Arthrex Synergy UHD4 Series User manual

SynergyUHD4 / SynergyID Imaging System
Quick Guide







1. Synergy console
2. Synergy laser light source (only for
fluorescence imaging)
3. Synergy camera head
4. Light cable (only for fluorescence
imaging: bifurcated type)
5. Endoscope
6. Tablet
7. Monitor
1. Power Up Cart/System
■ Plug in main power cord and turn on main switch
on cart
■ Switch on individual devices as needed
■ Blue start screen is displayed on tablet
after  -  minutes
2. Enter Patient Data on Tablet
■ Log in with user and password
■ Select
■ The following screen appears for patient entry:
• Required: Surgeon, Procedure, Patient
(all other fields are optional)
• Date of birth (calendar icon)
- From right to left (year | month | day)
- “Set”
• Select one of the following:
a) Patient appears in patient list
b) Select twice to begin surgery
right away

3. Assemble Equipment
■ Connect camera head to console
■ Connect light cable
• Plug light cable onto scope (check for correct
light post adapter)
•
• Plug light cable into Synergy console on the
leftmost
• Only for fluorescence imaging: Plug the other
open cable ending of the bifurcated side into
laser console (make sure that it is fully inserted
and leading downwards)
■ White Balance
• Press “LED” button on Synergy console and
dim room lights
• Direct endoscope to a white surface and press
left or right camera head button for white
balance
• If not successful, try again within  seconds or
use “White Balance” button on Synergy console
• Green check mark appears on main monitor
once white balance was successful
4. During the Procedure
■ Adjust focus with gray ring on camera head
■ Individual camera button programming, short-
press and long-press functionalities (standard
functions include image / video capture, zoom)
■ Functions and settings can also be controlled
from the tablet
■ Caution: Never directly expose eyes to the light
coming from the light cable or endoscope!
5. End the Procedure
■ Select and confirm with “Yes”
■ Review, export, or print images and videos as
needed; when done, select “Finish Review”
■ The blue tablet start screen will be displayed again
6. Power Down the System
■ Shut down Synergy console (press and
hold green on / o button)
■ Switch o the other devices individually
■ Press main switch on the side of the cart
arthrex.com
©2023-01 Arthrex GmbH. All rights reserved. LI2-000126-en-US_B
This description of technique is provided as an educational tool and clinical aid to assist properly licensed medical professionals in the usage of specific Arthrex products. As part
of this professional usage, the medical professional must use their professional judgment in making any final determinations in product usage and technique. In doing so, the
medical professional should rely on their own training and experience, and should conduct a thorough review of pertinent medical literature and the product’s directions for use.
