QUICK GUIDE
Please review this guide carefully before using the product.
·Charging Time
100 minutes
(On full discharged: 150 minutes)
· Operating Time
100 minutes (Two times of mop
cleaning with one full charging)
After 50 minutes of cleaning, the robot
will stop automatically to inform you to
change mop pads and put more water in
the water tanks.
Prevent the battery discharge by turning
off the power switch on the bottom.
① Moisten mops thoroughly with
water and attach them to the
main unit after wringing
them out.
④ Close the rubber stopper of the water water tanks and
attach the water tanks to the bottom of the main unit.
(Pressing it while turning side to side will install it with a
click sound.)
⑤ Turn on the power switch located on the
bottom of the main unit.
(You will hear a sound, when turned on.)
⑥ Start cleaning by pushing the button
of main unit or the remote control.
② Attach the mops centrally on
the bottom side of the water tanks.
③ Open the rubber stopper of
the water tanks and fill with water.
Components
How To Use
RS700 Main Unit
Water Tank
Microfiber Mops
Remote Control
Power Adapter
Please check before using the product!
·Please charge the product fully before the
first operation.
·When charging the battery, the button on
the main unit and the remote control don’t
work .
·Do not use any other power adapter other
than the one, which came with the unit.
Yellow LED Blinks
Low Battery Level
Blue LED Blinks
Medium Battery Level
LED is Off
Full Battery
Charging
How to Start the Wet Cleaning Mode
Right
Wrong
Right
Wrong
MTG GmbH

You can select different cleaning modes by using the remote control.
① Attach the dry mops centrally
on the bottom side of the
water tanks.
② Attach the water tanks to the
bottom of the main unit.
③ Turn on the power switch
on the bottom of the main
unit.
④ Start ‘dry cleaning mode’
by pushing the button of
the remote control.
www.moneual.de
[email protected]
Select Cleaning Mode
Precautions When Using the Product
Cleaning Sensors
Simple Trouble Shooting
LED Lamp is Off
Check LED Lamp
Alarms Sounds During Cleaning
Auto Cleaning
Dry Mop
Cleaning Mode
As a basic cleaning mode, cleans
the entire space efficiently.
Y Curve Cleaning
Thoroughly cleans with Y curve
patterns as if wiping floor
by hands.
Focus Cleaning
Intensively cleans the
surrounding area relative to the
main unit current location.
Corner Cleaning Mode
Cleans the corner to repeat
turning 180° along the walls.
Manual Cleaning Mode
Cleans the floor while you can
change direction by using the
remote control.
Turbo Mode
Clean the whole space faster by
the increased motor speed.
·Before charging the product, please check to see if you are using
the adapter, which came with the unit.
※If connected with a non authorized adapter, the product may be damaged.
The warranty is invalid.
※Don't moisten the mop.
·If water gets inside the main unit, it will be damaged.
※If the water gets inside the main unit, do not use it and contact the customer center.
The warranty is invalid.
·If there is dust or the foreign substance on sensors, gently wipe them
using a cotton swab or dry cloth.
·If sensors are contaminated severely, wipe them using a slightly wet
cotton swab.
※ Do not clean the device under water, with benzene or alcohol.
·If the device is not used for 5 minutes after switching
on the power button, the LED lamp turns off.
·If pushing the button of the main unit or the remote
control, the robot cleaner will start cleaning.
·The battery status is too low, so the device
doesn't work.
·Please charge the battery
·When the battery is charging, the button
of the main unit or remote control does
not work.
·Check whether the front or rear bumper is
pushed.
·Check if there is any foreign substance on
the cliff detection sensors on the bottom of
the main unit.
·Check if there is any foreign substance on
the obstacle detection sensors in the front
of bumper.
·Check whether connected the authorized
adapter.
·Start the robot cleaner again after turning
on/off the system power switch
·If the same symptom is repeated, please
turn off the system power switch and
contact the customer service.
·After 50 minutes of cleaning, the device will
sound an alarm to remind you of exchanging
the mop pads and refill the water tanks.
·For better cleaning results, please restart the
device after mop exchange and water refill.
Unauthorized disassembling of the device may cause damage. ｜ If there is a problem with operation, please contact customer service center. ｜ The warranty period of the battery is six months.
Obstacle Detection Sensor
LED Off LED On
Blue LED
blinks
Yellow LED
On Yellow LED
blinks
Cliff Detection Sensor
Red LED
blinks
Be careful not to get water
inside the operating button.
Do not turn the main unit
upside down when there is
water in the water tanks.
Do not put the robot cleaner
in humid places
(toilet, veranda in rainy day)
