© Stäubli Faverges 2008
Arm - RX series 90B family
Instruction manual
D28045104F - 02/2008

2D28045104F - 02/2008
© Stäubli Faverges 2008

D28045104F - 02/2008 3
© Stäubli Faverges 2008
TABLE OF CONTENTS
1 - INTRODUCTION....................................................................................9
1.1. FOREWORD ........................................................................................................................... 11
1.1.1. Objective of this manual .............................................................................................. 11
1.1.2. Special messages concerning warnings, alerts, and information................................ 11
1.2. DEFINITION OF THE ELEMENTS AROUND THE ROBOT CELL ........................................ 12
1.3. REMINDER CONCERNING THE SAFETY STANDARDS ..................................................... 13
1.4. SAFETY DIRECTIVES CONCERNING TO THE WORK ENVIRONMENT ............................ 14
1.4.1. Analysis of safety around the robot cell....................................................................... 14
1.4.2. Rules concerning the robot's work area ...................................................................... 14
1.5. SAFETY DIRECTIVES CONCERNING TO STAFF PROTECTION ....................................... 15
1.5.1. Mechanical and electrical dangers. ............................................................................. 15
1.5.2. Robot cell safety devices............................................................................................. 16
1.5.3. Safety directives concerning to protection of the equipment....................................... 17
2 - DESCRIPTION.....................................................................................21
2.1. IDENTIFICATION.................................................................................................................... 23
2.2. GENERAL PRESENTATION.................................................................................................. 25
2.3. DESIGNATION OF ROBOTS OF THE RX SERIES 90B FAMILY ......................................... 27
2.4. GENERAL CHARACTERISTICS............................................................................................ 27
2.4.1. Overall dimensions...................................................................................................... 27
2.4.2. Work environment ....................................................................................................... 27
2.4.3. Weight ......................................................................................................................... 29
2.5. PERFORMANCE .................................................................................................................... 29
2.5.1. Torque limits................................................................................................................ 29
2.5.2. Amplitude, speed and resolution ................................................................................. 29
2.5.3. Modification of amplitudes........................................................................................... 31
2.6. LOAD CAPACITY – MECHANICAL INTERFACE ................................................................. 33
2.6.1. Load capacity .............................................................................................................. 33
2.6.2. Attachment of additional load on forearm.................................................................... 35
2.6.3. Additional load diagrams ............................................................................................. 37
2.7. USER CIRCUIT ....................................................................................................................... 39
2.8. RELEASING JOINT BRAKE .................................................................................................. 39
2.9. PNEUMATIC AND ELECTRIC CIRCUITS (EXCEPT FOR CLEAN ROOM APPLICATION) ... 41
2.9.1. Pneumatic circuit ......................................................................................................... 41
2.9.2. Electric circuit .............................................................................................................. 41
2.10. PNEUMATIC AND ELECTRIC CIRCUITS CLEAN ROOM APPLICATION........................... 43
2.10.1. Pneumatic circuit ......................................................................................................... 43
2.10.2. Electric circuit .............................................................................................................. 43

4D28045104F - 02/2008
© Stäubli Faverges 2008

D28045104F - 02/2008 5
© Stäubli Faverges 2008
2.11. PRESSURIZATION SYSTEM FOR DUSTY SURROUNDINGS OR SPATTERING WITH
LIQUIDS .................................................................................................................................. 45
2.11.1. Purpose ....................................................................................................................... 45
2.11.2. Installation ................................................................................................................... 45
2.12. SAFETY .................................................................................................................................. 47
3 - ON-SITE PREPARATION....................................................................49
3.1. WORKING SPACE ................................................................................................................. 51
3.2. ATTACHMENT........................................................................................................................ 51
4 - INSTALLATION ...................................................................................53
4.1. ARM PACKAGING ................................................................................................................. 55
4.2. HANDLING OF PACKING ...................................................................................................... 55
4.3. UNPACKING AND INSTALLATION OF THE ARM ............................................................... 55
4.4. INSTALLATION OF ARM ....................................................................................................... 57
4.4.1. Installation of arm on floor........................................................................................... 57
4.4.2. Installation of arm on ceiling........................................................................................ 57
4.4.3. Mounting floor quality .................................................................................................. 57
4.5. SPRING TENSION .................................................................................................................. 59
5 - INTERNAL VARIATIONS BETWEEN VARIOUS TYPES OF ARMS .61
5.1. PURPOSE OF THIS CHAPTER ............................................................................................. 63
5.2. JOINTS 1AND 2..................................................................................................................... 63
5.3. JOINTS 3AND 4..................................................................................................................... 65
6 - TRANSMISSION CASING OIL CHANGE ...........................................67
6.1. JOINT 1TRANSMISSION CASING ....................................................................................... 69
6.2. JOINT 2TRANSMISSION CASING ....................................................................................... 69
6.3. JOINT 3TRANSMISSION CASING ....................................................................................... 71
6.4. JOINT 4TRANSMISSION CASING ....................................................................................... 71
6.5. TRANSMISSION CASING OF JOINTS 5AND 6 ................................................................... 73
6.6. PROCEDURE FOR REPLACING THE FLAT SEAL .............................................................. 73
6.6.1. Removing the seal....................................................................................................... 73
6.6.2. Fitting a new seal ........................................................................................................ 73

6D28045104F - 02/2008
© Stäubli Faverges 2008

D28045104F - 02/2008 7
© Stäubli Faverges 2008
7 - OPERATIONS ON MOTORS ..............................................................75
7.1. MOTOR PLAY ADJUSTMENT PROCEDURE ....................................................................... 77
7.1.1. Access to motors......................................................................................................... 77
7.1.2. Joints 1, 2, 3and 4 ...................................................................................................... 77
7.1.3. Joints 5and 6 .............................................................................................................. 77
7.2. REPLACEMENT OF A MOTOR ............................................................................................. 79
7.2.1. Joint 1.......................................................................................................................... 79
7.2.2. Joint 2.......................................................................................................................... 81
7.2.3. Joint 3.......................................................................................................................... 83
7.2.4. Joint 4.......................................................................................................................... 85
7.2.5. Joints 5and 6 .............................................................................................................. 87
8 - PREVENTIVE MAINTENANCE ...........................................................89
8.1. MAINTENANCE FREQUENCY .............................................................................................. 91
8.2. CHECKING OIL LEVELS ....................................................................................................... 93
8.2.1. Arm in floor-mounted position ..................................................................................... 93
8.2.2. Arm in ceiling-mounted position .................................................................................. 95
8.3. GREASING OF THE BALANCE SYSTEM ECCENTRIC BEARINGS ................................... 97
9 - RECOMMENDED SPARE PARTS....................................................101

8D28045104F - 02/2008
© Stäubli Faverges 2008

Chapter 1 – Introduction
D28045104F - 02/2008 9
© Stäubli Faverges 2008
CHAPTER 1 –
INTRODUCTION

10 D28045104F - 02/2008
© Stäubli Faverges 2008

Chapter 1 – Introduction
D28045104F - 02/2008 11
© Stäubli Faverges 2008
1.1. FOREWORD
The information contained in the present document is the property of STÄUBLI and it cannot be
reproduced, in full or in part, without our prior written approval.
The specifications contained in the present document can be modified without notice. Although all
necessary precautions have been taken to ensure that the information contained in this document is correct,
STÄUBLI cannot be held responsible for any errors or omissions found in the illustrations, drawings and
specifications contained in the said document.
If any difficulties are met with during operation or servicing of the robot that are not referred to in this
document, or if further information is required, please contact the STÄUBLI After Sales Department, "Robot
Division".
STÄUBLI ®, UNIMATION ®, VAL ®
are brands registered by STÄUBLI INTERNATIONAL AG.
1.1.1. OBJECTIVE OF THIS MANUAL
The objective of this manual is to provide information concerning the installation, operation and
maintenance of STÄUBLI robots. It provides help for the persons working on the equipment, for reference
purposes only. Indeed, in order to understand the present document and the use of STÄUBLI robots, it is
necessary for staff to acquire the corresponding knowledge by following a "robots" training course as
provided by STÄUBLI.
1.1.2. SPECIAL MESSAGES CONCERNING WARNINGS, ALERTS, AND
INFORMATION
In this document, there are two formats for warnings and alerts. The messages contained in the boxes
inform staff of the potential risks involved in carrying out an action.
These boxes are as follows (they are shown in decreasing order of importance):
Danger message
Warning message
DANGER:
Instructions drawing the reader's attention to the risks of accidents that could
lead to serious bodily harm if the steps shown are not complied with. In general,
this type of indication describes the potential danger, its possible effects and the
steps necessary to reduce the danger. It is essential to comply with the
instructions to ensure personal safety.
CAUTION:
Instructions drawing the reader's attention to the risks of material damage if the steps
shown are not complied with. It is essential to comply with these instructions to ensure
equipment reliability and performance levels.

12 D28045104F - 02/2008
© Stäubli Faverges 2008
Notes
Paragraphs of the "note" type provide very important information to help the reader to understand a
description or a procedure.
Note:
Supplies further information, or underlines a point or an important procedure. This
information must be memorized to make it easier to apply and ensure correct sequencing
of the operations described.
1.2. DEFINITION OF THE ELEMENTS AROUND THE ROBOT CELL
Person: general term identifying all individuals likely to come close to the STÄUBLI robot cell.
Staff: identifies the persons specifically employed and trained to install, operate, and service the STÄUBLI
robot cell.
User: refers to the persons or the company responsible for operating the STÄUBLI robot cell.
Operator: refers to the person who starts or stops the robot, or controls its operation.

Chapter 1 – Introduction
D28045104F - 02/2008 13
© Stäubli Faverges 2008
1.3. REMINDER CONCERNING THE SAFETY STANDARDS
The robot is a sub-assembly designed for integration in a robot cell. It has been designed and built to enable
the "robot cell" unit to comply with regulatory provisions. Compliance of the robot cell is the responsibility of
the prime contractor who very frequently is the owner.
The user must make sure that the staff programming, operating, maintaining or repairing the robot or the
robot cell are correctly trained and show the skills necessary to carry out these tasks in full safety.
In France, for example, posters isued by the CRAM are available to remind operators of the safety rules
applicable in the vicinity of robot stations.
The electrical equipment of the robot and the robot cell must comply with standard EN 60204-1.
The characteristics of the power supply and the grounding terminals must comply with the manufacturers'
specifications.
The robot and its controller are designed to meet a "Category III" safety level.
Standards applicable
Installation of the robot must be planned in accordance with the standard instructions.
DANGER:
The robot is a fast moving machine. These movements can be dangerous.
Always comply with the safety standards recommended for robot use and
inform operators about the dangers faced.
• ISO 10218-1, 2006 Robots for industrial environment - Safety
•EEC 98 / 37 "Machine Safety" Directive European Directive
•Standard EN 292 General principles
•Standard EN 294 Safety distances
•Standard EN 418 Emergency stop equipment
•Standard EN 953 Protective elements
•Standard EN 954-1 Machine safety
•Standard EN 349 Minimum clearances
•Standard EN 1050 Risk assessment
•Standard EN 1088 Locking devices
•Standard EN 60204-1 Electrical equipment on machines
•Standard EN 999 Speed on approach towards the human body
•Standard EN 61 000-6-4 Electromagnetic compatibility - Emission
•Standard EN 61 000-6-2 Electromagnetic compatibility - Immunity
•Standard CEI 34-1 Electrical rotating machines

14 D28045104F - 02/2008
© Stäubli Faverges 2008
1.4. SAFETY DIRECTIVES CONCERNING TO THE WORK ENVIRONMENT
1.4.1. ANALYSIS OF SAFETY AROUND THE ROBOT CELL
Safety must be taken into account for the robot cell from the design and development stage on.
Before planning the installation of the robot cell, it is necessary to study the following points:
•Plan the safety strategies that reduce risks to an acceptable level.
•Define the tasks required for the foreseeable applications and assess the access and/or approach
requirements.
•Identify the sources of risks including the failures and the failure modes associated with each of the tasks.
The risks can involve:
•the cell itself
•its association with other items of equipment
•the interactions between persons and the cell.
•Assess and estimate the risks stemming from cell operation:
•programming risks
•operating risks
•risks during use
•maintenance risks for the robot cell.
•Select the protective methods:
•use of protective devices
•installation of signalling means
•compliance with safe working procedures.
These points are taken from the standards applicable to robots.
Note:
This list is not exhaustive. Above all, it is necessary to comply with the standards in force
in your country.
1.4.2. RULES CONCERNING THE ROBOT'S WORK AREA
The controlled area or isolation area in which the robot moves must be determined using protective devices
(protective elements).
Note:
Protective elements are devices protecting persons from a dangerous area. See the
standards currently in force concerning safety for industrial handling equipment.
DANGER:
To ensure reliability and precision in the robot's movements, the robot cell
environment must comply with the levels of disturbance set out in the safety
standards.
DANGER:
At the time of an emergency stop, the final position of the arm can never be
determined precisely because of the kinetic energy involved. It is thus
necessary to make sure that no persons or obstructions are present in the
robot's work area when the arm is powered up.

Chapter 1 – Introduction
D28045104F - 02/2008 15
© Stäubli Faverges 2008
1.5. SAFETY DIRECTIVES CONCERNING TO STAFF PROTECTION
Stäubli robots work with computer controlled mechanisms, capable of moving at high speed and exerting
considerable force. Like all robots and most industrial equipment, they must be controlled with great care
by the user of the robot cell. All staff using Stäubli robots must be familiar with the warnings and
recommendations given in this manual.
1.5.1. MECHANICAL AND ELECTRICAL DANGERS.
To turn of power, set the CS8C main switch to the "0" position.
To prevent inadvertent during the service operation, the main switch must be locked in 0position using a
padlock whose key is to be kept by the person carrying out the service operation. The locked status must
be shown by a sign. For example, put a "Do not operate" sign in place.
Before powering up the system, make sure that all the electrical protection systems have been fitted and
that there is no risk of electric shocks.
Note:
When the main switch is set to 0, voltage remains present between the input terminals
(mains supply filter) and the main switch input.
•Do not connect or disconnect components while the unit is under power. The connection between the
controller and the robot arm can only be made if the controller has been switched off.
•The arm must not be loaded during maintenance operations.
•If unusual sounds or vibrations are noted on the robot arm, especially following a shock or some other
incident, it is necessary to inspect the tool and gripper fastenings carefully and make diagnoses at low
speed.
Note:
If a crash of the arm occurs, all safety components involved in the safety have to be
checked carefully to verify they are still operating and not damaged: hard stop devices on
the arm, electrical limit switches, calibration of the robot. Don't hesitate to call Stäubli
service for any doubt.
Each time a calibration, adjustment or recovery procedure is done, the calibration of the
arm has to be controlled carefully to verify that the robot is able to move in its expected
angular range and not more. This verification has to be done at slow speed.
DANGER:
Disconnect all the electrical and pneumatic power supplies before carrying out
any work on the controller or the arm.
DANGER:
Each time the arm is powered on, keep one hand close to the "Emergency stop"
button in order to be able to press it as quickly as possible in the event of a
problem.
DANGER:
All persons are prohibited from remaining in the isolation area in which the robot
arm operates. Certain robot working modes such as the "brake release" mode
can lead to unforeseeable arm movements.

16 D28045104F - 02/2008
© Stäubli Faverges 2008
Figure 1.1
Following maintenance work, whether it involves mechanical, electrical, pneumatic or software operations,
it is advisable to make sure that the robot functions correctly, first at low speed while the person stays
outside the cell, and then under the normal conditions of use. In particular, make sure that all the protective
and safety systems are correctly in place, and that calibration of the robot is correct.
1.5.2. ROBOT CELL SAFETY DEVICES
The safety devices must form an integral part of the design and installation of the robot cell. Operator
training and compliance with the operating procedures constitute a major element in setting up the safety
devices and systems.
Stäubli robots are equipped with various communication functions, helping the user to develop safety
devices for the robot cell. These functions include the emergency stop circuits, the digital Input/Output lines,
and the display system for error and warning messages (see the "Integration" chapter). When the system
is used without the MCP, these messages/warnings can only be consulted via the application program.

Chapter 1 – Introduction
D28045104F - 02/2008 17
© Stäubli Faverges 2008
1.5.3. SAFETY DIRECTIVES CONCERNING TO PROTECTION OF THE
EQUIPMENT
1.5.3.1. CONNECTIONS
•Before connecting the controller to the power supply, make sure that its nominal voltage does indeed
correspond to the network voltage.
•When connecting the controller, use a cable whose cross-section corresponds to the power rating shown
on the manufacturer's plate.
•Before removing or inserting an electronic component, switch off arm power and then switch off controller
power and comply with the procedure.
•Take care to avoid blocking the air inlets and outlets for the controller airflow path.
•Never use the emergency stop to power down the arm under normal conditions of use.
1.5.3.2. INFORMATION ON ELECTROSTATIC DISCHARGES
What is an electrostatic discharge?
Everyone has felt the effects of static electricity on their clothes or when they touch a metal object, without
being aware of the damage that can be done to electronic components by static electricity.
Our desire to integrate the notions of quality and reliability in our products makes it necessary to prevent
electrostatic discharges from causing damage to them. This means that all the staff and login users must
be informed.
Storage of a charge
An electric charge is created simply by combining a conductor, a dielectric and the ground (lowest reference
potential, usually the ground in the case of an electrostatic charge).
Example: people, printed circuits, integrated circuits, components, conducting mats when separated from
the ground by a dielectric.
Electrostatic discharges or ESD
Most people have experienced ESD by receiving an electric shock when walking on a carpet and touching
a doorknob or when getting out of a car.
In most case, the following is true:
•To feel an ESD, a charge of at least 3500 V is required.
•To hear one, a charge of at least 5000 V is required.
•To see a spark, a charge of at least 10 000 V is required.
This shows that it is possible to develop charges of over 10 000 V before noticing an electrostatic discharge!

18 D28045104F - 02/2008
© Stäubli Faverges 2008
Risks created by an electrostatic discharge
A high ESD voltage (several thousand volts) creates danger for electronic components. A semi-conductor
must be handled carefully to prevent destruction by ESD. ESD are truly dangerous. It is estimated that they
destroy only 10% of the components that they effect. The other 90% of components fall into the
"deteriorated" category. A component may be damaged with simply 25% of the voltage required to destroy
it.
These hidden faults can lead to problems that appear several days, weeks or even months after the
incident. Components may also undergo a change in their operating characteristics. Initial tests are
successfully passed but an intermittent error occurs under vibration or temperature constraints. The same
components will pass the "on/off" test successfully, as carried out during repairs, but the problem will
reappear again once on site.
Typical ESD voltages
SOURCE
LOW RELATIVE
HUMIDITY
10 - 20%
AVERAGE RELATIVE
HUMIDITY
40%
HIGH RELATIVE
HUMIDITY
65 - 90%
Walking on carpet 35 kV 15 kV 1,5 kV
Walking on vinyl 12 kV 5 kV 0,3 kV
Working at the
workstation
6 kV 2,5 kV 0,1 kV
Plastified instructions 7 kV 2,6 kV 0,6 kV
Polyethylene bags 20 kV 2 kV 1,2 kV
Cellular polyurethane 18 kV 11 kV 1,5 kV
CHARGE SOURCES
Work surfaces Packaging
Floors Handling
Chairs Assembly
Carriages Cleaning
Clothes Repairing
PARTS SENSITIVE TO STATIC CHARGES
Electronic cards
Power supplies
Encoders
etc

Chapter 1 – Introduction
D28045104F - 02/2008 19
© Stäubli Faverges 2008
1.5.3.3. PREVENTION OF DAMAGE DUE TO ELECTROSTATIC DISCHARGES
It is essential to guard against electrostatic discharges during an intervention concerning electronic
components, sub-assemblies and complete systems.
Elimination of the danger due to ESD requires a combined team effort. By complying with the following
instructions, you can substantially reduce the potential damage caused by ESD and ensure long-term
reliability for the robot.
•Inform the staff of the risks stemming from ESD.
•Know the critical zones sensitive to ESD.
•Know the rules and procedures to deal with ESD.
•Always carry components and boards in a tray to protect them from electrostatic charges.
•Always ground yourself before working on a workstation.
•Keep non-conducting equipment (static charge generators) away from components and boards.
•Use tools providing protection from ESD.
STÄUBLI workstation
To handle electronic cards, STÄUBLI workstations are given a grounded coating that dissipates static
electricity. An anti-static bracelet is required to handle boards or electronic components.
Work zones
Remove objects that generate static electricity charges from the work area, such as:
•plastic cups
•polystyrene
•notebooks
•plastic files and document holders.
Printed circuits, boards and electronic components must be kept in anti-static bags.
Anti-static wrist strap
Use an electrostatic wrist strap connected to the frame of the controller or to the frame of the arm and the
ground during all handling of boards or components. The wrist straps are supplied as part of the standard
equipment for the robot.
CAUTION:
Use an anti-static wrist strap and an anti-static mat connected to the controller for all
work involving handling of boards or components.
