Honeywell STDW810 User manual

Honeywell Process Solutions
SmartLine Wireless Transmitter
Professional Installation Guide
34-SW-25-03
Revision 1
December 2018

Revision 1 SmartLine Wireless Transmitter Professional Installation Guide ii
Notices and Trademarks
Copyright 2018 by Honeywell International Inc.
Revision 1, December 2018
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as may
be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and
specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell Process Solutions
1250 W Sam Houston Pkwy S
Houston, TX 77042

Revision 1 SmartLine Wireless Transmitter Professional Installation Guide iii
About This Document
This document outlines professional installation requirements for the SmartLineTM Wireless Pressure
Transmitter
for the Honeywell OneWireless Network. Professional installation is required to comply with
certification
agency and legal requirements. This document must be adhered to for all installations of the Honeywell
SmartLine Wireless Transmitters.
Honeywell does not recommend using devices for critical control where there is a single point of failure
or where single points of failure result in unsafe conditions. OneWireless is targeted at open loop
control, supervisory control, and controls that do not have environmental or safety consequences. As
with any process control solution, the end-user must weigh the risks and benefits to determine if the
products used are the right match for the application based on security, safety, and performance.
Additionally, it is up to the end-user to ensure that the control strategy sheds to a safe operating condition
if any crucial segment of the control solution fails.
Revision Information
Document Name
SmartLine Wireless Transmitter Professional Installation
Guide
Document ID
34-SW-25-03
Revision Number
Publication Date
1st release
Revision 1
December 2018
References
The following list identifies all documents that may be sources of reference for material discussed in this
publication.
Document Title
Doc #
SmartLine Wireless Transmitter User’s manual
34-SW-25-01
OneWireless R310 Release Notes
OWDOC-X252-en-310A
OneWireless R310 Migration Users Guide
OWDOC-X258-en-310
OneWireless R310 Field Device Access Point Users Guide
OWDOC-X256-en-310
OneWireless R310 Wireless Device Manager Users Guide
OWDOC-X254-en-310
OneWireless R300 Experion PKS Integration Guide
OWDOC-X259-en-300
OneWireless R300 Wireless LAN Controller Configuration Guide
OWDOC-X255-en-300
OneWireless R300 Network Planning an Installation Guide
OWDOC-X253-en-300

Telephone and Email Contacts
iv SmartLine Wireless Transmitter Professional Installation Guide Revision 1
Support and contact info
For Europe, Asia Pacific, North and South America contact details, refer to the back page of this
manual or the appropriate Honeywell Support web site:
Honeywell Corporate www.honeywell.com
Honeywell Process Solutions https://www.honeywellprocess.com/*
Training Classes https://www.honeywellprocess.com/en-US/training
Telephone and Email Contacts
Area
Organization
Phone Number
United States and
Canada
Honeywell Inc.
1-800-343-0228 Customer Service
1-800-423-9883 Global Technical Support
Global Email
Support
Honeywell Process Solutions
[e-mail]

Symbol Definitions
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide v
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol
Definition
ATTENTION: Identifies information that requires special consideration.
TIP: Identifies advice or hints for the user, often in terms of performing a task.
CAUTION
Indicates a situation which, if not avoided, may result in equipment or work (data) on
the system being damaged or lost, or may result in the inability to properly operate
the process.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against unsafe
practices.
CAUTION symbol on the equipment refers the user to the product manual for
additional information. The symbol appears next to required information in the
manual.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could
result in serious injury or death.
WARNING symbol on the equipment refers the user to the product manual for
additional information. The symbol appears next to required information in the
manual.
WARNING, Risk of electrical shock: Potential shock hazard where HAZARDOUS
LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or 60 VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which equipment may be
sensitive. Observe precautions for handling electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the protective earth
(green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as noise immunity
improvement. NOTE: This connection shall be bonded to Protective Earth at the
source of supply in accordance with national local electrical code requirements.
Earth Ground:Functional earth connection. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance with national and
local electrical code requirements.
Chassis Ground: Identifies a connection to the chassis or frame of the equipment
shall be bonded to Protective Earth at the source of supply in accordance with
national and local electrical code requirements.
continued

Symbol Definitions
vi SmartLine Wireless Transmitter Professional Installation Guide Revision 1
Symbol
Description
The Factory Mutual®Approval mark means the equipment has
been rigorously tested and certified to be reliable.
The Canadian Standards mark means the equipment has been
tested and meets applicable standards for safety and/or
performance.
The Ex mark means the equipment complies with the requirements
of the European standards that are harmonized with the 94/9/EC
Directive (ATEX Directive, named after the French "ATmosphere
EXplosible").
For radio equipment used in the European Union in accordance
with the R&TTE Directive the CE Mark and the notified body (NB)
identification number is used when the NB is involved in the
conformity assessment procedure. The alert sign must be used
when a restriction on use (output power limit by a country at certain
frequencies) applies to the equipment and must follow the CE
marking.
The ISA100 Wireless Compliant logo indicates the device has
received ISA100.11a conformance certification and is registered
with the Wireless Compliance Institute, assuring device
interoperability.
CRN
Canadian Registration Number

Contents
Symbol Definitions
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide vii
Contents
1. DESIGNATION, SCOPE AND PREFACE ............................................................ 1
1.1 Designation...................................................................................................................................1
1.2 Scope.............................................................................................................................................2
1.3 Preface ..........................................................................................................................................2
1.4 Site survey ....................................................................................................................................2
1.5 Abbreviations & Definitions........................................................................................................3
2. FEDERAL COMMUNICATION COMMISSION (FCC) .......................................... 5
2.1 FCC Compliance Statement........................................................................................................5
2.2 Industry Canada (IC)....................................................................................................................5
2.2.1 IC Compliance Statements....................................................................................................................5
2.2.2 RF Safety Statement .............................................................................................................................5
2.3 FCC and Industry Canada (IC) Identification Numbers............................................................6
2.3.1 ISA100 Radios.......................................................................................................................................6
2.4 Intended Country Usage..............................................................................................................6
2.4.1 NORTH AMERICA ................................................................................................................................6
2.4.2 EUROPEAN UNION..............................................................................................................................6
3. SMARTLINE WIRELESS TRANSMITTER GENERAL DESCRIPTION ............... 7
3.1 Intended Used...............................................................................................................................7
3.2 SmartLine Wireless Transmitter.................................................................................................7
4. PRODUCT SPECIFICATION ................................................................................ 8
4.1 ISA100 Radio, 2.4 GHz .................................................................................................................8
4.2 SmartLine Wireless Transmitter User Environment.................................................................9
4.3 SmartLine Wireless Instrument Power Specifications.............................................................9
4.4 Weight ...........................................................................................................................................9
4.5 Dimensions.................................................................................................................................10
5. CABLES.............................................................................................................. 11
5.1 SmartLine Wireless Transmitter with N Connectors Antenna or Lightning Arrestor
Cables.....................................................................................................................................................11
5.2 Transmitter connection status..................................................................................................11
5.3 Antenna Lightning Arrestors ....................................................................................................12

Contents
Symbol Definitions
viii SmartLine Wireless Transmitter Professional Installation Guide Revision 1
6. APPROVED ANTENNA TYPES/GAINS............................................................. 13
6.1 Antenna Details ..........................................................................................................................13
7. EQUIVALENT ISOTROPICALLY RADIATED POWER (EIRP).......................... 14
7.1 EIRP LIMITS ................................................................................................................................14
8. SETTING TX POWER......................................................................................... 18
8.1 TX Power Setting........................................................................................................................18
9. AGENCY LABEL INFORMATION...................................................................... 19
9.1 External FCC/IC Labels..............................................................................................................19
9.1.1 External FCC/IC Label ........................................................................................................................19
10. RF SAFETY, MAXIMUM PERMISSIBLE EXPOSURE (MPE) STATEMENT..... 20
10.1 MPE Statement........................................................................................................................20
11. AGENCY COMPLIANCE.................................................................................... 21
11.1 Radio and EMC Certifications...............................................................................................21
11.1.1 Federal Communication Commission (FCC).......................................................................................21
11.1.2 Industry Canada (IC)...........................................................................................................................21
11.1.3 European Telecommunications Standards Institute (ETSI).................................................................21
11.2 Product Safety Agency Certifications.......................................................................................21
11.2.1 European Union Certification (CE-mark).............................................................................................21

Contents
Tables
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide ix
Tables
Table 1-1 –SmartLine Wireless Transmitter Types....................................................................1
Table 1-2 –Table of Abbreviations and Definitions.....................................................................3
Table 4-1 Specifications of ISA100 Radio Module in SmartLine Wireless Transmitter................8
Table 4-2 User Environment Specifications for SmartLine Wireless Transmitter........................9
Table 5-1 Transmitter to Antenna or Lightning Arrestor Cable Specifications for SmartLine
Wireless with N connectors................................................................................................11
Table 6-1 Approved Antenna Types/Gains...............................................................................13
Table 7-1 Maximum EIRP Limits for ISA100 Radios ................................................................14
Table 7-2 ISA100 Transmit Power Settings for the antennas and cable lengths specified
above ................................................................................................................................16
Figures
Figure 3-1 SmartLine Wireless Pressure Transmitter showing 4 dBi Integral Antenna...............7
Figure 4-1 Dimensions of a typical SmartLine Wireless Transmitter with the 4 dBi Integral
Antenna Option..................................................................................................................10
Figure 6-1 Remote Antennas...................................................................................................13

1. Designation, Scope and Preface
1.1. Designation
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide 1
1. Designation, Scope and Preface
1.1 Designation
This document is valid for the following SmartLine Wireless Transmitter types:
Table 1-1 –SmartLine Wireless Transmitter Types
Model
Number
Type
Model Number
Description
Model Key Number
STDW
Differential Pressure
Transmitter
STDW810/820/830/870/720/730/770
STGW
Gauge Pressure
Transmitter
STGW840/870/84L/87L
STGW740/770/73L/74L/77L/78L/79L
STAW
Absolute Pressure
Transmitter
STAW84L/740/74L
STFW
Flange Mount
Pressure
Transmitter
STFW828/724
STRW
Remote Seal
Pressure
Transmitter
STRW87G/74G/82D/73D

1. Designation, Scope and Preface
1.2. Scope
2 SmartLine Wireless Transmitter Professional Installation Guide Revision 1
1.2 Scope
This document outlines professional installation requirements for the Honeywell SmartLine
Wireless Transmitter for the Honeywell OneWireless Network. Professional installation is
required to comply with certification agency and legal requirements. This document must be
adhered to for all installations of the Honeywell OneWireless SmartLine Wireless Transmitters.
1.3 Preface
This manual covers professional installation of the Honeywell OneWireless SmartLine Wireless
Transmitters. See the Getting Started with Honeywell OneWireless, Honeywell OneWireless
Planning Guide and Honeywell OneWireless SmartLine Wireless User’s Guides for general
information on overall system implementation, configuration, and management of these devices.
The SmartLine Wireless is classified by the FCC as a device that must be professionally
installed. To be in compliance with FCC requirements, the transmitter must be installed with one
of the approved antennas listed in this document.
1.4 Site survey
It is assumed for the purposes of this document that a site survey has been performed and that the
antenna types, cable lengths and lightning surge arrestors were appropriately selected per the
results of that survey. Any changes to these items as a result of the actual installation of the
SmartLine Wireless transmitters into the site may require that the TX power setting of the radio
board needs to be adjusted from the factory setting in order to maintain agency approvals. See
Section 0 and Section 8 for more information.

1. Designation, Scope and Preface
1.5. Abbreviations & Definitions
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide 3
1.5 Abbreviations & Definitions
The term Honeywell SmartLine Wireless Transmitter will be used to describe the composite
unit which includes the Honeywell ISA100 RF Module and all subassemblies housed within the
SmartLine Wireless Transmitter enclosure.
Table 1-2 –Table of Abbreviations and Definitions
ACMA
Australian Communications and Media Authority
AD
Authentication Device
ANATEL
National Telecommunications Agency
(Agência Nacional de Telecomunicações)
ATEX
Potentially Explosive Atmospheres Directive
AWG
American Wire Gauge
Co-located
Two or more radios transmitting simultaneously and with less than
20cm of separation distance.
CSA
Canadian Standards Association
DCS
Distributed Control System
DSSS
Direct Sequence Spread Spectrum
EMC
Electromagnetic Compatibility
ETSI
European Telecommunications Standards Institute
EU
European Union
FCC
Federal Communications Committee
FHSS
Frequency-Hopping Spread Spectrum
FM
Factory Mutual
FSK
Frequency Shift Keying
GFSK
Gaussian Frequency Shift Keying
GTS
Honeywell Global Technical Services
IC
Industry Canada
IEEE
Institute of Electrical and Electronics Engineers
INMETRO
National institute of Metrologia, Quality and Technology
(Instituto Nacional de Metrologia, Qualidade e Tecnologia)
IR
Infrared
IrDA
Infrared Data Association
ISA100
International Society of Automation open-standard wireless
networking technology

1. Designation, Scope and Preface
1.5. Abbreviations & Definitions
4 SmartLine Wireless Transmitter Professional Installation Guide Revision 1
KCC
KMOC
Korean Communications Commission, Republic of Korea
Kuwait Ministry of Communications
MIC
Japan Ministry of Internal Affairs and Communications
MPE
Maximum Permissible Exposure
MSG
Honeywell Model Selection Guide
NA
North America –United States of America and Canada
NEMA
National Electrical Manufacturers Association
OQPSK
Offset Quadrature Phase-Shift Keying
TELEC
Japan Telecom Engineering Center
TIIS
Japan Technology Institution of Industrial Safety
TNTC
Thailand National Telecommunications Commission
TX
Transmit
Wi-Fi
Wireless Local Area Network based on IEEE 802.11 Specifications
WNSIA
Wireless Network for Secure Industrial Application

2. Federal Communication Commission (FCC)
2.1. FCC Compliance Statement
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide 5
2. Federal Communication Commission (FCC)
2.1 FCC Compliance Statement
This device complies with Part 15 of FCC Rules and Regulations. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radiofrequency energy and, if not installed and
used in accordance with these instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own
expense.
Intentional or unintentional changes or modifications must not be made to the SmartLine
Wireless unless under the express consent of the party responsible for compliance. Any such
modifications could void the user’s authority to operate the equipment and will void the
manufacturer’s warranty.
2.2 Industry Canada (IC)
2.2.1IC Compliance Statements
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropic radiated power (EIRP) is not more than that permitted
for successful communication.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
This Class A digital apparatus complies with Canadian ICES-003.
French: Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
2.2.2RF Safety Statement
To comply with FCC’s and Industry Canada’s RF exposure requirements, the following
antenna installation and device operating configurations must be satisfied.
Remote Point-to-Multi-Point antenna(s) for this unit must be fixed and mounted on outdoor
permanent structures with a separation distance between the antenna(s) of greater than 20 cm
and a separation distance of at least 20 cm from all persons.
Furthermore, when using integral antenna(s) the SmartLine Wireless unit must not be co-
located with any other antenna or transmitter device and have a separation distance of at least
20cm from all persons.

2. Federal Communication Commission (FCC)
2.3. FCC and Industry Canada (IC) Identification Numbers
6 SmartLine Wireless Transmitter Professional Installation Guide Revision 1
2.3 FCC and Industry Canada (IC) Identification Numbers
This information is shown on the product.
2.3.1ISA100 Radios
Honeywell Identification for ISA100 Intrinsically Safe RF Modules: 51454941-001
Honeywell SmartLine Wireless Transmitter ISA100 Radio Limited Modular
Approval
Federal Communication Commission Identification for Intrinsically Safe RF
Modules: S5751454941
Industry Canada Identification for Intrinsically Safe RF Modules: 573W-51454941
2.4 Intended Country Usage
2.4.1NORTH AMERICA
Country
ISO 3166 2 letter code
Canada
CA
United States
US
2.4.2EUROPEAN UNION
Region
2 letter code
European Union
EU

3. SmartLine Wireless Transmitter General Description
3.1. Intended Used
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide 7
3. SmartLine Wireless Transmitter General Description
3.1 Intended Used
The SmartLine Wireless Transmitter is a key component of the Honeywell OneWireless
Network. The SmartLine Wireless Transmitter uses a low-powered ISA100 2.4 GHz radio to
communicate with Radio Infrastructure and Gateway devices that are connected to a wired DCS
network.
3.2 SmartLine Wireless Transmitter
Figure 3-1 shows the SmartLine Wireless Transmitter with integral antenna.
Figure 3-1 SmartLine Wireless Pressure Transmitter showing 4 dBi Integral Antenna

4. Product Specification
4.1. ISA100 Radio, 2.4 GHz
8 SmartLine Wireless Transmitter Professional Installation Guide Revision 1
4. Product Specification
4.1 ISA100 Radio, 2.4 GHz
WARNING!
The SmartLine Wireless Transmitter must be Professionally Installed in
accordance with the requirements specified in this document. See Section 7
for professional installation maximum TX power setting requirements.
Only the specified TX power settings, antenna types and gains and cable lengths
(attenuation) as outlined in this document are valid for SmartLine Wireless
Transmitter installations.
Table 4-1 Specifications of ISA100 Radio Module in SmartLine Wireless
Transmitter
Item
Specification
Wireless
Standard
FCC 15.247 / IEEE 802.15.4 Direct Sequence Spread Spectrum
(DSSS), 2.4 GHz
Data Rates and
Modulation
Data Rate: 250 kbps
Modulation: Offset Quadrature Phase-Shift Keying (OQPSK –DSSS)
Frequency Band
2,405 –2,475 MHz
Module Transmit
Power
Maximum: 20 dBm
(Maximum transmit power will vary by channel)
Receive
Sensitivity
(typical)
-100 dBm

4. Product Specification
4.2. SmartLine Wireless Transmitter User Environment
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide 9
4.2 SmartLine Wireless Transmitter User Environment
Table 4-2 User Environment Specifications for SmartLine Wireless Transmitter
Item
Specification
Operating Temperature:
–40ºC to +85ºC (–40°F to +185°F)
Storage Temperature:
–40ºC to +85ºC (–40°F to +185°F)
Operating Humidity:
0 to 100% RH
Other Environmental specifications and information may be found in the appropriate Instrument
Specification available on the Honeywell website. www.honeywellprocess.com
4.3 SmartLine Wireless Instrument Power Specifications
The SmartLine Wireless Transmitters operate from two (2) D-size 3.6V Lithium Thionyl
Chloride (Li/SOCl2) batteries. These are joined in series to produce a maximum voltage of +7.6
Vdc. An optional external +24 Volt power supply option is also available.
4.4 Weight
Most non-pressure sensing versions of the SmartLine Wireless transmitter have a maximum
weight of 7.0 lbs (3.2 kg). Pressure transmitter versions can weigh from 7.0 lbs (3.2 kg) to 35 lbs
(15.9 kg) for a flange equipped model. These weights do not include remote cables or antennas.
Add 8.0 lbs (3.6 kg) to any transmitter equipped with the stainless steel housing option (A3 or
SH option).

4. Product Specification
4.5. Dimensions
10 SmartLine Wireless Transmitter Professional Installation Guide Revision 3
4.5 Dimensions
Figure 4-1 Dimensions of a typical SmartLine Wireless Transmitter with the 4 dBi Integral Antenna Option
