Chapter 1 Overview
In the fields of Real-time Signal Processing, Digital Image Processing and others, high-speed and high-precision data
acquisition modules are demanded. ART PCI8932 data acquisition module, which brings in advantages of similar
products that produced in china and other countries, is convenient for use, high cost and stable performance.
ART PCI8932 is a data acquisition module based on PCI bus. It can be directly inserted into IBM-PC/AT or a computer
which is compatible with PCI8932 to constitute the laboratory, product quality testing center and systems for different
areas of data acquisition, waveform analysis and processing. It may also constitute the monitoring system for industrial
production process.
Software
Analysis Software
ART PCI8932 module is well-suited for precision data acquisition analysis applications, which you can specifically
address with the ART Data Acquisition Measurement Suite. The suite has two components –digital and graphics mode
analysis (functions) for voltage (any signal can be transformed into the voltage signal), frequency response and other
analysis.
Unpacking Checklist
Check the shipping carton for any damage. If the shipping carton and contents are damaged, notify the local dealer or
sales for a replacement. Retain the shipping carton and packing material for inspection by the dealer.
Check for the following items in the package. If there are any missing items, contact your local dealer or sales.
¾PCI8932 Data Acquisition Board
¾ART Disk
a) user’s manual (pdf)
b) drive
c) catalog
¾Warranty Card
FEATURES
Analog Input
¾Input Range: ±10V, ±5V, ±2.5, 0~10V
¾13-bit resolution
¾Sampling Rate: 500KS/s
Note: The actual channel sampling rate = sampling rate / number of sampling channels
Frequency Formula: sampling frequency= main frequency/the number of frequency division, main frequency and
frequency division are variable.
¾Analog Input Mode: 16SE/8DI
¾AD Conversion Time: ≤1.6us
¾Programmable Gain: 1, 2, 4, 8 (AD8251 default )or 1, 2, 5, 10 (AD8250) or 1, 10, 100, 1000 (AD8253)
¾Analog Input Impedance: 10MΩ

PCI8932DataAcquisition V6.018
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 4
¾Amplifier Set-up Time: 785ns(0.001%)(max)
¾Non-linear error: ±3LSB(Maximum)
¾System Measurement Accuracy: 0. 1%
¾Operating Temperature Range: 0℃~55℃
¾Storage Temperature Range: -20℃~70℃
Analog Output
¾Output Range: ±10V, ±5V, 0~10V, 0~5V
¾12-bit resolution
¾Set-up Time: 10μs (0.01%)
¾Channel No.: 4-channel
¾Non-linear error: ±1LSB(Maximum)
¾Output error (full-scale): ±1LSB
Digital Input
¾Channel No.: 16-channel
¾Electric Standard: TTL compatible
¾High Voltage: ≧2V
¾Low Voltage: ≦0.8V
Digital Output
¾Channel No.: 16-channel
¾Electrical Standard: TTL compatible
¾High Voltage: ≧4.45V
¾Low Voltage: ≦0.5V
¾Power-on Reset
Timer Function
¾Counter Channel No.: three independent counter
¾Counter Mode: subtract count
¾Counter Resolution: 24-bit
¾Count Mode: six count modes, (software-configurable)
¾electrical standard: TTL compatible
Other features
Board Clock Oscillation: 40MHz
Board Dimension: 143.8mm (L)*98mm (W) * 16mm (H)

PCI8932DataAcquisition V6.018
Chapter 2 Components Layout Diagram and a Brief Description
2.1 The Main Component Layout Diagram
2.2 The Function Description for the Main Component
2.2.1 Signal Input and Output Connectors
CN1: Analog signal input and output connectors
P1: Digital input port
P2: Digital output port
2.2.2 Potentiometer
RP1: Analog signal input zero point adjustment potentiometer
RP2: Analog signal input full-scale adjustment potentiometer
RP4, RP7, RP3, RP8: Analog output VOUT0~VOUT3 zero-point adjustment potentiometer
RP6,RP9,RP5,RP10：Analog output VOUT0~VOUT3 full-scale adjustment potentiometer
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 5

PCI8932DataAcquisition V6.018
2.2.3 Jumper
JP2, JP4: Analog output VOUT0 output range setting
JP1, JP3: Analog output VOUT2 output range setting
Voltage Range JP1 JP3
0~5V
0~10V
±5V
±10V
JP5, JP7: Analog output VOUT1 output range setting
Voltage Range JP5 JP7
0~5V
0~10V
±5V
±10V
JP6, JP8: Analog output VOUT3 output range setting
Voltage Range JP1 JP3
0~5V
0~10V
±5V
±10V
2.2.4 Physical ID of DIP Switch
DID1: Set physical ID number. When the PC is installed more than one PCI8932 , you can use the DIP switch to set a
physical ID number for each board, which makes it very convenient for users to distinguish and visit each board in the
progress of the hardware configuration and software programming. The following four-place numbers are expressed by
the binary system: When DIP switch points to "ON", that means "1", and when it points to the other side, that means
"0." As they are shown in the following diagrams: place "ID3" is the high bit."ID0" is the low bit, and the black part in
the diagram represents the location of the switch. (Test software of the company often uses the logic ID management
equipments and at this moment the physical ID DIP switch is invalid. If you want to use more than one kind of the
equipments in one and the same system at the same time, please use the physical ID as much as possible.).
ON
1
ID0ID1ID2ID3
234
ON
DID1
The above chart shows"1111", so it means that the physical ID is 15.
Voltage Range JP2 JP4
0~5V
0~10V
±5V
±10V
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 6

PCI8932DataAcquisition V6.018
ON
1
ID0ID1ID2ID3
234
ON
DID1
The above chart shows"0111", so it means that the physical ID is 7.
ON
1
ID0ID1ID2ID3
234
ON
DID1
The above chart shows"0101", so it means that the physical ID is 5.
ID3 ID2 ID1 ID0 Physical ID（Hex）Physical ID（Dec）
OFF（0）OFF（0）OFF（0）OFF（0）0 0
OFF（0）OFF（0）OFF（0）ON（1）1 1
OFF（0）OFF（0）ON（1）OFF（0）2 2
OFF（0）OFF（0）ON（1）ON（1）3 3
OFF（0）ON（1）OFF（0）OFF（0）4 4
OFF（0）ON（1）OFF（0）ON（1）5 5
OFF（0）ON（1）ON（1）OFF（0）6 6
OFF（0）ON（1）ON（1）ON（1）7 7
ON（1）OFF（0）OFF（0）OFF（0）8 8
ON（1）OFF（0）OFF（0）ON（1）9 9
ON（1）OFF（0）ON（1）OFF（0）A 10
ON（1）OFF（0）ON（1）ON（1）B 11
ON（1）ON（1）OFF（0）OFF（0）C 12
ON（1）ON（1）OFF（0）ON（1）D 13
ON（1）ON（1）ON（1）OFF（0）E 14
ON（1）ON（1）ON（1）ON（1）F 15
2.2.5 Status indicator
ADRead: AD working status indicator
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 7

PCI8932DataAcquisition V6.018
Chapter 3 Signal Connectors
3.1 The Definition of Signal Input and Output Connectors
37 core plug on the CN1 pin definition
Pin definition about CN1:
Pin feature Pin function definitionPin name
AI0~AI15 Input Analog input, reference ground is AGND.
VOUT~VOUT3 Output Analog output, reference ground is AGND.
AGND GND Analog ground. This AGND pin should be connected to the
system’s AGND plane.
DGND GND Digital ground. This DGND pin should be connected to the
system’s DGND plane.
CLK0~CLK2 Input Counter clock input.
GATE0~GATE2 Input Counter gate.
OUT0~OUT2 Output Counter out.
+5V Output 5V power supply output.
NC NC
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 8

PCI8932DataAcquisition V6.018
3.2 Digital Input Connector
20 core plug P1 pin definition
P1 pins definition
Type Function definitionSignal Name
DI0-DI15 Input Digital signal input pins, reference ground is DGND.
DGND GND Digital signal ground
3.3 Digital Output Connector
20 core plug P2 pin definition
P2 pins definition
Type Function definitionSignal Name
DO0-DO15 Output Digital signal input pins, reference ground is DGND.
DGND GND Digital signal ground
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 9

PCI8932DataAcquisition V6.018
Chapter 4 Connection Ways for Each Signal
4.1 Analog Input Single-ended Connection
Single-ended mode can achieve a signal input by one channel, and several signals use the common reference ground.
This mode is widely applied in occasions of the small interference and relatively many channels.
Figure 4.1 single-ended input connection
4.2 Analog Input Differential-ended Mode
Double-ended input mode, which was also called differential input mode, uses positive and negative channels to input a
signal. This mode is mostly used when biggish interference happens and the channel numbers are few.
Single-ended/double-ended mode can be set by the software, please refer to PCI8932 software manual.
According to the diagram below, PCI8932 board can be connected as analog voltage double-ended input mode, which
can effectively suppress common-mode interference signal to improve the accuracy of acquisition. Positive side of the
8-channel analog input signal is connected to AI0~AI7, the negative side of the analog input signal is connected to
AI8~AI15, equipments in industrial sites share the AGND with PCI8932 board.
Figure 4.2 double-ended input connection
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 10

PCI8932DataAcquisition V6.018
4.3 Other Connections
Figure 4.3 analog signal output connection
Figure 4.4 digital signal input connection
Figure 4.5 digital signal output connection
Figure 4.6 Clock Input/Output and Trigger Signal Connection
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 11

PCI8932DataAcquisition V6.018
Chapter5 Subtractive Counter
Mode 0: Interrupt on terminal count
Under this mode, when given the initial value, if GATE is high level, the counter immediately begins to count by
subtracting “1” each time, the counter output OUT turns into low level; when the count ends and the count value
becomes 0, the counter output OUT becomes and keeps high level until given the initial value or reset. If a counter
which is counting is given a new value, the counter will begin to count from the new value by subtracting “1” each time.
GATE can be used to control the count, GATE=1 enables counting; GATE=0 disables counting.
OUT signal changes high from low can be used as interrupt request.
Time diagram is shown in Figure 1.
Figure 1
Mode 1: Hardware retriggerable one-shot
The mode can work under the role of GATE. After given the initial count value N, OUT becomes high level, the
counter begins to count until the appearance of the rising edge of GATE, at this moment OUT turns into low level;
when the count ends and the count value becomes 0, OUT becomes high level, that is, the output one-shot pulse width
is determined by the initial count value N. If the current operation does not end and another rising edge of GATE
appears, then the current count stops, the counter begins to count from N once again, and then the output one-shot pulse
will be widened. When the count reduction of the counter has not yet reached zero, but it is given a new value N1. Only
when it is the rising edge of GATE, the counter starts to count from N1.
Time diagram is shown in Figure 2.
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 12

PCI8932DataAcquisition V6.018
Figure 2
Mode 2: Rate Generator
Under this mode, the counter is given the initial count value N and begins to count from (N-1), OUT becomes high
level. When the count value becomes 0, OUT turns into low level. After a CLK cycle, OUT resumes high level, and the
counter automatically load the initial value N and begin to count from (N-1). Thus the output will continue to output a
negative pulse, its width is equal to one clock cycle, the clock number between the two negative pulses is equal to the
initial value that is given to the counter. GATE=1 enables counting; GATE=0 disables counting. GATE has no effect on
OUT. If change the initial count when counting, it will be effective next time.
Time diagram is shown in figure 3.
Figure 3
Mode 3: Square wave mode
Similar to Mode 2, the counter is given the initial count value N and begins to count from (N-1). When the signal of
GATE is high level, it starts to count, timer/counter begins to count by subtracting “1” each time, more than half the
initial count value. The output OUT has remained high level, when the count value is more than half of the initial count
value; but the output OUT becomes low level, when the count value is less than half of the initial value. If the initial
count value N is an even number, the output is 1:1 square-wave; if the initial count value N is an odd number, the
output OUT has remained high level during the previous (n +1)/2 count period; but the output OUT becomes low level
during the post (n-1)/2 count period, that is, the high level has one clock cycle more than the low level. If change the
initial count when counting, it will be effective next time. When GATE = 0, the count is prohibited, when GATE = 1,
the count is permitted. Time diagram is shown in figure 4.
Figure 4
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 13

PCI8932DataAcquisition V6.018
Mode 4: Software triggered strobe
Under this mode, the counter is given the initial count value N and begins to count, the output OUT becomes high level.
When the count value becomes 0, it immediately outputs a negative pulse which is equal to the width of one clock
cycle. If given a new count value when counting, it will be effective immediately. GATE=1 enables counting; GATE=0
disables counting. GATE has no effect on OUT. Time diagram is shown in figure 5.
Figure 5
Mode 5: Hardware triggered strobe
Under this mode, when the signal of GATE is on the rising edge, the counter starts to count (so it is called hardware
trigger), the output OUT has remained high level. When the count value becomes 0, it outputs a negative pulse which is
equal to the width of one clock cycle. And then the rising edge of GATE signal can re-trigger, the counter starts to
count from the initial count value again, in the count period, the output has remained high level. When the count
reduction of the counter has not yet reached zero, but it is given a new value N1. Only when it is the rising edge of
GATE, the counter starts to count from N1. Time diagram is shown in figure 6.
Figure 6
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 14

PCI8932DataAcquisition V6.018
Chapter6 Notes, Calibration and Warranty Policy
6.1 Notes
In our products’ packing, user can find a user manual, a PCI8932 module and a quality guarantee card. Users must
keep quality guarantee card carefully, if the products have some problems and need repairing, please send products
together with quality guarantee card to ART, we will provide good after-sale service and solve the problem as quickly
as we can.
When using PCI8932, in order to prevent the IC (chip) from electrostatic harm, please do not touch IC (chip) in the
front panel of PCI8932 module.
6.2 Analog Signal Input Calibration
Every device has to be calibrated before sending from the factory. It is necessary to calibrate the module again if users
want to after using for a period of time or changing the input range. PCI8932 default input range: ±10V, in the manual,
we introduce how to calibrate PCI8932 in ±10V, calibrations of other input ranges are similar.
Prepare a digital voltage instrument which the resolution is more than 5.5 bit, install the PCI8932 module, and then
power on, warm-up for fifteen minutes.
1) Zero adjustment: select one channel of analog inputs, take the channel AI0 for example, connect 0V to AI0,
and then run ART Data Acquisition Measurement Suite in the WINDOWS. Choose channel 0, ±10V input
range and start sampling, adjust potentiometer RP2 in order to make voltage value is 0.000V or about 0.000V.
Zero adjustment of other channels is alike.
2) Full-scale adjustment: select one channel of analog inputs, take the channel AI0 for example, connect
9995.11mV to AI0, and then run ART Data Acquisition Measurement Suite in the WINDOWS. Choose
channel 0, ±10V input range and start sampling, adjust potentiometer RP1 in order to make voltage value is
9995.11mV or about 9995.11mV. Full-scale adjustment of other channels is alike.
3) Repeat steps above until meet the requirement.
6.3 Analog Signal Output Calibration
In the manual, we introduce how to calibrate PCI8932 in ±10V input range; calibrations of other input ranges are
similar.
1) Connect the ground of Digital Voltage Meter to any analog (AGND) of CN1 37-core D-type plug, and connect the
Voltage Meter Input to the DA channels that need calibration. Run PCI8932 testing procedure under Windows, select
the DA output detection.
2) To set analog output to 0V, by adjusting the zero potentiometer (RP4, RP7, RP3, RP8), so that the corresponding
output is 0.000V.
3) To set analog output to 9995.11V, by adjusting the full-scale potentiometer (RP6, RP9, RP5, RP10), so that the
corresponding output is 9995.11V.
4) Repeat the above step 2), step 3), until meet the requirement.
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 15

PCI8932DataAcquisition V6.018
6.4 DA use
In demonstration program, the continuous output interval of waveform output can not be carried out; the main objective
is to test the strength of DA output.
6.5 Warranty Policy
Thank you for choosing ART. To understand your rights and enjoy all the after-sales services we offer, please read the
following carefully.
1. Before using ART’s products please read the user manual and follow the instructions exactly. When sending in
damaged products for repair, please attach an RMA application form which can be downloaded from:
www.art-control.com.
2. All ART products come with a limited two-year warranty:
¾The warranty period starts on the day the product is shipped from ART’s factory
¾For products containing storage devices (hard drives, flash cards, etc.), please back up your data before sending
them for repair. ART is not responsible for any loss of data.
¾Please ensure the use of properly licensed software with our systems. ART does not condone the use of pirated
software and will not service systems using such software. ART will not be held legally responsible for products
shipped with unlicensed software installed by the user.
3. Our repair service is not covered by ART's guarantee in the following situations:
¾Damage caused by not following instructions in the User's Manual.
¾Damage caused by carelessness on the user's part during product transportation.
¾Damage caused by unsuitable storage environments (i.e. high temperatures, high humidity, or volatile chemicals).
¾Damage from improper repair by unauthorized ART technicians.
¾Products with altered and/or damaged serial numbers are not entitled to our service.
4. Customers are responsible for shipping costs to transport damaged products to our company or sales office.
5. To ensure the speed and quality of product repair, please download an RMA application form from our company
website.
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 16

PCI8932DataAcquisition V6.018
Products Rapid Installation and Self-check
Rapid Installation
Product-driven procedure is the operating system adaptive installation mode. After inserting the disc, you can select the
appropriate board type on the pop-up interface, click the button【driver installation】; or select CD-ROM drive in
Resource Explorer, locate the product catalog and enter into the APP folder, and implement Setup.exe file. After the
installation, pop-up CD-ROM, shut off your computer, insert the PCI card. If it is a USB product, it can be directly
inserted into the device. When the system prompts that it finds a new hardware, you do not specify a drive path, the
operating system can automatically look up it from the system directory, and then you can complete the installation.
Self-check
At this moment, there should be installation information of the installed device in the Device Manager (when the
device does not work, you can check this item.). Open "Start -> Programs -> ART Demonstration Monitoring and
Control System -> Corresponding Board -> Advanced Testing Presentation System", the program is a standard testing
procedure. Based on the specification of Pin definition, connect the signal acquisition data and test whether AD is
normal or not. Connect the input pins to the corresponding output pins and use the testing procedure to test whether the
switch is normal or not.
Delete Wrong Installation
When you select the wrong drive, or viruses lead to driver error, you can carry out the following operations: In
Resource Explorer, open CD-ROM drive, run Others-> SUPPORT-> PCI.bat procedures, and delete the hardware
information that relevant to our boards, and then carry out the process of section I all over again, we can complete the
new installation.
BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN) 17
