Aport-214PG is a FreeRTOS Programmable Device Server. It features Ethernet, RS-
485 and DIO in a single unit and is C programmable with embedded web server.
Software developer can use powerful Atmel Studio to program to compile and debug
their applications. Lots of example programs are included for users to jump start their
applications. A Manager utility is included to discover Aport-214PG and upgrade its
application firmware remotely.
1.1 Features
 Atmel SAM4E16E ARM Cortex-M4 120M z
 1MB on-chip flash and 128KB on-chip SRAM.
 2MB flash and 128KB SRAM via SPI expansion
 One 10/100Mbps Ethernet port
 Two RS-485 serial port
 Four isolated Digital input
 Two Relay output
 FreeRTOS operating system
 Support lwIP and BSD socket library
 Support tiny web server
 Windows configuration utility included
 Toolchain: Atmel Studio
 One Micro-SD Card interface
 Low Power operating
 Remote firmware upgrade
1.2 Specifications
 PU: Atmel SAM4E16E Cortex-M4 120M z
 Memory: 1MB on-chip flash and 128KB on-chip SRAM
2MB flash and 128KB SRAM via SPI expansion
 Mass Storage:
 MicroSD socket inside x 1
 SD 2.0 compliant, Support SD C
 Network Interface:
 1 x 10/100Mbps Ethernet
 RJ45 Connector
 Protection: 1.5KV Magnetic isolation

Aport-214PG ardware Guide
ARTILA
6
 Serial port:
 2 x RS-485
 Signal: Data+ (D+), Data-(D-)
 RS-485 Automatic Flow Control: Yes
 Isolation digital input:
 Channel number: 4
 Photo isolation (AC in): 2500Vrms
 Logical igh: 5~24Vdc
 Logical Low: 0~1.5Vdc
 Input type: AC input
 Input resistance: 1.2K [email protected]W
 Relay output:
 Channel number: 2
 Contact rating: 30VDC@1A or 125VAC@0.5A
 Pin define: NC / COM / NO
 Power Input: +9 ~ +48VDC, terminal block
 Dimension (W x L x ): 78 x 108 x 24mm (3.0 x 4.25 x 0.94in)
 Weight: 290g (0.64lb)
 LED Indicator: Power, Ready, DO, RS-485, LAN, Status (user defined)
 Operating Temperature: 0~70°C
 Installation: Wall mounting, DIN-rail mounting (with optional kit)
1.3 Packing List
 Aport-214PG: Programmable device server
 Software toolchain (download from Atmel web support)
 Manager Utility (download from Artila web)
1.4 Optional Accessory
 DK-35A (36-DK35K-000): DIN RAIL Mounting Kit
 PWR-12V-1A (31-62100-000): 110~240VAC to 12VDC 1A Power Adaptor

Aport-214PG ardware Guide
ARTILA
7
2. Layout
2.1 Outline

Aport-214PG ardware Guide
ARTILA
8
2.2 Dimension
Unit=mm

Aport-214PG ardware Guide
ARTILA
9
3. Pin Assignment and Definition
3.1 LED Indicator
The LED provides the Aport-214PG operation information described as follow:
 RDY: Ready LED keeps ON when Aport-214PG software is ready for operation.
 PWR: Power LED keeps ON if power (+9VDC to +48VDC) is correct.
 DO0 / DO1: These LEDs indicate the relay status. When the coil of relay is
energized, the LED will be ON.
 LAN: Link and Activity LED will turn ON when the Ethernet cable is connected.
When there is network data traffic, this LED will flash.
 STATUS: User defined, control by software/GPIO
 RS-485 (D1/D2): This LED is dual color and it indicates the serial data traffic of RS-
485 respectively. The Yellow LED stands for receiving data and Green LED means
transmitting data.
3.2 Power Input
Connecting +9 ~ +48VDC power line to the Power in terminal block(V+/V-). If the power
is properly supplied, the Power LED will keep solid green and a beep will be heard.
V+: DC power + in
V-: Power ground

Aport-214PG ardware Guide
ARTILA
10
3.3 RS-485 Serial Port (D1 & D2)
D1+ / D2+: Data+
D1- / D2-: Data-
Enable/Disable Termination resistor for RS-485 (J2 & J3)
The Aport-214PG equips on-board 120Ohm termination resistor for each RS-485 port.
Default setting is disable termination resistor. In order to enable termination resistor,
please remove the top cover of the Aport-214PG, and the adjust the associated jumper
to short position1 - 2, shown below:
J2 is termination resistor selection for RS-485(D1)
J3 is termination resistor selection for RS-485(D2)
Termination Resistor Enabled
Termination Resistor Disabled (default)
3.4 Relay Output (DO0 & DO1)
DO0_N : Relay two normal close
DO0_ OM: Relay two common
DO0_NO: Relay two normal open
DO1_N : Relay one normal close
DO1_ OM: Relay one common
DO1_NO: Relay one normal open
3.5 Isolated Digital Input
DI0: Digital input 1
DI1: Digital input 2
DI2: Digital input 3
DI3: Digital input 4
DI OM: Common pin of DI0~DI3
DI1~4
DI_COM
