ARTEX ME406 User manual

P/N 11934-S36 1 of 8
Cirrus Design Section 9
SR20 Supplements
Pilot’s Operating Handbook and
FAA Approved Airplane Flight Manual
Supplement
for
Artex ME406 406 MHz ELT System
When Artex ME406 406 MHz ELT System is installed in the Cirrus
Design SR20, this POH Supplement is applicable and must be
inserted in the Supplements Section (Section 9) of the Cirrus Design
SR20 Pilot’s Operating Handbook. This document must be carried in
the airplane at all times. Information in this supplement adds to,
supersedes, or deletes information in the basic SR20 Pilot’s Operating
Handbook.
This POH Supplement Change, dated Revision 01: 12-18-08,
supersedes and replaces the Original release of this POH
Supplement dated 08-15-07.
Revision 01: 12-18-08

2 of 8 P/N 11934-S36
Section 9 Cirrus Design
Supplements SR20
Section 1 - General
The 406 MHz emergency locator transmitter (ELT) is a radio-frequency
transmitter that generates a signal to assist in search and rescue for
missing aircraft. The ELT automatically transmits the standard sweep
tone on 121.5 MHz if rapid deceleration is detected. In addition, for the
first 24 hours of operation, a 406 MHz signal containing aircraft
specific information is transmitted at 50 seconds for 440 milliseconds.
8
CIRCUIT
BREAKER
PANEL
(REF)
4
MOUNTING
TRAY (REF)
SR20_FM09_2676
1
2
3
7
6
1
5
WA
R
N
ING
F
ORWA
RD
LEGEND
1. LED Annunciator
2. Remote Switch
3. Antenna
4 Remote Cable
5. Main Control Switch
6. Antenna Jack
7. Attach Straps
8. Artex ME406 ELT
Artex ME406 ELT System
Revision 01: 12-18-08
Figure - 1

P/N 11934-S36 3 of 8
Cirrus Design Section 9
SR20 Supplements
Section 2 - Limitations
No Change.
Section 3 - Emergency Procedures
Forced Landing
Before performing a forced landing activate the ELT transmitter
manually by turning the ELT remote switch to the 'ON'-position.
Immediately after a forced landing, perform the following procedure:
• Note •
The ELT Remote Switch and Control Panel Indicator could be
inoperative in the event of a forced landing. If inoperative, the
inertia “G” switch will activate automatically. However, to turn
the ELT OFF and ON will require manual switching of the main
control switch located on the ELT unit.
1. ELT Remote Switch .........................................................Verify ON
• Switch the ELT Remote Switch ON even if the red LED
annunciator is flashing.
• If airplane radio operable and can be safety used (no threat of
fire or explosion), turn radio ON and select 121.5 MHz. If the
ELT can be heard transmitting, it is working properly.
2. Battery Power ..................................................................Conserve
• Do not use radio transceiver until rescue aircraft is sighted.
After sighting rescue aircraft:
3. ELT Remote Switch ................................................ “ARM” position
to prevent radio interference.
• Attempt contact with rescue aircraft with the radio transceiver
set to a frequency of 121.5 MHz. If no contact is established,
switch the panel mounted switch to the 'ON'-position
immediately.
(Continued on following page)
Revision 01: 12-18-08

4 of 8 P/N 11934-S36
Section 9 Cirrus Design
Supplements SR20
Portable Use of ELT
The ELT transmitter can be removed from the airplane and used as a
personal locating device if it is necessary to leave the airplane after an
accident. Access the unit as described below and set the ELT
transmitter control switch to the 'ON'-position.
1. Remove avionics bay access panel along the aft portion of the RH
fuselage or the lower aft center access panel of baggage
compartment.
2. Disconnect fixed antenna lead from front of unit.
3. Disconnect lead from remote switch and indicator unit.
4. Disconnect antenna from mounting tray.
5. Loosen attach straps and remove transmitter unit.
6. Attach antenna to antenna jack on front of unit.
7. Set main control switch to ON.
8. Hold antenna upright as much as possible.
Section 4 - Normal Procedures
No Change.
Section 5 - Performance
No Change.
Section 6 - Weight & Balance
Installation of the subject propeller adds the following optional (Sym =
O) equipment at the weight and arm shown in the following table.
ATA /
Item Description Sym Qty Part Number Unit Wt Arm
25-01 Artex ME406 ELT and Batteries O 1 17190-100 3.4 229.5
Revision 01: 12-18-08

P/N 11934-S36 5 of 8
Cirrus Design Section 9
SR20 Supplements
Section 7 - Systems Description
This airplane is equipped with a self-contained Artex ME406 406 MHz
ELT System. The transmitter unit is automatically activated upon
sensing a change of velocity along its longitudinal axis exceeding 4 to
5 feet per second. Once activated, the transmitter transmits VHF band
audio sweeps at 121.5 Mhz until battery power is gone. In addition, for
the first 24 hours of operation, a 406 MHz signal is transmitted at 50-
second intervals. This transmission lasts 440 ms and contains
identification data received by Cospas-Sarsat satellites. The
transmitted data is referenced in a database maintained by the
national authority responsible for ELT registration to identify the
beacon and owner.
The ELT transmitter is installed immediately behind the aft cabin
bulkhead, slightly to the right of the airplane centerline. The transmitter
and antenna are accessible through the avionics bay access panel
along the aft portion of the RH fuselage or the lower aft center access
panel of baggage compartment. The main transmitter control switch is
labeled “ON” - “ARM”. The transmitter is in the armed position for
normal operations. A red LED annunciator flashes when the ELT is
transmitting. A battery pack consisting of two “D” cell lithium batteries
mounts to a cover assembly within the transmitter to provide power to
the transmitter. The expiration date of the batteries are indicated on
the outside of the ELT battery case and recorded in the aircraft logs.
A warning buzzer is mounted to the transmitter mounting tray. When
the ELT is activated, the buzzer “beeps” periodically. This buzzer
operates in tandem with the ELT panel indicator and serves as a
redundant annunciation. Power to the buzzer is supplied by the ELT
batteries.
Serials 1005 thru 2015; The ELT Remote Switch and Control Panel
Indicator (RCPI) is located below the circuit breakers on the circuit
breaker panel or Serials 2016 and subsequent, below the Alternate
Induction Air Control knob near the pilot’s right knee.
The RCPI provides test and monitoring functions for the transmitter.
The panel contains a switch labeled “ON” - “ARM”, and a red LED
annunciator. The red LED annunciator flashes when the ELT is
transmitting. Power to the LED is supplied by the clock bus on the
MCU.
Revision 01: 12-18-08

6 of 8 P/N 11934-S36
Section 9 Cirrus Design
Supplements SR20
Section 8 - Handling, Servicing & Maintenance
ELT and RCPI batteries must be inspected in accordance with the
Airplane Maintenances Manual, 5-20 - Scheduled Maintenance
Checks.
The ELT and RCPI batteries must be replaced upon reaching the date
stamped on the batteries, after an inadvertent activation of unknown
duration, or whenever the batteries have been in use for one
cumulative hour.
Inspection / Test
After setting transmitter switch to ARM position, the ELT automatically
enters a self-test mode. The self-test transmits a 406 MHz test coded
pulse that monitors certain system functions before shutting off. The
test pulse is ignored by any satellite that receives the signal, but the
ELT uses this pulse to check output power and frequency. Other
parameters of the ELT are checked and a set of error codes is
generated if a problem is found. The error codes are indicated by a
series of pulses on the transmitter LED, remote control panel indicator
LED, and alert buzzer.
• Note •
FAA regulations require that transmitter tests only be done
during the first 5 minutes of each hour and must not last for
more than 3 audio sweeps (1.5 seconds). If you are at a
location where there is an FAA control tower or other
monitoring facility, notify the facility before beginning the tests.
Never activate the ELT while airborne for any reason.
Operators may wish to use a low quality AM broadcast
receiver to determine if energy is being transmitted from the
antenna. When the antenna of the radio (tuning dial on any
setting) is held about 6 inches from the activated ELT antenna,
the ELT aural tone will be heard on the AM broadcast receiver.
This is not a measured check, but it does provide confidence
that the antenna is radiating sufficient power to aid search and
rescue. The aircraft’s VHF receiver, tuned to 121.5 MHz, may
also be used. This receiver, however, is more sensitive and
could pick up a weak signal even if the radiating ELT’s antenna
is disconnected. Thus it does not check the integrity of the ELT
Revision 01: 12-18-08

P/N 11934-S36 7 of 8
Cirrus Design Section 9
SR20 Supplements
system or provide the same level of confidence as does an
AM radio.
1. Tune aircraft receiver to 121.5 MHz.
2. Turn the ELT aircraft panel switch "ON" for about 1 second, then
back to the "ARM" position. The receiver should transmit about 3
audio sweeps.
3. At turn-off (back to 'ARM' state) the panel LED and buzzer should
present 1 pulse. If more are displayed, determine the problem
from the list below.
4. Codes displayed with the associated conditions are as follows:
a. 1-Flash: Indicates that the system is operational and that no
error conditions were found.
b. 2-Flashes: Not used. If displayed, correct condition before
further flight.
c. 3-Flashes: Open or short circuit condition on the antenna
output or cable. If displayed, correct condition before further
flight.
d. 4-Flashes: Low power detected. If displayed, correct condition
before further flight.
e. 5-Flashes: Indicates that the ELT has not been programmed.
Does not indicate erroneous or corrupted programmed data. If
displayed, correct condition before further flight.
f. 6-Flashes: Indicates that G-switch loop is not installed. If
displayed, correct condition before further flight.
g. 7-Flashes: Indicates that the ELT battery has too much
accumulated operation time (> 1hr). If displayed, correct
condition before further flight.
Section 10 - Safety Information
No Change.
Revision 01: 12-18-08

8 of 8 P/N 11934-S36
Section 9 Cirrus Design
Supplements SR20
Revision 01: 12-18-08
Intentionally Left Blank
