AromaPlan DAP-102NP User manual

PRODUCT MANUAL
AromaPlan scent diffusers are powerful, easy to use and the most silent devices available.
Our innovative technology converts the liquid perfume into dry vaporous microparticles,
creating a practically invisible mist that drifts evenly throughout any space.
For example, when a candle burns, its perfume is stronger the closer you get.
Our devices are different. A space is scented evenly, regardless of where you are.
Our devices are perfect for scenting any setting, controlling foul odors and improving the
quality of indoor air in business and home environments.
With AromaPlan’s diffuser you have ultimate control. You can schedule the strength of the
fragrance as well as when it will automatically turn on and off, to perfectly scent your envi-
ronment according to your daily needs, without ever wasting your favorite fragrance.
Features:
• Easy oor or wall installation.
• Space evenly scented.
• No Residue.
• Safe for Kids & Pets
• Physical diffusion without
heating and water.
• Automatic scheduling on/off
according to your daily needs.
• Ultracold mist.
• Microparticles permit immediate and even
diffusion for lasting results.
• Automatic mode.
• Easily control fragrance concentration.
Attached Warranty Card
Please keep the Instruction and the warranty card carefully for further
reference. Please read all instructions before using the machine.
NO FLAME NO RESIDUE ECO-FRIENDLY PET-FRIENDLY
White Diffuser DAP-101NP &
Black Diffuser DAP-102NP
Avoid casualties and property loss, please always
follow the attentions as the following.
(The following basic safety precautions
should be always complied with)
I.Cautions
WARNING
May cause electric shock
or re hazard.
NOTE
May cause personal injury
or property damage
INSTALLING
1.Do not use unsafe plug or power.
2.Do not install the device at the place
where children can touch.
3.Do not install the device at the place
where can not bear strength and prone
result in falling and collapsing.
4.Do not tilt the device.
5.Keep the device away from re
and heat source, prohibit to store am-
mable and explosive materials
around the device.
6.Except for the atomizer, the housing
material is not resistant to corrosion.
7.Do not use device in high tempera-
ture or wet environment.
8.Do not use inammable, explosive,
corrosive and other hazardous solvents
work with the device.
INSTALLING
1.Ensure the rmness of installation area.
2.Install the device in a ventilative
and adequate space.
3.Do not block the sprayer by hand or
other obstructions when the device is
working.
4.Do not spill water or conductive, cor-
rosive liquid on the device surface or fall
inside of the device.
5.Do not operate device without stop-
ping. Suggested average daily usage
time should not exceed 14hours, and the
third level is recommended.
6.Cut off the power in extreme weather
environment.
PROHIBITION NECESSARY
Parameter
Model: PRO300
Voltage: 12V
Power: 7.5W
Capacity: 300ml
Weight: 0.9KG
Coverage: 300~400m³
Size: 170(L)X80.5(W)X206(H)mm
Atomizer
One-time
inner stopper
Nozzle
Fragrance
oil bottle
II.Specification
170mm
80.5mm
206mm
ATTENTION
The screws are optional parts for xing the equipment on
walls and the air conditioning tube is optional, if it is of
interest to the user, it is necessary to contact via e-mail for
more information and guidance on the installation process.

III.Instruction
Approved Certicate: CE, FCC, RoHS, CNAS and so on.
Application Place: Brand clothing store, 4S shop, bar, clubhouse and so on.
1. APP Operation Introduction
The device has four buttons :
“ ” is the return button
“ ” is the conrmation button,
“ ” is the increasing button
and “ ” is the shift button.
V.Operation Introduction
NORMAL WORKING INTERFACE
IV.How to use the equipament
https://youtu.be/hUPIElts7hE
VIDEO TUTORIAL - How to install your AromaPlan Diffuser
2. Buttons operation:
The device has four buttons:
1.Under the normal working interface, press “ ” and “ ” buttons at the same time to
enter the password setting interface. Password: 0000
2.Under the normal working interface, press “ ” and “ ” buttons at the same time to
turn on/off the essential oil detection function.
3.Under the normal working interface, press “ ” button to adjust the concentration
level A, B and C.
4.Under the normal working interface, press “ ” and “ ” buttons at the same time to
enter local time setting interface.
5.Under the normal working interface, press “ ” button to enter the working time and
frequency setting interface.
6.Under the normal working interface, long press “ ” button to turn on/off the fan.
7.Under the normal working interface, long press “ ” button to
turn off the machine.
3. Factory Reset:
Under the normal working interface, rstly, press the “ ” and “ ” buttons at the
same time until the interface shows YES/NO, then let your hand go.
Secondly, operate “ ” button to choose YES then press “ ” button to conrm it
and nish the setting.
4. Congure your diffuser
1.Programming Date/Time:
Programming your AromaPlan diffuser updating the
date and time is very simple.
After plugging in your machine you’re going to press “ ”
and “ ” buttons at the same time to update the time in a
24-hour format you’re rst going to click the button “ ”
in order to adjust the hour and then you’ll go to the button
“ ” to update the minutes.
DATE/TIME INTERFACE

Now once we have nished setting up this program screen
we can press “ ” for the diffuser to begin working in the
Normal Working Interface where you’ll see the countdown
of the Working (W) seconds that you programmed and the
Pause (P) for resting seconds that you programmed.
You can programming up to ve schedules.
3. Scenting schedule conguration:
The diffuser has three different intensity settings
depending on the size of your space once you are in the
home screen simply click “ ” and you will begin to see
the intensity changing from A, Band C.
The suggested intensity is for spaces up to 1000 square
feet use intensity A, spaces is up to 1500 square feet
use intensity B, spaces above 1500 square feet use
intensity C and if in any case you need more intensity
for your fragrance you’ll just hold “ ” for 5 seconds
and it’ll enter into turbo mode “ ”.
NORMAL WORKING INTERFACE
VI.Accessories and spare parts
Please clean the equipment periodically, suggest 2-3 months in 1 circle, so that it can
work under best condition.
Please cut off the power when cleaning, also do not use wet hand to operate it directly,
in case of electric shock and injury.
1. Long-term non-use
(1) Please turn off and cut off the power then roll up the power cord.
(2) Clean the lter components.
(3) Place the deodorant package which contains activated carbon in the device or package,
to prevent residual substances in the equipment produce odor.
(4) Please equip the machine with the dust cover, placed in the shade, ventilative place.
https://youtu.be/jw-mbckVvuQ
VIDEO TUTORIAL - How to congure your equipment
SCENTING SCHEDULE INTERFACE
NORMAL WORKING INTERFACE
Next, set the day of the week and the date using the same buttons as before to congure.
Clicking the “ ” button changes the item, and the “ ” button moves you to the next
item to be adjusted.
Press “ ” button to conrm it and nish the setting.
2. Scenting schedule conguration:
Programming working hours
After conguring the date and time, congure the
scenting schedule of the diffuser. The rst step is to
program the diffusers working hours. We will do this by
pressing “ ” in order to enter these settings.
Once you are in the program screen click “ ” to move
from the current day to the hour.
Now we can begin adjusting the diffusers Start Time (St) by clicking “ ”, we’ll change
the hour and we can click “ ” in order to change the minutes we will then click the “ ”
again in order to move to the end time.
Programming working intervals
Once we have nished setting up the hours, now we are going to adjust the intensity of your
fragrance this is done by setting up working intervals in seconds so we’ll click “ ” after
we adjust the time to come down to your Working (W) seconds this is how long your diffuser
will release fragrance, for example so we have it set to Work, by clicking “ ” button, for 30
seconds (30s). Then we will click the “ ” again in order to move it, so we can also adjust
the Pause (P) for resting time. We cal also ajust the Pause (P) for resting time, so for
example you can set it to pause for 90 seconds (90s) by clicking in “ ” button.

VII.Accessories and spare parts
NAME
Aroma diffuser
Adapter
Cap
Air conditioning tube
Key
Pneumatic ttings
1PC
1PC
1PC
1PC
2PC
1PC
NAMEQUANTITY QUANTITY
Screws
(including plastic
expansion tube)
Manual
Warranty card
Bottle sealing gasket
Mounting strip
2PC
1PC
1PC
1PC
2PC
VIII.After-sales Service
1. Provide free technical solutions and installation process guidance.
2. Provide free online FAQ consultation and scent-marketing suggestion.
IX.The equipment warranty and precautions
1. The equipment has a 1-year warranty (from the date of purchase).
2. Please provide the warranty card,Invoice or other provement which can prove the
equipment was ordered in our company to enjoy the free maintenance.
3. The human error or other wrong operation cause the fault not belong to the scope of
warranty, and will not be accepted to provide free maintenance.
