Aroma FlipGrill AHG-2233 User manual

Published By:
Aroma Housewares Co.
6469 Flanders Drive
San Diego, CA 92121
U.S.A.
1-800-276-6286
www.aromaco.com
© 2007 Aroma Housewares Company All rights reserved.

1
Im ortant Safeguards
Basic safety precautions should always be followed when using electrical appli-
ances, including the following:
1. Important: Read all instructions care-
fully before first use.
2. Do not touch hot surfaces. Use han-
dles or knobs
3. Use only on a level, dry, and heat-re-
sistant surface.
4. To protect against electrical shock,
do not immerse cord, plug or the ap-
pliance in water or any other liquid.
5. Close supervision is necessary when
the appliance is used by or near chil-
dren.
6. Unplug from outlet when not in use
and before cleaning. Allow unit to
cool before putting on or taking off
parts, and before cleaning or mov-
ing the appliance.
7. Do not operate any appliance with
a damaged cord or plug or after the
appliance malfunctions or has been
damaged in any manner. Return the
appliance to the nearest authorized
service facility for examination, repair
or adjustment.
8. The use of accessory attachments
not recommended by the manufac-
turer may create a risk of injury or
product malfunction.
9. Do not use outdoors.
10. Do not let cord touch hot surfaces or
hang over the edge of a counter or
table.
11. Do not place on or near a hot gas or
electric burner or in a heated oven.
12. Do not use the appliance for other
than its intended use.
13. Extreme caution must be used when
moving the appliance containing
hot oils or other liquids.
14. Use only with a properly grounded
120V AC power outlet.
15. Always unplug from the base of the
wall outlet. ever pull on the cord.
16. Always attach plug to appliance first,
then plug into the wall outlet. To dis-
connect, turn any control to off and
remove plug from wall outlet.
17. Do not leave the appliance unat-
tended while in use.
18. Always unplug grill and then remove
cord before attempting to move the
grill.
19. Do not use without base in place.
Clean after each use.
20. Fuel, such as charcoal briquettes, is
not to be used with this appliance.
21. When in operation, a fire may occur
if the grill is touching or near flamma-
ble material, including curtains,
draperies, walls, backsplashes, cabi-
nets and the like. Place grill at least
21 inches away from walls, appli-
ances, or any object which could be
damaged by heat.
22. Use only the appropriate Aroma
temperature control probe and
base when operating this appliance.

1. A short power-supply cord is provided to reduce risk resulting from becoming
entangled in or tripping over a longer cord.
2. Longer extension cords are available and may be used if care is exercised in
their use.
3. If a longer extension cord is used:
a. The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance.
b. The longer cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled by children or tripped over
unintentionally.
2
This appliance has a polarized plug (one blade is wider than the other); follow
the instructions below:
To reduce the risk of electric shock, this plug is intended to fit into a polarized
outlet only one way. If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not attempt to modify
the plug in any way.
If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
This applia ce is for household use o ly.
Short Cord Instructions
Polarized Plug

3
Parts Identification
1. Full Range Temperature Probe
2. Illuminating Power-On Light
3. Cool-Touch Handles
4. Heating Plate - Grill Surface
5. Heating Plate – Griddle Surface
6. Grease Drainage Holes
7. Stainless Steel Raclette Tray
8. Individual Raclette Trays
9. on-Skid Feet
10. Base
1
3
2
4
5
6
7
8
9
10

4
1. Read all instructions and important safeguards.
2. Remove all packaging materials and make sure items are received in good
condition.
3. Tear up all plastic bags as they can pose a risk to children.
4. Wash grill/griddle plate, stainless steel tray, individual Raclette trays, and base
in warm, soapy water. Rinse and dry thoroughly.
5. Wipe temperature probe with a soft, damp cloth. Dry thoroughly. Do not im-
merse probe, cord or plug in water or any other liquids.
•Do ot use abrasive clea ers or scouri g pads.
•Do ot immerse the temperature probe, cord or plug i water at a y time.
Using Your Fli Grill
Before First Use:
Atte tio
As an additional safety measure, the heating plate will only function
when properly docked to the plastic base. The temperature probe must
align with the slotted cradle as shown in the illustration below. If not prop-
erly aligned, the heating plate will not turn on.

5
Using Your Fli Grill
1. Place the base on a sturdy, level surface.
2. Place the heating plate onto the base, grill side up.
3. Insert the temperature probe into the side of the heating plate, making sure that
it is properly attached and sitting squarely on the base.
4. Plug the temperature probe into an electrical outlet.
5. It is recommended to have all ingredients prepared before heating up the grid-
dle, as it heats up quickly. Turn the temperature dial to the desired position (from
1 to 10). For best results, allow the grill a few minutes to heat up before beginning
to cook.
6. When the grill is hot, place food on the grill surface and cook as desired. DO
OT use metal utensils as they may damage the nonstick finish.
7. When finished cooking, turn the temperature dial to “OFF” and immediately un-
plug the temperature probe from the wall outlet.
8. Allow grill to cool completely.
9. When the grill has cooled, remove the temperature probe from the grill before
cleaning.
(See “HOW TO CLEAN” for clea up i structio s)
To Grill:
To Use the Griddle:
1. Place the base on a sturdy, level surface.
2. Place the heating plate onto the base, griddle side up.
3. Insert the temperature probe into the side of the heating plate, making sure that
it is properly attached and sitting squarely on the base.
4. Plug the temperature probe into an electrical outlet.
5. It is recommended to have all ingredients prepared before heating up the grid-
dle, as it heats up quickly. Turn temperature dial to the desired position (from 1
to 10). For best results, allow the griddle a few minutes to heat up before be-
ginning to cook.
6. When griddle is hot, place food on the griddle surface and cook as desired. DO
OT use metal utensils as they may damage the nonstick finish.
7. When finished cooking, turn the temperature dial to “OFF” and immediately un-
plug the temperature probe from the wall outlet.
8. Allow to cool completely.
9. When the griddle has cooled, remove the temperature probe from the griddle
before cleaning.
(See “HOW TO CLEAN” for clea up i structio s)

1. Place the base on a sturdy, level surface.
2. Place the stainless steel Raclette tray onto the base.
3. Place the heating plate onto the base, grill or griddle side up as desired.
4. Insert the temperature probe into the side of the heating plate, making sure
that it is properly attached and sitting squarely on the base.
5. Plug the temperature probe into an electrical outlet.
6. It is recommended to have all ingredients prepared before heating up the
grill/griddle, as it heats up quickly. Turn the temperature dial to the desired
position (see recipe for instructions). For best results, allow the grill/griddle
a few minutes to heat up before beginning to cook.
7. Place thin slices of cheese onto each of the individual nonstick Raclette
trays. Slide the trays into the indentations on the stainless steel Raclette tray
(beneath the grill/griddle plate), taking care not to touch the heating plate
in order to avoid burns.
8. Allow the cheese a few minutes to warm, then place remaining ingredients
to be cooked (will vary by recipe) onto the grill/griddle surface and cook
as desired. Do not use metal utensils, as they may damage the nonstick
coating.
9. When ingredients are ready, serve onto plates. Slide the individual Raclette
trays out from beneath the grill/griddle plate and pour the cheese over the
other ingredients.
10. Repeat steps 6 through 9 as desired. When finished, turn the temperature
dial to “OFF” and immediately unplug the temperature probe from the wall
outlet.
11. Allow to cool completely.
12. When the appliance and trays have cooled, remove the temperature
probe from the grill/griddle before cleaning.
(See “HOW TO CLEAN” for clea up i structio s)
To Make Raclette:
Using Your Fli Grill
6
To Use as a Warming Tray:
1. Place the base on a sturdy, level surface.
2. Place the heating plate onto the base, griddle side up.
3. Insert the temperature probe into the side of the heating plate, making sure
that it is properly attached and sitting squarely on the base.
4. Plug the temperature probe into an electrical outlet.
5. Turn the temperature dial to the desired position between 1 and 4. DO OT
turn above “4” when using as a warming tray.
6. Place appetizers or food to be warmed onto the griddle surface.
Continued on next page

7
How To Clean
Always unplug unit and allow to cool completely
before cleaning.
1. Always allow the unit to cool completely before cleaning.
2. Unplug the temperature probe from the wall outlet. Remove the temperature
probe from the grill/griddle plate. DO OT immerse cord or plug in water or
any other liquid.
3. To clean the temperature probe, wipe gently with a damp cloth and dry com-
pletely.
4. The base, heating plate, stainless steel tray and individual Raclette trays may
be placed in the dishwasher for cleaning. Otherwise, wash in warm soapy
water using a soft cloth.
5. Do not use abrasive cleaners or scouring pads, as they may damage the non-
stick coating and create a risk of electric shock.
6. Rinse and dry completely before next use.
Note:
To make cleaning a little easier, try either of these methods:
- Aluminum foil may be used to line the plastic base. This will collect the fats
and therefore make disposal very easy.
- When lining the base of the Flip Grill, it is important not to allow aluminum foil
to hang over the sides of the base, as this will prevent proper air circulation.
To Use as a Warming Tray:
7. Serve as desired. Do not use metal utensils, as they may damage the nonstick
coating.
8. When not in use, turn the temperature dial to “OFF” and immediately unplug
the temperature probe from the wall outlet.
9. Allow to cool completely.
10. When the griddle has cooled, remove the temperature probe before clean-
ing.
(See “HOW TO CLEAN” for clea up i structio s)
Using Your Fli Grill

8
Hel ful Hints
1. Please remember that the Flip Grill heating plate is coated with a nonstick sur-
face and that heat-safe plastic utensils should always be used.
2. If you’re grilling vegetables, fish or lean meat, it’s best to spray the grilling sur-
face with a cooking spray. If you are grilling meat with any amount of fat or if
the food has been marinated, there is no need to pre-treat the grill.
3. For best results, allow the grill/griddle plate to preheat for 5-7 minutes before
grilling.
4. If using a marinade with oil, place grill near an exhaust hood. Oil or fats will
produce some smoke.
5. Do not leave the grill on to “burn off” any food or drippings remaining on the
grill surface after cooking. In addition to causing unnecessary smoke this can
reduce the life of the nonstick coating and may present a fire hazard.
Problem Solution
The temperature probe
appears to turn on and off
during cooking.
- When the thermostat reaches the desired temperature, it will
temporarily shut off to avoid overheating. This is normal. It
will turn back on as needed to prevent the temperature
from dropping below the selected setting.
- Double check that the grill/griddle plate has not become
dislodged from the base. If the heating plate and temper-
ature probe are not properly situated on the base, the built-
in safety switch will automatically cut power to the heating
element. Allow to cool, then check the alignment of the
parts. Operation will resume normally when all pieces are
properly assembled.
My Raclette cheese is not
melting.
It is best to allow the cheese to melt a few minutes under the
heated grill before cooking other foods, as Raclette cheese
takes a while to melt. Also, a higher setting (8-10) is needed
when making Raclette.
Also, removing trays from beneath the heating plate and
placing them on the heated griddle for 30-40 seconds will
help to speed up the melting process.
Should I use the stainless
steel tray when I’m not
making Raclette?
Yes, it is best to use the Flip Grill with the stainless steel tray in
place at all times.
Troubleshooting

LIMITED WARRANTY
Aroma Housewares Company warrants this product free from defects in
material and workmanship for one year from provable date of purchase
in the continental United States.
Within this warranty period, Aroma Housewares Company will repair or re-
place, at its option, defective parts at no charge, provided the product is
returned, freight prepaid with proof of purchase and U.S. $12.00 for ship-
ping and handling charges payable to Aroma Housewares Company.
Before returning an item, please call the toll free number below for a re-
turn authorization number. Allow 2-4 weeks for return shipping.
This warranty does not cover improper installation, misuse, abuse or neg-
lect on the part of the owner. Warranty is also invalid in any case that the
product is taken apart or serviced by an unauthorized service station.
This warranty gives you specific legal rights and which may vary from
state to state and does not cover areas outside the United States.
AROMA HOUSEWARES COMPA Y
6469 Flanders Drive
San Diego, California 92121
1-800-276-6286
M-F, 8:30 AM - 5:00 PM, Pacific Time
Website: www.aromaco.com
9
