ASC SP003 User manual

1
SP003 Solar Water Pump Kit Instructions
By All Solar Central
www.allsolarcentral.com
Thank you rom the entire ASC amily or purchasing
an ASC solar product! Please read this entire booklet
be ore assembly.
Package contents:
1 x Water Pump with 16 t. Cable
1 x Solar Panel
1 x Solar Panel with Bracket
2 x Extension Tube
1 x Ground Spike
1 x Floating Foam
1 x Set o Fountain Nozzles
Notes: I there is any damage to the product or missing
parts, please contact us at 1-626-582-8898 or
www.allsolarcentral.com/contactus
Assembly Steps:
1. Connect the bracket, tubes and spike together.
Then attach the solar panel to the bracket. Slide
the holding bracket into the inside lip o the top
hal o the solar panel rame. The bracket holds
the weight o the solar panel. The solar panel can
be adjusted or optimal sunlight by using the
wingnut. Please see the diagram.
2. Insert the spike into the ground. Position the
solar panel so it’s acing south (in northern
hemisphere) as much as possible to maximize
daylight hours. It is important to angle the solar
panel to ace the sun when the sun is at its
highest point. Ensure the solar panel is not
shaded by trees, shrubs or buildings.
3. Connect the Pump to the back side o the Solar
Panel. IMPORTANT!! Slightly twist the connectors
when connecting to make sure the rubber seals
are ully in the grooves.
4. SOLAR PUMP FUN TIONS
This pump runs rom direct sunlight. The pumps
per ormance is directly related to the amount
and strength o sunlight received by the solar
panel. This solar pump is designed primarily to
operate in summer months but can also work in
spring and autumn i there is direct sunlight.
Notes: This model DOES NOT come with a
battery, so the pump will only work when the
solar panel is in sunlight.

2
5. PUMP MAINTENAN E
I you ind the pump starts losing power or stops
working, please clean the pump ilter and
impeller with clean water.
6. TROUBLE SHOOTING
•Check to see i the solar panel, pump and
led light are connected properly
•Check to see i the solar panel is correctly
positioned acing the sun. Please ensure
the solar panel is not in the shade or
obstructed by trees, shrubs or a building
(see step 2).
•Check water level and make sure the
pump is ully submerged in water
•Check to see i the pump ilter/impeller is
blocked by debris
•Check to see i the ountain tubing is
blocked by kinks or obstructions
•Check the pump. It may be “air locked”.
Turn the pump on/o switch several
times to clear any air that may have been
trapped.
7. TE HANI AL DATA
•
Max. Pump Water Flow: 180LPH
•Max. Pump Water Li t: 50CM / 20IN
•Working Voltage: DC6V – DC8V
•Pump Working Power: 0.65W – 1.15W
•Protection Grade o Pump: IP68
•Solar Panel: 2.5W; 8V; 0.312A
•Solar Panel Size: 190x150x18MM
•Protection Grade o Panel: IP44
8. WINTER PROTE TION
Indoor storage is recommended during winter
months. Normal operating temperature is
between 50 and 113 °F.
Please visit www.allsolarcentral.com or more
products and o ers.
