Arctic Accelero Mono PLUS User manual

4
3
2
1
Accelero Mono PLUS
Installation Manual
Choose the correct mounting hole size and spacers.
Telepítési kézikönyv: www.arctic.ac/fileadmin/amp/manual_hu.pdf
Instrukcja montażu: www.arctic.ac/fileadmin/amp/manual_pl.pdf
Installatiehandleiding: www.arctic.ac/fileadmin/amp/manual_nl.pdf
Руководство пользователя: www.arctic.ac/fileadmin/amp/manual_ru.pdf
Manuale di installazione: www.arctic.ac/fileadmin/amp/manual_it.pdf
Montageanleitung: www.arctic.ac/fileadmin/amp/manual_de.pdf
Guide d’installation: www.arctic.ac/fileadmin/amp/manual_fr.pdf
Manual de instalación: www.arctic.ac/fileadmin/amp/manual_es.pdf
Manual de Instalação: www.arctic.ac/fileadmin/amp/manual_pt.pdf
Installationsmanual: www.arctic.ac/fileadmin/amp/manual_se.pdf
Instalační příručka: www.arctic.ac/fileadmin/amp/manual_cz.pdf
Mounting Hole Compatible Models Appropriate
Spacers
6
Note: This table is for reference only. Please refer to your actual VGA card holes' position during installation. Updated
information is available at amp.arctic.ac.
①① 53.2 mm x 53.2 mm
②② 51.0 mm x 61.0 mm
③③ 58.4 mm x 58.4 mm
2.0 mm
4.0 mm
4.0 mm
2.0 mm
43.2 mm x 43.2 mm
??
53.2 mm - use53.2 mm - use
51.0 mm - use51.0 mm - use
58.4 mm - use58.4 mm - use
43.2 mm - use43.2 mm - use
oror
Accessories
Screws (M2)
Heatsinks
Ax 11 Bx 2 Cx 4 Dx 4 Ex 5
4-pin Fan
Power
Adapter
VGA Bracket
Mixing Wand
G-1 (White Compound 2 g)G-1 (Grey Compound 2 g)
x 1 x 1 x 1 x 1 x 1
x 4 x 4 (4.0 mm) x 1 (2.0 mm) x 1
Washers Spacers
x 2
Preparation
2 3
Not cleaning circuit components thoroughly with an eraser leads to no
adhesiveness of the thermal adhesive at all.
Apply tape onto the circuit components in order to prevent short circuit
caused by RAM and VR heatsink interference.
Apply tape onto the circuit components in order to prevent short circuit
caused by RAM and VR heatsink interference.
4
IT
RU
1
Please ensure that the fan connector pin assignment on your VGA
board is in accordance with the following table. Main Cable Set
Pin No. Color Description
Pin 1 Black Ground
Pin 2 Red VDC
Pin 3 Yellow Signal
Pin 4 Blue PWM
5
NVIDIA GeForce:
GTX 670
2.0 mm
58.4 mm x 58.4 mm
or
or
NVIDIA GeForce:
GTS 450, 250, 240 (OEM), 150 (OEM), GT 340, 330, 320, 130 (OEM),
9800 GTX+, 9800 GTX, 9800 GT, 9600 GT, 9600 GSO 512, 9600 GSO,
8800 GTS 512 (G92), 8800 GTS (G92), 8800 GT, 8800 GS (9600GSO),
7950 GT, 7900 GTX, 7900 GT, 7900 GS, 7800 GTX 512, 7800 GTX,
7800 GT, 6800 Ultra Extreme, 6800 Ultra, 6800 GT, 6800 GS AGP, 6800,
6800 GS, 6800 AGP, 6800 XT AGP, 6800 XT, 6800 LE
AMD Radeon:
HD 7870, 7850, 6950, 6870, 6850, 6790, 5870, 5850, 5830, 4890, 4870,
4850, 4830, 3870, 3850, X1950 XTX, X1950 XT, X1950 Pro, X 1950 GT,
X1900 XTX, X1900 XT, X1900 GT, X1800 XT, X1800 XL, X1800 GTO
NVIDIA GeForce:
GTX 560 Ti, 560 SE, 560, 550 Ti, 460 SE, 460
NVIDIA GeForce:
GTX 465, 8800 GTX (G80), 8800 GTS (G80)
NVIDIA GeForce:
6600 GT AGP, 6600 GT, 6600 LE, 6600 DDR2, 6600
AMD Radeon:
HD 7770, 6770, 6750, 5770, 5750, 4770, 2600 XT, X1650 XT, X1650 Pro,
X1600 XT, X1600 Pro, X1550, X1300 XT, X1300 Pro, X1300
Mounting Plate
(only used for HD 7770,
6770, 5770 & 5750)

A
B
C
D
1
Installation of Accelero Mono PLUS
2
XX
X: < 55 mm
X: 55 mm - 65 mm
X: > 65 mm
A
B
C
3
Secure this cooler onto the VGA card by partially fastening each
screw from A to B to C to D with 2 clockwise rotations. Repeat this
until you have tightened all screws. Do not completely fasten any
screw in one step.
4
Tips for applying G-1
RAM Cure time
5 hours
1 2 4
Apply pressure
(10 sec)
3
Voltage regulator
(apply glue generously)
Voltage regulator
(apply glue generously)
Sample installation of the voltage regulator heatsinks and RAM heatsinks
1 2
Place the heatsinks without touching the mounting plate.
Bx 1
Heatsinks
Ax 8
Heatsinks
3
Apply G-1 on all VR and RAM components.
4
Cx 2
Heatsinks
Ex 1
Heatsinks
Warranty
This ARCTIC product includes a six-year limited warranty. Please visit warranty.arctic.ac for further details.
The thermal compound is already pre-applied to the heatsink. If the cooler is installed for a second time, we highly recommend using MX-4 from ARCTIC. Only this compound guarantees optimal
performance in combination with the surface of our heatsinks.
Thermal Compound
© 2012 ARCTIC (HK) Ltd. All Rights Reserved.
No part of this manual including the products described in it, may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the
express written permission of ARCTIC (HK) Ltd. In no event shall ARCTIC its directors or employees be liable for any indirect damages, incidental or consequential damages arising from any defect or error in this manual or product.
ARCTIC Switzerland AG
www.arctic.ac
7a
7b
8
+
5 mins
Spacer
You MUST thoroughly mix all
contents in the two bags of G-1
for 5 minutes and applied within
15 minutes thereafter. Otherwise,
there will be NO adhesiveness
of the glue.
Spacer
HD 7770 no spacers
HD 7770: Assure the clip
bends slightly but does
not touch the boards
