Artos F501-3-1 User manual

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
INSTALLATION GUIDE
F501-3-1
opera lav faucet
BRUSHED NICKEL(BN)
CHROME(CH)

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
OPERATING SPECIFICATIONS
OPERATING PRESSURE
Minimum: 15 psi
Maximum: 75 psi
90psi+ may be necessary to install a pressure reducer
OPERATING TEMPERATURE
Maximum: 176°
FLOW RATE
1.2 USGPM
REQUIREMENTS
Max Surface Thickness: 1-5/8”
CODES
UPC Approved
F501-3-1
opera lav faucet

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
PRODUCT DIMENSIONS
F501-3-1
opera lav faucet
6-1/2”
2-1/4”
5”
1-1/8”
4-1/2”
5-3/4”
1-3/4”
3/8”
15/16”
2”
1/4”

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
STEP 1
F501-3-1
opera lav faucet

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
STEP 2
INSTALLATION STEPS

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
STEP 3
INSTALLATION STEPS
F501-3-1
opera lav faucet
HOT
COLD

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
FAUCET HANDLE F501-3-1 XP1
DRESS RING F501-3-1 XP2
CARTRIDGE SECURING NUT F501-3-1 XP3
CARTRIDGE F501-3-1 XP4
FAUCET BODY F501-3-1 XP5
FAUCET ESCUTCHEON F501-3-1 XP6
RUBBER WASHER F501-3-1 XP7
METAL WASHER F501-3-1 XP8
THREADED ROD(2) F501-3-1 XP9
UNDER DECK SECURING NUT(2) F501-3-1 XP10
FAUCET SPOUT SET SCREW F501-3-1 XP11
ALLEN WRENCH F501-3-1 XP12
AERATOR WASHER F501-3-1 XP13
AERATOR F501-3-1 XP14
AERATOR REMOVAL TOOL F501-3-1 XP15
SUPPLY HOSE O-RING(2) F501-3-1 XP16
SUPPLY HOSE(2) F501-3-1 XP17
1
2
3
4
5
6
11
12
7
8
9
10
16
15
14
13
17
F501-3-1
opera lav faucet
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
WESTOVER, INC 13305 B STREET OMAHA, NEBRASKA 68144 T:877.927.8679WWW.ARTOS.US.COM
©2016 ed. All technical and pricing information is subject to change without prior notice. To confirm accuracy check with Artos customer service.
faucets are guaranteed for life against leaks and finishing defects
for as long as the original purchaser owns it.
Damage caused by accident, misuse, abuse, improper installation, improper cleaning
or alteration will void the warranty. This warranty does not cover replacement parts
where damage is caused by normal wear and tear. Westover, Inc is not responsible
for labor charges, installation or other incidental or consequential costs. Proof of
purchase must be provided with all claims.
For best results, keep the following in mind to retain the high quality finish of your
faucets:
Use a soft, dampened sponge or cloth. On no account should you use an abrasive
material such as a brush, scouring pad or steel wool to clean surfaces.
Test your cleaning agent solution on an inconspicuous area before applying to the
entire faucet.
Wipe surfaces clean and rinse completely with water immediately after applying
cleaning agent.
An ideal cleaning technique is to rinse faucet thoroughly and blot dry any water
from the surface after each use.
CARE & MAINTENANCE
LIMITED LIFETIME WARRANTY
Please register this product online at WWW.ARTOS.US.COM
ITEM NO. F501-3-1
SERIAL NO.
F501-3-1
opera lav faucet
