Arctic Accelero L2 Plus User manual

• Superior cooling performance - 120 Watts
• Ultra quiet 92 mm PWM fan with low noise impeller
• RAM and voltage regulator cooling
• Pre-applied ARCTIC MX-4
• CrossFire and SLI compatible
Accelero L2 Plus
Superior Cooling Solution for Mainstream Graphic Cards
Main Features
www.arctic.ac
Year
Limited
Warranty
6

www.arctic.ac
Thanks to the mounting plate design in the
, it is compatible with a wide
range of graphic cards. The G-1 that is provided
for affixing RAMs and VRs optimizes heat
dissipation entirely. With a cooling capacity of
120 Watts, in addition to a 92 mm ultra quiet PWM
fan, this mechanism brings optimal cooling
performance and inaudible operation for any mid-
range graphic cards to perform at its fullest
extent.
Accelero L2 Plus
Compatibility
AMD Radeon
NVIDIA GeForce
HD 6870, 6850, 6790, 6770, 6750, 6670, 6670 (LP), 6570, 5850, 5830,
5770, 5570, 5550 (OEM), 4870, 4850, 4830, 4770, 4730, 4670, 4650,
4550, 4350 (LP), 3870, 3850, 3690, 3650, 3470, 3450, 2600 XT, 2600 Pro,
2400 XT, 2400 Pro, X1950 XTX, X1950 XT, X1950 Pro, X1950 GT, X1900
XTX, X1900 XT, X1900 GT, X1800 XT, X1800 XL, X1800 GTO, X1650 XT,
X1650 Pro, X1600 XT, X1600 Pro, X1550, X1300 XT, X1300 Pro, X1300
GTS 450, 240 (OEM), GT 440, 340, 330, 320, 240, 220, 130 (OEM), 9800
GTX+, 9800 GTX, 9800 GT, 9600 GT, 9600 GSO 512, 9600 GSO, 9500
GT, 9400 GT, 8800 GTS 512 (G92), 8800 GTS (G92), 8800 GT, 8800 GS
(9600GSO), 8600 GTS, 8600 GT GDDR3, 8600 GT DDR2, 8500 GT,
7950 GT, 7900 GTX, 7900 GT, 7900 GS, 7800 GTX 512, 7800 GTX, 7800
GT, 7600 GT, 7600 GS, 7200 GS (TC)
Air Flow
Max cooling capacity
Bearing
Weight
119 (L) x 94 (W) x 51 (H) mm
27 CFM/46 m³/h
120 Watts
250 g
Fluid Dynamic Bearing
Specifications:
Dimensions
92 mm
Fan
900 – 2000 RPM
Fan speed
Accelero L2 Plus
Superior Cooling Solution for Mainstream Graphic Cards
Cooling Performance at AMD HD 6770
Better
57 °C*
72 °C*
Accelero L2 Plus (at 2,000 RPM)
Stock Cooler (at 2,700 RPM)
Ambient temperature: 25 C
o*Heat spreader temperature
The compatibility list is based on AMD and NVIDIA's reference board layout only.
ARCTIC holds no responsibility for incompatibility on non standard cards. Please refer to
al2p.arctic.ac for the height restriction drawing and the latest compatibility list.
Noise Level at AMD HD 6770
0.4 Sone
0.7 Sone
Accelero L2 Plus (at 2,000 RPM)
Stock Cooler (at 2,700 RPM)
Better
Ambient temperature: 25 C
oTested with Accelero L2 Pro at 2,000 RPM
RAM and VR Cooling performance with G-1
G-1 (included)
Generic Thermal Tape (thickness: 0.15 mm)
0.75 °C/W
2.56 °C/W
Better
