Monoprice BT-300ANC User manual

BT-300ANC Bluetooth Wireless Over Ear
Headphones with Active Noise Cancelling (ANC)
P/N 33834

2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
•Do not expose this device to water or moisture of any kind.
•Do not use this device while operating a motor vehicle, heavy equipment, walking
in traffic, or any other situation in which situational awareness is a key to safety.
•This device contains a Lithium-ion battery. Dispose of this device only in accordance
with local, state, or federal regulations for electronic waste.
•Charge the battery before first use and at least once every three months to keep
the battery fresh and capable of holding the full charge.
•Do not allow the battery to fully discharge, as doing so can damage it and reduce
its maximum capacity.
•Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
•This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
INTRODUCTION
Thank you for purchasing these BT300ANC Active Noise Cancelling (ANC) Bluetooth®
Headphones. These headphones have been designed to provide you with great audio
quality, while blocking out ambient noises, such as engines and wind. The BT300ANC can
be used in multiple modes: Bluetooth with ANC active, Bluetooth without ANC, a wired
connection with ANC active, or a full passive wired connection without ANC to conserve
battery life.

3
FEATURES
•Over-the-ear design with Active Noise Cancelling (ANC) circuitry
•Bluetooth® radio with support for the A2DP, AVRCP, HFP, and HSP profiles
•Includes the aptX™ audio codec
•Built-in 200mAh Lithium-ion battery
•Up to 16 hours of audio playback with ANC disabled or up to 8 hours with ANC
active
•40mm drivers with neodymium magnets
•118dB sensitivity
•Audible low battery indicator
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com or via email at [e-mail]. Check the website for
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x BT300ANC Active Noise Cancelling (ANC) Bluetooth® Headphones
1x Micro USB Charging Cable
1x User's Manual

4
PRODUCT OVERVIEW
BATTERY CHARGING
Charge the battery before first use and at least once every three months to keep the
battery fresh and capable of holding a full charge. Do not allow the battery to fully
discharge, as doing so can damage it and reduce its maximum capacity.
To charge the battery in the headphones, first ensure that the headphones are powered
off. Next, plug one end of the included Micro USB Charging Cable into the Charging Port
on the headphones, then plug the other end into a USB power source, such as a computer
or USB wall charger. The LED Indicator (ANC) will illuminate red, indicating that charging is
taking place. When charging is complete, the indicator will turn off.
Note that if the headphones are powered on and the ANC Switch is in the ON position, the
LED Indicator (ANC) will illuminate purple instead of red.
When the battery level is low, an audible tone can be heard in the headphones. The tone
will repeat each minute.

5
BLUETOOTH PAIRING
Perform the following steps to pair the headphones with your Bluetooth® device.
1. With the headphones powered off, press and hold the Multi-Function Button (MFB)
for 3 seconds to power them on. The LED Indicator (Bluetooth) will alternately flash
red and blue, indicating that the headphones are in Bluetooth pairing mode.
If instead of alternately flashing red and blue, the LED Indicator (Bluetooth) flashes
blue every 3 seconds, the headphones are already paired with another device. Turn
the headphones off by pressing and holding the Multi-Function Button (MFB) for 5
seconds. Turn off or disable Bluetooth on the other device, then power the
headphones on again.
2. Open the Bluetooth settings on your device and scan for nearby Bluetooth devices.
3. Locate and select the MP33834 entry. If prompted for a passcode, enter 0000 (four
zeroes). The LED Indicator (Bluetooth) will stop flashing red and blue and will
instead flash blue every 3 seconds, indicating it is paired and connected with your
device.
OPERATION
Power
•Press and hold the Multi-Function Button (MFB) for 3 seconds to power the
headphones ON.
•Press and hold the Multi-Function Button (MFB) for 5 seconds to power the
headphones OFF.

6
Audio Playback
If the headphones are paired with a Bluetooth® enabled device with support for the A2DP
and AVRCP profiles, you can control the device using the controls on the headphones. Use
the following headphone buttons to perform the indicated functions on your paired
device.
•With audio playback stopped or paused, momentarily press the Multi-Function
Button (MFB) to start or resume playback.
•While audio is playing, momentarily press the Multi-Function Button (MFB) to pause
playback.
•Momentarily press the Volume+/Next Track button to increase the volume level.
When the maximum volume level is reached, the headphones will emit a beeping
sound.
•Momentarily press the Volume-/Prev Track button to decrease the volume level.
When the minimum volume level is reached, the headphones will emit a beeping
sound.
•Press and hold the Volume+/Next Track button to skip ahead to the next track.
•Press and hold the Volume-/Prev Track button to skip back to the beginning of the
current track. If already at the beginning of the track, it will skip back to the
beginning of the previous track.
Phone Calls
If the headphones are paired with a Bluetooth® enabled phone with support for the HFP
and HSP profiles, you can use the headphones to handle calls. Use the following
headphone buttons to perform the indicated functions on your paired phone.
•If you receive a call while using the headphones, audio playback will automatically
pause. Momentarily press the Multi-Function Button (MFB) to answer the call.
•If you want to reject an incoming call, press and hold the Multi-Function Button
(MFB) button for about 1 second, until you hear the audio indication. Audio
playback will automatically resume.

7
•While a call is in progress, momentarily press the Volume+/Next Track button to
increase the volume level. When the maximum volume level is reached, the
headphones will emit a beeping sound.
•While a call is in progress, momentarily press the Volume-/Prev Track button to
decrease the volume level. When the minimum volume level is reached, the
headphones will emit a beeping sound.
•When you are finished with a call, momentarily press the Multi-Function Button
(MFB) to terminate the call. Audio playback will automatically resume.
•If you wish to redial the last number called, double press the Multi-Function Button
(MFB).
Active Noise Cancelling (ANC)
•The headphones must be powered on for the Active Noise Cancelling (ANC) feature
to function.
•The Active Noise Cancelling (ANC) feature can be used with a both Bluetooth® and
wired connections.
•To enable the Active Noise Cancelling (ANC) feature, slide the ANC Switch to the
ON position. The LED Indicator (ANC) will illuminate.
•To turn off the Active Noise Cancelling (ANC) feature, slide the ANC Switch to the
OFF position. The LED Indicator (ANC) will turn off.

8
TROUBLESHOOTING
Q1: The headphones will not power on.
A1: Charge the battery.
Q2: The battery will not charge.
A2: Confirm that the USB power source is active. Check the cable connections. Try
replacing the Micro USB cable with a known good one.
Q3: The headphones will not pair with the Bluetooth® device.
A3: Ensure that Bluetooth is enabled on your device. Move the device closer to the
headphones during the pairing process. The headphones are already paired with another
device.
Q4: The headphones will not maintain a connection with the paired Bluetooth device.
A4: Verify that both devices are powered ON. Ensure that Bluetooth is enabled on your
device. Move the device closer to the headphones.
Q5: The connection range is very short and/or the sound is distorted or garbled.
A5: Verify that there are no other devices using the 2.4GHz frequency band. Ensure no
obstructions block the signal.
Q6: No sound is heard during audio playback.
A6: Confirm that both devices are powered ON. Verify that the audio source device is
equipped with the A2DP profile. Ensure that the volume levels on the audio source device
and headphones are not set to the minimum. Verify that the audio source is not paused.

9
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
or through email by sending a message to [email protected]. Check the website for
support times and links.
SPECIFICATIONS
Model
33834
Driver Size
40mm with neodymium magnets
Frequency Response
20 Hz ~ 20 kHz
Sensitivity
118dB ±3dB (1kHz @ 1mW)
Bluetooth® Pairing Name
MP33834
Supported Bluetooth Profiles
A2DP, AVRCP, HFP, HSP
Bluetooth Range
Up to 32 feet (10 meters)
Audio Codec
aptX™
Battery Capacity
200mAh
Charging Time
About 3 hours
Audio Playback Time (with ANC)
Up to 8 hours
Audio Playback Time (without ANC)
Up to 16 hours
Weight
12.6 oz. (358g)

10
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

11
Radio Notice for FCC
Caution
This FCC Part 15 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not expressly
approved by Monoprice, including the use of non-approved antennas, could void the user’s
authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Notice for Industry Canada
Caution
This IC RSS-210 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not expressly
approved by Monoprice, including the use of non-approved antennas, could void the user's
authority to operate this device.
This device complies with IC RSS-210. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

12
EU/UK Compliance
Hereby, Monoprice Inc. declares that the radio equipment type Bluetooth Headphones is in
compliance with Directives 2014/53/EU, 2011/65/EU with (EU) 2015/863, Radio Equipment
Regulations 2017 and Restriction of the Use of Certain Hazardous Substances in Electrical
and Electronic Equipment Regulations 2012. The full text of the declaration of Conformity is
available at the following internet address: https://www.monoprice.eu/
The information required by EU Radio Equipment Directive/UK Radio Equipment
Regulations related to the frequency band(s) and the maximum radio-frequency power
transmitted:
Frequency: 2.402 –2.48 GHz; Max Power: 5 dBm
Disposal and Recycling Information
The symbol indicates that this product should be disposed of separately from regular
household waste streams. It is your responsibility to dispose of this and other electrical and
electronics products via designated collection facilities appointed by the government or
local authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed information about
the disposal of your unwanted product, please contacts your local authorities, waste
disposal service, or the shop where you purchased the product.
Monoprice™ and all Monoprice logos are trademarks of Monoprice Inc.
The Bluetooth® word mark and logos are registered trademarks of Bluetooth SIG, Inc.
Qualcomm® is a trademark of Qualcomm Incorporated, registered in the United States and
other countries. aptX™ is a trademark of Qualcomm Technologies International, Ltd.,
registered in the United States and other countries. Qualcomm® aptX™ is a product of
Qualcomm Technologies International, Ltd.
