EDLUND BBPZ-20 User manual

M191 RevA
Edlund Company, LLC 319 Queen City Park Rd, Burlington, VT 05401 1-800-772-2126 www.e d l un dco .co m
Edlund Wireless Pizza Scale
MODEL BBPZ-20
Model
Capacity (lbs./oz.)
Capacity (g)
Platform (in)
Display Size (in)
BBPZ-20
20 lbs. x 0.05 oz, 20 lbs. x 0.002 lbs.,20
lbs. x 1/8 oz, 320 oz x 0.05 oz, 320 oz x
1/8 oz
10000 g x 1g
10.0” x 10.0”
OP = 12.0” x 12.0”
LED= 1.75” x 4.5”
Overall= 9.5” x 5.0” x 2.0”
POWER SOURCE: INPUT: 100~240 VAC ~ 50/60 Hz. 0.4A OUTPUT: 5VDC 1A
-Not
Legal for Trade –
O p era ting I nstr uc tions :
Thescale oper a t es on eight AA ba tt er ies for the display and two AAA batteries for the base , or two 5-volt Mini-USB power supplies (part #PS200 for US 115V 60Hz and part
#PS201 for 230V 50-60Hz). The scale has an automatic power off f ea tur e . If a battery is used , the scale will shut off after 7 minutes if no weighing operation is per f ormed .
The Auto-off feature is disabled when the power supply is used . Replace batteries or use the power supply when the LED shows “H Lo” or “b Lo”. (H Low = Head unit; b
Low = Base)
To install the ba tt er ies in the readout , unscrew the two screws for the battery b ox , install eight AA ba tt er ies , (observing polarity) and reinstall the c o ve r . For the base, turn
the base over and unscrew the one screw for the battery box cover, install two AAA batteries (observing polarity) and reinstall the cover. If power supplies are used, the
base and readout must be plugged in. The base power jack is underneath the scale and the readout jack is on the back of the readout. Make sure the power supply tips
are fully sea t ed in the jack.
Turn on the scale by pressing the “On/Off/Mode/Cal”swit ch . The scale readout will illuminate all segments followed by dashes for approximately 3 secondsand then display
Ze ro . If the scale is o v er loaded , an “ E ” will be displayed ; remove the weight immediately otherwise you may damage the scale. The scale cannot weigh over 105% of max
capacity. When a product is placed on the scale pla tf orm , the weight of the product is shown on the scale display in the units in which the scale is w eighing . You can
change the weighing mode units by pressing the “On/Off/ Mode / Ca l” butt on . This pr oduc t can now be “tared out”, i.e. shown as zero on the scale display , by depressing
the “ Ta r e ” butt on . The display will illuminate the tare indicator in the upper left corner. If an additional product is then placed on the pla tf orm , the weight of this additional
product can also be “tared out”by depressing the “ Ta r e ” butt on . This tare operation can be repeated up to the full capacity of the scale .
If the total product is now removed from the pla tf orm , the weight of the total product will be shown as a negative value on the scale display . This negative value can now
be removed from the display by depressing the “ Ta r e ” button . Depressing the “On/ O ff/Mode/Cal ”button while the scale is on for greater than five seconds will turn the
scale off.
Key Pad Functions:
[ On / Off /Mode/Cal] ~ Press to turn the scale on while its off.
~ Press to turn scale off. (With the scale on the button must be pressed for greater than 5 seconds)
~
Press to cycle through the weight units.
~ Press and hold the key to enter user calibration mode (SCALE MUST BE OFF)
[Tare] ~ Press to Tare the weight.
Using the wireless Bluetooth connection:
1.) There is slide switch on both display head and the scale base to enable or disable Bluetooth operation. If there is no cable connection between display head and scale base, please
slide the both slide switches to “ON” to enable the wireless function on both. The weighing data will be sent from the scale base to the display head wirelessly. In order to save the
energy consumption once the cable connection is established, the power to the BLE modules will be cut off.
2.) There is a LED on both display head and the scale to show the wireless connection status:
LED of Scale base:
- Steady flashing while waiting to be connected
- Lit up solidly after wireless connection is established
LED of the Display head:
- Quick flashing when unpaired or searching
- Long flashing when paired and establishing connection
- Lit up solidly after wireless connection is established
Calibration procedure:
1) MUST start with the scale off to enter the calibration feature. Press and hold the “On/Off/Mode/Cal” key for greater than 5 seconds. The calibration weight (2000g) will
flash on the display.
2) Momentarily Press the “On/Off/Mode/Cal” key and the display will change to read “CAL 0 “. Gently place the correct calibration weight on the platform.
3) When the calibration is complete the unit will briefly display “CAL F”, remove weight and scale will return to NORMAL WEIGHING MODE.
Note: If “CAL E” appears, this indicates that a calibration error has occurred, and the calibration process must be repeated. “CAL E” can occur when the calibration steps are
not followed in the correct order, the incorrect calibration weight was used, or the weight was not placed on the scale in time. “CAL E” will remain on the display until any key is
pressed on the scale. The scale then returns to the NORMAL WEIGHING MODE, and the scale will revert to the previous calibration settings. The calibration procedure must
be repeated in order to change the scale calibration settings.

M191 RevA
Edlund Company, LLC 319 Queen City Park Rd, Burlington, VT 05401 1-800-772-2126 www.e d l un dco .co m
Troubleshooting:
1.) In a dry environment, static electricity may cause your scale to shut down. If this happens, press “On/Off”to turn scale back on.
FCC statements:
The device has been evaluated to meet general RF exposure requirement; The device can be used in portable exposure condition without restriction
Federal Communication Commission (FCC) Radiation.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment. Such
modifications or changes could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
‐Reorient or relocate the receiving antenna.
‐Increase the separation between the equipment and receiver.
‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
‐Consult the dealer or an experienced radio/TV technician for help.
ISED:
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada RSS exemptes de licence standard(s).
Son fonctionnement est soumis aux deux conditions suivantes:
(1) cet appareil ne peut pas provoquer d'interférences, et
(2) cet appareil doit accepter toute interférence, y compris celles pouvant causer un mauvais fonctionnement de l'appareil.
