dPDB™dPDB FEATURES:
✔Two High-Quality
DI Boxes In One
Convenient Enclosure
✔Durable All-Steel
Construction
✔Instrument Input:
50k Ohm
✔Parallel Link Jack:
50k Ohm
✔Output Jack: 600 Ohm
XLR
✔Output Jack Ground
Lift: Switchable
APPLICATIONS:
✔Professional, Home
and Project Recording
Studios
✔Live Sound Systems
✔PA Systems
Permanent/Fixed Installs
✔Churches and
Concert Halls
✔Nightclubs and Practice
PA systems
✔DJ and Karaoke Sound
Systems
✔Monitoring Systems
DUAL PASSIVE DIRECT BOX
The new dPDB™ Dual Passive Direct Box
features two high-quality direct boxes in one
convenient enclosure. It is a rock solid, road-
worthy DI for connection of the outputs of
electronic musical instruments (or other audio
sources) to the balanced inputs of mixer consoles
and other balanced inputs. The high impedance
signal from a guitar or bass guitar pickup is
translated by the dPDB into a low impedance
balanced signal required by mixing consoles.
It also allows connection of a music source to
an instrument amplifier while simultaneously
patching it to a mixer.
So if you have a separate signal devices which
require twoindependentdirectboxes,dPDBisthe
two-in-onesolution for you.
Input Attenuation: Switchable (0dB, -20dB, -40dB)
Instrument Inputs: 50k Ohm
Parallel Link Jack: 50k Ohm
Output Jack: 600 Ohm XLR Output Jack
Ground Lift: Switchable
