Arctica U/C User manual

U/C White Refrigerator/Freezer
U/C SS Refrigerator/Freezer
400LTR White Refrigerator/Freezer
400LTR SS Refrigerator/Freezer
600LTR White Refrigerator/Freezer
600LTR SS Refrigerator/Freezer
MD143 LTR U/C GLASS DOOR REFRIG
MD 356 LTR U/R GLASS DOOR REFRIG
MD 580 LTR U/R GLASS DOOR REFRIG
Please read the manual before you use this product
This manual contains Important Safety Instructions which
must be strictly followed when using this equipment.

Safety Tips
▲Position on a flat, stable surface.
▲A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove
any components or service panels on this product.
▲ Consult Local and National Standards to comply with
The following:
*Health and Safety at Work Legislation
* BS EN Codes of Pratice
*Fire Precautions
*IEE Wiring Regulations
*Building Regulations
▲ DO NOT use jet/pressure washers to clean the appliance
▲ DO NOT use the appliance outside.
▲ DO NOT use electrical appliances inside the appliance
(e.g. heaters, ice-cream makers etc.)
▲DO NOT stand or support yourselves on the base, drawers or doors.
▲DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
▲ DO NOT place more than 30 kg load on each shelf.
WARNING:
Keep ventilation openings, in the appliance enclosure or
In the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the
type recommended by the manufacturer.
▲ Bottles that contain a high percentage of alcohol must
be sealed and placed vertically in the refrigerator.
▲ Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
▲ Always switch off and disconnect the power supply to the
unit before cleaning.
▲Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local authorities.
▲If the power cord is damaged, it must be replaced by an agent or
a recommended qualified technician in order to avoid a hazard.
▲Do not store explosive substances such as aerosol can switch a
flammable propellant in this appliance.
▲This appliance can be used by children aged from 8 years and above
and persons with reduced physical sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concern inguse of the appliance in a safe
way and understand the hazards Involved, children shall not play
with the appliance, cleaning and user maintenance shall not be
made by children without supervision The instructions concerning
persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge and
children
playing with the appliance are not required. Sound pressure level
at workstation is far below 70dB.
Introduction
Please take a few moments to carefully read through this manual.
Correct maintenance and operation of this machine will provide the best
possible performance from your product.
Pack Contents
The following is included:
*Refrigerator or Freezer
*Shelves：
Model Shelf Bottom
shelf
HEC906/907/908/909/HEF540
SR20/SF20(S)/SR20G
2 1
HEC910/911/HED105/106/HEF541/542
SR40/60(S)/SR40VG/60
3 1
HEC912/913/HED107/108
SF40V(S)/SF60V(S)
6 1
*Door Key
*Instruction manual
*Shelf spacer and hook
*Waste water tray
We pride ourselves on quality and service, ensuring that at the time of
packaging the contents are supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your
dealer immediately.
Installation
Note: If the appliance has not been stored or move in an upright
position, let it stand upright for approximately 12 hours before
operation. If in doubt allow the appliance to stand.
1. Remove the appliance from the packaging. Make sure that all
protective plastic film and coatings are thoroughly removed from all
surfaces.
2. Maintain a distance of 20cm (7 inches) between the unit and walls or
other objects for ventilation. Increase this distance if the obstacle is a
heat source.
Note: Before using the appliance for the first time, clean the shelves
and interior with soapy water.
3. Set the brakes on the castors to keep the appliance in position OR
Level the appliance by adjusting the screw feet.
Removable Gaskets
The door gasket keeps in the cold. For cleaning, it is easy to remove
without the use of tools—simple and hygienic.
Lock/Unlock the Doors
A lock is fitted to the doors to ensure foodstuffs are kept secure within
your appliance. Use the keys provided to lock/unlock the door
All COMPACT models are equipped with a door lock, ensuring that
stocks are safe after closing.

The R600a and R290 refrigerant used by this refrigerator
Install bottom front panel
Bottom front panel is placed in interior box in when packing product,
install bottom front panel with screws before using the product.
Fitting the Shelves
1. Place one set of shelf guides on either side of the cabinet at the
desired height.
2. Slide the shelf into place.
3. Repeat for the remaining shelves.
Note: This is vital for ensuring correct drainage of
condensation.
Operation
Storing Food
To get the best results from your appliance, follow these instructions:
*Only store foodstuffs in the appliance when it has reached the
correct operating temperature.
*Do not place uncovered hot food or liquid inside the appliance.
*Wrap or cover food where possible.
*Do not obstruct the fans inside the appliance.
*Avoid opening the doors for prolonged periods of time.
Turn On
1. Close the door(s) of the appliance.
2. Ensure the power switch is set to {0} and turn on at the socket.
3. Switch on the Power{1}.The current temperature within the
appliance is displayed.
Automatic Defrost
Refrigerant or freezer has forced air system in
evaporator, which will automatically run a defrost cycle.
Note: The cycle starts from the time the appliance is initially
powered up.
To manually defrost the appliance:
1. Press and hold the DEFROST Button for 5 seconds.
2. The defrost cycle will start immediately and the Defrost LED
illuminates. The defrost will last a maximum of 30minutes.
Note: Starting a manual defrost also resets the automatic
defrost timer. The next automatic defrost will start six hours
after the manual defrost has finished.
3. Waste water is collected in the waste water tray.
Cleaning, Care& Maintenance
▲ Switch off and disconnect from the power supply before cleaning.
▲ Clean the interior of the appliance as often as possible.
▲ Do not use abrasive cleaning agents. These can leave harmful
residues.
▲Clean the door seal with water only.
▲Always wipe dry after cleaning.
▲ Do not allow water used in cleaning to run through the drain hole
into the evaporation pan.
▲ Take care when cleaning the rear of the appliance. Sharp edges can
cut.
▲An agent or qualified technician must carry out repairs if required.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the
appliance.
We recommend that our agent or qualified technician clean the
condenser.

Troubleshooting
If your appliance develops a fault, please check the following table before making a call to your retailer.
Fault Probable Cause Action
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and switched on
Plug and lead are damaged Call your agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call your agent or qualified Technician
The appliance turns on,
but the temperature is
too high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Call your agent or qualified Technician
Doors are not shut properly Check doors are shut and seals are not damaged
Appliance is located near a heat source or air flow
to the condenser is being interrupted
Move the refrigerator to a more suitable location
Ambient temperature is too high Increase ventilation or move appliance to a cooler
position
Unsuitable foodstuffs are being stored in the
appliance
Remove any excessive hot foodstuffs or blockages to
the fan
Appliance is overloaded Reduce the amount of food stored in the appliance
The appliance is leaking
water
The appliance is not properly leveled Adjust the screw feet to level the appliance(if
applicable)
The discharge outlet is blocked Clear the discharge ourlet
Movement of water to the drain is obstructed Clear the floor of the appliance(if applicable)
The water container is damaged Call your agent or qualified Technician
The drip tray is overflowing Empty the drip tray(if applicable)
The appliance is
unusually loud
Loose nut/screw Check and tighten all nuts and screws
The appliance has not been installed in a level or
stable position
Check installation position and change if necessary

Technical Specifications
Model
NO.
Model
（ref）
Voltage
V
Current
A
Temperature
℃
Net capacity
Lt.
Dimension
W*D*H(mm)
Weight
(kg) refrigerant
HEC906 SR20 220-240VAC
50Hz 1.4 0～8 170 595*653*870
42 R600a/54g
HEC907 SR20S
HEC908 SF20 220-240VAC
50Hz 2 -18～ -22
170 595*653*870 44 R600a/65g
HEC909 SF20S
HEF540 SR20G 220-240VAC
50Hz 1.4 0～8 170 595*635*870
44 R600a/54g
HEC910 SR40 220-240VAC
50Hz 1.4 0～8 239 595*653*1840
68 R600a/128g
HEC911 SR40S
HEF541 SR40VG
220-240VAC
50Hz 1.4 0～8 220 595*635*1840
72 R600a/128g
HEC912 SF40V 220-240VAC
50Hz 2.6 -18～ -22
206 595*653*1840 85 R290/120g
HEC913 SF40VS
HED105 SR60 220-240VAC
50Hz 2 0～8 376 775*723*1840
81 R600a/145g
HED106 SR60S
HEF542 SR60VG
220-240VAC
50Hz 2 0～8 350 775*705*1840
85 R600a/145g
HED107 SF60V 220-240VAC
50Hz 2.8 -18～ -22
321 775*723*1840 101 R290/110g
HED108 SF60VS
IN CASE THE SUPPLY CABLE IS DAMAGED. THE MANUFACTURER OR THE
AFTER-SALES SERVICE. OR QUALIFIED TECHNICIAN SHALL REPLACE IT .IN
ORDER TO PREVENT ANY POSSIBLE RISK.
THE ELECTRIC PARTS REPAIR AND REPLACEMENT SHALL BE CARRIED OUT BY
QUALIFIED TECHNICIANS. WITH POWER SUPPLY DISCONNECTED.
ONLY QUALIFIED TECHNICIANS SHALL CARRY OUT THE EXTRAORDINARY
MAINTENANCE INTERVENTIONS.

Electrical Wiring
Appliances are supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as standard.
The plug is to be connected to a suitable mains socket. Appliances are wired as follows:
Live wire (colored brown) to terminal marked L
Neutral wire (colored blue) to terminal marked N
Earth wire (colored green/yellow) to terminal marked E
All appliances must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Disposal
EU regulations require refrigeration product to be disposed of by specialist companies who remove
or recycle all gasses, metal and plastic components.
Consult your local waste collection authority regarding disposal of your appliance. Local authorities
are not obliged to dispose of commercial refrigeration equipment but may be able to offer advice on how
to dispose of the equipment locally.
Compliance
Parts have undergone strict product testing in order to comply with regulatory standards and specifications
set by international, independent, and federal authorities.
Products have been approved to carry the following symbol:
Disposal of packaging
All packaging materials should be disposed of in an environmentally friendly way.
The cardboard may be used as scrap paper. The protective foil and the foam cushions are CFC-free.4
Do not allow children to play with the packaging and destroy plastic bags safely.
You can break or cut the cardboard into smaller pieces and give to a waste paper disposal service.
Environmental protection
Discarded electric appliances are recyclable and should not be discarded in the domestic waste!
Please actively support us in conserving resources and protecting the environment by returning this
appliance to the collection centers (if available).

Spare Parts List
Part Name Item No SF20&SF20S
HEC908/HEC909
SF40V&SF40VS
HEC912/HEC913
SF60V&SF60VS
HED107/HED108
SR20&SR20S
HEC906/HEC907
SR20G
HEF540
SR40&SR40S
HEC910/HEC911
SR60&SR60S
HED105/HED106
SR40VG
HEF541
SR60VG
HEF542
Glass door
SKC-2-150-0192-0
SKC-2-150-0185-0
SKC-2-150-0187-0
Door gasket
SKC-2-110-0433-0
SKC-2-110-0633-0
SKC-2-110-0645-0
SKC-2-110-0407-0
SKC-2-110-0473-0
SKC-2-110-0474-0
Door shaft
sleeve
SKC-2-110-0353-0
SKC-2-170-0218-0
Door hinge
(top)
SKC-2-006-0493-0
SKC-2-006-0635-0
SKC-2-006-0648-0
SKC-2-006-0620-0
Shaft for
hinge lever
skc-2-170-0211-0
Door hinge
(bottom)
SKC-2-001-2025-0
SKC-2-001-0494-0
Dixell
thermostat
SKC-4-030-0017-0
SKC-4-030-0018-0
Temperature
sensor SKC-4-030-0006-0
Door lock
SKC-2-170-0081-0
Contact
switch for
fan
SKC-4-050-0005-0
Evaporator
SKC-2-101-0071-0
SKC-2-101-0086-0
SKC-2-101-0087-0
SKC-2-101-0002-0
SKC-2-101-0049-0
SKC-2-101-0090-0
SKC-2-101-0091-0
Fan for SKC-4-001-0004-0

evaporator
SKC-4-001-0054-0
Defrost
heater
SKC-2-170-0283-0
SKC-4-020-0100-0
Condenser
SKC-2-102-0034-0
SKC-2-102-0022-0
SKC-2-102-0024-0
SKC-2-102-0018-0
SKC-2-102-0023-0
Fan for
condenser
SKC-4-001-0054-0
Wire shelf
SKC-2-120-0094-0
SKC-2-120-0105-0
SKC-2-120-0072-0
SKC-2-120-0066-0
SKC-2-120-0152-0
SKC-2-120-0069-0
SKC-2-120-0154-0
Shelf hook
SKC-2-110-0625-0
Shelf hold
bar
SKC-2-120-0073-0
SKC-9-000-0033-0
Wire shelf
（bottom）
SKC-2-120-0095-0
SKC-2-120-0068-0
SKC-2-120-0070-0
SKC-2-120-0038-0
SKC-2-120-0039-0
Power cord
（EU)
SKC-4-010-0080-0
SKC-4-010-0093-0
Compressor
SKC-4-040-0160-0
SKC-4-040-0059-0
SKC-4-040-0095-0
SKC-4-040-0177-0
Dry filter
SKC-2-103-0026-0
Adjustable
foot SKC-2-140-0008-0
Caster SKC-2-110-0638-0
Drain plug
SKC-2-110-0318-0
