AromaPlan DAP-102NP User manual

PRODUCT
MANUAL
AromaPlan scent diffusers are powerful, easy to use and the most silent devices
available. Our innovative technology converts the liquid perfume into dry vaporous
microparticles, creating a practically invisible mist that drifts evenly throughout any
space.
For example, when a candle burns, its perfume is stronger the closer you get.
Our devices are different. A space is scented evenly, regardless of where you are.
Our devices are perfect for scenting any setting, controlling foul odors and improving
the quality of indoor air in business and home environments.
With AromaPlan’s diffuser you have ultimate control. You can schedule the strength
of the fragrance as well as when it will automatically turn on and off, to perfectly scent
your environment according to your daily needs, without ever wasting your favorite
fragrance.
Features:
• Easy oor or wall installation.
• Space evenly scented.
• No Residue.
• Safe for Kids & Pets
• Physical diffusion without
heating and water.
• Automatic scheduling on/off
according to your daily needs.
• Ultracold mist.
• Microparticles permit immediate and
even diffusion for lasting results.
• Automatic mode.
• Easily control fragrance concentration.
Attached Warranty Card
Please keep the Instruction and the warranty
card carefully for further reference.
Please read all instructions before using the machine.
NO FLAME NO RESIDUE ECO-FRIENDLY PET-FRIENDLY
White Diffuser
DAP-101NP

Avoid casualties and property loss, please always follow
the attentions as the following.
(The following basic safety precautions
should be always complied with)
I.Cautions
WARNING
May cause electric shock
or re hazard.
NOTE
May cause personal injury
or property damage
INSTALLING
1.Do not use unsafe plug or power.
2.Do not install the device at the
place where children can touch.
3.Do not install the device at the
place where can not bear strength
and prone result in falling and
collapsing.
4.Do not tilt the device.
5.Keep the device away from re
and heat source, prohibit to store
ammable and explosive materials
around the device.
6.Except for the atomizer, the housing
material is not resistant to corrosion.
7.Do not use device in high tem-
perature or wet environment.
8.Do not use inammable, explosive,
corrosive and other hazardous sol-
vents work with the device.
INSTALLING
1.Ensure the rmness of installation
area.
2.Install the device in a ventilative
and adequate space.
3.Do not block the sprayer by hand
or other obstructions when the de-
vice is working.
4.Do not spill water or conductive,
corrosive liquid on the device sur-
face or fall inside of the device.
5.Do not operate device without
stopping. Suggested average daily
usage time should not exceed 14
hours, and the third level is recom-
mended.
6.Cut off the power in extreme
weather environment.
PROHIBITION NECESSARY
Parameter
Model: PRO300
Voltage: 12V
Power: 7.5W
Capacity: 300ml
Weight: 0.9KG
Coverage: 300~400m³
Size: 170(L)X80.5(W)X206(H)mm
Atomizer
One-time
inner stopper
Nozzle
170mm
80.5mm
206mm
Fragrance
oil bottle
II.Specification
ATTENTION
The screws are optional parts for
xing the equipment on walls and
the air conditioning tube is optional,
if it is of interest to the user, it is
necessary to contact via e-mail
for more information and guidance
on the installation process.

III.Instruction
Approved Certicate: CE, FCC, RoHS, CNAS and so on.
Application Place: Brand clothing store, 4S shop, bar, clubhouse and so on.
1. APP Operation Introduction
The device has four buttons :
“ ” is the return button
“ ” is the conrmation button,
“ ” is the increasing button
and “ ” is the shift button.
IV.How to use
the equipament
V.Operation
Introduction
NORMAL WORKING INTERFACE

2. Buttons operation:
The device has four buttons:
1.Under the normal working interface, press “ ” and “ ” buttons at
the same time to enter the password setting interface.
2.Under the normal working interface, press “ ” and “ ” buttons at
the same time to turn on/off the essential oil detection function.
3.Under the normal working interface, press “ ” button to adjust the
concentration level A, B and C.
4.Under the normal working interface, press “ ” and “ ” buttons at
the same time to enter local time setting interface.
5.Under the normal working interface, press “ ” button to enter the
working time and frequency setting interface.
6.Under the normal working interface, long press “ ” button to
turn on/off the fan.
7.Under the normal working interface, long press “ ” button to
turn off the machine.
3. Factory Reset:
Under the normal working interface, rstly, press the “ ” and “ ”
buttons at the same time until the interface shows YES/NO, then let your
hand go. Secondly, operate “ ” button to choose YES then press “ ”
button to conrm it and nish the setting.
4. Congure your diffuser
1.Programming Date/Time:
Programming your AromaPlan diffuser
updating the date and time is very simple.
After plugging in your machine you’re
going to press “ ” and “ ” buttons
at the same time to update the time in a
24-hour format you’re rst going to click
the button “ ” in order to adjust the
hour and then you’ll go to the button
“ ” to update the minutes.
DATE/TIME INTERFACE

Now we can begin adjusting the diffusers Start Time (St) by clicking “ ”,
we’ll change the hour and we can click “ ” in order to change the minutes
we will then click the “ ” again in order to move to the end time.
Programming working intervals
Once we have nished setting up the hours, now we are going to adjust the
intensity of your fragrance this is done by setting up working intervals in
seconds so we’ll click “ ” after we adjust the time to come down to your
Working (W) seconds this is how long your diffuser will release fragrance,
for example so we have it set to Work, by clicking “ ” button, for 30 seconds
(30s). Then we will click the “ ” again in order to move it, so we can also
adjust the Pause (P) for resting time. We cal also ajust the Pause (P) for
resting time, so for example you can set it to pause for 90 seconds (90s) by
clicking in “ ” button.
2. Scenting schedule conguration:
Programming working hours
After conguring the date and time,
congure the scenting schedule of the
diffuser. The rst step is to program the
diffusers working hours. We will do this
by pressing “ ” in order to enter these
settings.
Once you are in the program screen
click “ ” to move from the current day
to the hour.
SCENTING SCHEDULE INTERFACE
Next, set the day of the week and the date using the same buttons as
before to congure. Clicking the “ ” button changes the item, and
the “ ” button moves you to the next item to be adjusted.
Press “ ” button to conrm it and nish the setting.
NORMAL WORKING INTERFACE
Now once we have nished setting up this
program screen we can press “ ” for
the diffuser to begin working in the
Normal Working Interface where you’ll see
the countdown of the Working (W) seconds
that you programmed and the Pause (P) for
resting seconds that you programmed.
You can programming up to ve schedules.

3. Scenting schedule conguration:
The diffuser has three different intensity
settings depending on the size of your
space once you are in the home screen
simply click “ ” and you will begin to see
the intensity changing from A, Band C.
The suggested intensity is for spaces up
to 1000 square feet use intensity A,
spaces is up to 1500 square feet use
intensity B, spaces above 1500 square
feet use intensity C and if in any case you
need more intensity for your fragrance
you’ll just hold “ ” for 5 seconds and it’ll
enter into turbo mode “ ”.
NORMAL WORKING INTERFACE
Acess the ocial video tutorial:
https://youtu.be/jw-mbckVvuQ
VIDEO TUTORIAL
VI.Accessories
and spare parts
Please clean the equipment periodically, suggest 2-3 months in 1 circle,
so that it can work under best condition.
Please cut off the power when cleaning, also do not use wet hand to
operate it directly, in case of electric shock and injury.
1. Long-term non-use
(1) Please turn off and cut off the power then roll up the power cord.
(2) Clean the lter components.
(3) Place the deodorant package which contains activated carbon in the device
or package, to prevent residual substances in the equipment produce odor.
(4) Please equip the machine with the dust cover, placed in the shade,
ventilative place.

VII.Accessories
and spare parts
NAME
Aroma diffuser
Adapter
Cap
Air conditioning tube
Key
Pneumatic ttings
1PC
1PC
1PC
1PC
2PC
1PC
NAMEQUANTITY QUANTITY
Screws
(including plastic
expansion tube)
Manual
Warranty card
Bottle sealing gasket
Mounting strip
2PC
1PC
1PC
1PC
2PC
VIII.After-sales Service
1. Provide free technical solutions and installation process guidance.
2. Provide free online FAQ consultation and scent-marketing suggestion.
IX.The equipment
warranty and precautions
1. The equipment has a 1-year warranty (from the date of purchase).
2. Please provide the warranty card,Invoice or other provement which can prove
the equipment was ordered in our company to enjoy the free maintenance.
3. The human error or other wrong operation cause the fault not belong to the
scope of warranty, and will not be accepted to provide free maintenance.
