Archos G9 3G stick User manual

Thank you for purchasing this ARCHOS product.

3G READY: Always stay connected
Because you shouldn’t be forced to choose between a 3G and a Wifi tablet
at purchase, ARCHOS have developed the ARCHOS G9 3G stick; a standard
USB 3G stick that accepts any Sim card that works on any PC as well as on
your ARCHOS 80 G9 & 101 G9 Tablets.
Your ARCHOS 3G Stick is designed so that you can easily set it up and start
using it right away.

Contents 3
Contents
Chapter 1: FAQ: Frequently asked questions
5 Questions you may have for the setup of the APN
Chapter 2: Unpack, Set Up, Go
Data plans: service provider's information:
7 TPG
8 Optus
10 Telstra
Chapter 3: Using the 3G Stick
13 Inserting your Sim card
14 Connecting your ARCHOS G9 3G stick to a PC running windows
15 Connecting your ARCHOS G9 3G stick to a Mac

Chapter 1 Frequently asked questions 4
1
Frequently asked questions

Chapter 1 Frequently asked questions 5
Most of the time no setup is required when plugging your 3G stick with
your sim card into your device. However, in some cases, you may need
to enter your Carriers APN details.
FAQ
•Q: What is an “APN”?
•A: “APN” stands for Access Point Name. It allows you to connect
to the internet & identifies your data access to the Carrier.
•Q: Do I need to setup the APN for my data provider?
•A: After inserting your sim card and connecting the 3G dongle to
your unit,the setup will be automatic, in most cases. However,
sometimes it is necessary to manually enter the APN
information.
•Q: How do I enter APN details into my Android Device?
•A: Usually, it’s something along the lines of this:
oSettings ->
oWireless & Networks ->
oMobile Networks ->
oAccess Point Names ->
o*Hit the Menu button* (top right corner of the screen ->
New APN)
oEnter the details you find below for your carrier.

Chapter 2 Unpack, Set Up, Go 6
2
Unpack, Set Up, Go

Chapter 2 Unpack, Set Up, Go 7
TPG (900/2100 MHz)
TPG Mobile – Internet TPG Mobile – MMS
Name: TPG Internet TPG (Optus) MMS
APN: internet mms
Proxy: 203.139.83.152 -
Port: 8070 -
Username: - -
Password: - -
Server: - -
MMSC: - http://mmsc.optus.com.au:8002/
MMS Proxy: - 61.88.190.10
MMS Port: - 8070
MMS Protocol: - WAP 2.0
MCC: 505 505
MNC: 02 02
Authent. Type: default mms
APN Type: - -

Chapter 2 Unpack, Set Up, Go 8
Optus (900/2100 MHz)
Optus- Post Paid Mobile Broadband (e.g. if you’re
using your SIM in a Tablet)
Name: Optus Yes Internet
APN: connectcap
Proxy: -
Port: -
Username: -
Password: -
Server: -
MMSC: -
MMS Proxy: -
MMS Port: -
MMS Protocol: (Android 2.1+): WAP
MCC: 505
MNC: 02
Authent. Type: PAP
APN Type: internet

Chapter 2 Unpack, Set Up, Go 9
Optus (900/2100 MHz) Cont'd
Optus- Internet Optus – MMS
Name: Optus- Internet Optus MMS
APN: yesinternet mms
Proxy: - -
Port: - -
Username: - -
Password: - -
Server: - -
MMSC: - http://mmsc.optus.com.au:8002/
MMS Proxy: - 61.88.190.10
MMS Port: - 8070
MMS WAP 2.0 WAP 2.0
MCC: 505 505
MNC: 02 02
Authent. PAP PAP
APN Type: internet or default mms

Chapter 2 Unpack, Set Up, Go 10
Telstra (850/2100 MHz)
Telstra – Internet
3G/EDGE/GPRS Telstra – MMS
Name: Telstra Internet Telstra MMS
APN: telstra.iph telstra.mms
Proxy: - -
Port: - -
Username: - -
Password: - -
Server: wap.telstra.com/wap -
MMSC: - http://mmsc.telstra.com:8002
MMS Proxy: - 10.1.1.180
MMS Port: - 80
MMS Protocol: WAP 2.0 WAP 2.0
MCC: 505 505
MNC: 01 01
Authent. Type: CHAP CHAP
APN Type: default,supl mms
If you aren't able to enter your APN settings
manually, you can phone Telstra on 12 51 11

Chapter 3 Using the 3G Stick 11
Please note this guide is provided for information only and
the material provided is current as at November 2011. The
setup information may be subject to change by each
independent service provider, as products evolve with time.
In doubt please contact your carrier to validate the settings.
Depending on your carrier, and the data plan you have
chosen, you may not be able to edit the cellular data
settings, as they are already saved in the sim card, the
setup will then be automatic.
Some carriers have a frequency of 850 MHz in certain
region, meaning the 3G stick will not be compatible
everywhere with all operators.

Chapter 3 Using the 3G Stick 12
3
Using the 3G Stick

Chapter 3 Using the 3G Stick 13
Inserting your Sim card
The Archos G9 3G stick can be connected on the network of all the major
cellphone providers. Your Archos G9 3G stick accepts any standard SIM
card.
To insert a SIM card, you need to:
1. Remove the Archos G9 3G stick cap, and push the unmarked side
of the case towards the plug.
2. Insert the sim card into its slot. Make sure to insert it properly.
3. Put back the case.

Chapter 3 Using the 3G Stick 14
Connecting your ARCHOS G9 3G Stick to a PC running
windows
Installation procedures may vary based on the operating system installed
on your PC.
1. Turn on your PC.
2. Plug the modem into the USB interface slot to begin software
installation.
Windows should automatically detect the new device and will prompt
you to begin installation.
3. After following the prompts of installation setup, upon completion, a
shortcut will be placed on your desktop for quick future access.
4. When you launch the application, a pin number may be required to
continue. Enter your sim card pin number.
NOTE
- If installation “auto-run” does not begin, you will need to locate the
“autoRun.exe” file in the driver path. Double-Click on AutoRun.exe
to run the installation manually.
- Please do not remove the SIM card when the modem is in use.
Upon successful installation of the USB modem program, the program
will launch automatically.
You may also double-click the short cut icon on the desktop to launch
the program.

Chapter 3 Using the 3G Stick 15
Connecting your ARCHOS G9 3G Stick to a Mac
This application requires MAC OS X10.4.9 or 10.6.
1. To install the modem connect the 3G Stick on MAC OS X. Please
double click on CD icon that appears on your desktop. Then click on
the installer icon "My Connection.pkg" or "HPSA USBModem.pkg",
depending on your case.
2. Click Continue.
3. Select the Partition where you want to install the application and click
“Continue” Follow the prompts until you are prompted to click
“Install”, and enter your password.
4. When the installation is finished, you need to restart your computer
to use the modem.
5. The application is automatically stored in your Application's folder.
You may keep this application in the Dock for easy access.
Clicking it will start the connecting process.

© Copyright® ARCHOS™ 2011. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without the
written consent of i-Tech representing Archos in Australia.
Other company and product names mentioned herein may be trademarks of their
respective companies.
Mention of third-party products is for informational purposes only and constitutes neither an
endorsement nor a recommendation. i-Tech assumes no responsibility with regards to the
performance or use of these products.
The above mentioned carriers have been tested with the 3G stick, and Archos G9 Tablets
successfully connected on their respective network.
Some carriers have a frequency of 850MHz in certain region though, meaning the 3G stick
will not be compatible everywhere with all operators.
Every effort has been made to ensure that the information in this manual is accurate.
Archos or i-Tech are not responsible for printing or clerical errors.
