ARTRAY ARTCAM-USB3 Series User manual

August30,2012
Ver1.12
USB3.0 CCD CAMERA
ARTCAM-USB3 Series(CCD)
INSTRUCTION BOOKLET
0.33 M pixels ARTCAM-424KY-USB3 Series
1.5 M pixels ARTCAM-267KY2-USB3 Series
2.0 M pixels ARTCAM-274KY2-USB3 Series
5.0 M pixels ARTCAM-655KY-USB3 Series
ARTRAYCO., LTD.

- 2 -
Contents
1.Attention···············································3
2.Introduction···········································6
3.MainFeatures·······································6
4.TheProduct··········································7
5.ConnecttheCamera······························8
6.Specifications········································9
7.ExternalDimensions······························11
8.RecommendedPC································13

- 3 -
1.Attention
■Aboutthismanual
1．Beforeusingthecamera, pleasereadthismanual thoroughly.
2．Pleasekeep thismanualreachableandalwaysrefertothecontentswhenneeded.
3．Pleasecontactusifthemanualislostordamaged.Wewillprovidean replacement.
4．Wecannotguaranteethesafetyof improper usesof the camera.
5．Foryoursafety,pleasefollowthedirectionsofthismanual.
6．Allcontentsaresubjecttochange.
7．Imagesin thismanualmayhave beensimplifiedto beeasier comprehended.
8．Please contact usifyoufind any unclearpoints ormistakesinthismanual.
9. Quoting, copyingoralteringsomeorallpartsofthe manual withoutourpermission isprohibited.
10．Wearenotresponsibleforanylostordamagesonyourprofitsduetotheuse of our products.
11．Pleaseunderstandthatouroverseabranchesdonotprovidemaintenanceorrepairservices.
■About the Icons
Tokeepthesafetyoftheuser,otherpeopleandtheirproperties,please payattention tothefollowingicons.
W Warning
Iftheuserfailstofollowtheinstruction,physicalinjuryonhumanordamagesonhardwaremayoccur.
Caution
Iftheuserfailsto followtheinstruction,seriousinjuryordeathmayoccur.

- 4 -
■For Safe Use
Warning
●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of
fires and electric shocks.If the productisdefective, pleasecontact us forrepair orexchange.For your safety, pleasedo
notdisassemble,modifyorrepairthecameraonyourown.
Pleasestopusingtheproductandturnoffthepowerimmediatelywhen:
・The productbecomessmokyorgetsextremelyhotonthesurface,ormakesunusual smellsorsounds.
・Foreign material orwater gets into the product.
・Theproductfallsandbecomes damaged.
●Do not place theproductonunstablesurfaces.Theproductmaybefallenandpeoplemayget hurt.
Caution
●Do not expose the product to steam orfumesto avoid electric shocksand fires.
●Do not leavetheproductin high temperature placessuchas insideof vehicles orunderdirect sunlight.
High temperaturemaycausedamagestothe camera,orevencausefires.
●Do not cover the product with cloth or other materials. The product may get extremely hot and the heat may cause
deformationson thepartsorevencausefires.
●Pleaseavoiddroppingorshockingtheproductastheproductmaybe damaged.
●Do not touchthecablewitha wethand.Suchactionmaycauseelectricshocks.
●Please avoid continuously contacting the surface of the camera to your skin when the camera is being used. The
surfacetemperatureofthecameramaycauseburns.
■Other Notices
●Please do not use the camera under strong lights such as sun light for a long period. Also please do not expose the
cameraunderstronglightsevenwhentheproductisnotbeingusedbecausethesensormightbedamaged.
Maintenance
●Wipethedirtonsurfacewithsoftcloth or tissuepaper. Donotusealcohol,thinnerorbenzene toavoiddamagingthe
surfacepaints.
ElectroMagneticInterference
●The camera may interference with electronic devices such as TV and radio. Please do not place the camera next to
suchequipment.

- 5 -
■Export Control
The Government of Japan controls military sensitive goods and technologies including relevant dual-use goods and
technologies.
This product is a Catch-all Control item subject to the Foreign Exchange and Foreign Trade Act and its relevant
legislations.Exceptforexportingtothe 27whitecountriesdesignatedintheCabinetOrder,exportlicensesarerequired
if the products are going to be used for military use or if the end user of the product is related to all kinds of military
activities.If yourcircumstances causethe needtoapplyexportlicenses,pleasenotifyusbeforeyouplaceorders.Also,
please notify us in advance if the end users or purposes of use change after thepurchase and thus cause the need to
applyexportlicenses.
*The27whitecountriesnotundertheUNSCArmsEmbargo:
Argentina, Australia, Austria, Belgium, Bulgaria, Canada, Czech Republic, Denmark, Finland, France, Germany,
Greece, Hungary,Ireland, Italy,Republic of Korea, Luxemburg, Netherlands, New Zealand, Norway, Poland, Portugal,
Spain,Sweden,Switzerland,UnitedKingdom,andUnitedStates
About the Japanese Security Export Controls, please refer to the webpage for Security Export Control Policy, The
MinistryofEconomy,TradeandIndustry:
http://www.meti.go.jp/policy/anpo/englishpage.html
■Guarantee
To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods,
deliverydatesandthecustomerinformationarewellkeptinoursystem.
Formoredetails,pleaserefertothesitesbelow:
HardwareWarranty:http://www.artray.us/download/artray_warranty.pdf

- 6 -
2. Introduction
ARTCAM-USB3SeriesisCCD camerasforindustrialuse.
Thisseries adoptUSB3.0interface,sothedatacanbedeliveredtoPC directlywithoutacaptureboard.
3. Main Features
・USB3.0 Interface
OurcamerasadoptUSB3.0interfacewhichprovidesamaximumtransferrateof5Gbps, directly toPC.
・HighResolution,HighFrameRate
WeprovidehighspeedUSB3.0CCDcameras ofresolutionsfrom 0.33mega pixels to5 megapixels.
・SmallandLight
Ourcamerasaresmallandlight,thuscanbeeasilyinstalledaccordingtoyourdesires.
・VarietiestoYourNeeds
Weprovideavarietyincluding casedcameras,board typecameras,C-Mountboard typecameras.
Also,weprovidecolor,monochromeandNIRmodelstomeetcustomers’needs.
・BoundedViewer Software
WeprovidetheViewerSoftware-ART-Viewer(WindowsXP/Vista/7).
Withthissoftware,userscaneasilypreview,saveimagesandchangecamerasettings.
・2DMeasurement&FilingSoftware(Optional)
Useful2Dmeasuring functions are availablewiththe optional 2DMeasuring &FilingSoftware -ART-MEASURE.
・RecordingSoftware(Optional)
TheoptionalrecordingsoftwareART‐RECallowstheusertosavemoviesinAVIformat.
・SoftwareDevelopmentKit(Optional)
Forcustomerwhoprefersto createtheirownimageprocessingsoftwareoruseourcamerawithotherapplications,we
provideSDK uponrequests.

- 7 -
4. The Product
1)Camera
2)USB3.0cable TYPEA-Bconnector 2m
3)IntroductionBooklet
4)Viewersoftware/DeviceDriverCD
<Options>
1)C Mountlens
2)2Measurement&FilingSoftware [ART-MEASURE]
3)Recording Software [ART-REC]
4)SoftwareDevelopmentKit [ARTCCM-SDK]

- 8 -
5. Connect theCamera
5-1 Howtoconnecta camera
5-2 ShutterSpeed
ShutterspeedcanbechangedonthestandardviewersoftwareART-Viewer.
The shutter speed is set directly on the sensor register, so please refer to the following formulas for the real exposure
time.
Model
Method
424KY-USB3Series
Range: 2～524(ExposureTime: 1/76923～1/147sec)
ExposureTime=((525 –ShutterValue)×780)×0.01667 [μsec] *at 60MHz
267KY2-USB3Series
Range: 1～1058(ExposureTime: 1/4655～1/26.28 sec)
ExposureTime=((1068 –1–3–ShutterValue)×1790)×0.02 [μsec]
*at 50MHz
274KY2-USB3Series
Range: 2～1251(ExposureTime: 1/31250～1/25 sec)
ExposureTime=((1252 –ShutterValue)×1920)×0.01667 [μsec] *at 60MHz
655KY-USB3 Series
Range: 2～2078(ExposureTime: 1/18797～1/9.05sec)
ExposureTime=((2079 –ShutterValue)×3192)×0.01667 [μsec] *at 60MHz

- 9 -
6.Specifications
6-1 ColorModel
ARTCAM-424KY-USB3
ARTCAM-267KY2-USB3
ARTCAM-274KY2-USB3
ARTCAM-655KY-USB3
SensorType
CCD ColorImageSensor
ActivePixels
659(H) x494(V)
1392(H)x 1040(V)
1628(H) x 1236(V)
2456(H)x 2058(V)
ActiveImager
Size
4.88(H) x3.66(V)mm
1/3”
6.47(H)x 4.83(V)mm
1/2”
7.16(H) x5.44(V)mm
1/1.8”
8.47(H)x 7.10(V)mm
2/3”
ScanMode
ProgressiveScan
Pixel Size
7.4(H) x7.4(V)μm
4.65(H)x 4.65(V)μm
4.4(H) x 4.4(V)μm
3.45(H)x 3.45(V)μm
ShutterType
GlobalShutter
ColorFilterArray
RGBBayerPattern
FrameRate
146fps
26fps
25fps
9fps
ShutterSpeed
1/76923～1/147s
1/4655～1/26.28s
1/31250～1/25s
1/18797～1/9.05s
Interface
USB3.0BulkTransfer
Synchronization
System
InternalSynchronization
LensMount
CMount
Power
DC5V(SuppliedbyUSBport)
Power
Consumption
UnderApprox.4W
Ambient
Conditions
OperatingTemperature/Humidity: 0～35°C /10～80%(Noncondensing)
StorageTemperature/Humidity: 0～60°C /10～95%(Noncondensing)
External
Dimensions
50(W)x 47(H)x 74.9(D)mm
*Lens,tripodandcablenotincluded
50(W)x 47(H)x 79.9(D)mm
*Lens,tripodandcablenotincluded
Weight
Approx.180g
*Lens,tripodandcablenotincluded
Approx.200g
*Lens,tripodandcablenotincluded

- 10 -
6-2MonochromeModel
ARTCAM-424KY-BW-USB3
ARTCAM-267KY2-BW-USB3
ARTCAM-274KY2-BW-USB3
ARTCAM-655KY-BW-USB3
SensorType
CCD MonochromeImageSensor
ActivePixels
659(H) x494(V)
1392(H)×1040(V)
1628(H) x 1236(V)
2456(H)×2058(V)
ActiveImager
Size
4.88(H) x3.66(V)mm
1/3”
6.47(H)×4.83(V)mm
1/2”
7.16(H) x5.44(V)mm
1/1.8”
8.47(H)×7.10(V)mm
2/3”
ScanMode
ProgressiveScan
Pixel Size
7.4(H) x7.4(V)μm
4.65(H)x 4.65(V)μm
4.4(H) x 4.4(V)μm
3.45(H)x 3.45(V)μm
ShutterType
GlobalShutter
FrameRate
146fps
26fps
25fps
9fps
ShutterSpeed
1/76923～1/147s
1/4655～1/26.28s
1/31250～1/25s
1/18797～1/9.05s
Interface
USB3.0BulkTransfer
Synchronization
System
InternalSynchronization
LensMount
CMount
Power
DC5V(Supplied byUSBport)
Power
Consumption
UnderApprox.4W
Ambient
Conditions
OperatingTemperature/Humidity: 0～35°C /10～80%(Noncondensing)
StorageTemperature/Humidity: 0～60°C /10～95%(Noncondensing)
External
Dimensions
50(W)×47(H)×74.9(D)mm
*Lens,tripodandcablenotincluded
50(W)×47(H)×79.9(D)mm
*Lens,tripodandcablenot
included
Weight
Approx.180g
*Lens,tripodandcablenotincluded
Approx.200g
*Lens,tripodandcablenot
included

- 11 -
7. ExternalDimensions
7-1 C-MOUNT,CASED,USBCABLETYPE
ARTCAM-424KY-USB3/424KY-BW-USB3
ARTCAM-267KY2-USB3/267KY2-BW-USB3
ARTCAM-274KY2-USB3/274KY2-BW-USB3

- 12 -
7-2 C-MOUNT,CASED,USB CABLETYPE
ARTCAM-655KY-USB3/655KY-BW-USB3

- 13 -
8. SystemRequirements
8-1 Recommended SystemRequirements
●Intel chipset, SouthbridgeaboveICH6
●CPU: IntelCore2duo 2.4GHzor higher
●Memory:Above 512MB
●OS:WindowsXPorabove
8-2 MinimumSystemRequirements
●USB3.0 Enhanced Host Controller
●CPU: IntelPentium41.7GHzorhigher
●Memory:Above 256MB
●OS:Windows2000(SP4)orabove
Caution
■Pleaserefertherestrictionsbelowwhenyou useARTCAM.
(1)Recommended Systemrequirements
Ifthesystemspecificationsarebelowtherecommendedrequirements,itispossiblethatthecameramaynotreachthe
maximumspeed.
(2)UseofotherUSB3.0hardware
The data on our camera/converter is transferred in bulk mode. For this reason, when using our camera/converter,
please avoid using other bulk transferred USB3.0 hardware such as Memory stick, External HDD, External DVD,
CDROMandetc.
Asasolution,werecommendto install aPCIUSB host card tothePC and connectexternalUSBhardware to thisport
only.
(3)USB3.0cable Extension
We cannot guarantee the functionality of the USB3 camera if the user adopts USB3.0 extension cables or repeaters
which are notconfirmed by us.With the extension cables or repeaters, the bandwidth of transfer may differ, and thus
causedmalfunctionssuchasa lowframerateorrecognition failureonthecamera.
Whatmaycause theproblemis that theregulation of the power lines becomes not enough,andso causesimpudence
mismatchon data signals.
*Fortherecommendedextensioncable,pleasecontactoursalesdepartment. (TEL: [phone])
ARTRAYCO., LTD.
1-17-5Kouenjikita,Suginami-ku,Tokyo 166-0002Japan
Tel: [phone] Fax: [phone]
Email: [e-mail] URL: www.artray.us
