ARMATIX iS1 User manual

ArmatixiS1 User Manual 1/19 2011-07-01
iS1 SmartSystem
User Manual

ArmatixiS1 User Manual 2/19 2011-07-01
Masthead
Shouldyou requirefurther information on ourproducts or technicalsupport,please
donot hesitateto contactus.
ArmatixGmbH
Feringastraße4
85774 Unterföhring
Germany
Tel.: +49 89 / 427 29 79 - 0
Fax: +49 89 / 427 29 79 - 79
[e-mail]
Managingdirectors: BerndDietel,Ernst Mauch,Guenter-Maximilian Hefner, Franz
Hermann
Companyregistered offices: Petersberg
Jena CountyCourt
HRB 501907
VAT ID:DE 235056291
Legal disclaimer:
Despitethegreatest care takenin the compilation ofthis document, datacan change
even at short notice.We can therefore giveno guaranteeor assumeanyliabilityfor
theup-to-dateness, correctness and completeness oftheinformation contained.
Content and layout of the operating manual areprotected by copyright.Duplicationof
thepagesortheir contents shall requiretheprior written approval ofARMATIX
GmbH,insofar as the duplication is notpermitted bylaw.
Copyrights 2011:
ArmatixGmbH,Unterföhring.
All rights reserved. Text, illustrationsand diagrams and theirlayoutin thisoperating
manual are protected bycopyright lawsand otherintellectualpropertyrights. The
content of thisoperating manualmustnotbe copied, distributed, modified or made
accessible to third parties for commercial purposes.

ArmatixiS1 User Manual 3/19 2011-07-01
Thisdevicecomplies with Part 15 ofthe FCC Rules. Operationissubjectto the
followingtwoconditions:
1. Thisdevicemaynot cause harmful interference, and
2. thisdevicemustaccept anyinterference received,including interference that
maycause undesired operation.
Changes or modifications not expresslyapprovedbythepartyresponsible for
compliancecouldvoidthe user's authorityto operate the equipment.
Note: Thisequipmenthasbeentested and found to complywith the
limits foraClass B digital device, pursuant topart 15of theFCC
Rules.Theselimits are designed to provide reasonableprotection
against harmful interferenceina residential installation. This
equipmentgenerates,usesand canradiateradiofrequencyenergyand, ifnot
installed and usedin accordancewith the instructions, maycause
harmful interferenceto radio communications.However, thereisno
guarantee that interferencewill notoccur ina particular installation.
If thisequipmentdoes causeharmful interferenceto radio or television
reception, whichcan be determined byturning theequipment off andon, theuser is
encouraged totrytocorrect theinterference byoneormore ofthefollowing
measures:
•Reorient or relocate the receivingantenna.
•Increase the separation between the equipment and receiver.
•Connect theequipmentintoan outlet onacircuit differentfrom that towhich
thereceiver isconnected.
•Consult thedealer or an experiencedradio/TV technicianfor help.

ArmatixiS1 User Manual 4/19 2011-07-01
Contents
1. Introducing....................................................................................................................6
2. Installing drivers...........................................................................................................7
3. Uninstalling drivers ....................................................................................................15
4. Troubleshooting.........................................................................................................16
4.1. WindowsXP Forces A Reboot AfterInstallingaDevice................................ 16
4.2. Driver InstallationFailsAnd WindowsXP Gives Error Code 10...................16
4.3. WindowsXP DisplaysAnErrorAnd Then Terminates Installation...............16
5. Contact Information...................................................................................................18
Appendix A - Revision History..........................................................................................19
Appendix B - Reference....................................................................................................20

ArmatixiS1 User Manual 5/19 2011-07-01
List of Figures
Figure 2. 1............................................................................................................................8
Figure 2. 2............................................................................................................................8
Figure 2. 3............................................................................................................................9
Figure 2. 4............................................................................................................................9
Figure 2. 5..........................................................................................................................10
Figure 2. 6..........................................................................................................................10
Figure 2. 7..........................................................................................................................11
Figure 2. 8..........................................................................................................................11
Figure 2. 9..........................................................................................................................12
Figure 2. 10........................................................................................................................12
Figure 2. 11........................................................................................................................13
Figure 2. 12........................................................................................................................13
Figure 2. 13......................................................................................................................144
Figure 4. 1
………………………………………………………………………………...177

ArmatixiS1 User Manual 6/19 2011-07-01
1. Introducing
Thisdocument describes theprocess of installing the Armatix iS1 device forthe
MicrosoftWindowsXP operating system.

ArmatixiS1 User Manual 7/19 2011-07-01
2. Installing drivers
To install the Armatix iS1deviceunder WindowsXP, followthe instructions
below:
•Use the iS1 driver CD or downloadthelatest drivers from the Armatix website
and unzip them to a location onyour PC.
•If you are runningWindowsXP or WindowsXP SP 1, temporarilydisconnect
your PC fromtheInternet.This canbe done byeither removing the network
cablefrom yourPCor bydisablingyour network card bygoingto the"Control
Panel\Network and Dial-Up Connections", right-clickingon theappropriate
connection and selecting "Disable" from the menu.The connection can bere-
enabledafter the installation is complete. Thisis not necessaryunder
WindowsXP SP 2 if configured to ask beforeconnecting to Windows Update.
WindowsXP SP 2 can have the settings for Windows Update changed
through"Control Panel\System" then selectthe "Hardware" tab andclick
"WindowsUpdate".
•Connect thedevice to a spare USB port on your PC. Once thecomposite
driver hasbeeninstalled Windows Found NewHardware Wizard will launch. If
there is no availableInternet connection or WindowsXP SP 2 is configured to
ask before connectingto WindowsUpdate,the screen shown in Figure 2.1 is
displayed.Select "No, not this time" fromtheoptionsavailable andthen click
"Next" toproceed with the installation. If there is anavailable internet
connection, WindowsXP willsilentlyconnect to the Windows Updatewebsite
and install anysuitable driveritfindsfor the device inpreference to thedriver
manuallyselected.
Figure 2. 1

ArmatixiS1 User Manual 8/19 2011-07-01
•Select "Install from a listor specific location (Advanced)" asshownin Figure
2.2belowandthen click "Next".
Figure 2. 2
•Select "Search forthebest driver inthese locations" and enter the filepath in
thecombo-box ("C:\CDM2.02.04" in Figure 2.3 below)or browse to it by
clicking the browse button. Once the file pathhas been entered in thebox,
click next toproceed.
Figure 2. 3

ArmatixiS1 User Manual 9/19 2011-07-01
•If WindowsXP is configured towarn when unsigned (non-WHQL certified)
drivers areaboutto be installed, themessage dialogue shown in Figure 2.4
willbe displayed unless installing a Microsoft WHQL certifieddriver. Click on
"ContinueAnyway" to continue withtheinstallation.IfWindows XP is
configured to ignore filesignature warnings,nomessagewillappear.
Figure 2. 4
•Thescreen shown inFigure 2.5 will bedisplayedas WindowsXP copies the
required driver files.
Figure 2. 5

ArmatixiS1 User Manual 10/19 2011-07-01
•Windowsshould then displayamessageindicatingthatthe installation was
successful (Figure 2.6). Click "Finish" to complete the installation forthefirst
port ofthe device.
Figure 2. 6
•TheFound NewHardware Wizard will launch automaticallytoinstalltheCOM
port emulation drivers. As above, select"No, not this time" From the options
and click "Next" toproceed with the installation (Figure 2.7).
Figure 2. 7

ArmatixiS1 User Manual 11/19 2011-07-01
•Select "Install from a listor specific location (Advanced)" asshownin Figure
2.8belowandthen click "Next".
Figure 2. 8
•Select "Search forthe best driver inthese locations" and enter the file path in
thecombo-box ("C:\CDM2.02.04" in figure 2.9 below) or browse to it by
clicking the browse button. Once the file pathhas been entered in the box,
click next toproceed.
Figure 2. 9

ArmatixiS1 User Manual 12/19 2011-07-01
•If WindowsXP is configured towarn when unsigned (non-WHQL certified)
drivers areaboutto be installed, themessage dialogue shown in Figure 2.10
willbe displayed unless installing a Microsoft WHQL certifieddriver. Click on
"ContinueAnyway" to continue withtheinstallation.IfWindows XP is
configured to ignore filesignature warnings,nomessagewillappear.
Figure 2. 10
•Thescreen shown inFigure 2.11willbedisplayed as Windows XP copies the
required driver files.
Figure 2. 11
•Windowsshould then displayamessageindicatingthatthe installation was
successful (Figure 2.12). Click "Finish" to complete the installation for the first

ArmatixiS1 User Manual 13/19 2011-07-01
port ofthe device.
Figure 2. 12
•Open the DeviceManager (located in"ControlPanel\System" then selectthe
"Hardware" taband click "DeviceManger") andselect "View> Devices by
Connection",thedeviceappears as a "USB Serial Converter" with an
additional COMport with the label "USB SerialPort" (Figure 2.13).
Figure 2. 13

ArmatixiS1 User Manual 14/19 2011-07-01
3. Uninstalling drivers
Devicescan be removed using the Device Managerbysimplyright-clicking
on the device andselecting"Uninstall". Thiswilldeletetheassociated registry
entries for that deviceonly.
Under WindowsXP, driverfiles andOEMINFand PNF files must be removed
manuallyor byusing a custom application.OEMINF andPNF files are located in
the Windows\Infdirectoryand canbe identifiedbysearching for a VID and PID
string matching the device installede.g.VID_0403&PID_6001. Once the
matchingOEMINF files are found(e.g. oem10.inffor FTDIBUS.INF and
oem11.inf for FTDIPORT.INF), the correspondingPNF filesmustalso be
removed(e.g.oem10.pnfand oem11.pnf). Driver filesare located inthe
Windows\System32and Windows\System32\Drivers directories.

ArmatixiS1 User Manual 15/19 2011-07-01
4. Troubleshooting
4.1. WindowsXPForces A Reboot After Installing a Device
Thisproblem can occur ifanapplication is accessing a filewhile the New
Hardware Wizardistrying tocopyit.This usuallyoccurs with the FTD2XX.DLL
file. Selecting not torestartthe computer then unpluggingand re-plugging the
devicemayallowthedevice tofunction properlywithoutrestarting. Restarting the
machine will allowthe device to work correctly.
4.2. Driver Installation FailsAnd Windows XP GivesError
Code 10
Windowserror code10 indicates a hardware error or failed driver installation. This
error mayappear ifa device has insufficientpower to operate correctly(e.g.
pluggedinto a bus poweredhubwith other devices), or mayindicateamore
serioushardware problem.Also,it maybe indicative ofUSB root hub drivers
being incorrectlyinstalled.
4.3. WindowsXPDisplays An Error AndThen Terminates
Installation
If thefollowingscreen is displayed withthismessage,Windows XP has been
configured to block the installationofanydrivers that are notWHQLcertified.
Figure 4. 1

ArmatixiS1 User Manual 16/19 2011-07-01
Twooptionsare available to successfullyinstall the device. Either a certified
versionofthe driver can beinstalled (ifavailable) or the driver signing options can
be changedto either warnorignore toallowthe installation tocomplete.
To changethecurrent driversigning setting, goto "ControlPanel\System", click
on the "Hardware" tabandthen click "Driver Signing". Thedesired signingoption
maythenbe selected.

ArmatixiS1 User Manual 17/19 2011-07-01
5. Contact Information
ArmatixGmbH
Feringastr. 4
D-85774 Unterfoehring
Germany
Tel:[phone]
Fax: [phone]
E-Mail: inf[email protected]

ArmatixiS1 User Manual 18/19 2011-07-01
Appendix A - Revision History
Version 0.1 First Draft 01/07/2011

ArmatixiS1 User Manual 19/19 2011-07-01
Appendix B - Reference
Future TechnologyDevices InternationalLtd
Application NoteAN_104
FTDIDrivers Installation guideforWindowsXP
Web:http://www.ftdichip.com
