Ashley Chloe HELIX CUFF User manual
CONTROLS PAIRING AND BATTERY INDICATORS SPECIFICATIONS SAFETY INFORMATION STATEMENTS WARRANTY
Press the main button once to answer an incoming call.Answer call:
Press the main button once to end a call.
End call:
Press the main button for 2 seconds to reject the incoming call.
Reject call:
Press the main button twice to redial the last number called.
Redial:
Press the main button once to play music.
Play music:
Press the main button once to pause music.
Pause music:
Press the volume up button for 1 second for previous track.
Previous track:
Press the volume down button for 1 second for next track.
Next track:
Press volume up or volume down button for 3 seconds.Activate voice command:
Dimension:
Cuff: 5.11" - 7.68" Circumference (13 - 19.5cm)
Earbud: 0.39"D x 0.63"L (10x16mm)
Headset: 1.81"L x 0.51"W x 0.43"H (46x13x11mm)
Weight:
Cuff: 1.8 oz (51.4g)
Headset: 0.48 oz (13.6g)
Battery type:
Rechargeable lithium-ion polymer battery
Battery input: 5V / 20mA
Battery capacity: 40mAh
Charging time: About 1.5 hours
Standby time (power on): About 72 hours
Standby time (power off): About 30 days
Music/Talk time: Up to 3 hours
Frequency response: 50Hz - 20kHz
Impedance: 16 ohms
Bluetooth version: 4.1
Bluetooth profiles:
HFP, HSP, AVRCP, A2DP, and APTX
Maximum Bluetooth working distance: 30 ft (10m)
Audio enhancements:
noitcuderesion®cVc
Use Responsibly
Do not use headset when it is unsafe to do so: while operating a vehicle, crossing the street, or during any
activity or environment where full attention to your surroundings is required.
It’s dangerous to drive while wearing the headset and in many places illegal because it decreases ability to
hear life-saving sounds outside of the vehicle, such as another car’s horn or emergency vehicle sirens.
Please avoid wearing the headset while driving.
Listen Responsibly
To avoid hearing damage, make sure that the volume on your music player is turned down before
connecting your headset. After placing the headset in your ear, gradually turn up the volume until you
reach a comfortable listening level. Noise levels are measured in decibels (dB); exposure to any noise at or
above 85 dB can cause gradual hearing loss. Monitor your use; hearing loss isafunction of loudness versus
time. The louder itis, the less time you can be exposed to it. The softer itis, the more time you can listen to it.
FCC and IC Compliance Statement
This device complies with Part 15 of the FCC rules
and Industry Canada license-exempt RSS
standards. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference; and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
EU Compliance Statement
Ashley Chloe Inc. hereby declares that this wireless
device is in compliance with the essential
requirements and other relevant provisions of the
R&TTE Directive.
Caution Statement
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate this
equipment.
WARNING: Do not expose this product to liquid or
excessive heat.
Disposal Information
The symbol indicates that this product and/or
battery should not be disposed of with household
waste. When you decide to dispose of this product
and/or its battery, do so in accordance with local
environmental laws and guidelines.
Limited Six (6) Months Warranty with proof of purchase. Exempt from warranty are limited-life
consumable components subject to normal wear and tear, e.g. ear tips, batteries and other accessories.
The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. All other trademarks and
trade names are those of their respective owners.
© 2016 ASHLEY CHLOE INC. ALL RIGHTS RESERVED.
Ashley Chloe is a registered trademark of Ashley Chloe Inc.
Helix Cuff is a trademark of Ashley Chloe Inc.
h e l i x c u f f
Fashion Wearablewith Wireless Headset
www.ashleychloe.com
Note: Please ensure your mobile device supports voice command function for this feature. To prevent possible hearing damage, do not listen at high volume levels for long periods of time.
1. No device connected: Double-blinking red flashes
2. Pairing mode: Flashes in red and white
3. Paired: White flashes
4. Low battery: Beeps every 5 seconds
5. Charging: Solid red light
6. Fully charged: Solid white light
123456
x2
PACKAGE HOW TO REMOVE HEADSET
1. Helix Cuff
2. Wireless Headset
3. Earbud Tips: Small, Medium, Large
1. Press down on the cover near the end of the cuff to open the cover.
2. Take out the earbuds one by one.
3. Uncoil the cords from around the cuff.
4. Pull out the control unit from the cuff.
HOW TO INSERT HEADSET BACK HOW TO WEAR HEADSET PAIRING PAIRING WITH TWO DEVICES (SMART MULTIPOINT CONNECTIVITY)
1. Place the control unit back in the cuff.
2. Coil the cords around the cuff.
3. Place the earbuds into the correct position one by one.
The Helix Cuff and the headset are not waterproof.
Avoid excessive water on the headset.
For the best Bluetooth connection, keep source device in direct view of the
headset. The human body may interfere and weaken signal in some conditions.
4. USB Charging Cable
5. Cleaning Cloth
1 2 3 4 1 42 3
1. Pair and connect the headset with the first device.
2. Turn off the Bluetooth function of the first device.
3. Pair and connect the headset with the second device.
4. Reconnect first device with headset and both devices will be paired.
1 42 3
1 2 3
Wear Helix Cuff
on the wrist
Adjust to fit your wrist
by moving the magnet
Wear the headphones
on the head
5
CHARGING: Fully charge the headset before use with the microUSB charging cable.
POWER ON/OFF: Press the main button for 2 seconds until the LED indicator
flashes red 3 times.
Volume Up
Volume Down
LED Indicator
Micro-USB Charging Port
Mic
Main Button
4 sec
Helix Cuff Headset
Bluetooth
1. Press the main button for 4 seconds until the LED indicator blinks white
and red alternatively.
2. Select “Helix Cuff Headset” on your mobile device to connect via Bluetooth.
3. Once paired, the LED indicator will flash white.
2 31
OFF ON
Device A Device A Device B Device A
Press Down
