Artesian Spas Gold Series User manual

Gold Series
in.k600 full-function keypad
with streamlined interface
User's manual
Giving full control to wet fingers!

1
Gold series in.k600
Table of contents
overview ......................................................................................... 3
warning ...........................................................................................4
function description ...................................................................... 5
icon description.............................................................................6
installation
- high prole .......................................................................9
- drilling template..............................................................10
connections................................................................................... 11
functions ........................................................................................12
specications ................................................................................17
table of contents

2
Gold series in.k600
3
Gold series in.k600

2
Gold series in.k600
3
Gold series in.k600 overview
Gold Series
in.k600 full-function keypad that gives
complete control to wet ngers!
Artesian spas' gold series of advanced in.k600 keypads feature a
high prole with a large LCD display, streamlined interface and
raised keys that let users easily control all in.xm functions and pro-
gramming directly from spa side, creating a true and unique user
experience directly from spa side.

4
Gold series in.k600
5
Gold series in.k600
warning
WARNINGS:
Before installing or connecting the unit,
please read the following.
FAILURE TO COMPLY WITH THE FOLLOWING WARNINGS MAY
SIGNIFICANTLY SHORTEN THE PRODUCT’S LIFE TIME, AND
LEAD TO FAILURES AS WELL AS HAZARDOUS CONDITIONS*.
COMMON SENSE MUST ALWAYS PREVAIL WHEN EVALUATING
THE INSTALLATION AND/OR USE OF ANY ELECTRONIC
CONTROL IN A FINAL APPLICATION.
• The maximum ambient conditions this PRODUCT is subjected
to (temperature, humidity, etc.) are not to be exceeded.
• This PRODUCT must be installed by qualied personnel.
• Only qualied personnel are to service this PRODUCT.
There are no user serviceable parts inside.
• This PRODUCT is only compatible with Aeware’s in.pac line
of products.
• This PRODUCT should be installed on a clean at surface.
• The gasket on the back of the unit will prevent water inltration
inside, behind the mounted surface. If the gasket is damaged,
the user must seal the back of the unit with silicone to avoid any
leakage behind the mounted surface.
* HAZARDOUS CONDITION:
A condition that is potentially damaging and/or dangerous to
its operator or surroundings. This includes, but is not limited
to: re, ooding or other water damage, dielectric breakdowns
(presence of high voltage), etc.

4
Gold series in.k600
5
Gold series in.k600
"Ok" Key
"On/Off" Key
"Program" Key
"Minus" Key
"Right"
Multifunction Key
"Plus" Key
"Left"
Multifunction Key
"Light" Key
"Pump" Keys
function description

6
Gold series in.k600
7
Gold series in.k600
Heating icon Economy
mode icon Smart winter mode icon
Program icon
Service icon
Filtering icon
Pump icons
Light icon
Progress bar icon
AM/PM (˚F/ ˚C)
Time, temperature
& message digits
Set point icon
icon description

6
Gold series in.k600
7
Gold series in.k600
Icon Description
Light icon
The "Light" icon lights up when the light is on.
Pumps icons
The "Pump" indicator numbers light up and their icons become animated when pumps
are on.
Service icon
A problem has been detected. Do not enter the water! Spa service is required.
Smart winter mode icon
The "SWM" icon automatically turns on when freeze protection is active.
It ashes while system purges the spa plumbing.
Economy mode icon
The "Economy" icon lights up when lter cycle is on
Filter Cycle icon
The "Filter Cycle" icon lights up when lter cycle is on. It ashes when ltering is suspended.
Heater icon
The "Heater" icon lights up when the heater is on.
Progress bar
A visual indication of the time remaining before an equipment is turned off or before the
end of the standby mode.
icon description

8
Gold series in.k600
9
Gold series in.k600
Icon description
Set Point icon
The "Set Point" icon automatically turns on when set point setting menu is activated.
(SP message on display). It ashes when:
1- there is a call for heat and heater has not started yet,
2- heater has just turned off and element is cooling down or
3 - if system is performing a check ow.
Program icon
The "Program" icon lights up when Programming.
icon description

8
Gold series in.k600
9
Gold series in.k600
To install the in.k600 high prole, use the drilling template
provided in this section. Determine the mounting location and
stick the template on chosen location. The user must cut out two
0.25" diameter holes for the xation studs and one 2" diameter
hole for the cable (as illustrated above).
Insert keypad and align it correctly, then secure it properly in place
by using the two wing nuts provided.
Installation in.k600 high prole
Gasket with or without
adhesive
Optional
wing nuts and
spacers
2.563"
0.25"
2"
2.563"
installation

10
Gold series in.k600
11
Gold series in.k600
2"
51.0 mm
TYP. 2x ø ø 0.25"
6.4 mm
5.125"
130.0 mm
2.563"
65.0 mm
2.563"
65.0 mm
driling template high prole

10
Gold series in.k600
11
Gold series in.k600
Connecting in.k600 keypad to in.xm
To connect the in.k600 keypad,
simply insert its in.link connec-
tor into the appropriate keypad
connector (as illustrated).
To provide additional access-
control, an auxiliary keypad is
also available (optional).
Main keypad in.k600
Connect in.k600 keypad into
the appropriate in.keys main
keypad connector
(as illustrated above).
connections

12
Gold series in.k600
13
Gold series in.k600
On/Off key
Standby Mode : When this
feature is activated, allows to
stop all pumps at the same time
by a simple click of a button!
Use On/Off key to pause all
pumps*.
Progress bar will display the
remaining time before the
system automatically exits
Standby mode (user can also
exit Standby mode at any time
by pressing again on On/Off
key).
In order to warn the user, the
spa light will ash for a few
seconds before the exit of
Standby mode and restart the
pumps. The "Stby" message is
also displayed during Standby
mode.
*Pumpwillstayturnedonif
thereisarequestformoreheat.
Pump 1 key
Press Pump 1 key to turn
Pump 1 on at high speed.
Press a second time to turn
pump off.
A built-in timer automatically
turns pump off after 20 min-
utes, unless pump has been
manually deactivated rst.
Pump 2 key
Press Pump 2 key to turn
Pump 2 on at high speed.
Press a second time to turn
pump off.
A built-in timer automatically
turns pump off after 20 min-
utes, unless pump has been
manually deactivated rst.
functions

12
Gold series in.k600
13
Gold series in.k600
Pump 3 key
Press Pump 3 key to turn
Pump 3 on at high speed.
Press a second time to turn
pump off.
A built-in timer automatically
turns pump off after 20 min-
utes, unless pump has been
manually deactivated rst.
Light key
Press Light key to turn light on at
high intensity.
Press a second time to turn
light off.
A built-in timer automatically
turns light off after 2 hours,
unless it has been manually
deactivated rst.
+/- keys
Use (+) or (-) key to set desired
water temperature. The tempe-
rature setting will be displayed
for 5 seconds to conrm your
new selection.
The "Set Point" icon indicates
that the display shows the
desired temperature, NOT the
current water temperature!
Program key
Use Program key to display
time or enter Programming
menu by pressing and holding
key. In Programming mode,
the following parameters can
be set: time, purge cycle's
start time, and frequency, also,
Economy mode's start time as
well as its duration and nally
the choice of temperature
display unit.
functions

14
Gold series in.k600
15
Gold series in.k600
Setting the time
Enter Programming mode by
holding Prog. key pressed
down for 3 sec. The display will
show the current time setting.
Setting the hour:
Use (+) or (-) key to change hour
setting (AM/PM).
Setting the minutes:
Press Ok key.
Use (+) or (-) key to change
minutes setting.
Setting purge cycle start
time
To program the purge cycle,
you must enter these param-
eters: start time, and frequency.
During a purge cycle, pumps
run for one minute to purge the
plumbing.
Press Ok key a second time.
The display will show PSxx,
with "xx" representing the
starting hour.
Use (+) or (-) key to change
setting (0:00 h - 23:00h).
Purge cycle frequency
Press Ok key a third time.
The display will show PFxx, with
"xx" representing the number of
purge cycles per day (up to 24).
Use (+) or (-) key to change
setting.
functions

14
Gold series in.k600
15
Gold series in.k600
Setting Economy mode
The Economy mode allows you
to lower the temperature set
point of the spa by 20 °F
(11 °C) during a certain period
of the day.
Press Ok key a fourth time.
Use (+) key to enable the
economy mode, the display
will show EP 1.
Use (-) key to disable economy
mode, the display will show
EP 0.
Setting Economy start time
To program the Economy
mode, you must enter two
parameters: the start time and
the duration.
Press Ok key a fth time.
The display will show ESxx,
with "xx" representing the
starting hour.
Use (+) or (-) key to change
setting (0:00 h - 23:00h).
Setting Economy duration
Press Ok key an sixth time.
The display will show Edxx,
with "xx" representing the
duration in hours.
Use (+) or (-) key to change
setting.
If the Economy mode is not
required the duration must be
set to "0".
If continuous activation of the
Economy mode is required the
duration must be set to "24".
When in Economy mode, the
“Econ” message is displayed.
functions

16
Gold series in.k600
17
Gold series in.k600
Setting temperature unit
Water temperature can be
displayed in either Fahrenheit
(˚F) or Celsius (˚C).
Press Ok key a seventh time.
The display will show either
˚F or ˚C.
Use (+) or (-) key to change
setting.
Press Ok key a last time to go
back to normal mode.
Water temperature regulation
In a regulation cycle, the system
rst generates water ow
through the heater housing
and the plumbing, in order to
ensure accurate water tem-
perature readings as well as
avoiding heater activation in dry
conditions.
After verifying pump activation
and taking a water temperature
reading if required, the system
automatically turns the heater
on to reach and maintain water
temperature at Set Point.
Cooldown
While performing these tasks,
the heater is not allowed to
turn on and its icon ashes.
The heater is not allowed also
to come on throughout the
cool down period of the heater
element.
Smart Winter Mode
Our Smart Winter Mode
protects your system from
the cold by turning pumps on
several times a day to prevent
water from freezing in pipes.
functions

16
Gold series in.k600
17
Gold series in.k600
General specications:
Environmentals:
Storage temperature: 85°C (185°F) to -30°C (-22°F)
Operating temperature: 65°C (149°F) to -20°C (-68°F)
Humidity: up to 95% condensing
Mechanical Specs:
Weight: 0.4763 Kg (1.05 lbs)
Dimensions (W x H x D): Front panel
High Prole:  7.00" x 3.625" x 0.7"
Low Prole:  8.726" x 4.227" x 0.200"
Standars: IP ratings IPX6
Specicationsanddesignaresubjecttochangewithoutpriornotice.
specications

Advanced electronics! Water resistance!
www.aeware.ca
in Canada, available through
Gecko Electronics Inc.
450 des Canetons, Quebec City (Quebec)
G2E 5W6 Canada,1.800.78.GECKO
in U.S.A, available through
Spa Builders Systems Group
9225 Stellar Court, Corona
CA, USA 92883, 1.866.639.7274
9919-100665
Rev 10/05
