Argo MILO PLUS User manual

V
06/20
31
PORTABLE AIR CONDITIONER (LOCAL)
MILO PLUS
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
EN

V
06/20
32
The Refrigerant R290
 To realize the function of the air conditioner unit, a special refrigerant circulates in the
system. The refrigerant is the fluoride R290 = 3 GWP (Global warming potential). This
refrigerant is flammable and inodorous. It can lead to explosions under certain
conditions, however the flammability of this refrigerant is very low and it can be ignited
only by fire.
 Compared to other common refrigerants, R290 is a non-polluting refrigerant with no
harm to the ozonosphere and a no effect upon the greenhouse effect. R290 has very
good thermodynamic features which lead to a really high energy efficiency. The
unitsthereforeneedless filling.
Warning:
Do not try to accelerate the defrosting process or to clean the appliance in different ways other
than those recommended by the manufacturer. Should repair be necessary, contact your
nearest authorized Argoclima Service Centre. Any repairs carried out by unqualified personnel
may be dangerous. The appliance has to be stored in a room that doesn’t have any
continuously operating ignition sources. (for example: open flames, an operating gas
appliance or an operating electric heater.) Do not pierce or burn.
Appliance has to be installed, operated and stored in a room with a floor area larger than 15
m
2
.
For repairs, strictly follow manufacturer’s instructions only for appliances filled with R290
flammable gas. Beawarethatrefrigerants do nothaveanyodour.
Appliance filled with flammable gas R290.
Before installing and using the appliance, read the owner’s manual.
Before repairing the appliance, read the service manual.

V 06/20
33
GENERAL OPERATING AND SAFETY INSTRUCTIONS
 This appliance is a local air conditioner designed for domestic use.
 Only use this air-conditioner as described in this manual.
 Ensure that the required voltage and frequency (220-240V/50 Hz)
match the available power source.
 Fuse style T3.15AH250V, the electricity passing through the fuse
cannot be above 3.15A.
 This appliance can be used by children aged from 8 years and
above and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
 Children shall not play with the appliance.
 Cleaning and user maintenance shall not be made by children
without supervision.
 Ensure that the electricity system is able to deliver the operating
current required by the air conditioner, in addition to that normally
absorbed by other appliances (household appliances, lighting

V 06/20
34
system, etc.). Please refer to the maximum power input data
indicated on the air conditioner's data plate.
 Connection to the electricity grid must take place in accordance
with current installation standards.
 Ensure that the automatic switches and system protection valves
are able to withstand a start-up current of 6A (normally for less than
1 second).
 The system socket must always be fitted with an efficient earth
connection.
 Make sure that the plug is fully inserted. Do not use multiple
adapters. Do not touch the plug with wet hands. Make sure that the
plug is clean.
 Do not use the plug as a means by which to start/stop the air
conditioner: use the ON/OFF button on the remote control or on the
control panel.
 Do not install the air conditioner in rooms where it may receive
water splashes (e.g. laundry rooms).
 This air conditioner can be used by children of 8 years of age or
older, and by persons with reduced physical, sensory and mental
abilities or who lack the necessary know-how and experience to
operate it, if under the supervision or instruction of a person
responsible for their safety, so that they are fully aware of the
attendant risks.
 Before moving or cleaning the device, ensure that it is unplugged
from the socket.
 Do not move the air conditioner while it is operating; first turn the
appliance off, check for any condensate build-up and empty it if
necessary.
 To turn the appliance off, set the remote control to OFF and remove
the plug from the socket. Pull on the plug only. Do not pull the cord.
 Do not use the appliance if the cord or plug are damaged. If the
power supply cord is damaged, it must be replaced by the

V 06/20
35
manufacturer, dealer or a similarly qualified person so as to avoid
any safety risks.
 Keep the unit away from fire, possible fire sources, inflammable or
explosive objects.
 Do not leave the unit unattended while it’s operating, turn the unit
off and unplug it.
 If drainage hose is used, the ambient temperature musnt’t be lower
than 0°C. It can cause water leakage to the air conditioner.
 Do not splash or pour water on the air conditioner
PRECAUTION!
 Do not insert any objects into the air conditioner: this is very
dangerous as the fan turns at high speed.
 Ensure that air circulates freely around the unit. Do not cover
the air intake and delivery grilles with drapes or any other
means.
WARNING!
 The air conditioner must be positioned at least 50 cm from the wall
or any other obstacles, on a flat and stable surface so as to avoid
water leaks.
 The air conditioner is fitted with a system for protecting the
compressor from overload. This means that the compressor
only starts 3 minutes after its previous stoppage.
 Please wait at least 3 minutes before starting the unit. This
helps prevent the compressor from being damaged.
WARNING!

V 06/20
36
In the event of an anomaly, switch the appliance off and unplug
it from the socket. Do not dismantle or attempt to repair or
modify the product. In the event of a malfunction, contact the
service centre directly.
WARNING!
 Do not expose the air conditioner to direct sunlight, as the
colour of the materials may change; moreover, the appliance
may overheat causing the protection mechanism to intervene
and switch the appliance off.
 Do not use insecticides, oils, detergents or spray paints near
the appliance; do not use aggressive chemical detergents to
clean the casing: this may damage the finish and colour.
 Close all open windows to maximise air conditioning
efficiency.
The manufacturer will not be held liable if safety and accident
prevention rules are not observed.

V 06/20
37
DESCRIZIONE DELL’APPARECCHIO
FRONT VIEW REAR VIEW

V
06/20
1) CONTROL PANEL
AND FUNCTION BUTTONS
WITHOUT REMOTE CONTROL
2) VERTICAL FINS AND AIR INTAKE
3) WHEELS
4) CORD CABLE CLAMP
5) POWER CORD
6) AIR FILTER
Min/max operating limits (internal
temperature)
Cooling: 16 °C DB / 35 °C DB
Heating: 10 °C DB / 27 °C DB
Dehumidification: 16 °C DB / 35 °C DB
Cooling mode room temperature adjustment range: 16 °C DB
PRE
-
OPERATING CHECKS AND OPERATIONS
The following space must be maintained to ensure the operating efficiency of the portable air conditioner.
APPLIANCE START
Open the packaging and remove the box from above. Remove the product and the other elements supplied
(illustrated in the box below).
LCD remote control
Round fitting for window (1) to
be positioned between the end
of the tube and the end fitting
for the window(in the
packaging is the same fitting
mounted on the porthole kit
AND FUNCTION BUTTONS
7) AIR FILTER
8) AIR EXPULSION HOSE
9) JOINT
10) END FITTING FOR WINDOW
11) REMOTE CONTROL
temperature)
Cooling mode room temperature adjustment range: 16 °C DB
/ 30 °C DB
OPERATING CHECKS AND OPERATIONS
The following space must be maintained to ensure the operating efficiency of the portable air conditioner.
APPLIANCE START
-
UP
Open the packaging and remove the box from above. Remove the product and the other elements supplied
Type AAA batteries for the
remote control
End fitting for window,
supplied into 2 partsto be
joined with 2 tabs that fit
together. (2)
38
The following space must be maintained to ensure the operating efficiency of the portable air conditioner.
Open the packaging and remove the box from above. Remove the product and the other elements supplied

V
06/20
39
(A).
Flat fitting for positioning
between the air discharge
outlet and the hose
Hose
Drain hose Cord winder
Drainage pipe
Screws
Window unit kit (3 pcs)
(A+B+C)
Round fitting for window unit, to be
positioned between the end of the
tube and the window unit (A)
Window unit (B) Cap (C)
Position the product vertically on a flat and stable surface, as close as possible to a window and at least 50 cm from walls
or other nearby obstacles.
INSTALLATION OF CORD WINDER HOOKS
Install the cord winder hooks to the back of the unit using the
screws, as shown in the figure.
The hooks must be positioned facing upwards and
downwards.
When the appliance is not being used, wind the power
cord around the hooks.
Wind the cord around the hook.
USE WITH END FITTING FOR WINDOW
Connect the flat fitting to the hose, extend the hose as far as
necessary for reaching the outside and it connect to the back
of the air conditioner.
Next, slide the flat fitting downwards into the grooves (A)
and secure it with the hook (B).
The upward-facing side of the flat fitting is marked "TOP".
1. Hook
2.
Screw

V 06/20
40
Connect the round window fitting (1) to the end of the hose
then the end fitting for the window (2), previously obtained by
joining parts A and B
Open the windows and lock one of the two leaves with the
handle.
Place the end fitting against the fixed leaf of the window,
and draw the other leaf towards it.
USE WITH WINDOW UNIT KIT
1. To make the hole in the glass it is advisable to take
the porthole kit accessory to the glazier.
2. Insert the window unit into the window.
3. Insert the round fitting into the retractable flexible pipe and
insert the latter with its round fitting into the window unit
without the plug..
4. Insert the round fitting onto the flexible pipe.
5.Insert the flat fitting onto the hose. 6. Slide the flat fitting downwards into the grooves (A) and

V 06/20
41
secure it with the hook (B).
The upward-facing side of the flat fitting is marked "TOP".
7. The outlet must be between 40 cm and 130 cm above the ground. Avoid tight curves or bends in the flexiblehose.
8. If the air conditioner is not used for prolonged periods, disconnect the pipe and plug the window unit.
Connect the power cord to a suitable electric socket (220–240 V). Insert the supplied batteries into the remote control and
make sure the poles match. Select the desiredoperating mode from the remote control.
HOW TO USE THE APPLIANCE
This appliance can be used for cooling, dehumidifying and ventilating.
When switching between modes, the fan continues to rotate but the compressor stops: the compressor will start after 3
minutes. This delay protects the compressor from potential damage.

V 06/20
42
Cooling, Heating, Fan Dehumidifying
THE DISCHARGE TUBE MUST ALWAYS BE CONNECTED to the appliance: the only exception is when the
appliance is used solely for dehumidification, in which case it is advisable to let the appliance discharge
directly into the environment for maximum efficiency (consult the "Dehumidification Mode" paragraph).
Regularly clean the air filters beneath the easily removable rear grille to keep the air conditioner working efficiently.
OPERAT
ING MODES
1. COOLING MODE (COOL)
 The first time it is turned on, the air conditioner operates in ventilation
 Press the MODE button to select Cool mode
 The "Cool" LED on the control panel will turn on.
 The temperature can be adjusted to between 16 °C and 30 °C.
 In this mode, whenever the ON/OFF button is pressed, the unit switches off, the appliance saves the temperature
setting and, when switched back on again, retains this setting.
 In this mode, the fan speed can be adjusted and the Timer and SLEEP functions can be set.
 For more silent operation, run the fan at low speed.
2. HEATING MODE (HEAT)
 The “Heat” LED on the control panel will turn on.
 The temperature can be adjusted to between 16 °C and 30 °C.
 In this mode, each time the ON/OFF button is pressed the unit switches off, the appliance saves the temperature
setting and retains this setting when it is switched on again.
 In this mode, the fan speed can be adjusted and the Timer and SLEEP functions can be set.
 For more silent operation, run the fan at low speed.
3. DEHUMIDIFICATION MODE (DRY)
 Press the MODE button to select Dry.
 The temperature is controlled by the PCB and cannot be regulated.
 In this mode, whenever the ON/OFF button is pressed, the unit switches off, the appliance saves the settings
and, when switched back on again, retains them.
 The fan speed is set to low and cannot be adjusted.
NOTE
The air conditioner does not cool the room when it is used as a dehumidifier.
When the appliance is used as a dehumidifier, the flexible hose must not be connected.
For maximum dehumidification efficiency, leave the rear discharge attachment free to discharge directly into the
environment.
The dehumidification mode is recommended during autumn and winter.
If used in summer, it is best to leave the flexible hose attached so that the hot air can be discharged
towards the outside rather than into the room.
During dehumidification, continuous drainage should be implemented (consult the next chapter, "CONDENSATE
ELIMINATION").
4. VENTILATION MODE (FAN ONLY)
 Press the MODE button to select Fan and wait until the relative icon appears.

In this mode, the fan speed can be adjusted.

V
06/20
43

The temperature cannot be adjusted.
HOW TO ELIMINATE CONDENSATE
This appliance automatically vaporises condensate in the cooling and heating mode.
When the air conditioner operates in cooling and heating mode, there is no need to drain condensate continuously; only
in certain weather conditions with very humid air may it occur that water deposits inside the unit. When its inner tank is
full, the air conditioner beeps 8 times and the message "H8" appears on the display to signal that the tank is full
and stop the appliance's operation.
Cooling and Heating
When the unit operates in the cooling and heating mode, ensure that the
rubber cap closing the drainage opening on the back of the appliance is
properly positioned.
To empty the container, switch the air conditioner off and unplug the cord.
Remove the cap from the rear drainage opening and place its end over a
normal drain. Ensure that the tube is not twisted or bent. The tube must
slope downwards. Re-close the drainage opening with the cap, insert it into
the clamp and resume use of the air conditioner.
Dehumidification
WARNING!
When using the air conditioner in dehumidification mode, always dispose continuous drainage, in order to maximise
dehumidification efficiency.
Use the drainage outlet on the appliance. The water can be drained into a drain by simply connecting a tube with 14
mm internal diameter (not supplied).
1. Remove the cap by turning it anti-
clockwise then remove the plug.
2. Screw the connection tube
provided turning it clockwise.
3. Next, insert the drainage tube
into the connection tube.
4. Avoid bends in the drainage tube.
REMOTE CONTROL
OPERATION
FOR OPTIMAL OPERATION OF THE REMOTE CONTROL UNIT, ADDRESS THE
TRANSMITTER HEAD TO THE RECEIVER LOCATED ON THE AIR CONDITIONER.
To operate the remote control press the ON / OFF button on the handset. The icon on the remote
control display will flash once and you will hear a sound signal indicating that the signal has been
sent to the air conditioner.
In the off mode, the set temperature and the set timer will be displayed on the remote control.

V 06/20
44
REMOTE CONTROL BATTERIES
Insert the batteries into the remote control, while respecting the
indicated polarities.
Only use type AAA 1.5V batteries.
Remove the batteries if the remote control is not used for a month
or longer.
Do not attempt to recharge the batteries.
Replace all batteries at the same time.
Do not throw the batteries into fire: they may explode.
INFORMATION FOR CORRECT DISPOSAL OF THE BATTERIES PURSUANT TO EUROPEAN DIRECTIVE
2006/66/EC and modifications by Directive 2013/56/EU
Replace the batteries when depleted. At the end of their working life, batteries must be disposed of separately from
unsorted waste. They must be must be delivered to appropriate separated waste disposal plants or to dealers that
provide a similar service. Separate waste disposal of batteries prevents potential negative effects on the
environment and human health resulting from inadequate disposal, and also allows the materials from which it is
made to be recovered and recycled in order to achieve significant savings in terms of energy and resources. The
separate disposal obligation is underlined by the crossed-out dustbin symbol appearing on the battery. Illegal
disposal of the product by the user is subject to administrative penalties as per current regulations.
FOR OPTIMAL OPERATION OF THE REMOTE CONTROL UNIT, ADDRESS THE
TRANSMITTER HEAD TO THE RECEIVER LOCATED ON THE AIR CONDITIONER.
To operate the remote control press the ON / OFF button on the handset. The icon on the remote
control display will flash once and you will hear a sound signal indicating that the signal has been
sent to the air conditioner.
In the off mode, the set temperature and the set timer will be displayed on the remote control.

V 06/20
45
1. ON/OFF BUTTON
2. TEMPERATURE AND TIMER BUTTON
3. MODE BUTTON
4. SWING BUTTON
5. TEMPERATURE AND TIMER BUTTON
6. FAN SPEED BUTTON
7. TIMER OFF BUTTON
8. CLOCK BUTTON
9. TIMER ON BUTTON
10. SLEEP BUTTON
11. TEMPERATURE SETTING BUTTON
13. X-FAN AND LIGHT BUTTON
14. TASTO WIFI
1. I Feelfunction
2. Auto Mode
3. Cool mode
4. Dry mode
5. Fan mode
6. Heat mode
7. TIMER ON/OFF function
8. Sleep mode
9. Light
10. Fan speed setting
11. Signal transmission
12. Turbo mode
13. 8°C heating function
14. Temp. display
15. Clock
16. TIMER ON/OFF Display
17. Parental lock
18. Up/down swing
19. X-Fan function
20. HEALTH function
21. AIR function
22. Set temp.
23. Outdoor ambient temp.
24. Indoor ambient temp.

V 06/20
46
(1) ON/OFFBUTTON
Press this button to switch the unit on or off.
When switched on, the appliance will start functioning based on its last settings (save function).
(2) MODE SELECTION BUTTON (MODE)
Press this button to select the various operating modes, according to the following sequence:
In the COOL mode the display lights up. In the DRY and FAN modes the display does not light up.
(3) TEMPERATURE + - AND TIMER ADJUSTMENT BUTTONS
The temperature can be adjusted to between 16 °C and 30 °C.
Increase temperature（+):
1) Allows for adjusting the desired temperature in cooling (COOL) mode.
2）Whenever the（+) button is pressed, the set temperature increases by 1 °C.
Decrease temperature (- ):
1) Allows for adjusting the desired temperature in cooling (COOL) mode.
2）Whenever the ( - ) button is pressed, the set temperature decreases by 1 °C.
The same button allows for setting the TIMER.
(4) FAN SPEED ADJUSTMENT BUTTON
Press this button when the appliance is switched on for adjusting the ventilation speed in cooling mode (AUTO), to low
(Low), medium (Med) or high (High).
The fan speed cannot be adjusted in DRY mode and is fixed to low speed.
(5) WIFI BUTTON (on both the remote control and portable unit)
Press this button to turn on/off the WiFi function. When the WiFi is on the LED is lighted on.
To reset WiFi settings hold this button for 10 seconds.
(6) “SWING” BUTTON
Press “SWING” top turn on or off the swing function.
X-FAN BUTTON ((on the remote control)
Pressing the X-FAN button in cooling or dehumidification mode, when the power is turned off the fan
continues to operate for about 2 minutes to completely dry the evaporator.
SLEEP BUTTON (on the remote control)

V 06/20
47
Press this button to activate the Sleep function, which automatically adapts the temperature to changes in body and
room temperature throughout the night, so as to optimise comfort when sleeping and minimise consumption.
In cooling mode, the temperature increases by 1 °C in an hour then by 2 °C in two hours, and remains in this setting
for the whole period. The Sleep function is not available in the ventilation, dehumidification and auto modes. The
indicator light turns on whenever the Sleep function is set.
TIMER BUTTON (onthe remote control)
Press and hold this button for 1 second to set the timer.
1）Timer-on (automatic switch-on)
When the appliance is off, this button is used to set a delay after which the unit will switch on.
Remote control: Press TIMER. The T-ON and H icons will light up on the remote control. Press the + and - buttons
within 5 seconds to set the delay. The T-ON icon will remain on to indicate that the TIMER has been set.
Portable unit: Press TIMER. Select a number of hours from 0.5 to 24. Press the TIMER button to confirm.
2）Timer-off (automatic switch-off)
When the appliance is running in the COOL mode, set a delay after which the unit will switch off.
Remote control: Press TIMER. The T-OFF and H icons will light up. Press the + and - buttons within 5 seconds to
set the delay. Select a number of hours from 0.5 to 24. Press the TIMER button to confirm. The T-OFF icon will
remain lit to indicate that the switch-off TIMER is running.
Portable unit: Press TIMER. Select a number of hours from 0.5 to 24. Press the TIMER button to confirm.
Resetting the timer: If a TIMER has been set, press TIMER to display the delay. Press TIMER again to cancel the
setting.
IFEEL FUNCTION
Press the "▲" and "MODE" buttons simultaneously to start the I FEEL function and the corresponding icon will
be displayed on the remote control. After setting this function, the remote control will send the room
temperature detected to the unit, which automatically adjusts the internal temperature based on the detected
temperature.
Press these two buttons again simultaneously to deactivate the I FEEL function and the icon will disappear.
When this function is active, place the remote control close to the user, in any case in the room where the air
conditioner is located, so that the latter can receive the signal sent by the remote control.
(7) TEMPERATURE AND ERROR DISPLAY
Problem Cause Solution
H8 Tank full of water. Empty the tank.
If the problem persists, contact a service centre.
F1 Room temperature sensorfailure. Contact a service centre.
F2 Failure of temperature sensor on the
evaporator.
Contact a service centre.
F0 Refrigerant leakage. Air conditioner
out of order.
Contact a service centre.
H3 Overload protection device on
compressor.
The room temperature exceeds the appliance's operating
range (beyond 35°) or there is too much humidity. Wait for
the temperature to drop below 35 °C.
Check if the evaporator and compressor are obstructed by
objects. If they are, remove the objects, disconnect the unit
then restore the power supply.
Clear the obstructed ventilation grilles.
If the problem persists, contact a service centre.
E8 Overloadprotection.
F4 The external temperature sensor has
short-circuited.
Contact the service centre.
The temperature and error display lights up only in the COOL mode. In the DRY and FAN modes the display does not light
up.
SAFETY FUNCTIONS
REMOTE CONTROL LOCK
Simultaneously press "+" and "-" to lock the remote control.
The "Lock" icon will light up on the remote control, and the latter will not respond to commands.
SWITCHING BETWEEN °C AND °F.
Press the "-" and "MODE" buttons simultaneously to switch between °C and °F.

V 06/20
48
LIGHT FUNCTION
Press the “+” and “FAN” buttons simultaneously for 3 seconds to set the activation/ deactivation of the lamp.
WIFI GUIDE
How to set and operate the air conditioner with Wifi
1. Make sure that the device (smartphone or Tablet) used is equipped with a standard
version of Android (version 4.4 or higher) and iOS (iOS7.0 or higher) as the operating
system. For more details refer to the App.
2. Units can be connected and controlled only via Wi-Fi network or via Hotspot function.
3. Routers with WEP encryption are not supported.
4. The application interface is universal for all products and many features may not match
for all units. It may vary depending on the operating system used or the update in use. Refer
to the currentversion.
5. If the access protection on your Router is active in the "MAC Filter" / "MAC address filter"
item, enable the access to the network of the MAC address of the device.
Installation and use instruction
1. Frame the QR Code using a QR Code Reader
or search for the "EWPE SMART" application in the app store
download and install the application.
Install the App by referring to its guide. Once the installation is complete, the icon
appears on the smartphone's home page.
NB:
Before starting any procedure, disconnect the power supply from the product, allow
a few minutes to pass and reconnect it.

V 06/20
49
2. Registration and access.
After installing the application, open "EWPE SMART" and click Sign up to register.
PLEASE NOTE:
• USERNAME: must be UNIQUE, composed of name + number, without spaces (egRossi57)
• Personal email: if already registered, retrieve Username / Password. It is not possible to create
another account with the same mail.
• PASSWORD: must have at least one capital letter, symbols or special characters (- ;, etc.) and
numbers.
• Repeat PASSWORD written above
• EUROPE country
Open the app Make the registration before Access
3. Addingunits
Clicking on the icon of the little man opens a menu that includes, among other things, the
"Help" function.
Follow the instructions that appear on your device to add the unit.or add a new unit, press +
in the upper right corner of the homepage.
A menu appears with all the categories of devices that can be connected.

V
06/20
50
Select the relevant type:
1) in case of a portable air conditioner: the third box on right
2) in case of rensidential air conditioner: the fist box on left
3) in case of commercial air conditioner: the central box
