION, à pleine puissance, l’écoute prolongée du baladeur
peut endommager l’oreille de l’utilisateur.
Article 15 de la FCC –L’exploitation est sujette aux deux conditions
suivantes :
1. Cet appareil ne doit pas causer d’interférence nuisible ;
2. Cet appareil doit accepter toute interférence de réception, y compris
celles pouvant causer une opération non souhaitée.

-17 -
Avis de droits d’auteur
Copyright ARCHOS © 2001 –Tous droits réservés.
Tout ou partie de ce document ne peut en aucun cas être copié, photocopié,
reproduit, traduit ou réduit pour tout appareil électronique sans autorisation
écrite préalable de la société ARCHOS. Toutes les marques citées sont des
marques déposées par leurs propriétaires respectifs. Informations données
sous réserve d’erreurs typographiques et susceptibles de modifications sans
préavis. Photos et illustrations non contractuelles.

-18 -
1. Vue d’ensemble
Batteries faibles
Lecteur occupé
Témoin d’alimentation
Ejection
Ejection mécanique
Capot
Interface
interchangeable
Adaptateur AC/DC
Sortie “Line out”
Capot des Batteries
Batteries

-19 -
2. Installation du matériel
NOTEZ : N’essayez pas d’ouvrir le capot du CESAR tant que
le lecteur n'est pas complètement installé sur l’ordinateur.
Le capot peut-être verrouillé.
NOTEZ : Il est recommandé de charger les batteries pendant
4 heures avant la première utilisation.
•Branchez le câble d’alimentation sur le connecteur
d’alimentation.
La prise se trouve au dos du CESAR.
•Branchez l’adaptateur AC/DC dans une prise
électrique.
•Vérifiez que le voyant vert “ON” est allumé.
•Après avoir chargé les
batteries pendant 4 heures,
connectez le câble d’interface
sur le connecteur au dos du
CESAR.

-20 -
3. Installation des pilotes du périphérique
sur le PC
Lorsqu’on utilise CESAR pour la première fois, il faut installer les
pilotes, selon la version de l’interface (PCMCIA, USB, USB2 ou Fire
Wire). Chaque installation de pilote est différente.
A. Installation de l’Interface PCMCIA
NOTEZ : Pour l’interface PCMCIA, les pilotes Windows sont utilisés
par défaut.
La disquette de pilotes n’est pas requise pour cette installation.
Windows 95, Windows 98, Windows 98SE & ME :
•Allumez votre système et patientez jusqu’à la fin du Démarrage
de Windows.
•Insérez la carte PCMCIA (Logo d’Archos vers le haut) dans
un logement ouvert PCMCIA de votre ordinateur portable.
•Une fenêtre s’ouvrira “Nouveau Matériel Trouvé” et vous
guidera tout au long de l’installation. Lorsque les pilotes du
périphérique sont demandés, décochez toutes les cases. Puis
cliquez Suivant.
•Pour Windows 98 (4.10.1998) choisissez “Le pilote mis à jour
recommandé ” puis cliquez Suivant:
