ARTRAY 1000MINI Series User manual

- 1 -
November 25, 2022
Ver1.02
USB2.0 CMOS CAMERA
ARTCAM-1000MINI
INSTRUCTION BOOKLET
10.0M pixels ARTCAM-1000MINI
ARTRAY CO., LTD.

- 2 -
Contents
1. Attention.................................................................................................................................................. - 3 -
2. Introduction............................................................................................................................................. - 6 -
3. Main Features......................................................................................................................................... - 6 -
4. The Product ............................................................................................................................................ - 7 -
4.1. Cased model（ARTCAM-1000MINI/1000MINI-BW）................................................................ - 7 -
4.2. Open frame model（ARTCAM-1000MINI-OP/1000MINI-BW-OP）......................................... - 7 -
5. Connections ............................................................................................................................................ - 8 -
5.1. How to connect a camera .............................................................................................................. - 8 -
5.2. Shutter Speed.................................................................................................................................. - 8 -
5.3. Operation clock settings ................................................................................................................ - 8 -
6. Specifications ......................................................................................................................................... - 9 -
6.1. Color Model ..................................................................................................................................... - 9 -
6.2. Monochrome Model...................................................................................................................... - 10 -
7. Dimensions ........................................................................................................................................... - 11 -
7.1. CASED, USB CABLE DIRECT TYPE............................................................................................ - 11 -
7.2. OPEN FRAME TYPE ..................................................................................................................... - 12 -
8. Spectral Sensitivity Characteristics ................................................................................................... - 13 -
8.1. ARTCAM- 1000MINI series(Color model) .................................................................................. - 13 -
8.2. ARTCAM-1000MINI-BW series (Monochrome model)............................................................. - 13 -
9. System Requirements.......................................................................................................................... - 14 -
9.1. Recommended System Requirements ....................................................................................... - 14 -

- 3 -
1. Attention
■About this manual
1. Before using the camera, please read this manual thoroughly.
2. Please keep this manual reachable and always refer to the contents when needed.
3. Please contact us if the manual is lost or damaged. We will provide a replacement.
4. We cannot guarantee the safety of improper uses of the camera.
5. For your safety, please follow the directions of this manual.
6. All contents are subject to change.
7. Images in this manual may have been simplified to be easier comprehended.
8. Please contact us if you find any unclear points or mistakes in this manual.
9. Quoting, copying or altering some or all parts of the manual without our permission is prohibited.
10. We are not responsible for any lost or damages on your profits due to the use of our products.
11. Please understand that our oversea branches do not provide maintenance or repair services.
■About the Icons
To keep the safety of the user, other people and their properties, please pay attention to the following
icons.
W Warning
If the user fails to follow the instruction, serious injury or death may occur.
Caution
If the user fails to follow the instruction, physical injury on human or damages on hardware may occur.

- 4 -
■For Safe Use
Warning
●In following circumstances, please stop using the product and turn off the power immediately to
prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or
exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
Please stop using the product and turn off the power immediately when:
・The product becomes smoky or gets extremely hot on the surface, or makes unusual smells or sounds.
・Foreign material or water gets into the product.
・The product falls and becomes damaged.
●Do not place the product on unstable surfaces. The product may be fallen and people may get hurt.
Caution
●Do not expose the product to steam or fumes to avoid electric shocks and fires.
●Do not leave the product in high temperature places such as inside of vehicles or under direct
sunlight. High temperature may cause damages to the camera, or even cause fires.
●Do not cover the product with cloth or other materials. The product may get extremely hot and the
heat may cause deformations on the parts or even cause fires.
●Please avoid dropping or shocking the product as the product may be damaged.
●Do not touch the cable with a wet hand. Such action may cause electric shocks.
●Please avoid continuously contacting the surface of the camera to your skin when the camera is
being used. The surface temperature of the camera may cause burns.
■Other Notices
●Please do not use the camera under strong lights such as sun light for a long period. Also please do
not expose the camera under strong lights even when the product is not being used because the sensor
might be damaged.
■Maintenance
●Wipe the dirt on surface with soft cloth or tissue paper. Do not use alcohol, thinner or benzene to
avoid damaging the surface paints.

- 5 -
■Electro Magnetic Interference
●The camera may interference with electronic devices such as TV and radio. Please do not place the
camera next to such equipment.
■Export Control
This product is a Catch-all Control item subject to the Foreign Exchange and Foreign Trade Act and its
relevant legislations. Except for exporting to the 26 white countries designated in the Cabinet Order,
export licenses are required if the products are going to be used for military use or if the end user of the
product is related to all kinds of military activities. If your circumstances cause the need to apply export
licenses, please notify us before you place orders. Also, please notify us in advance if the end users or
purposes of use change after the purchase and thus cause the need to apply export licenses.
About the Japanese Security Export Controls, please refer to the webpage for Security Export Control
Policy, the Ministry of Economy, Trade and Industry:
www.meti.go.jp/policy/anpo/englishpage.html
The above is based on the enforcement laws and regulations at the time of issuance of this document.
Please be sure to check the latest laws and regulations before actually exporting this product.
■Guarantee
To save the environment, we do not issue warranty in printed format. Instead, all records of the
warranty periods, delivery dates and the customer information are well kept in our system.
For more details, please refer to the following link:
Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf
●We do not guarantee the functions of this product or the descriptions on this manual to be
completely adapted to the users’end applications or marketing purposes. We are also not held
responsibility for any direct or indirect damages caused by our products under any circumstances.
●Please do not use this product for a task that require high reliability. This product is not
manufactured to be used as medical, nuclear, aerospace, transportation equipment or equipment or
that is highly related to human safety. We are not held responsibility for any damages on the users’
property, equipment or personal safety caused by this product.
■Disposal
●To dispose this product, please return the camera to us. If you decide to dispose the camera without
returning it to us, please follow related regulations and have the camera disposed as an industrial
waste. Please always keep track of the disposal, and make sure the disposed camera cannot be
accessed or used by any third party.

- 6 -
2. Introduction
ARTCAM-1000MINI is a CMOS camera for industrial use.
This camera adopts USB2.0 interface, so the data can be delivered to a PC directly without a capture
board.
The mini size 20 x 25 x 25mm and light weight, it is suitable for the device integration.
The open frame model of the structure that a sensor board and a USB board separated, it is suitable for
various apparatus.
3. Main Features
⚫High Resolution
With high resolution of 10 mega pixels.
⚫USB2.0 Interface
Adopting USB2.0 interface, thus enables direct data transfer to PC without a capture board or a host
adapter card.
⚫Small and Light
Our cameras are small and light, thus can be easily installed according to your desires.
The board type camera with small type board lens is easy to be incorporated with other machines.
⚫ROI (Region Of Interest)
One major benefit of CMOS sensor is the ROI function which enables readout of designated partial
images with a faster transmission speed.
Total
vertical
pixels
Total horizontal pixels
(0,0)
(Horizontal
origination,
Vertical
origination)
Horizontal pixels
Vertical
pixels
Valid area

- 7 -
⚫Mirror function
You can flip images vertically and horizontally by process of a sensor.
⚫Included Viewer Software
ART-Viewer (Windows 7/8/10).
Users can easily preview, save images and change camera settings by ART-Viewer.
⚫Direct Show compatible
Except for being recognized as a standard USB device on the PC, some of the cameras may also be
recognized as a DirectShow device.
(Please check if the model is DirectShow compatible with the sales representative before purchase)
⚫2D Measurement & Filing Software(Optional)
Useful 2D measuring functions are available with the optional 2D Measuring & Filing Software -
ART-MEASURE.
⚫Included Software Development Kit
When developing image processing software, a software development kit that enables you to acquire
Camera image acquisition and camera control are possible with other applications is included as
standard. You can also download it from the website below.
http://www.artray.us/download_sdk.html
4. The Product
4.1. Cased model（ARTCAM-1000MINI/1000MINI-BW）
1) Camera
2) Board Lens f8.8mm
3) USB Cable: one end of the cable integrated to the camera, 0.9m approx.
4) Instruction Booklet/Viewer Software/Device Driver CD/Software Development Kit[ARTCCM-SDK]
4.2. Open frame model（ARTCAM-1000MINI-OP/1000MINI-BW-OP）
1) Sensor board
2) Control board
3) Flexible flat cable
4) USB Cable: Directly from the control board, 0.9m approx.
5) Instruction Booklet/Viewer Software/Device Driver CD/Software Development Kit[ARTCCM-SDK]
<Options>
1) Board Lens (M12 P0.5)
2) 2D Measurement & Filing Software [ART-MEASURE]
3) 5m Extension Cable with USB2.0 Repeater

- 8 -
5. Connections
5.1. How to connect a camera
5.2. Shutter Speed
Shutter speed can be changed on the standard viewer software ART-Viewer.
The shutter speed is set directly on the sensor register, so please refer to the following formulas for the
real exposure time.
Model
Method
1000MINI series
TBD
5.3. Operation clock settings
Users can switch the operation clock between 24MHz / 12MHz with the standard viewer software or
SDK.

- 9 -
6. Specifications
6.1. Color Model
MODEL
ARTCAM-1000MINI
ARTCAM-1000MINI-OP
Sensor Type
CMOS Color Image Sensor
Active Pixels
3856(H)×2764(V)
Active Imager Size
6.41(H)×4.59(V)mm, 1/2.3”
Scan Mode
Progressive Scan
Pixel Size
1.67(H)×1.67(V)μm
Shutter Type
Rolling Shutter
Color Filter Array
RGB Bayer Pattern
Frame Rate
2.2fps
Shutter Speed
1/3052～1.348s
Interface
USB2.0 Bulk Transfer
Synchronization System
Internal Synchronization
Lens Mount
Board Lens Mount M12 P0.5(ARTCAM-1000MINI)
No lens mount(ARTCAM-1000MINI-OP)
Power
DC5V (Supplied by USB port)
Power Consumption
Under Approx.2W
Ambient Conditions
Operating Temperature/Humidity：-10~50°C /10~95%(Non condensing)
External Dimensions
20(W)×25(H)×25(D)mm(1000MINI)
Sensor board 14(W)×15(H)mm, USB control board 15(W)×9(H)mm
(1000MINI-OP)
*Lens, tripod mount not included
Weight
TBD

- 10 -
6.2. Monochrome Model
MODEL
ARTCAM-1000MINI-BW
ARTCAM-1000MINI-BW-OP
Sensor Type
CMOS monochrome image sensor
Active Pixels
3856(H)×2764(V)
Active Imager Size
6.41(H)×4.59(V)mm, 1/2.3”
Scan Mode
Progressive Scan
Pixel Size
1.67(H)×1.67(V)μm
Shutter Type
Rolling Shutter
Frame Rate
2.2fps
Shutter Speed
1/3052～1.348s
Interface
USB2.0 Bulk Transfer
Synchronization System
Internal Synchronization
Lens Mount
Board Lens Mount M12 P0.5(ARTCAM-1000MINI-BW)
No lens mount(ARTCAM-1000MINI-BW-OP)
Power
DC5V (Supplied by USB port)
Power Consumption
Under Approx.2W
Ambient Conditions
Operating Temperature/Humidity：-10~50°C /10~95%(Non condensing)
External Dimensions
20(W)×25(H)×25(D)mm(1000MINI-BW)
Sensor board 14(W)×15(H)mm, USB control board 15(W)×9(H)mm
(1000MINI-BW-OP)
*Lens, tripod mount not included
Weight
TBD

- 11 -
7. Dimensions
7.1. CASED, USB CABLE DIRECT TYPE
ARTCAM-1000MINI / ARTCAM-1000MINI-BW

- 12 -
7.2. OPEN FRAME TYPE
ARTCAM-1000MINI-OP / ARTCAM-1000MINI-BW-OP

- 13 -
8. Spectral Sensitivity Characteristics
8.1. ARTCAM- 1000MINI series(Color model)
8.2. ARTCAM-1000MINI-BW series (Monochrome model)

- 14 -
9. System Requirements
9.1. Recommended System Requirements
●Host Controller
This camera is applicable to USB 2.0.
●CPU
The driver of this camera is applicable to computer architecture “x86”or “amd64”.
The specification of CPU effects directly the imaging process speed, therefore it is highly
recommended to utilize a high-end CPU if possible.
●Memory
In the viewer software, there is a data buffer which can store 4 to 8 frames.
Therefore, it is necessary to keep spare space at least for 8 frames in the memory.
(For example, when using 1.3MP color camera, 1280 x 1024 x 3 x 8 [byte] = 30[MB] is necessary.)
It is highly recommended to keep enough memory space especially when using high resolution
camera.
●OS
This camera is applicable only to the architecture of Windows NT (32bit/64bit).
Standard functions are confirmed with OS after Windows 7.
In addition, it is recommended to use Windows 10.
Caution
■Please refer the restrictions below when you use ARTCAM series.
(1) Recommended System Requirements
If the system specifications do not meet the requirements recommended above, it may be difficult to
run at the maximum frame rate.
(2) Connection of Multiple USB Devices
When connecting multiple USB devices to one USB host controller, some USB device may fail to
function stably depending on the specifications of the host controller.
(Problem of power supply, data transfer bandwidth, etc.)
To avoid power supply problem, it is recommended to use powered USB hub.
(3) USB2.0 Cable Extension
We cannot guarantee the functionality of the USB2.0 camera if the user adopts USB2.0 extension
cables or repeaters which are not confirmed by us. With the extension cables or repeaters, the
bandwidth of transfer may differ, and thus caused malfunctions such as a low frame rate or recognition
failure on the camera.
What may cause the problem is that the regulation of the power lines becomes not enough, and so
causes impudence mismatch on data signals.
*For the recommended extension cable, please contact our sales department.
(TEL: [phone])

- 15 -
ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17
1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan
Tel: [phone] Fax: [phone]
Email: [e-mail] URL: www.artray. us
