Ashly Sra-2075 User manual

Specifying the right power amp is oen easier than

nding it. Our SRA Series makes it a snap to get exactly

what you need.

SRAs are advanced, ecient ampliers perfect for

installaons with modest power requirements. Housed

in a compact single rack space chassis, and weighing

only 10lbs, they're designed to drive 4 or 8 Ohm loads.

Choose from 4 models available in 2 and 4-channel

conguraons with power rangs of 75W and 150W

per channel into 4 Ohms. The 150W models are

capable of driving 25V constant voltage lines directly.

Switch mode power supplies and Class-D amplier

circuitry provide an extremely power ecient soluon.

They are convecon cooled, so lile maintenance is

needed aer the installaon, and no annoying fan

noise. Of course you get the reliability, superior sonic

quality and rugged construcon you’ve come to

expect from Ashly.

SRA Features:

• Convecon cooling

• Extremely low noise

• Extensive protecon circuitry

• Level aenuators for each channel

• Signal present and clip alert status LEDs

• Selectable input sensivity

• Defeatable 80Hz HPF

• Euroblock inputs/outputs

• Stereo or bridged mode switch per channel pair

• Remote stand-by control

• Adjustable turn-on delay up to 8 seconds

• Stereo headphone jack (on 2-channel models)

• Safety/Compliance:



TUV



, CE, FCC, RoHS

Notes: 0dBu = 0.775 VRMS

Frequency Response

(8 Ohms) 20Hz–20kHz, ±1.0dB

Distoron (SMPTE, typical) < 0.5% - 8 Ohm load, 10dB below

rated power

Distoron (THD-N, typical) < 0.5% - 8 Ohm load, 10dB below

rated power, 20Hz–20kHz

Damping Factor

(8 Ohm load, < 1 kHz) > 200 into 8 Ohms

Input Impedance 20k Ohms, Balanced

Input Sensivity 1dBu (75W), 4dBu (150W)

Gain 26dBu, 36dBu, Selectable

Maximum Input Level +21dBu

HPF 80Hz 2

Order, defeatable

Cooling Convecon

Output Circuitry Class D

Amplifier/Load Protection

Output Overcurent, DC Output,

Main Supply Rail Overvoltage,

Chassis Temperature, Inrush

Liming, Mains Fuse

Environmental 40-120° F, (4-49° C) noncon-

densing

Front Panel

Controls AC Power Switch, Level

Indicators (LED color)

Power (Blue), Standby (Yellow),

Protect (Red), Signal (Green),

Clip (Red)

Rear Panel

Controls

80Hz HPF, Gain/Sensivity: +26dB,

+36dB, Bridge/Stereo Switch,

Remote Standby, Delay

Connectors (each channel) Input: 3-Pin Euroblock

Output: Euroblock

Cordset 3-Prong IEC

SRA SERIES Standard Power amPlifierS

 2075 4075 2150 4150

Channels 2 4 2 4

Max Output Power: Per Channel, 20Hz–20KHz, 1% THD All Channels Driven

4 Ohms 75W 75W 150W 150W

8 Ohms 40W 40W 80W 80W

8 Ohms (Bridged) 150W 150W 300W 300W

Line Current Draw: All Channels Driven @ 4 Ohms

Standby Mode 37mA 39mA 89mA 102mA

No Signal 320mA 565mA 370mA 660mA

Typical (1/8 power pink noise) 0.70A 1.25A 1.10A 1.95A

Max (1/3 power pink noise) 1.23A 2.25A 2.10A 3.80A

Thermal Dissipaon: BTU/hr, All Channels Driven @ 4 Ohms

Standby Mode 13 15 14 23

No Signal 61 113 72 137

Typical (1/8 power pink noise) 73 145 111 211

Max (1/3 power pink noise) 85 150 126 263

Signal to Noise

20Hz–20kHz, unweighted

>100dB

>100dB >103dB >103dB

tations are subject to change without notice. Ashly Audio

is a division of Jam Industries, Ltd. DS-1 1213

Sra2075

Sra2150

Sra4075

Sra4150

5-Year Warranty Hand-built in

Webster, NY



Dimensions 19”W x 1.75"H x 11”D (483mm x 45.5mm x 279.4mm)

Unit Weight 2075: 8.75lbs (3.97kg) 2150: 8.83lbs (4kg)

4075: 9.4lbs (4.27kg) 4150: 9.48lbs (4.3kg)

Shipping Weight 2075/2150: 15lbs (7kg) 4075/4150: 16lbs (8kg)

Power Req. 120VAC, 240VAC ±10%, 50/60Hz (factory set)

|





|

|





The two-channel power amplier shall deliver a minimum power of 40 Was RMS per channel into 8 Ohm loads and 75 Was RMS per channel into 4 Ohm loads with all channels operang.

When switched into bridged-mono mode, the amplier shall deliver at least 150 Was RMS into an 8 Ohm load. The power amplier shall have Euroblock input and output connectors and

a TRS headphone connector on the front panel. It shall have balanced analog inputs and a selectable 80Hz high-pass lter. The power amplier shall have a 26db/36dB input sensivity switch

and remote standby. It shall include a turn-on delay funcon of up to 8 seconds. The output circuitry shall be Class D, convecon cooled with a frequency response of 20Hz to 20KHz ±1.0dB.

Signal-to-Noise shall be greater than 100dB unweighted. The front panel shall provide the status of power, standby, protect, signal level and clip. The amplier shall mount in a standard 19 inch

rack using one space (1.75” high) and weigh 9 pounds.

The power amplier shall be an Ashly model 



The two-channel power amplier shall deliver a minimum power of 80 Was RMS per channel into 8 Ohm loads and 150 Was RMS per channel into 4 Ohm loads with all channels operang.

When switched into bridged-mono mode, the amplier shall deliver at least 300 Was RMS into an 8 Ohm load. The power amplier shall have Euroblock input and output connectors and

a TRS headphone connector on the front panel. It shall have balanced analog inputs and a selectable 80Hz high-pass lter. The power amplier shall have a 26db/36dB input sensivity switch

and remote standby. It shall include a turn-on delay funcon of up to 8 seconds. The output circuitry shall be Class D, convecon cooled with a frequency response of 20Hz to 20KHz ±1.0dB.

Signal-to-Noise shall be greater than 103dB unweighted. The front panel shall provide the status of power, standby, protect, signal level and clip. The amplier shall mount in a standard 19 inch

rack using one space (1.75” high) and weigh 9 pounds.

The power amplier shall be an Ashly model 



The four-channel power amplier shall deliver a minimum power of 40 Was RMS per channel into 8 Ohm loads and 75 Was RMS per channel into 4 Ohm loads with all channels operang.

When switched into bridged-mono mode, the amplier shall deliver at least 150 Was RMS into an 8 Ohm load. The power amplier shall have Euroblock input and output connectors. It shall

have balanced analog inputs and a selectable 80Hz high-pass lter. The power amplier shall have a 26db/36dB input sensivity switch and remote standby. The output circuitry shall be Class

D, convecon cooled with a frequency response of 20Hz to 20KHz ±1.0dB. Signal-to-Noise shall be greater than 100dB unweighted. The front panel shall provide the status of power, standby,

protect, signal level and clip. The amplier shall mount in a standard 19 inch rack using one space (1.75” high) and weigh 10 pounds.

The power amplier shall be an Ashly model 



The four-channel power amplier shall deliver a minimum power of 80 Was RMS per channel into 8 Ohm loads and 150 Was RMS per channel into 4 Ohm loads with all channels operang.

When switched into bridged-mono mode, the amplier shall deliver at least 300 Was RMS into an 8 Ohm load. The power amplier shall have Euroblock input and output connectors. It shall

have balanced analog inputs and a selectable 80Hz high-pass lter. The power amplier shall have a 26db/36dB input sensivity switch and remote standby. The output circuitry shall be Class

D, convecon cooled with a frequency response of 20Hz to 20KHz ±1.0dB. Signal-to-Noise shall be greater than 103dB unweighted. The front panel shall provide the status of power, standby,

protect, signal level and clip. The amplier shall mount in a standard 19 inch rack using one space (1.75” high) and weigh 10 pounds.

The power amplier shall be an Ashly model 
