Air conditioner without outdoor unit
APOLLO
SERVICE MANUAL
I. Removing back panel
1. first remove a total of 6 screws on the left and right sides of the front shell with a
screwdriver; remove the screws fixed to the back plate.
2. pull the back plate outward by hand to ensure that the upper and lower clamps of the
front shell are detached from the back plate.
The front housing and the rear back plate
joint has the clasp, when disassembles pays
attention.
The front housing and the rear back plate
joint has the clasp, when disassembles pays
attention.
II. Removal of front housing assemblies
1. swing the guide plate to the horizontal position, remove the three screws behind the guide
plate with a screwdriver.
2. remove the 2 screws fixed on the electronic control box cover, remove the electronic
control box cover, and pull out the connected terminal for subsequent disassembly and
maintenance. .
3. slightly lift the base with the hand, pull the front shell out, the left and right sides of the
front shell and the machine left and right sides of the sheet metal joint clip to ensure that has
been detached, the front shell bottom and the machine inside the base joint clip to ensure
that has been detached, horizontal move out of the front shell, when moving out pay
attention to loosen the connection line.
III. Dismantling of electronic control components
1. remove the 2 screws of the fixing appliance box and remove the appliance box.
2. remove the screws fixing the main control PCB and remove the main control PCB.
Remove the screws that fix the PCB radiator and the electronic control box and remove the
PCB radiator.
3. remove the 2 screws on the fixed heat dissipation fan bracket and remove the
heat dissipation fan.
4. remove the screws that fix the reactor and remove the reactor.
VI. Remove the evaporator duct assembly
1. remove the screws that fix the motor press plate and remove the motor press
plate.
1. remove the screws fixed to the evaporator to the air duct assembly.
1. remove the screws fixed to the evaporator to the air duct
assembly.
