AREBOS AR-HE-SPA4SLH User manual

Original User Manual –AREBOS SPA Pool
1
SPA Pool
*Style of the hot tub may differ from image shown above.*
List of contents
Please follow all security measures in this user´s manual to ensure a secure use.
Thank you for trusting in AREBOS.

Original User Manual –AREBOS SPA Pool
2
Table of Contents
1. Safety instructions ..........................................................3
1.1 Explanation of the symbols .......................................................................3
1.2 Specific safety instructions........................................................................ 4
1.2.1 Private Use ................................................................................................................. 4
1.2.2 Child safety................................................................................................................. 4
1.2.3 Electricity and electric shock hazard.......................................................................... 4
1.2.4 Cartridge filter and suction power............................................................................. 5
1.2.5 Health risks................................................................................................................. 5
1.2.6 Hyperthermia............................................................................................................. 6
1.2.7 Other precautions...................................................................................................... 6
2. Technical data.................................................................8
3. Installation......................................................................9
3.1 Find a safe location for the pool................................................................ 9
3.2 Assemble the spa pool ............................................................................ 10
3.3 Installation of LED lights (where applicable)............................................ 12
3.4 Fill the spa pool with water ..................................................................... 13
3.5 Connect the spa to the mains.................................................................. 13
4. Operation .....................................................................14
4.1 Before using the pool for the first time ................................................... 14
4.2 Control panel........................................................................................... 14
4.2.1 FILTER button........................................................................................................... 14
4.2.2 BUBBLE button......................................................................................................... 15
4.2.3 HEATER button......................................................................................................... 15
4.2.4 SET TEMP button...................................................................................................... 15
5. Cleaning, maintenance and storage ..............................16
5.1 Draining the water .................................................................................. 16
5.2 Filter cartridge......................................................................................... 16
5.3 Water treatment..................................................................................... 18
5.4 Water treatment products ...................................................................... 19
5.5 Cleaning the pool .................................................................................... 19
5.6 Repairs .................................................................................................... 19
5.7 Winter storage ........................................................................................ 20
6. Troubleshooting............................................................21
7. Environmentally friendly disposal .................................26
7.1 Disposal and packaging ........................................................................... 26
7.2 Disposal of old equipment....................................................................... 26
EU Declaration of Conformity ............................................27

Original User Manual –AREBOS SPA Pool
3
Thank you for buying our product. Please read the operating instructions carefully before using the
product for the first time. If you hand over the product to third parties, these operating
instructions must also be handed over. Keep the instruction manual for future reference.
1.Safety instructions
1.1 Explanation of the symbols
Warning! Read the safety
instructions carefully. Failure to
follow the safety precautions
can result in serious injury or
damage. Keep the operating
instructions in a safe place.
Use with caution when using this
article.
Caution! Make sure the product
is grounded!
Warning of electrical voltage!
Note: Pull out the mains plug!
Risk of drowning. It is essential to
ensure that children do not have
access to the spa without
supervision. To prevent accidents,
make sure that children are always
supervised when using the spa.
Shower thoroughly before
entering the spa to keep pollen,
dandruff, dust and other
particles out of the water.
Do not leave children unattended
when using the spa. Ensure that
children are not left unsupervised
near the spa.
Always cover the spa with the
supplied insulation cover after use.
Do not jump into the spa. Risk
of serious injury!
No open flame or fire!
The exterior and the interior shell of
the spa may incur irreparable
damage if it is closed to high
temperatures.

Original User Manual –AREBOS SPA Pool
4
1.2 Specific safety instructions
•This device was built according to the current state of the art and taking into account
the existing safety regulations. Nevertheless, this whirlpool can pose a hazard to
people and property if it is used improperly or not for the intended purpose or if the
safety and warning instructions are not followed.
1.2.1 Private Use
•This whirlpool is intended for private use only.
•Caution! As a pool owner, you must comply with local and state laws
regarding child safety, safety barriers and other safety requirements.
Please contact the local building authority for further details.
1.2.2 Child safety
•Risk of drowning! It is important to ensure that children do not have
access to the whirlpool without supervision.
•To avoid accidents, ensure that children are always supervised when using the spa.
•Warning! Make sure that children are not left near the spa unsupervised.
-Attach a self-closing door or lockable gate, fence or child grille.
-Always cover the whirlpool after use.
•Warning! Do not leave children unsupervised when using this hot tub to
minimize the risk of injury.
1.2.3 Electricity and electric shock hazard
•Warning! Maintenance and repair work on the electrical components
and any replacement of the power cable may only be carried out by a
qualified electrician.
•Warning! The pool is equipped with a residual current device or residual
current circuit breaker (RCCB) at the end of the power cable. The RCCB
must be checked before each use. Do not use the pool if the RCCB is not
working properly. Pull the mains plug until the error has been found and
rectified. Contact a qualified electrician to correct the error. Do not
bypass or open the RCCB. The RCCB must be easily accessible and visible,
with a minimum distance of 1.5 m to the whirlpool.
•Warning! The whirlpool must not have an external switching device, e.g.
a timer, or connected to a circuit that is switched on and off by a power
supply at certain times.
•Warning! The power supply must meet the product specifications. Do
not connect the device if the power supply does not meet the specified
regulations! Contact your local qualified electrician for more information.
The circuit for the device must be protected via a residual current device
with a rated residual current of max. 30 mA.
•Warning! This whirlpool has an earthed connection for an earthed solid
copper wire with a minimum diameter of 4 mm². A ground connection

Original User Manual –AREBOS SPA Pool
5
must be made between this device and any metal ground at a distance of
4.92 ft (1.5 m).
•Warning risk of electric shock! Do not use an extension cord to connect
the pool to the power supply.
•Warning risk of electric shock! Install the pool at a distance of at least
4.92 ft (1.5 m) from all metal surfaces. Metal parts must be permanently
connected to the ground connection using a solid copper cable.
•Warning risk of electric shock! It is not permitted to set up or operate
lighting devices, telephones, radios, televisions or other electrical devices
within a 4.92 ft (1.5 m) radius of the whirlpool.
•Warning risk of electric shock! Do not use the whirlpool when it is
raining.
•Warning! Always pull out the power plug before cleaning, removing,
servicing or making any other adjustments.
•Warning! The power cable must not be buried. Place the cable so that it
cannot be damaged by lawn mowers, hedge trimmers or other devices.
•Warning! If the connection cable of this device is damaged, it must be
replaced by a qualified electrician.
1.2.4 Cartridge filter and suction power
•If the cartridge filter is missing or defective, long hair or parts of the body can be
sucked in and get into the supply line, which can lead to serious accidents. Children in
particular are at risk of injury and must be protected from the dangers. Prevent risk
of injury:
-Never operate the whirlpool if the filter cartridge is defective or not attached.
-A defective filter cartridge must be replaced immediately. Make sure that only an
original part is used when replacing.
1.2.5 Health risks
•Warning! The water temperature in the whirlpool must not be higher
than 40°C. Water temperatures between 38 and 40°C are not considered
harmful to healthy adults. A lower temperature is recommended for
longer stays in the whirlpool (more than 10 minutes) or for small
children.
•Warning! Before using the whirlpool, the water temperature must be
measured with an accurate thermometer, as the tolerance of the
thermostat is +/- 2°C.
•Warning! Because higher water temperatures in the first few months of
a pregnancy pose a major risk to the unborn child, pregnant women (or
women who may be pregnant) must set the spa water temperature to a
maximum of 38°C. Pregnant women should always seek advice from
their doctor before using the pool.

Original User Manual –AREBOS SPA Pool
6
•Warning! The use of alcohol or drugs or medication before or during the
use of the pool can lead to loss of consciousness and therefore drowning.
•Warning! People who are taking medication should seek advice from a
doctor before using the pool as some medications can cause drowsiness,
increased heart rate, or abnormal blood pressure or blood circulation.
•Warning! People who are overweight, have heart diseases, have high or
low blood pressure, have circulatory disorders, or have diabetes should
seek medical advice before using the pool.
•Warning! Leave the pool immediately if you feel uncomfortable or
sleepy.
•Warning! Clean and change the water regularly to avoid bacterial
growth.
1.2.6 Hyperthermia
•A long stay in the water can lead to hyperthermia (increased body temperature).
Hyperthermia occurs when the body temperature exceeds the normal value of 37°C
by several degrees. Symptoms of hyperthermia include drowsiness, indifference and
an increase in body temperature. The consequences of hyperthermia can be:
-failure to recognize impending dangers;
-lack of heat awareness;
-lack of feeling for the heat when leaving the bubble bath;
-inability to leave the bubble bath;
-damage to the fetus in pregnant women;
-loss of consciousness and risk of drowning.
1.2.7 Other precautions
•Warning! This hot tub can be used by children aged 8 years and over as
well as by persons with reduced physical, sensory or mental abilities or
lack of experience and knowledge if they have been supervised or have
been instructed on the safe use of the device and understand the
resulting dangers. Children must not play with the device.
•Cleaning and user maintenance must not be performed by children
without supervision.
•Warning! Do not turn on the pool when the water inside is frozen.
•Warning! Pets should be kept away from the pool to avoid damage.
•Caution! To avoid damaging the pump, the pool must never be operated
if it is not filled with water.
•Danger! Enter and exit the pool slowly and carefully. There is a risk of
slipping on damp surfaces.
•Caution! For safe bathing pleasure and to avoid damage to the
components of the whirlpool, professional water cleaning is required.
Use water care products in accordance with the manufacturer's
instructions. Do not add bath oil or bath salts to the pool water.

Original User Manual –AREBOS SPA Pool
7
•Danger! Cover the pool when it is not in use. This can prevent children
from using the pool unsupervised.
•Caution! The pool should not be operated at temperatures below 4° C.
•Caution! The continuous filter and heating operation should not take
longer than 48 hours.

Original User Manual –AREBOS SPA Pool
8
2.Technical data
SPA Pool Type
(with LED
lighting)
CORFU
PALMA
TENERIFE
SANTORINI
BALI
MONACO
SPA pool
Type
FLORENCE
GRANADA
BARCELONA
ROME
BERGEN
VENICE
Model
AR-HE-SPA4SLH/4RLH/6SLH/6RLH/2OCLH/4OCLH
AR-HE-SPA4SAH/4RRH/6SRH/6RAH/2OHH/4OAH
Engine power
(heater)
1800 W
1800 W
1800 W
1800 W
1800 W
1800 W
Engine power
(air blower)
600 W
600 W
600 W
600 W
600 W
600 W
Power supply
AC 220-240V / 50Hz
Filter pump
power
12 V / 30 W
12 V / 30 W
12 V / 30 W
12 V / 30 W
12 V / 30 W
12 V / 30 W
Flow rate
1400 l/h
1400 l/h
1400 l/h
1400 l/h
1400 l/h
1400 l/h
Temperature
increasing rate
1.0 -2.0°C /
hour
1.0 -2.0°C /
hour
1.0 -2.0°C /
hour
1.0 -2.0°C /
hour
1.0 -2.0°C /
hour
1.0 -2.0°C /
hour
Cable length
5 m
5 m
5 m
5 m
5 m
5 m
User capacity/
Seating
capacity
4 persons
4 persons
6 persons
6 persons
2 persons
4 persons
Max. water
capacity
600 L
800 L
910 L
1000 L
550L
600L
Temperature
range
20°C - 40°C
20°C - 40°C
20°C - 40°C
20°C - 40°C
20°C - 40°C
20°C - 40°C
Number of
massage jets
110
110
130
130
90
110
Pool size
(external)
154x154cm
Ø180cm
185x185cm
Ø208cm
190x120cm
154x154cm
Pool size
(internal)
114X114cm
Ø140cm
145X145cm
Ø168cm
150 x 80cm
114X114cm
Height of the
pool
65cm
65cm
65cm
65cm
65cm
65cm
Form
square
round
square
round
oval
octagonal
Net weight
22 kg
22 kg
26 kg
26 kg
22kg
24kg

Original User Manual –AREBOS SPA Pool
9
3.Installation
3.1 Find a safe location for the pool
•Warning! Do not install your pool in any of the following places:
-Underneath electrical power lines or close to underground electrical installations (if in
doubt, ask your electrician).
-on an uneven surface.
-on a balcony.
-in a place where water and humidity can cause damage.
-on carpets or other materials that are damaged by moisture.
-on a base consisting of loose, non-loadbearing stones, wooden blocks or other materials
that can shift.
•This may damage the pool that is not covered by the warranty.
The subsurface must meet the following requirements:
•Stable
The subsurface must be solid and able to bear a weight of at least 360 kg/m². Concrete tiles
and wooden planks must be made in such a way that they can bear this weight. The total
weight of the whirlpool when filled with water and four people is approximately 1200 kg.
•Horizontal (level)
A horizontal surface is particularly important. The water level must always be horizontal. A
level and horizontal surface ensures that the weight is evenly distributed between the floor
area (on which the greatest weight rests) and the outer walls, which form a self-supporting
frame and ensure stability. The importance of adequate ground support cannot be
overstated.
•Drainage system
There must be a functional drainage system for the absorption and removal of any
overflowing water.
Indoor or outdoor assembly:
•If you would like to assemble your pool
outdoor, make sure that there are no sharp
objects in the vicinity of the spa.
•If you would like to assemble your pool
indoor, make sure the floor is waterproof
and has a non-slip surface. The room must
be well-ventilated to prevent excess
moisture.
ATTENTION!
Do not expose the SPA to direct sunlight
for prolonged periods. Be aware that direct
sunlight can cause the outer shell of the
spa to bulge and become irreversibly
deformed.

Original User Manual –AREBOS SPA Pool
10
3.2 Assemble the spa pool
•Open the box and pull out the folded pool and accessories.
•Do not use tools with blades (knives, cutters, etc.) to open the packaging to avoid
damaging the film.
•Step a. Lay the ground sheet on a flat, even surface free from sharp objects;
Uncoil the cables and plug which located under the motor block and remove packing
materials on the pipes.
•b. Open the air outlet on top of the filter heating element of the whirlpool and screw on the
filling hose.
