Arizona Instrument ZSP-150-F User manual

ARIZONA INSTRUMENT LLC
3375 N Delaware St | Chandler, AZ 85225
800.528.7411 | sales@azic.com | www.azic.com AZI P/N 700-0102-C
MADE IN THE USA
USER MANUAL
ZSP-150-F
ELECTRONIC BALANCE
December 2016
ARIZONA INSTRUMENT LLC
3375 N Delaware Street | Chandler, AZ 85225 USA
800.528.7411 | 602.470.1414 | f 602.281.1745
www.azic.com
Email:
General – [email protected]
International – intl@azic.com

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 2 of 22
ZSP-150-F Electronic Balance
Setup and Operation Manual
Thank you for choosing a Zeta Series SP-150 (ZSP-150-F) Electronic Balance from Arizona
Instrument LLC. AZI is pleased to provide you with a balance designed and manufactured for
years of reliable service and proudly made in the USA.
Please read this manual completely before using your balance. This information will enable you to
fully utilize your balance and should be located nearby to be used as a quick reference guide. The
balance is intended to be used only in the manner outlined in this manual. Misuse of the balance
may cause product failure.
PROPRIETARY RIGHTS NOTICE
The material in this manual contains valuable information developed by Arizona Instrument LLC for
use with the Computrac®Vapor Pro®line of moisture analyzers. No part of this manual can be
reproduced or transmitted in any form or by any means, electronic, mechanical, or otherwise. This
includes photocopying and recording or in connection with any information storage or retrieval system
without the express written permission of Arizona Instrument LLC.
ALL RIGHTS RESERVED
©Copyright 2007-2016 Arizona Instrument LLC

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 3 of 22
Table of Contents
ZSP-150-F Electronic Balance.............................................................................2
Unpacking and Setup.............................................................................................................4
Operating Environment..........................................................................................................4
Leveling the Balance .............................................................................................................5
Connecting to an Electrical Outlet.........................................................................................5
The On/Off Button (I/O)........................................................................................................6
RS-232 Interface Cable..........................................................................................................6
Connecting the ZSP-150-F to the Vapor Pro®/ Vapor Pro Rx®...........................................7
Using the ZSP-150-F with the Vapor Pro® / Vapor Pro®Rx.................................................7
Connecting the ZSP-150-F to the Vapor Pro®XL ................................................................8
Using the ZSP-150-F with the Vapor Pro® XL......................................................................8
ZSP-150-F Front Panel Display and Controls.......................................................................9
The ON/OFF (I/O) Button.....................................................................................................9
The ZERO Buttons ................................................................................................................9
The MODE Button.................................................................................................................9
The SEND Button..................................................................................................................9
The RANGE/FUNCTION Button.......................................................................................10
CAL 1 [Auto-Calibration] - Using an external calibration weight......................................10
CAL 2 - Linearity ................................................................................................................11
Capacity Tracker..................................................................................................................11
Selectable Vibration Filters and Stability Indicator.............................................................11
ZSP-150-F Rear Panel.........................................................................................................12
RS-232 Front Panel Configuration......................................................................................12
Troubleshooting Guide.......................................................................................14
ZSP-150-F Specifications ..................................................................................15
FCC Compliance................................................................................................16
Limited Warranty...............................................................................................16
Extended Warranty.............................................................................................16
Returned Goods Policy.......................................................................................17
Balance Kit Contents and AZI Part Numbers....................................................17
Appendix A - Front Panel Parts Counting .........................................................18
Appendix B - Weight Checking.........................................................................19
Appendix C - Live Animal/Severe Environment Weighing (T)........................20
Appendix D - Percent Weighing (%).................................................................21
Trademark and Copyright Protection.................................................................22

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 4 of 22
Unpacking and Setup
The balance, weighing pans, remote power supply and windscreen are packed in a foam support to
protect them from shock during shipping and handling. Save and reuse all packing material for future
shipments. A null modem cable, a 100g weight and this user’s manual are also packed with the
balance. Refer to Balance Kit Contents and AZI Part Numbers on page 17 for a complete list of
the contents of the kit and the associated AZI part numbers.
Operating Environment
The environment in which your balance is used is very important. Air movement, temperature
changes, vibrations, direct sunlight, etc. influence the performance of high precision balances.
Therefore, place your balance on a solid, sturdy surface that is free of air currents and vibration and
not in direct sunlight. The surface should not be magnetic and should be located away from doors,
windows, heaters, air conditioners and fans.
Figure 1 - Balance Full View

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 5 of 22
Leveling the Balance
Adjust (turn) the front feet (see Figure 2) to level the balance by centering the bubble in the level
indicator, which is shown in Figure 1. Turning the foot as shown below raises that side of the
balance and an opposite adjustment lowers it. Turn both feet together to raise or lower the front of
the balance. When properly adjusted the metal center shaft of the assembly will protrude from the
center of the plastic foot and will support the balance. The plastic foot will be raised up against the
bottom of the balance and will not be touching the weighing table.
Connecting to an Electrical Outlet
The balance is supplied with a 115/230 VAC, 50/60 Hz automatic switching, remote power supply
with five international plug adapters. This power supply will work with most electrical outlets.
However, before making any connections, verify that the power (VAC) requirement shown on the
power supply is compatible with the AC power outlet to which the balance will be connected and the
proper plug adapter for your outlet is installed on the power supply.
First, plug the round connector into the rear panel receptacle.
Then, plug the power supply into an AC outlet.
NOTE: Your balance must be plugged in and switched on for at least one (1) hour, then calibrated,
prior to use. Please see the calibration instructions on page 10.
AZI recommends that the balance be plugged into an electrical outlet at all times. This ensures that
the balance is always warmed up and ready to use.
Figure 2 - Leveling the Balance

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 6 of 22
The On/Off Button (I/O)
Press the ON/OFF (I/O) button one time to turn on the balance and observe the turn-on sequence
shown below.
During this sequence the balance is doing an automatic systems
check to verify it is functioning properly. After the balance has
been plugged in and turned on, allow it to warm up for at least 1
hour, then follow the Auto-calibration instructions (page 10) to
calibrate the balance.
RS-232 Interface Cable
Your balance is equipped with a bi-directional RS-232 compatible interface. The included Null
Modem Cable (AZI P/N 200-0069) is a custom cable manufactured to the following diagram. Only
this cable will provide the connections necessary for the ZSP-150-F Balance to communicate with the
Computrac®Vapor Pro®series of moisture analyzers.
ZSP-150-F's Null Modem Cable
Figure 3 - Turn-On Sequence

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 7 of 22
Connecting the ZSP-150-F to the Vapor Pro®/ Vapor Pro Rx®
The balance is configured to interface directly with the Vapor Pro®series of Moisture Analyzers.
Weight readings at the balance can be transmitted directly to the Vapor Pro®or Vapor Pro®Rx
through the null modem cable connection.
To enable this communication between the balance and the Vapor Pro®/ Vapor Pro®Rx:
•Power to both units should be switched OFF.
•Connect the null modem cable (AZI P/N 200-0069) to the RS-232 connector at the rear of the
balance. Connect the other end of the cable to the balance connector at the rear of the Vapor
Pro®/Vapor Pro®Rx.
•Switch the power to both units ON.
•On the Vapor Pro®/Vapor Pro®Rx, press the [Menu] key.
•Use the [Down] key to highlight the SETUP MENU.
•Press the [Selct] key to access this menu.
•Highlight the EXT BALANCE SETUP option and press [Selct].
•Highlight and select the SELECT BALANCE DRIVER option.
•Use the [Edit] key to select AZISP150 as the external balance.
•Press [Quit] and then [Accpt] key to program this option.
•Select the CHECK BALANCE COMM option to verify the cable is connected and that the
Vapor Pro® /Vapor Pro®Rx and the balance are communicating.
•Use the [Esc] key to return to the MAIN MENU.
If the Communication Check is not successful, the balance’s communication settings need to be reset
to their factory presets. Refer to RS-232 Front Panel Configuration on page 12 for instructions on
resetting the balance to the required factory presets.
Using the ZSP-150-F with the Vapor Pro® / Vapor Pro®Rx
•From the MAIN MENU on the connected Vapor Pro®/Vapor Pro®Rx, select the MEMORY
START MENU and then ADD/EDIT MEMORY START.
•Access the memory start to be edited using the [Up] or [Down] keys and the [Selct] key.
•At the SAMPLE WEIGHT ENTRY MODE option, select DIGITAL BALANCE.
When a test is run using that memory start parameter, the Vapor Pro®/Vapor Pro®Rx will
automatically check for data communication. The weight readings from the external balance will be
displayed on the Vapor Pro®/Vapor Pro®Rx display. Follow the display prompts to proceed through
the weighing and testing sequence.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 8 of 22
Connecting the ZSP-150-F to the Vapor Pro®XL
The balance is configured to interface directly with the Vapor Pro®series of Moisture Analyzers.
Weight readings at the balance can be transmitted directly to the Vapor Pro®XL through the null
modem cable connection.
To enable this communication between the balance and the Vapor Pro®XL:
•Power to both units should be switched OFF.
•Connect the null modem cable (AZI P/N 200-0069) to the RS-232 connector at the rear of the
balance. Connect the other end of the cable to the TCI/BALANCE connector at the rear of the
Vapor Pro®XL.
•Switch the power to both units ON.
Using the ZSP-150-F with the Vapor Pro® XL
•From the MAIN MENU on the connected Vapor Pro®XL, select TEST PROGRAMS.
•Use the arrows keys to locate the desired Test Program and touch it to highlight it.
•Press [VIEW] to access the Test Program.
•Select TEST START OPTIONS.
•Set SAMPLE WEIGHT ENTRY: to Balance.
•Touch the top left corner of the screen to return to the previous screen or press the silver
Home button below the LCD to return to the Main Screen
When a test is run using this Test Program, the Vapor Pro®XL will automatically check for data
communication. The weight readings from the external balance will be displayed on the Vapor Pro®
XL display. Follow the instrument display prompts to proceed through the weighing and testing
sequence.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 9 of 22
ZSP-150-F Front Panel Display and Controls
Figure 4 - Balance Front Panel
The ON/OFF (I/O) Button
The ON/OFF (I/O) button is located in the upper left corner of the balance’s front panel. When the
balance is off, pressing the button will start the turn-on sequence shown in Figure 3. During this
sequence the balance is doing an automatic systems checkout to ensure it is functioning properly.
When the balance is on, pressing the ON/OFF button will turn off the balance.
The ZERO Buttons
There are two (2) ZERO buttons. Pressing either button at any time returns the display to zeros.
When a weighing that has been zeroed out is removed from the weighing pan, a negative reading is
displayed. To return the display to zeros, press one of the ZERO buttons.
The MODE Button
Pressing the MODE button starts the unit of weight cycle as follows: grams (g), carats (ct),
pennyweights (dwt), troy ounces (ozt), ounces (oz), pounds (lb), kilograms (kg), and milligrams (mg).
When the desired unit of weight appears, press the MODE button a second time to select that unit of
weight.
The SEND Button
The SEND button is not normally employed in everyday usage of the balance, although it is used in
certain specific configuration procedures, as detailed later in this manual.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 10 of 22
The RANGE/FUNCTION Button
Pressing the RANGE/FUNCTION button begins the following menu cycle:
•PCS – Front panel parts counting See Appendix A (p. 18) for details
•HI OK LO – Checkweighing See Appendix B (p. 19) for details
•CAL 1 – Auto-calibration See Auto-calibration on p. 10
•CAL 2 – Linearity – Factory Use Only DO NOT USE
•T – Live animal weighing See Appendix C (p. 20) for details
•% - Percent weighing See Appendix D (p. 21) for details
To select the desired function, press the MODE button when it appears on the display.
CAL 2 is set at the factory and should never require further adjustment. The procedure for CAL 1
begins below. For the other functions listed in the RANGE/FUNCTION menu cycle, refer to the
appendices, beginning on page 18.
CAL 1 [Auto-Calibration] - Using an external calibration weight
Perform auto-calibration every time you move your balance. It is extremely important to use high
quality weights and verify the balance has been warmed up for at least one (1) hour prior to
calibration.
User Action
Balance Response
1
Remove any containers or weighing
samples so that nothing is on the weighing
pan, then press the ZERO button.
Zeros are displayed.
2
Press the RANGE/FUNCTION button
Balance display cycles repeatedly through PCS, HI
OK LO, CAL 1, CAL 2, T and %.
3
Press the MODE button when CAL 1
appears.
CAL 1 and a flashing 0 are displayed.
4
Wait 10 seconds for the balance to
stabilize, then press the ZERO button.
The display stops flashing and a solid 0 is displayed.
In approximately 15 seconds, when this step is
complete, a single weight or two alternating weights
will begin flashing on the display.
5
Place one of the flashing weights in the
center of the balance’s weighing pan.
The display stops flashing the alternating weights
and the selected weight is displayed.
6
Wait 10 seconds for the balance to
stabilize, then press the ZERO button.
The display will momentarily blink, then the selected
weight will continue to be displayed. In approximately
15 seconds, when this step is complete, the display
will blank, flash “OK”, then display the calibration
weight including decimal places.
The balance is now
calibrated and in the normal weighing mode.
7
Remove the calibration weight.
The display returns to zeros.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 11 of 22
CAL 2 - Linearity
Linearity is set in the balance’s software at the factory during the manufacturing process. It requires a
special set of weights that are not available commercially. When a CAL 1 function is performed the
linearity is automatically reset as well. Unless the balance is damaged the linearity will not change.
Therefore, CAL 2 should never be performed by the user.
Capacity Tracker
The capacity tracker located between the 0% and 100% at the bottom of the front panel display
provides a graphic display of the used and unused portions of the weighing range. Each segment
represents 10% of the balance’s total capacity. As 10% of the balance’s capacity is used the first
segment will illuminate. As 20% of the balance’s capacity is reached the second segment will light
and so on.
Selectable Vibration Filters and Stability Indicator
Balances are equipped with three user-selectable vibration filters, which reduce fluctuating readings
in varying weighing conditions. The balance was delivered to you set in the high filtering mode (Fil
HI). This is the most aggressive filtering mode. Normal filtering (Fil nor) and low filtering (Fil Lo) can
be selected for quieter conditions and faster response.
The stability indicator, OK, is illuminated when the variance of the readings are below the preset
stability parameters as selected by the user. The stability indicator is useful in determining the
stability of the weighing environment. In normal weighing the OK stability indicator should come on
within five seconds after the sample has been placed on the pan and the windscreen is closed. If the
stability indicator does not come on or takes a very long time this indicates it is too noisy of an
environment for that level. Try improving the environment or raise the filter level To enter the
selection mode proceed as follows: To exit the selection mode and return to normal operation, turn
the balance off and then back on again at any time.
To enter the filter selection mode, proceed as follows:
User Action
Balance Response
1
Hold the MODE button down while pressing
the ON/OFF button.
OK and the current filter, Fil nor (filtering normal),
Fil Lo (filtering low), or Fil HI (filtering high) are
displayed.
2
Press the SEND button until the desired
vibration filter is displayed.
Displays selected filter.
3
Press the RANGE/FUNCTION button.
SAVEd is displayed followed by returning to
normal operation.
To exit the selection mode and return to normal operation, turn the balance off and then back on
again at any time.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 12 of 22
ZSP-150-F Rear Panel
The rear panel of the ZSP-150-F provides the power connector, an RS-232 connector, a USB
connector and a security bracket. The security bracket may be used to provide a convenient method
of securing the balance.
ZSP-150-F Rear Panel
RS-232 Front Panel Configuration
The RS-232 Configuration Mode allows changes to the baud rate, front panel control, software
protocol, parity and auto send parameters. The balance is preconfigured at Arizona Instrument to
communicate with the Computrac®Vapor Pro®moisture analyzers.
Any changes to the recommended configuration will affect communication with
the Vapor Pro®/ Vapor Pro®Rx or Vapor Pro®XL.
It is not necessary to follow the entire configuration procedure on the next page if only one
parameter is to be changed. Follow steps 1 and 2, and then use the MODE button to cycle through
the different parameters. When the parameter to be changed is displayed, toggle the setting using
the SEND button until the desired setting is displayed. Save the setting using the RANGE /
FUNCTION button. The balance will confirm by displaying “SAVEd” and then return to normal
operation.
USB
RS-232
Power
Security
Bracket

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 13 of 22
To enter RS-232 configuration mode, proceed as follows:
Procedure Display Reading
1
Hold the SEND button down while pressing the
ON/OFF button
The current baud rate is displayed
2
Press the SEND button until br 9600 is displayed.
br 9600
3
Press the MODE button to move to the next
parameter: PARITY
The current parity setting, PA EVEn,
PA odd or PA none is displayed.
4
Press the SEND button until PA none is displayed.
PA none
5
Press the MODE button to move to the next
parameter: AUTO SEND
The current auto send setting, AS OFF
or AS on is displayed.
6
Press the SEND button until AS ON is displayed.
AS ON
7
Press the MODE button to move to the next
parameter: CONTINUOUS SEND.
The current continuous send setting,
CS OFF or CS on is displayed.
8
Press the SEND button until CS OFF is displayed.
CS OFF
9
Press the MODE button to move to the next
parameter: SEND WHEN STABLE (SS).
The current send when stable setting,
SS OFF or SS on is displayed.
10
Press the SEND button until SS OFF is displayed.
SS OFF
11
Press the MODE button to move to the next
parameter: DISPLAY BLANKING.
The current display blanking setting, bL
on or bL OFF is displayed.
12
Press the SEND button until bL OFF is displayed.
bL OFF
13
Press the RANGE / FUNCTION button.
SAVEd is displayed followed by
returning to normal operation.
Changing any of these settings from the AZI factory
presets is NOT recommended, and will affect
communication with the Computrac®Vapor Pro®
moisture analyzers.
If any of the preset values are changed, use the above instructions
to restore the balance’s ability to communicate with the Computrac®
Vapor Pro®by resetting the values to the preset AZI defaults listed.
Verify the balance’s ability to communicate with the Vapor Pro®/ Vapor Pro®Rx as detailed in
Connecting the ZSP-150-F to the Vapor Pro®on page 7.
Settings Summary:
br 9600
PA NONE
AS ON
CS OFF
SS OFF
bL OFF

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 14 of 22
Troubleshooting Guide
PROBLEM
POSSIBLE CAUSE
POSSIBLE SOLUTION
The display is blank
Balance not turned on
Press ON/OFF button
Power cable not plugged in
Plug in power cable
No power from AC outlet
Turn on circuit breaker or change AC
outlets
OL appears on display
Maximum capacity exceeded
Reduce container weight
Weigh sample in smaller increments
UL appears on display
Pan is not in place
Ensure pan is positioned properly
Balance is out of range
Press ZERO button
Display is unstable
Drafts/air currents present
Install windscreen or relocate balance
Vibrations present
Isolate or relocate balance
Weight readings are
incorrect
Balance is out of calibration
Re-calibrate balance
Balance is not level
Level balance
Balance was not re-zeroed
Press ZERO before weighing
Unit of weight set incorrectly
Select desired weighing unit (p. 9)
Sample touching windscreen
Reposition sample
Display stays in turn-on
sequence
Sub-pan and/or weighing pan
not in place
Place pan(s) on balance
Excessive draft or vibration
Isolate or relocate balance
Power supply connected to wall
outlet before balance
Unplug from wall outlet, wait 5
seconds, re-plug into wall outlet.
Partially lit display,
“weird”/”garbage”
characters on the display
“Live” cord plugged into balance
Unplug from wall outlet, wait 5
seconds, re-plug into wall outlet.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 15 of 22
ZSP-150-F Specifications
Weighing Mode Single Range
Capacity 150 g
Readability 0.001 g
Tare Range 0-150 g
Repeatability (Standard Deviation) 0.001 g
Linearity ±0.0015 g
Stabilization Time User Selectable
Weighing Speed Adaptive
Update Interval 200 ms
Data Interface
RS-232 bidirectional interface is standard. Baud rates
are 4800, 9600 and 19,200
Pan Size Circular 4.5 inch diameter
Operating Temperature 5 °C to 40 °C
Relative Humidity
80% for temperatures up to 31 °C decreasing linearly
to 50% at 40 °C
Power Supply Automatic switching 115/230 Volts AC, 50/60 Hz ± 10%
Windscreen Circular 6 inch diameter x 3.5 inches high
Housing (W x D x H) 7.5" x 11.25" x 3.25"
Weight ≈ 9.5 lbs

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 16 of 22
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. The
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at their own expense.
Shielded interconnect cables and shielded power cords must be employed with this equipment to
ensure compliance with the pertinent RF emission limits governing this device.
Changes or modifications not expressly approved by Arizona Instrument could void the user's
authority to operate the equipment.
Limited Warranty
This Arizona Instrument Electronic Balance and its accessories are warranted against defects in
materials and workmanship for one (1) year from the date of delivery. During the warranty period,
Arizona Instrument will repair, or, at its option, replace at no charge, components that prove to be
defective. The equipment must be returned, shipping prepaid, to Arizona Instrument's product
service facility. This limited warranty does not apply if the equipment is damaged by accident or
misuse or as a result of service or modification by other than an Arizona Instrument LLC service
facility. The foregoing warranty is in lieu of all other warranties expressed or implied including but not
limited to any implied warranty of merchantability, fitness, or adequacy for any particular purpose or
use. Arizona Instrument LLC shall not be liable for any special, incidental or consequential damages
whether in contract, tort or otherwise.
Extended Warranty
Extended warranty coverage can be purchased in a one, two or three year term at the time of balance
purchase. Details are included on a separate information sheet accompanying the balance or by
calling Arizona Instrument at 1-800-528-7411.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 17 of 22
Returned Goods Policy
Should it become necessary to return any item to Arizona Instrument for any reason, please contact
our Customer Service Department at (800) 235-3360 or (602) 470-1414 to obtain a Return Materials
Authorization (RMA) Number. When you call, please be ready to provide the serial number and a
description of the problem. Frequently we can provide self-help information that will eliminate the
need for returning the unit(s). You may also obtain an RMA Number by contacting Customer Service
If equipment return is required, please pack the item in the original box and packing material. As an
alternate, place equipment in a snug-fitting box, then pack that box in a larger box with at least four
inches of packing material between the two boxes. Arizona Instrument does not assume
responsibility for under-packed items.
Please include the RMA# and the name and phone number of the person we should contact
regarding repair question(s).
Balance Kit Contents and AZI Part Numbers
The ZSP-150-F Electronic Balance is available from AZI as two different part numbers, depending on
your local line voltage, with contents as described below.
PART #
ITEM DESCRIPTION
Y990-0082
External Balance Kit, 110V or
Y990-0083
External Balance Kit, 220V
Kit Contents:
200-0069
Null Modem Cable
690-0024
100g Weight, Class F
700-0102
Manual, ZSP-150 External Balance (this manual)
990-0213
ZSP-150-F External Balance

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 18 of 22
Appendix A - Front Panel Parts Counting
Procedure
Display Reading
1
Press the RANGE/FUNCTION
button.
Display cycles repeatedly through PCS, HI-OK-LO,
CAL1, CAL2, T, and %.
2
Press the MODE button while PCS
appears on the display,
PCS and 0 flash. This is a prompt to zero the balance
with the container you will be using to weigh the initial
sample.
3
Place the empty container on the
pan, wait 10 seconds, then press
the ZERO button.
PCS and 10 flash. This is a prompt to place 10 pieces in
the container and press zero.
4
Place 10 pieces in the container,
wait 10 seconds, then press the
ZERO button.
PCS continues to flash and OK appears on the display
while a stable weight is obtained. Then 10.000, or
something very close to it appears on the display. The
number of decimal places depends on the weight. PCS
continues to flash. This prompts you that you may now
increase the size of the sample if you wish. The decimal
places are an aid. When adding more samples, if the
decimal part approaches .5 you cannot be sure of the
exact count.
5
If you need a larger sample, add
pieces (the balance will count them)
until the decimal part is near 0.7 or
0.3. Then press the ZERO button.
The balance will round to the nearest whole number but
still show the decimal places. This step may be repeated
as many times as you wish.
6
When you are satisfied the sample
is large enough, press the ZERO
button once again.
The balance rounds to the nearest whole number, the
decimal places disappear, and PCS lights steadily.
7
When you wish to count something
else, press the MODE button.
You are now back at step 2 with a flashing PCS and 0.
8
If you want to exit the counting
mode, press the MODE button
again.
You are now in the weighing mode you used just before
selecting pieces.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 19 of 22
Appendix B - Weight Checking
The following procedure checks the weight of individual parts against user-programmed upper and
lower weight limits.
Procedure
Display Reading
1
Press the RANGE/FUNCTION
button.
Display cycles repeatedly through PCS, HI-OK-LO,
CAL1, CAL2, Tand %.
2
Press the MODE button when HI-OK-
LO appears on the display.
HI, LO and O flash.
3
Press the ZERO button.
HI flashes and zeros are displayed.
4
Place weight on pan that represents
the upper limit of the acceptable
weight span.
HI flashes and weight is displayed.
5
Press the ZERO button.
LO flashes and upper limit weight is displayed.
6
Remove upper limit weight and place
weight on the pan that represents the
lower limit.
LO flashes and weight is displayed.
7
Press the ZERO button.
HI-OK-LO briefly appears then OK and the low limit
weight are displayed.
8
Remove low limit weight.
LO appears and zeros are displayed.
The balance is now ready to check the weight of parts. The balance displays OK along with the
weight of the part if the part is within the selected limits. If the part is too heavy, HI and the weight are
displayed. If the part is too light, LO and the weight are displayed. The limits are stored until the
balance is turned off. To exit weight checking, press the MODE button and the balance will return to
normal operation.

AZI Customer Service 800-528-7411 Manual, ZSP-150-F Page 20 of 22
Appendix C - Live Animal/Severe Environment Weighing (T)
Note: At any time during the T procedure you can reach the final reading more quickly by
pressing the RANGE/FUNCTION button. This resets the time averaging and allows the balance
to reach the final weight faster.
Procedure
Display Reading
1
Press the RANGE/FUNCTION button.
Display cycles repeatedly through PCS, HI-OK-LO, CAL 1,
CAL2, T, and %.
2
Press the MODE button when T
appears on the display.
T appears in the display and the balance is now in the time
averaging weighing mode.
3
Place a container/cage on the pan.
T appears in the display as well as a slowly increasing
weight of the container/cage.
4
When the balance has stabilized,
press the ZERO button to zero out the
container/cage weight.
T appears in the display as well as zeros.
5
Remove the container/cage and place
the sample/animal in the
container/cage.
T and a slowly decreasing negative weight are displayed.
6
Replace the container/cage with the
enclosed sample/animal on the
weighing pan.
After the sample/caged animal is placed on the pan, the
weight reading will slowly stop decreasing and then slowly
start increasing as the weight reading is averaged over
time. When the weight stops drifting upward, you have
reached the final time averaged weight reading.
7
If you want to reach the final time
averaged weight reading more quickly,
press the RANGE/FUNCTION button
This resets the time averaging mode.
The final time averaged weight reading is reached more
quickly.
8
If you want to exit the time averaging
weighing mode, press the MODE
button.
The balance returns to normal operation.
Table of contents
