Artis EXCITE UNITY User manual

MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
ARTIS CARDIO - EXCITE
UNITYTM
User Manual

2
Contents
Il test di Wingate...................................................................30
Bruce test ............................................................................. 31
Bruce modied test.............................................................32
Astrand modied test..........................................................33
Costill & Fox test ..................................................................34
Naughton test.......................................................................35
Balke & Ware test ................................................................36
Military tests.........................................................................38
The Air Force PRT test for Bike and Recline.......................39
The Navy PRT test for Bike, Recline and Synchro............. 41
The Air Force PRT test for Run.............................................42
The Navy PRT test for Run...................................................42
Gerkin Protocol.....................................................................43
Army PFT test .......................................................................44
PEB (Federal Law Enforcement) test................................44
Marine Corps PFT test..........................................................45
Preset proles......................................................................46
Create your own...................................................................47
Constant heart rate (CPR) exercise...................................48
Training zone exercise.........................................................49
Weight loss exercise............................................................50
Green deal............................................................................. 51
Cool down..............................................................................52
Conguration menu.............................................................53
Description of Unity - Artis Line............................................ 3
Description of Unity - Excite Line ......................................... 4
Unity integration with NFC and Bluetooth........................... 5
Status bar................................................................................ 6
Home Page.............................................................................. 7
Exercises................................................................................. 8
Data displayed during the exercise ................................... 10
Keys that are active during the exercise .......................... 11
Quick start ............................................................................ 13
Warm Up................................................................................ 13
Hi-low blocks ..................................................................14
Hills........................................................................................ 15
Burn out ................................................................................ 16
Speed shift............................................................................ 17
Cross training ....................................................................... 18
Goal driven exercises .......................................................... 19
Fitness test...........................................................................20
Smart test............................................................................. 23
Single stage model............................................................... 24
Multistage model .................................................................25
Maximal tests.......................................................................26
Technogym maximal test ................................................... 27
Custom maximal test for Run.............................................28
Custom maximal test for Top..............................................29
Unity

3
Description of Unity - Artis Line
A - Screen: it allows you to view and control information, settings and
contents both for workouts and for entertainment. The tablet-style
touch screen interface allows you to include the contents oered by
the Technogym App Store.
B - Support for iPod/iPhone/iPad: this is used to connect your iPod/iPhone
to the equipment. If connected, the device charges. This support is
optional.
C - Input for TGS key and mywellness key. The device reads the training
data on the TGS key or mywellness key and memorises the exercise
results.
D - Headphone connector: used to plug in headphones and listen to audio
content; or also an earphone with microphone to make Skpe calls.
E - USB port
F - NFC sensor
G - Webcam
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
A
B
E
C D
A
B
E
DC
G
G
FF
Unity

4
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
A
F
BB
D D
A
C
C
E
EF
Unity
Description of Unity - Excite Line
A - Screen: it allows you to view and control information, settings and
contents both for workouts and for entertainment. The tablet-style
touch screen interface allows you to include the contents oered by
the Technogym App Store.
B - Support for iPod/iPhone/iPad: this is used to connect your iPod/iPhone
to the equipment. If connected, the device charges. This support is
optional.
C - Input for TGS key and mywellness key. The device reads the training
data on the TGS key or mywellness key and memorises the exercise
results.
D - Headphone connector: used to plug in headphones and listen to audio
content.
E - USB port
F - NFC sensor

5
Unity integration with NFC and Bluetooth
How to use the NFC sensor
Activate the Internet connection on your device and download the data with NFC.
Identify the position of the NFC sensor on your device (on a smartphone, for example).
Before starting the exercise, place your own device on the equipment and line the sensor on your device up with the NFC logo. In this way, your device
connects to the Technogym cloud and displays the training program and video showing how to do the exercises correctly.
At the end of the exercise the results are saved in the Technogym cloud.
To connect with NFC:
- the internet connection in Unity must be activated;
- the Technogym application must be installed in your personal device
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV
MUSIC
OUTDOORS
How to use Bluetooth
Bluetooth functionality makes it possible to manage the audio contents of your Apple
device directly with Unity.
Activate the Bluetooth connection on your device (for example, on your smartphone).
Press the Music button in Unity.
A list of devices will appear; select your device.
Conrm the match in your device.
Now Unity and the Bluetooth device are connected and it will not be necessary to
repeat the procedure. Simply turn on Bluetooth in your device and move towards Unity.
Unity can also be connected with the Bluetooth headphones in the same way.
Unity

6
Status bar
The contents and controls vary according to the equipment on which it is installed.
The status bar is the only element that is always shown.
15:30
ESERCIZI
AVVIO
TV LINGUA
WEB
GUIDAMIMYWELLNESS ESERCIZIO
A DISTANZA
ESERCIZIO
A TEMPO
ESERCIZIO
A CALORIE
Unity
Touch the HOME symbol
to go to the home page.
Touch the BACK symbol
to go back 1 level, to the
previous page.
Touch the AUDIO symbol to control
the audio volume.
The time is in read only mode.

7
The characteristics of the product and the initial page may dier according to the
version, the amount of personalised settings and the applications used.
The screen may appear as totally blank, with a ashing LED (in the Artis Line); or with
a screensaver.
Touch the screen at any point to switch it on.
To personalise the screensaver connect to the Technogym website,usingthe credentials
supplied when purchasing Unity.
Home Page
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
Unity

8
14:00
GOAL DRIVEN
HEART RATE
DRIVEN
ADVANCED
ON TREND
TIME
CALORIES
DISTANCE
Select the exercise
Decide the time
you want to exercise
GOAL EXERCISE IN TIME
TESTS
Unity
Exercises
Touch the blue box EXERCISES.
For a quicker search, all the exercises are divided into categories.
To start one of the exercises or the test:
- touch the name of the category; a list of exercises or tests will appear on the right
- touch the name of the exercise or test; a brief description of the exercise or test
will appear
- touch the scroll symbol on the right.
The following is the list of categories and the exercises included in each of them.
The number of exercises, categories and tests may vary depending on the line (Artis
or Excite) and product.
Goal driven exercises
These are exercises which start quickly because the only parameter that requires
setting is the goal value.
- time
- distance
- calories
Heart rate driven exercises
These are exercises performed at a constant heart rate and therefore the heart rate
monitor must be used:
- CPR, constant pulse rate
- Training zone
- Weight loss
On trend
- Hi-low blocks
- Hills
- Cross training
- Burn out, exercise specic for Bike and Recline Artis
- Speed shift, exercise specic for Run Artis

9
Unity
Exercises
Advanced exercises
These are exercises in various steps, with preset load variations or variations set by the user:
- Preset proles
- Create your own
Tests
Depending on the type of equipment, there are three test categories available:
- Maximal tests
- Submaximal tests
- Military tests
You may be asked to enter data before starting the exercises and the test.
Age and weight data are not generally needed to start an exercise, they are optional. Entering your age and weight is useful for some calculations; for example:
- if your weight is entered, the calculation of calories burned will be more precise;
- if your age is entered, calculation of your max heart rate will be more precise.
If no user data is entered, the calculations are based on a use who is 30 years old and weighs 70 kg.

10
Unity
Data displayed during the exercise
During the exercise, data related to the exercise will be displayed at the centre of the
screen. The following data is shown for all products:
- time elapsed, expressed in minutes and seconds;
- calories burned, expressed in kilocalories;
- distance covered, expressed in kilometres;
- heart rate, if detected, expressed in beats per minute.
In Bike, Top and Recline the following data is also shown:
- power, expressed in watts;
- speed, expressed in rpm, that is “revolutions per minute”;
- eort level.
In Synchro, Step, Vario and Crossover the following data is also shown:
- power, expressed in watts;
- speed, expressed in spm, that is “strides per minute”;
- eort level.
In Run and Jog the following data is also shown:
- gradient, expressed as a percentage;
- speed, expressed in km/h;
- pace, expressed in min/km
MYWELLNESS
14:00
TV
EXERCISES
425
time
heart rate
min:sec calories kcal
10.5
distance
km
78
COOL DOWN
6.0
pace
km/h
1.0 0
15:00
time
min:secbeats/min
gradient
(%)
31:56
speed
km/h
STOP
PAUSE WEB
In the Excite Step the distance is expressed in oors.
The theoretical max heart rate (HR) is calculated with the formula
220-age, therefore we recommend inserting the age whensetting
an exercise, even though it is not compulsory, for a correct heart
rate display.
W
Always check that your heart rate never goes above
90% of your maximum rate.

11
Unity
Keys that are active during the exercise
Pause / Stop key
To interrupt the exercise for a quick pause. During pauses, all values remain where
they were; press RESTART to continue, or STOP to nish. A message informs you of the
maximum pause time, after which the exercise stops, displaying the results achieved
up to the interruption.
Stop key
To end the exercise without a cool down.
The Stop key to nish the exercise is present while the exercise is paused.
Cool down key
To end the exercise and start the cool down.
Change speed keys (in Run and Jog)
During the exercise, the + and - keys in the speed box can be used to change the speed
of the treadmill belt. The speed increases or decreases by 0.1 km/h each time the key
is pressed.
You can also use the Fast Track control on the right to change the speed.
Change gradient keys (in Run and Jog)
During the exercise, the + and - keys in the gradient box can be used to change the
gradient of the treadmill belt. The gradient increases or decreases by 0.5% each time
the key is pressed.
You can also use the Fast Track control on the right to change the gradient.
MYWELLNESS
14:00
TV
EXERCISES
425
time
heart rate
min:sec calories kcal
10.5
distance
km
78
COOL DOWN
6.0
pace
km/h
1.0 0
15:00
time
min:secbeats/min
gradient
(%)
31:56
speed
km/h
STOP
PAUSE WEB

12
Unity
Keys that are active during the exercise
Change eort level keys (in Bike, Recline, Synchro, Vario, Step, Top and Crossover)
During the exercise, the + and - keys in the eort level box can be used to change the eort level. The level increases or decreases by 1 unit each time the
key is pressed.
The combination of eort level and speed of movement determines the workload or power expressed in watts. The power value during the exercise can be
checked on the screen.
In the exercises that are driven from a constant workload (speed, power, heart rate), there are also the + and - keys to change the value of the workload.

13
Unity
Quick start
Exercises started with Start are on a time increase basis; the age and weight values
are predened, i.e. 30 years and 70 kilograms.
In Bike, Recline, Synchro, Vario and Crossover, this exercise is performed at a constant
torque and starts at eort level 1.
In Top this exercise is performed at a constant torque and starts at eort level 5.
In Step this exercise is performed at a constant speed and starts at eort level 1.
In Run, when starting the speed of the belt is 0.8 km/h, with a 0% gradient.
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
Warm Up
Warm Up is a specic Top Excite exercise and can be found in the on trend category.
The Warm Up is a warm up exercise for the upper part of the trunk performed at constant torque mode.
This warm up lasts 4 minutes, 3 minutes with the forward movement and 1 minute backwards.
The duration of the WARM UP can be modied in the conguration menu; in case of modication, the movement remains forward for the rst 3/4 of the
exercise, and backwards for the remaining 1/4.
At the end of the exercise there is no cool down.

14
obiettivo
14:00
76 1200.02
10:00
10
253
193
132
75
76
77
effort level
speed distance
time
time
heart rategoal
watt
rpm
PAUSE
STOP
Unity
Hi-low blocks
The Hi-low blocks exercise can be found in the On trend category.
Challenging interval training to maximise exercise eectiveness: the Hi-low blocks prole is an alternative to the usual interval training and burns more
calories.
It has a wide intensity range: from 80% to 140% of the selected eort level.
It improves aerobic endurance and the eectiveness of the workout can be immediately perceived.
To start this exercise, you must set the duration and eort level.
The minimum duration is 10 minutes.
The age and weight settings are optional.

15
obiettivo
14:00
76 1200.02
10:00
10
253
188
124
75
76
77
effort level
speed distance
time
time
heart rategoal
watt
rpm
PAUSE
STOP
Unity
Hills
The Hills exercise can be found in the On trend category.
Smooth variations around the level you choose: the Hills prole has slight changes in intensity.
Intensity ranges from 85% to 120% of the selected eort level.
It improves aerobic endurance more quickly and increases calorie consumption.
To start this exercise, you must set the duration and eort level.
The minimum duration is 10 minutes.
The age and weight settings are optional.
This prole manages the specic eort level specied by the user, calculated with the tness test. You should therefore do the tness test rst and perform
the exercise at an eort level that is no higher than the recommended one.

16
obiettivo
14:00
77 1200.02
10:00
10
136
68
0
0
40
79
effort level
speed distance
time
time
heart rategoal
watt
rpm
PAUSE
STOP
Unity
Burn out
The Burn out exercise can be found in the On trend category.
Intervals with self adaptive resistance; the Burn out prole consists of an anaerobic exercise performed at a constant speed.
It improves performance with a short duration exercise.
To start this exercise, you must set the duration and eort level.
The age and weight settings are optional.
This exercise is available for in and Recline.

17
MYWELLNESS
14:00
GAMES
EXERCISE GOAL
IN DISTANCE
EXERCISE GOAL
IN TIME
EXERCISE GOAL
IN CALORIES
EXERCISES
START
TV OUTDOORS
WEB
Runtronic Fast Track
Unity
Speed shift
The Speed shift exercise can be found in the On trend category.
The smartest way to do interval training you can easily change from one set
exercise speed and another, using the Fast Track Control.
To start this exercise, you must set the speeds, which may be 2, 3 or 4 dierent
speeds.
The age and weight settings are optional.
The exercise starts with the rst speed you have set.
During the exercise use the Fast Track Control to go directly from one set speed
to another.
This exercise is available in Run.

18
obiettivo
14:00
76 1200.02
14:00
10
253
188
124
75
76
77
effort level
speed distance
time
time
heart rategoal
watt
rpm
PAUSE
STOP
Unity
Cross training
The Cross training exercise can be found in the On trend category.
Enjoy a great variety to kill boredom; the Cross training prole consists of a series of changes in intensity at a medium/high eort level.
To start this exercise, you must set the duration and eort level.
The age and weight values are optional.

19
Unity
Goal driven exercises
To start a goal driven exercise, you must rst select one of the goals:
- time, i.e. the exercise duration,
- distance to cover,
- calories to burn.
Press the Enter key to continue.
Then select the goal value and press the Enter key to continue.
The age and weight settings are optional.
In Bike, Recline, Synchro, Vario and Crossover, this exercise is performed at a constant torque and starts at eort level 1.
In Top, this exercise is performed at a constant torque and starts at eort level 5.
In Step, this exercise is performed at a constant speed and starts at eort level 1.
In Run, when starting the speed of the belt is 0.8 km/h, with a 0% gradient.

20
Unity
Fitness test
The tness test is also suitable for a quite unt or moderately t user.
You need to wear the heart rate monitor to perform the test; if there is no heart rate signal the test does not start.
To start the test, you must enter your age, weight and gender.
The tness test is in three stages; in the warm up stage the workload is determined externally; in the next two stages, the workload is internal, as it is
determined by the heart rate.
Fitness test for Bike, Recline, Synchro, Vario
stage time workload
warm up 90 seconds 50 watts
1 3 minutes after reaching the workload
60% of the Max heart rate if the HR at the end of warm up is <= 100
65% of the Max heart rate if the HR at the end of warm up is > 100
2 4 minutes after reaching the workload 75% of the Max heart rate
Fitness test for Run and Jog
stage time workload
warm up 90 seconds speed 3.5 km/h and 0% gradient
1 3 minutes after reaching the workload
60% of the Max heart rate if the HR at the end of warm up is <= 100
65% of the Max heart rate if the HR at the end of warm up is > 100
2 4 minutes after reaching the workload 75% of the Max heart rate
