YOKOGAWA YTA Series User manual

User’s
Manual
IM 01C50C05-01EN
4th Edition
YTA70P
Temperature Transmitter
IM 01C50C05-01EN

Toc-1
IM 01C50C05-01EN
CONTENTS
1. Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
■ Notes on the User’s Manual.............................. 1-2
■ Notes on Safety and Modications ........................1-2
■ Notes on Factory settings................................1-2
■ For Safe Use of Product.................................1-3
■ Symbols used in this manual .............................1-4
■ Warranty .............................................1-5
■ Waste Electrical and Electronic Equipment (WEEE) Directive ... 1-6
■ The Authorized Representative for this product in the EEA is: ...1-6
■ Manual number .......................................1-6
■ Trademarks ..........................................1-6
■ Control of Pollution Caused by the Product ..................1-7
2. Notes on Handling ...............................2-1
2.1 Label ............................................2-2
2.2 Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.3 Storage ..........................................2-3
2.4 Choosing the Installation Location .....................2-3
2.5 Use of a Transceiver ................................ 2-4
2.6 Withstand Voltage Test .............................. 2-4
2.7 Installation of Explosion Protected Type Transmitters ..........2-5
2.7.1 ATEX Certication ............................ 2-5
2.7.2 FM Certication ..............................2-5
2.7.3 IECEx Certication ...........................2-5
2.7.4 CSA Certication .............................2-5
2.7.5 Label of Explosion Protected Type ...............2-5
3. Part Names .....................................3-1
YTA70P
Temperature Transmitter
IM 01C50C05-01EN 4th Edition
4th Edition: July 2021 (YK)
All Rights Reserved, Copyright © 2014, Yokogawa Electric Corporation

Toc-2
IM 01C50C05-01EN
4. Installation ......................................4-1
5. Wiring ..........................................5-1
5.1 Notes on Wiring ....................................5-1
5.2 Loop Construction ..................................5-1
5.3 Cable Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.3.1 Input signal Cable Selection.................... 5-3
5.3.2 Output Signal Cable Selection ..................5-3
5.4 Cable and Terminal Connections ......................5-3
6. Maintenance ....................................6-1
6.1 General ..........................................6-1
6.2 Trim adjustment....................................6-1
6.2.1 Trim Procedure ..............................6-1
6.3 Troubleshooting ....................................6-3
7. GeneralSpecications ............................7-1
7.1 Standard Specications..............................7-1
7.2 Optional Specications ..............................7-2
7.3 EMC Conformity ...................................7-4
7.4 EU RoHS Directive .................................7-4
8. HART Communicator Operation ....................8-1
8.1 Connection and Requirements ........................8-1
8.2 Parameters .......................................8-2
8.3 Device Variables Mapping ..........................8-12
8.4 Parameter List ....................................8-14
Appendix1. ATEX Installation drawing YTA70PQA01 ......A-1
Appendix2. FM Installation drawing YTA70PQF01......A-3
Appendix3. IECEx Installation drawing YTA70PQI01 ......A-4
Appendix4. CSA Installation drawing YTA70PQC01.......A-6
Appendix5. Label of Explosion Protected Type ........A-7
Parts List for Connectors
Revision Information

1-1
IM 01C50C05-01EN
1. Preface
The YTA70P temperature transmitter is fully factory-tested according to the
specications indicated on the order.
In order for the YTA70P temperature transmitter to be fully functional and
to operate in an e󰀩cient manner, the manual must be carefully read to
become familiar with the functions, operation, and handling of the YTA70P.
This manual gives instructions on handling, wiring and maintenance of
YTA70P temperature transmitters. Changing the parameter settings requires
a terminal dedicated to the HART protocol . For details on how to set the
parameters of these transmitters, refer to chapter 8.
Document No. Explanation
IM 01C50C05-01EN YTA70P Temperature Transmitter
GS 01C50C05-01EN YTA70P Temperature Transmitter
These manuals can be downloaded from the website of Yokogawa or
purchased from the Yokogawa representatives.
Website address: http://www.yokogawa.com/d/

1-2
IM 01C50C05-01EN
■NotesontheUser’sManual
• This manual should be delivered to the end user.
• This manual and the identication tag attached on packing box are
essential parts of the product; keep them in a safe place for future
reference.
• The information contained in this manual is subject to change without
prior notice.
• The information contained in this manual, in whole or part, shall not be
transcribed or copied without notice.
• In no case does this manual guarantee the merchant ability of the
transmitter or its adaptability to a specic client need.
• Should any doubt or error be found in this manual, submit inquiries to
your local dealer.
• No special specications are contained in this manual. When products
whose su󰀩x code or optional codes contain code “Z” and an exclusive
document is attached, please read it along with this manual.
• Changes to specications, structure, and components used may not lead
to the revision of this manual unless such changes a󰀨ect the function and
performance of the transmitter.
■NotesonSafetyandModications
• This product is designed to be used by a person with specialized
knowledge.
• Before handling the YTA70P, it is absolutely imperative that users of this
equipment read and observe the safety instructions mentioned in each
section of the manual in order to ensure the protection and safety of
operators, the YTA70P itself and the system containing the transmitter.
We are not liable for any accidents arising out of handling that does not
adhere to the guidelines established in the safety instructions.
■NotesonFactorysettings
• Model YTA70P is shipped with the ordering settings from the factory.
The label information is shown in Chapter 2.1. The factry setting
information refer to Chapter 7.1.

1-3
IM 01C50C05-01EN
■ForSafeUseofProduct
Please give your attention to the followings.
(a) Installation
• The instrument must be installed by an expert engineer or a skilled
personnel. The procedures described about INSTALLATION are not
permitted for operators.
• All installation shall comply with local installation requirement and local
electrical code.
(b) Wiring
• The instrument must be installed by an expert engineer or a skilled
personnel. The procedures described about WIRING are not permitted
for operators.
• Please conrm that voltages between the power supply and the
instrument before connecting the power cables and that the cables are
not powered before connecting.
(c) Maintenance
• Please do not carry out except being written to a maintenance
descriptions. When these procedures are needed, please contact
nearest YOKOGAWA o󰀩ce.
(d) Modication
• Yokogawa will not be liable for malfunctions or damage resulting from
any modication made to this instrument by the customer.
(e) Product Disposal
• The instrument should be disposed of in accordance with local and
national legislation/regulations.
(f) Authorized Representative in EEA
• In relation to the CE Marking, The authorized representative for this
product in the EEA (European Economic Area) is:
Yokogawa Europe B.V.
Euroweg 2, 3825 HD Amersfoort,The Netherlands

1-4
IM 01C50C05-01EN
■Symbolsusedinthismanual
The YTA70P temperature transmitter and this manual use the following
safety related symbols and signals.
WARNING
Contains precautions to protect against the chance of explosion or
electric shock which, if not observed, could lead to death or serious injury.
CAUTION
Contains precautions to protect against danger, which, if not observed,
could lead to personal injury or damage to the instrument.
IMPORTANT
Contains precautions to be observed to protect against adverse
conditions that may lead to damage to the instrument or a system failure.
NOTE
Contains precautions to be observed with regard to understanding
operation and functions.
Some of the diagrams in this manual are partially omitted, described in
writing, or simplied for ease of explanation. The screen drawings contained
in the instruction manual may have a display position or characters (upper/
lower case) that di󰀨er slightly from the full-scale screen to an extent that does
not hinder the understanding of functions or monitoring of operation.

1-5
IM 01C50C05-01EN
■Warranty
The warranty period of the instrument is as of condition shown when
purchasing.
Any trouble arising during the warranty period shall be replaced at free of
charge.
The following problems or troubles shall not be eligible of charge-exempt
repair.
• Caused by improper usage or storage of the customer which exceeds
the specication requirements.
• Caused by mishandling or modication.
• Caused by re, earthquake or other acts of God that are not directly a
result of problems of the instrument.
● Conditionsnoteligibleforcharge-exemptrepair.
• Problems caused by improper or insu󰀩cient maintenance on the part of
the customer.
• Trouble or damage caused by mishandling, misusage, or storage that
exceeds the design or specication requirements.
• Problems caused by improper installation location or by maintenance
conducted in a non-conforming location.
• Trouble or damage was caused by modication or repair that was
handled by a party or parties other than our consigned agent.
• Trouble or damage was caused by inappropriate relocation following
delivery.
• Trouble or damage was caused by re, earthquake, wind or ood
damage, lightning strikes or other acts of God that are not directly a result
of problems with this instrument.

1-6
IM 01C50C05-01EN
■WasteElectricalandElectronicEquipment(WEEE)Directive
 (ThisdirectiveisonlyvalidintheEU)
This product complies with the WEEE Directive marking requirement.
The following marking indicates that you must not discard this electrical/
electronic product in domestic househole waste.
Product Category
With reference to the equipment types in the WEEE directive Annex 1,
this product is classied as a “Monitoring and Control instrumentation”
product.
Do not dispose in domestic household waste.
When disposing products in the EU, contact your local Yokogawa
Europe B.V. o󰀩ce.
■TheAuthorizedRepresentativeforthisproductintheEEAis:
Yokogawa Europe B.V.
Euroweg 2, 3825 HD Amersfoort, THE NETHERLANDS.
■Manualnumber
The last two characters of the manual number and general specication
number indicate the language in which the manual is written.
■Trademarks
• HART is a trademark of the HART Communication Foundation.
• Registered trademarks or trademarks appearing in this manual are not
designated by a TM or ® symbol.
• Other company names and product names used in this manual are the
registered trademarks or trademarks of their respective owners.

1-7
IM 01C50C05-01EN
■ControlofPollutionCausedbytheProduct
This is an explanation for the product based on “Control of Pollution caused
by Electronic Information Products” in the People’s Republic of China.
電
電
子
子
情
情
報
報
製
製
品
品
汚
汚
染
染
制
制
御
御
管
管
理
理
弁
弁
法
法
（
（
中
中
国
国
版
版
R
R
o
o
H
H
S
S
）
）
产品中有害物质或元素的名称及含量
型号 部件名称
有害物质
铅
（Pb）
汞
（Hg）
镉
（Cd）
六价铬
（Cr(VI)
）
多溴联苯
（PBB）
多溴二苯醚
（PBDE）
YTA70P
温度变送器
壳体 × ○○○○○
基板组件 × ○○○○○
电源连接线 × ○○○○○
○：表示该部件的所有均质材料中的有害物质的含量均在 GB/T26572 标准中所规定的限量以下。
×：表示至少该部件的某些均质材料中的有害物质的含量均在 GB/T26572 标准中所规定的限量以上。
环保使用期限：
该标识适用于 SJ /T11364 中所述，在中华人民共和国销售的电子电气产品的环保使用期限。
注）该年数为“环保使用期限”，并非产品的质量保证期。

2-1
IM 01C50C05-01EN
2. Notes on Handling
The YTA70P temperature transmitter is fully factory tested upon shipment.
When the YTA70P is delivered, check the appearance for damage, and also
check that the transmitter parts shown in Figure 2.1 are included with your
shipment.
A CJC Connector
or an RTD Connector
Temperature Transmitter
YTA70P
User’s Manual
F0201.ai
A CJC or an RTD connector is attached to the product as specified in
the order, and the connector not attached to the product is included in
the package.
11 12 13 14
Figure 2.1 Transmitter parts

2-2
IM 01C50C05-01EN
2.1 Label
The model name and conguration are indicated on the Label. Verify that
the conguration indicated in the “Model and Su󰀩x Code” in Chapter 7 is in
compliance with the specications written on the order sheet.
F0202.ai
Sub-labelMain label
Suffix
Model name
This notation shows setting at
the shipment.
When user changes the setting,
the user revises the notation.
Figure2.2 Labels
2.2 Transport
To prevent damage while in transit, leave the transmitter in the original
shipping container until it reaches the installation site.

2-3
IM 01C50C05-01EN
2.3 Storage
When an extended storage period is expected, observe the following
precautions:
1. If at all possible, store the transmitter in factory shipped condition, that is,
in the original shipping container.
2. Choose a storage location that satises the following requirements.
• A location that is not exposed to rain or water.
• A location that is not exposed to direct sunlight.
• A location subject to a minimum of vibration or impact.
• The following temperature and humidity range is recommended.
Ordinary temperature and humidity (25°C, 65%) are preferable.
Temperature: -40 to 85°C
Humidity: 0 to 95% RH (Non-Condensation)
2.4 ChoosingtheInstallationLocation
Although the temperature transmitter is designed to operate in a
vigorous environment, to maintain stability and accuracy, the following is
recommended:
(1) Ambient Temperature
It is preferable to not to expose the instrument to extreme temperatures
or temperature uctuations. If the instrument is exposed to radiation
heat a thermal protection system and appropriate ventilation is
recommended.
(2) Environmental Requirements
Do not allow the instrument to be installed in a location that is exposed
to corrosive atmospheric conditions. When using the instrument in a
corrosive environment, ensure the location is well ventilated. The unit
and its wiring should be protected from exposure to rainwater and direct
sunlight.
(3) Impact and Vibration
It is recommended that the instrument be installed in a location that is
subject to a minimum amount of impact and vibration.

2-4
IM 01C50C05-01EN
2.5 UseofaTransceiver
Although the temperature transmitter is designed to resist inuence from high
frequency noise; use of a transceiver in the vicinity of installation may cause
problems. Installing the transmitter in an area free from high frequency noise
(RFI) is recommended.
2.6 WithstandVoltageTest
CAUTION
• Overvoltage of the test voltage that is so small that it does not cause
an dielectric breakdown may in fact deteriorate insulation and lower
the safety performance; to prevent this it is recommended that the
amount of testing be kept to a minimum.
• The voltage for the withstand voltage test must be 500 VAC or lower.
Failure to heed these guidelines may cause faulty operation.
Withstandvoltagetestprocedure
■ Testing between the output terminal and the input terminal
1. Lay transition wiring between 11 and 14 of connector. *1
2. Lay transition wiring between all input terminals (except CJC) of
connector. *1
3. Connect the withstand voltage tester (with the power turned OFF)
between the transition wiring shown in steps 1 and 2 above.
4. After setting the current limit value of the withstand voltage tester to 10
mA, turn the power ON, and carefully increase the impressed voltage
from 0 V to the specied value.
5. The voltage at the specied value must remain for duration of one
minute.
6. Upon completion of the test, carefully reduce the voltage so that no
voltage surge occurs.
*1: Refer to Figure 5.3 for terminal Number.

2-5
IM 01C50C05-01EN
2.7 Installation of Explosion Protected Type Transmitters
In this section, further requirements and di󰀨erences and for explosion
protected type instrument are described. For explosion protected type
instrument, the description in this chapter is prior to other description in this
user’s manual.
CAUTION
To preserve the safety of explosion protected type instrument requires
great care during mounting, wiring.
Safety requirements also place restrictions on maintenance and repair
activities. Please read the following sections very carefully.
2.7.1 ATEXCertication
See Appendix.1 ATEX Installation drawing YTA70PQA01
2.7.2 FMCertication
See Appendix.2 FM Installation drawing YTA70PQF01
2.7.3 IECExCertication
See Appendix.3 IECEx Installation drawing YTA70PQI01
2.7.4 CSACertication
See Appendix.4 CSA Installation drawing YTA70PQC01
2.7.5 Label of Explosion Protected Type
See Appendix.5 Label of Explosion Protected Type
NOTE
The YTA70P is a single sensor input model.
Please ignore the loop construction of CH2.

3-1
IM 01C50C05-01EN
3. Part Names
A CJC Connector
or an RTD Connector
Temperature Transmitter
YTA70P
F0301.ai
12 13 14
11
Figure 3.1 Part Names

4-1
IM 01C50C05-01EN
4. Installation
For details of choosing the installation location, refer to the guidelines
outlined in Section 2.4, “Choosing the installation location”.
F0401.ai
Mounting on DIN rail
11 12 13 14
Figure4.1 MountingtheTransmitter

4-2
IM 01C50C05-01EN
①
②
F0402.ai
First, remember to turn off power supply and remove output signal cable.
Detach the device from the DIN rail by lifting the lock.
11 12 13 14
Figure4.2 DetachtheTransmitter

5-1
IM 01C50C05-01EN
5. Wiring
5.1 Notes on Wiring
IMPORTANT
• Lay wiring as far away as possible from electrical noise sources such
as large transformers, motors and power supplies.
• To prevent electrical noise, the signal cable and the power cable must
not be housed in the same conduit.
5.2 Loop Construction
The YTA70P is a two-wire temperature transmitter that uses the output
power supply wiring and signal wiring alternately.
The transmission loop requires DC power. Connect the transmitter with the
distributor as shown in Figure 5.1 or Figure 5.2.
For the transmission loop, the load resistance of the distributor or other
instrument to be installed in the loop and the lead wire must be within the
range shown in Figure 5.3.
F0501.ai
Input signal
(Thermocouples,
RTDs,DC millivolts,etc)
Output signal
Distributor
(Power supply unit) Receiver
+
–
Figure5.1 LoopConstruction(forGeneral-useType)

5-2
IM 01C50C05-01EN
F0502.ai
<Hazardous location> ← → <Nonhazardous location>
Input signal
(Thermocouples,
RTDs,DC millivolts,etc)
Output
signal
Distributor
(Power supply unit) Receiver
+
–
Safety
barrier
Figure5.2 LoopConstruction(forIntrinsicallySafeType)
(Ω)
Power supply voltage E (V DC)
600
250
R
8.0 13.8 21.8
External
load
resistance
E-8
0.0236
R=
Digital
Communication
range
F0503.ai
35.0
Figure 5.3 RelationbetweenPowerSupplyVoltageandLoadResistance
Note: For intrinsic safe explosion protected type units, the internal
resistance of the safety barrier is also included in the load resistance.
