ASC SP008 User manual

1
SP008 Solar Water Pump Kit Instructions
By All Solar Central
www.allsolarcentral.com
Thank you rom the entire ASC amily or purchasing
an ASC solar product! Please read this entire booklet
be ore assembly.
Package contents:
1 x Water Pump with 16 t. Cable
1 x LED Light Ring with 16 t. Cable
1 x Battery Control Box
1 x Solar Panel with 6.5 t. Cable
1 x Solar Panel Bracket
2 x Extension Tube
1 x Ground Spike
1 x Set o Fountain Nozzles
Notes: I there is any damage to the product or missing
parts, please contact us at 1-626-582-8898 or
www.allsolarcentral.com/contactus
Assembly Steps:
1. Connect the bracket, tubes and spike together.
Then attach the solar panel to the bracket. Slide
the holding bracket into the inside lip o the top
hal o the solar panel rame. The bracket holds
the weight o the solar panel. The solar panel can
be adjusted or optimal sunlight by using the
wingnut. Please see the diagram.
2. Insert the spike into the ground. Position the
solar panel so it’s acing south (in northern
hemisphere) as much as possible to maximize
daylight hours. It is important to angle the solar
panel to ace the sun when the sun is at its
highest point. Ensure the solar panel is not
shaded by trees, shrubs or buildings.
3. Connect the Solar Panel, LED Light, and Pump to
the Battery Control Box (See diagram below:)
IMPORTANT!!
Slightly twist the connectors when connecting to
make sure the rubber seals are ully in the
grooves.
4. The assembled Solar Pump should look like this:

2
5. BATTERY ONTROL BOX OPERATION
Note: The LED light is designed to work at night
only
The solar pump is designed mainly or use during
summer hours, but it will also work in spring and
all as long as the sunlight conditions are good
enough in your region. And the new Winter Mode
will extend battery li e time during the winter.
The pump’s per ormance depends on the
orientation o the solar panel towards the sun
(see section 2) and the strength on sunlight.
This ASC solar pump kit comes with three
operation modes: Continuously On, 2-4hrs Timer,
and Winter mode.
a. ONTINUOUSLY ON MODE: This mode works
best if you want to maximize the pump’s daily
usage. Press [Power] button, the top
indicator light [On] will be on. The pump will
run continuously until the battery runs out o
power. The pump will automatically restart
when the battery is recharged under proper
sunlight.
b. DAILY TIMER MODE: This mode works best if
you want the pump run at the same time
every day (The time you start the mode).
Press [Timer] button repeatedly until the
indicator light [2hrs], [3hrs] or [4hrs] is lit –
the pump will run or 2, 3, or 4 hours and
shut down (in standby) or 22, 21, or 20
hours. This setting will repeat at the same
time every day. You can reset the pump’s
daily start up time by switching it to a new
desired time using this mode.
c. WINTER MODE: This mode works best in
winter or poor weather. Press [Winter]
button, the top indicator light [Pulse] will be
on. The pump will run or 20 seconds in every
60 seconds. It is recommended to use this
mode to extend battery li e time in winter or
poor weather.
PUMP FLOW ONTROL button: Use this
button to adjust the water flow rate. Press
[Flow Rate] repeatedly to adjust the water
low rate (total 3 levels). Notes: Higher water
low rate will consume more power and
reduce the battery li e time.
LOW BATTERY light: The [Low Bat.] indicator
light will be blinking when the battery is low,
and pump/LED light will shut down shortly to
protect the battery. The [Low Bat.] indicator
light will turn o until the battery is
recharged.
6. PERFORMAN E OF THE PUMP
The per ormance o the pump depends on the
orientation o the solar panel towards the sun
and the sunlight strength. In order to achieve
max per ormance, please make sure the panel is
acing in the direction o the sun. A solar panel
positioned in the shade or in poor weather will
not maximize the charge. This models pump
per ormance will depend on the battery power
level. The pump will not work i battery power is
too low.
7. PUMP MAINTENAN E
I you ind the pump starts losing power or stops
working, please clean the pump ilter and
impeller with clean water.
8. BATTERY REPLA EMENT
I properly maintained this solar pump has been
designed to run or many years. The Lead-acid
battery does have a limited li e span and might
need to be replaced a ter 18-24 months o use. I
the battery appears less e icient, please try to
boost charge it. To do this, leave the system o
or 2 to 3 sunny days to allow ully charge to the

3
battery. It is recommended to do this occasionally
to maximize battery li e time.
To replace battery, please ollow these steps:
a. Remove the screws rom the Battery Box
b. Remove the lid and control panel rom
the battery box slightly
c. Disconnect the battery connectors, then
remove and replace the old battery.
NOTES: Please make sure to connect the new
battery correctly: Red or + and Black or - . Only
original battery should be used or replacement
as other alternatives may be incompatible and
may damage the control panel and will void the
warranty. For parts, please go to
www.allsolarcentral.com.
9. TROUBLE SHOOTING
•Check to see i the solar panel, pump and
led light are connected properly
•Check to see i the solar panel is correctly
positioned acing the sun. Please ensure
the solar panel is not in the shade or
obstructed by trees, shrubs or a building
(see step 2).
•Check i [low bat.] light is on. I so, this
indicates that the battery power is low.
Switch o the pump and leave the solar
panel charging under direct sunlight or 1
or 2 days.
•HARGING TIPS: Press button [Power] to
turn o the system. All indicator lights
should be o . All solar power will now be
used to charge the battery.
•Check water level and make sure the
pump is ully submerged in water
•Check to see i the pump ilter/impeller is
blocked by debris
•Check to see i the ountain tubing is
blocked by kinks or obstructions
•Check the pump. It may be “air locked”.
Turn the pump on/o switch several
times to clear any air that may have been
trapped.
10. TE HANI AL DATA
•
Max. Water Flow: 800LPH
•Max. Water Li t: 200CM/6.5FT
•Max. Fountain Height: 110CM/3.6FT
•Working Voltage: DC15V – DC18V
•Pump Working Power: 3.6W – 6.3W
•Protection Grade o Pump: IP68
•Solar Panel: 8W; 18V; 0.444A
•Solar Panel Size: 358x238x18mm
•Protection Grade o Panel: IP44
•Battery: Lead-acid 12V/5AH
•Protection Grade o Battery Box: IP44
•LED Light Working Voltage: DC12V
•LED Light Working Power: 0.12W
•Protection Grade o LED Light: IP68
11. WINTER PROTE TION
Indoor storage is recommended during winter
months. Normal operating temperature is
between 50 and 113 °F. Battery can be recharged
at temperatures between 32 and 113 °F.
IMPORTANT!!
In order to keep your battery healthy during long
storage times, please make sure the battery is
ully recharged be ore storing. To do this, turn o
the pump by pressing button [Power] and charge
the battery or 1 or 2 sunny days. See Step 9 –
Charging Tips

4
PROPOSITION 65 WARNING:
Battery posts, terminals and related accessories
contain lead and lead compounds, chemicals
known to the State o Cali ornia to cause cancer
and reproductive harm. Wash hands a ter
handling. For more in ormation go to
https://www.p65warnings.ca.gov/
BATTERY DISPOSE: Never dispose o batteries in
the garbage. Disposal o batteries in the garbage
is unlaw ul under state and ederal
environmental laws and regulations. Always take
used batteries to your local battery-recycling
center.
Please visit www.allsolarcentral.com or more
products and o ers.
