Asko D5906 User manual

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most from your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.
Operating Instructions
Dishwasher
ASKO D5906

Contents
2Front panel
3Safety instructions
4Before washing for the first time
5Loading the dishwasher
7Using the dishwasher
10Settings
13Care and cleaning
15Troubleshooting
18Technical information
19Installation
23Service
24Program chart
25Your notes
Front panel
1 32 5 68
7
4
1 On/Left-on mode
2 Program selector
3 Program symbol
4 Display
5 Rinse aid indicator
6 TAB (3-in-1/all-in-one detergent)
7 Salt indicator
8 Start/Stop
The panel is fitted with touch buttons with audible feedback (see the chapter Settings).
NOTE!
•Two minutes after pressing any button, the control panel enters energy-saving mode. Close and reopen the door, or press the
On/Left-on mode button, to reactivate the panel.
2

Safety instructions
General
•Read the operating instructions and keep them in a safe place!
•Never use the dishwasher for any purpose other than that
specified in these operating instructions.
•Do not load the dishwasher door or dishwasher baskets with
anything other than dishes.
•Never leave the dishwasher door open as someone may trip
on it.
•Use only dishwasher detergent!
•This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appli-
ance by a person responsible for their safety.
•Damaged mains cables must only be replaced by a qualified
electrician.
•This dishwasher is for household or similar use, such as:
- staff kitchens in shops, offices and other workplaces.
- farms.
- for guests at hotels, motels and other types of accommo-
dation.
- bed & breakfast hotels.
•Never place dishes with solvent residues in the dishwasher
due to the risk of explosion. Nor may dishes that contain ash,
wax or lubricants be washed in the dishwasher.
WARNING!
Knives and other pointed items must be placed with the points
down in the cutlery basket or horizontally in other baskets.
Installation
See the section Installation.
Child safety
•Always close the door and start the program immediately after
you have added the detergent.
•Keep children away from the dishwasher when the door is
open. Some detergent may remain inside!
•Do not allow children to use or play with the dishwasher. Be
especially vigilant when the door is open.
WARNING!
Dishwasher detergents are strongly alkaline. They can be ex-
tremely dangerous if swallowed. Avoid contact with skin and
eyes and keep children away from the dishwasher when the
door is open.
Check that the detergent compartment is empty after comple-
tion of the wash cycle.
Winter storage/Transport
•Store the dishwasher where the temperature remains above
freezing.
•Avoid long transport distances in very cold weather.
•Transport the dishwasher upright or laying on its back.
Overflow guard function
The overflow protection starts pumping out the machine and turns
off the water supply if the water level in the dishwasher exceeds
the normal level. If the overflow protection is triggered, turn off
the water supply and call the service division.
Cleaning
When cleaning the edge around the door, use only a slightly
damp cloth. Do not spray water around the edge! Moisture can
make its way into the lock, which contains electrical components.
Packing material
Sort waste materials in accordance with local guidelines.
Disposal
•When the dishwasher has reached the end of its service life
and is to be disposed of, it should immediately be made un-
usable. Pull out the power cable and cut it as short as possi-
ble.
•The dishwasher is manufactured and labelled for recycling.
•Contact your local authority for information about where and
how your dishwasher should be correctly recycled.
3

Before washing for the
first time
Program key
Some dishwashers include program keys in different languages.
Attach the program key in the desired language to the top of the
door.
The water softener
In order to achieve good dishwashing results, the dishwasher
needs soft water (water with low mineral content). Hard water
leaves a white coating on dishes and the dishwasher.
Water hardness is specified using the following scales: The
German water hardness scale (°dH) and the French water hard-
ness scale (°fH). A water supply with a water hardness in excess
of 6°dH (9°fH) must be softened. This is done automatically with
the aid of the built-in water softener. In order for the softener to
function optimally, it must be adjusted to the hardness of the
water supply.
Contact the local waterworks, or measure the water hardness
using the supplied test strip, to check the water hardness in your
area. Once you have adjusted the water softener, use detergent
and rinse aid doses suitable for soft water.
How to use the test strip:
1 Turn on the water tap and let the water run for a minute or so.
2 Fill a glass with cold water.
3 Remove the test strip from its packaging.
4 Dip the test strip in the water for about one second.
5 Wait one minute. Now compare the colours of the squares
with the water hardness table.
°fH°dHTest strip
<5<3
4 green
>7>4
1 red
>15>8
2 red
>25>14
3 red
>38>21
4 red
Adjusting the water softener
In section Settings on page 12 the process for setting the water
softener is described. Don't forget to put salt in the salt compart-
ment after you have set the water softener.
Fill up the salt
Before you begin using a dishwasher with a water softener, you
must fill the salt compartment with salt. Use large grain salt or
special dishwasher salt.
WARNING!
Top up the salt just before running a program. To avoid the risk
of rust stains, the dishwasher must be rinsed immediately after
topping up the salt.
Never pour dishwasher detergent into the salt compartment.
This destroys the water softener!
Do as follows the first time:
1 Unscrew the lid as illustrated.
2 Place the funnel supplied with the dishwasher in the salt
compartment top-up hole. First, pour in about 1 l of water.
3 Then add salt, a maximum of 1.5 kg, until the compartment is
full.
4 Wipe up any excess salt so that the lid can be screwed on
firmly.
5 Run a program to ensure that any salt in the dishwasher is
rinsed away.
Salt compartment lid
Refill salt indicator
When the salt needs topping up, the above symbol lights on the
display.
When the salt runs out, unscrew the cap and fill the container
with salt. Water is only needed the first time! Wipe clean and
tighten. Run a program to ensure that any salt in the dishwasher
is rinsed away.
NOTE!
After topping up, it may take a while before the symbol goes
out.
Top up with rinse aid
By using rinse aid you will improve your drying result. You will
also achieve a better dishwashing result with glassware and
dishes.
1 Open the rinse aid compartment lid.
2 Carefully top up with rinse aid. Only add rinse aid to the level
marked max.
3 Wipe up any splashes of rinse aid around the compartment.
4 Close the lid firmly.
Refill rinse aid indicator
When the rinse aid needs topping up, the above symbol lights
on the display.
4

NOTE!
After topping up, it may take a while before the symbol goes
out.
Setting the rinse aid dosage
The section Settings describes how to set the rinse aid dosage.
Rinse aid dispensing can be set from (Off) to (High
dose). (Factory settings: )
Increase the rinse aid dosage:
•If the dishes have water marks.
Decrease the rinse aid dosage:
•If the dishes have a sticky white/blue film.
•If the dishes are streaked.
•Build-up of foam. If you have very soft water, the rinse aid can
be diluted 50:50 with water.
Loading the dishwasher
Economic dishwashing
Run programs only with a full load
Wait to run a program until the dishwasher is full. This way you
save energy. Use the Rinse & Hold program to rinse the dishes
if there are any unpleasant odours while you wait for the dishwash-
er to become fully loaded.
Run programs at a lower temperature
If the dishes are only slightly dirty, you can select a program with
a low temperature.
Do not rinse under running water
Simply scrape off large food particles before loading the dish-
washer.
Choose a green detergent
Read the environmental declaration on the packaging!
Connect to cold water...
If you use oil or electricity to heat your home.
Connect to hot water (max. 70 °C)...
If you use district heating, solar power or geothermal power to
heat your home. Choosing a hot water connection cuts program
times and reduces the dishwasher's electricity consumption.
Fragile dishes
Some cookware is not dishwasher safe. This can be for several
reasons. Some materials cannot withstand strong heat, others
can be damaged by dishwashing detergent.
Fragile decoration
Porcelain with decoration on top of the glazing (the items feel
rough) should not be washed in a dishwasher.
Crystal/Glass
Place items so that they do not touch each other during the wash.
Use a short program with the lowest possible wash temperature.
Delicate and very fragile items should not be washed in a dish-
washer.
Glassware washed in a dishwasher at high temperatures can
gradually develop a grey film that cannot be removed. Wash fine
glassware at a low temperature and with a small amount of deter-
gent.
Silver
Silver and stainless steel items should not come into contact, as
the silver can become discoloured.
Cutlery with glued handles
Some types of glue are not dishwasher safe. In such cases, the
handles may loosen.
Wood
Wooden items should only be washed in a dishwasher if marked
dishwasher safe.
Aluminium
Aluminium can lose its shine if washed in a dishwasher. However,
good quality aluminium pans can be washed in a dishwasher,
even if some of the shine will be lost.
Plastic items
Avoid washing plastic items that cannot withstand high tempera-
tures.
The dishwasher's baskets
The dishwasher is equipped with an upper basket and a lower
basket with cutlery basket.
5

The appearance of the baskets may differ depending on the
dishwasher setup.
Upper basket
Place glasses, cups, bowls, side plates and saucers in the upper
basket. All dirty surfaces should face inwards and downwards!
Wine glasses are placed on the wine glass shelf and knives are
placed in the knife stand on the right (if fitted).
Raising the upper basket
1 Pull out the upper basket.
2 Grab the sides of the upper basket with both hands and lift it
up.
Lowering the upper basket
1 Pull out the upper basket.
2 Pull out the two locking handles on either side to lower the
upper basket.
Lower basket
Place plates, side plates, serving dishes, pots and cutlery (in the
cutlery basket) in the lower basket.
Place pots or pans in the right-hand rear part of the lower basket
for the best cleaning performance from the rear spray nozzle
(WideSpray™), which is intended for these types of dishes.
Foldable tines
Lower the foldable tines (plate supports) when washing pots and
pans. Release the foldable tines by pressing the catch inwards
before adjusting their position.
Washing large plates
Move the foldable tines and their mounts to widen the distance
between the tine rows to adapt the lower basket to plates with a
diameter greater than 25 cm.
Cutlery basket
Place cutlery with the handles facing down, except for knives,
and spread them out as much as possible. Ensure that spoons
do not stack inside each other.
The cutlery basket is best placed in the middle at the front of the
lower basket to best utilise dishwashing performance from the
unique spray nozzle (Power Zone Cutlery™), which is intended
for the cutlery basket.
WARNING!
Knives and other pointed items must be placed with the points
down in the cutlery basket or horizontally in other baskets.
Fold-down section for small items
The cutlery basket has a fold-down section in the middle for small
items, or small shafts, such as electric whisk attachments.
ac
b
6

Cutlery basket with lid
ac
b
Positioning of cutlery basket lid (in upper basket)
The cutlery basket lid can be removed and used, for example,
as an extra cutlery basket in the upper basket (see below).
ab
NOTE!
Check that the spray arms can rotate freely.
Using the dishwasher
Add detergent
1 Prewash detergent compartment
2 Main wash detergent compartment
Detergent is added according to water hardness.
Follow the instructions on the detergent packaging. This dishwash-
er is fitted with a water softener, so use detergent and rinse aid
doses suitable for soft water.
Too much detergent can result in less effective dishwashing and
also entails greater environmental impact.
Add the detergent to the detergent compartment. There is a
compartment for the prewash and one for the main wash. If
powder and liquid dishwasher detergents are used, add a small
amount of the detergent to the prewash compartment. Contact
the detergent manufacturer if you have any questions about the
detergent.
WARNING!
Children must be supervised –dishwasher detergent is corro-
sive!
NOTE!
Use only dishwasher detergent! Washing up liquid must not
be used as the foam that forms prevents the dishwasher from
operating effectively.
Dishwasher tablets
Halve the tablet if it is difficult to close the dispenser lid. There is
a risk that the detergent will not be released properly if the lid is
tight and will not open correctly.
NOTE!
Dishwasher tablets are not recommended for short programs
(less than 75 minutes). Use powder or liquid dishwasher deter-
gent instead.
3–in–1/All-in-one detergent
Read through the directions for these products carefully. If any-
thing is unclear, contact the detergent manufacturer.
Chapter Settings describes how to activate TAB (3-in-1/All-in-one
detergent). Note that salt must be put in the salt compartment. If
you are not satisfied with the dishwashing or drying results, de-
activate the TAB (3-in-1/ All-in-one detergent) setting and top up
the salt, detergent and rinse aid. See Chapter Before washing
for the first time.
7

On/Left-on mode
Press and hold the On/Left-on mode button until the display lights
up.
Program selection
Press the Program selector one or more times until the desired
program symbol appears on the display.
Sani A
This program is ideal to use when hygiene demands are set high.
The temperature of the main wash is 60 °C °C. The final rinse is
85 °C °C for 6 minutes.
Sani B
Choose Sani B if you want a quicker program that still fulfils hy-
giene demands. The temperature of the main wash is 50 °C °C.
The final rinse is 85 °C °C for 3 minutes.
Heavy wash
Program for very dirty dishes, such as pans, casserole dishes
and oven dishes. If these dishes do not completely fill the dish-
washer, you can add plates and the like.
Normal program
Use to wash normally soiled load, such as plates, serving dishes,
cups, glasses and so on.
Daily wash
A program suitable for day-to-day dishwashing. This program
can also clean dried leftovers, but is not intended for burnt food,
such as on oven dishes.
Quick wash
This program is used for glasses and porcelain that is slightly
dirty, such as coffee cups.
Delicate wash
If the dishes are not very dirty, you can select Delicate wash. This
program is intended for glasses and porcelain that have just been
used and as such do not require such a powerful program.
This program can be used for delicate dishes. See also the sec-
tion Fragile dishes in Chapter Loading the dishwasher.
Eco wash
Use when you want to save water. For normally dirty dishes.
Rinse & Hold
Used to rinse dishes while you wait for the dishwasher to become
fully loaded.
Start the dishwasher
Press and hold Start/Stop until the display shows (the door
open symbol). This indicates that the dishwasher is ready to start.
Close the door properly, otherwise the dishwasher will not start.
The display flashes three times with the remaining time to indicate
that the program has started.
NOTE!
If the machine does not start within 2 minutes of the last button
press, the display returns to showing the last program run.
Time remaining
Once you have selected a program, the display indicates how
long the program took the last time it was used. Once you have
started the dishwasher, the display indicates how much program
time remains. The remaining time is updated after the water for
the final rinse has been heated.
This may differ somewhat from time to time depending on the
temperature of the water supply, the amount of dishes, the ambi-
ent temperature and other factors.
While the program is running, the time counts down and the re-
maining program time is shown on the display. The remaining
time is shown, for example, as 1:15, which means the program
will run for another 1 hour and 15 minutes.
NOTE!
During the first run of each program, the remaining time dis-
played can be slightly misleading, as the dishwasher is estimat-
ing the time. When you run the program a second time, the
dishwasher will calculate the remaining time based on the
previous duration of the program.
Stopping or changing a program
If you want to change program after starting the dishwasher,
open the door then press and hold Start/Stop for three seconds.
Add more detergent if the lid of the detergent dispenser has
opened. Then choose a new program, press Start/Stop and close
the door.
Do you want to add more dishes?
Open the door. The dishwasher stops automatically. Add the
dishes, close the door and the dishwasher continues the program.
If the dishwasher is turned off using
the On/Left-on mode button or due
to a power failure
If the dishwashing program was not finished, the interrupted
program continues when power is restored.
NOTE!
During drying, the program is interrupted if the power is cut or
the door is open for more than 2 minutes.
8

Once the program has finished
Once the program has finished, “End”appears on the display.
At the end of the program, you will hear a short beep. Chapter
Settings describes how to change this function.
Once the dishwasher has finished, it only uses standby power.
Drying
For additional drying the door should be opened 35 mm upon
completion of the drying cycle. For more information, see page
18 in the chapter Technical information.
9

Settings
Do as follows to open the settings menu:
First, open the door. Turn off the dishwasher using the On/Left-on mode button (press and hold). Release the
button.
1.
Press and hold the On/Left-on mode button until the display lights up.2.
Within five seconds, press and hold the Program selector and the Start/Stop button.3.
PROGPROG
+Release the buttons when the display shows .4.
Press to save the set value and continue to the next
setting.
Current setting.
Current setting value.
Press to browse between setting values.
You can now adjust the following settings:
DescriptionSettingsOptionsButton press
The dishwasher uses a buzzer to indicate when a pro-
gram is finished or when a fault has occurred.
Buzzer volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
If you do not want to change any other settings, press Start/Stop several times to step through the entire settings menu.
This sound is used to confirm each button press.Operation volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
For adjusting the contrast of the display on the front
door.
LCD contrast
(Display on the front of the door)
Press Start/Stop to save the setting value and continue to the next setting.
10

DescriptionSettingsOptionsButton press
For adjusting the contrast of the display on the panel.LCD contrast
(Display on the panel)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
Rinse aid dosage setting.Rinse aid
(Off)
(Low dosage)
(High dosage)
Press Start/Stop to save the setting value and continue to the next setting.
You can activate this setting when using 3-in-1/All-in-
one detergent. The dishwashing programs automatical-
ly adapt to provide the best possible dishwashing and
drying results every time. If you deactivate this option,
the dishwasher will return to its normal function for all
programs.
TAB
(3-in-1/all-in-one detergent)
(Off)
(On)
If this setting is activated, there is no need to add rinse
aid since this option disables rinse aid dispensing. It
also reduces the amount of salt added to the water
softener. Note that salt must be put in the salt compart-
ment.
NOTE!
In order to achieve good dishwashing results, it is
essential to check which type of detergent or all-in-
one product best suits your needs! Read the deter-
gent packaging carefully for information on proper
use. Always follow the directions for use or informa-
tion on the detergent packaging!
Press Start/Stop to save the setting value and continue to the next setting.
11

DescriptionSettingsOptionsButton press
Adjusting the water softener. Read off the appropriate
setting from the water hardness table below.
°dH
0-3
4-5
6-8
9-11
12-14
15-19
20-24
25-29
30-39
40+
0-5
6-9
10-14
15-20
21-25
26-34
35-43
44-52
53-70
71+
°fH °dH °fH
Water hardness
(Soft water)
(Hard water)
Press Start/Stop to save the setting value and continue to the next setting.
The display on the front shows the current water tem-
perature in Celsius or Fahrenheit for the Sani A and
Sani B programs.
Temperature unit
(certain models only)
(Off)
(°C)
(°F)
Press Start/Stop to exit the settings menu.
12

Care and cleaning
Coarse filter
The coarse filter traps larger food particles, which cannot get
past the drainage pump. Empty the coarse filter as necessary.
1 Lift the coarse filter by the handle.
2 Empty the coarse filter. Remember to replace it!
Coarse filter
Fine filter
Debris that collects on the fine filter is automatically rinsed away
during each wash. However, the fine filter and its pipe section
should be cleaned a couple of times a year.
1 Turn the handle anticlockwise once.
1x
Fine filter
2Lift the pipe section straight up by the handle. Free the coarse
filter to clean the pipe section.
3 Remove and clean the fine filter.
4 Replace in reverse order. Check that the edges seal properly
when replacing the fine filter.
Pipe section
5 Lock the filter in place by turning the handle clockwise to the
stop position. The handle should point straight out from the
dishwasher.
1x
NOTE!
The dishwasher must not be used without the filter in place!
Diswashing efficiency can be affected if the course filter is in-
correctly fitted. After cleaning ensure that filter handle is fully
locked with the handle pointing out of the dishwasher.
Drainage pump
The pump can be accessed from inside the dishwasher.
1 Cut the power to the dishwasher by pulling out the plug from
the wall socket!
2 Remove the coarse filter and pipe section.
3 Remove the small yellow fitted piece at the left of the bottom
drain (see illustration below).
4 By inserting your finger into the hole you can turn the pump
blade to release anything blocking it.
5 Reinstall the fitted piece and filters.
6 Plug the machine in again.
If the dishwasher still does not start and a whirring sound is
heard, the overflow protection has been activated.
•Shut off the water.
•Remove the plug from the wall socket.
•Call the service division.
NOTE!
Do not forget to reinstall the fitted piece.
Spray arms
Holes and bearings can sometimes become blocked. Remove
any debris using a pin or something similar. The spray arms also
have holes on their undersides.
To facilitate cleaning, you can remove the spray arms. Remember
to screw them firmly back into place afterwards.
13

Lower spray arm
•Pull the lower spray arm straight up to release it.
Upper spray arm
•Pull out the upper basket.
•Unscrew the spray arm bearings counterclockwise to remove
the spray arm from the upper basket.
Door
When cleaning the edge around the door, use only a slightly
damp cloth (with a little cleaner if necessary).
WARNING!
Do not use a spray bottle or the like around the door lock. This
is to ensure that water does not penetrate the door catch and
come into contact with the electrical components.
Limescale deposits
The dishwasher tub is made of stainless steel and is kept clean
through normal use. However, if you have hard water, limescale
deposits may form in the dishwasher. If this happens, run the
Normal program program with two tablespoons of citric acid in
the detergent compartment (with no dishes in the machine).
Front panel
Keep the touch buttons clean and free from grease. Wipe them
clean with a dry or slightly damp cloth. Never use cleaners –they
can scratch the surface. Use the On/Left-on mode button to turn
off the dishwasher before cleaning the touch buttons to avoid
activating any buttons unintentionally.
14

Troubleshooting
ActionType of faultDisplay
Call the service division.Overfilling
See "Water remains in the dishwasher" in the table
below.
Water outlet fault
Check that the water tap is on.Water inlet fault
Check whether dishwasher inlet hose is connected to
a pressure limiting valve (some pressure limiting valves
may restrict the supply of water to the dishwasher).
Turn off the water tap and call the service division.Inlet valve leakage
Turn off the machine with the On/Left-on mode button and then turn it on again to clear the error message from the display.
ActionPossible causesProblem
Remove the arms and clean them.The spray arms do not rotate.The dishes are not clean.
Check that the dishes are not blocking the
spray arms.
Avoid large packages.Old detergent. Detergent is a perishable
product.
Dose according to water hardness. Far too
much or far too little detergent results in
poorer dishwashing results.
Incorrect detergent dosage.
Select a more powerful program.Dishwashing program too weak.
Do not cover porcelain with large bowls or
the like. Avoid placing very tall glasses in the
corners of the baskets.
Dishes loaded incorrectly.
Place dishes to sit steady.Glasses and cups have toppled over during
the program.
Screw the filter firmly into place. See the
section Care and cleaning.
The filter is not correctly fitted.
Check that the salt compartment lid is prop-
erly tightened. Otherwise call the service di-
vision.
The water softener is leaking salt.Spots or films on the dishes.
See the section Settings.Incorrect water softener setting.
See the sections Before washing for the first
time and Settings.
Incorrect rinse aid dosage setting.
Top up with salt. See the section Before
washing for the first time.
Salt compartment empty.
Deactivate the TAB (3-in-1/ All-in-one deter-
gent) setting and top up the salt and rinse
aid.
3-in-1/All-in-one detergent is used and the
TAB (3-in-1/All-in-one detergent) setting is
activated.
Wash crystal at a low temperature and with
a conservative amount of detergent. Contact
the detergent manufacturer.
Too high temperature and/or too much deter-
gent can cause etching on crystal. Unfortu-
nately, this cannot be repaired, only prevent-
ed.
15

ActionPossible causesProblem
Reduce the amount. See the sections Before
washing for the first time and Settings. If you
have very soft water, you may want to dilute
the rinse aid 50:50 with water.
Rinse aid dosage setting too high.The dishes have a sticky white/blue film.
Rinse off these types of foodstuffs if not
starting the dishwasher immediately. Why
not use the Rinse & Hold program.
Some foodstuffs, such as mustard, mayon-
naise, lemon, vinegar, salt and dressings,
can mark stainless steel if left for too long.
Spots on stainless steel or silver.
Silver and stainless steel items should not
come into contact during dishwashing.
All stainless steel can cause spots on silver
if they come into contact during dishwashing.
Aluminium can also cause spots on dishes.
Use a detergent with a bleaching agent.Lipstick and tea can be difficult to wash off.Spots left after washing.
Check that the dishes are placed securely.
Spin the spray arms to make sure they can
rotate.
The dishes are not correctly placed or the
spray arms are not rotating.
Rattling sound when dishwashing.
Press and hold Start/Stop until the display
shows (the door open symbol). This
indicates that the dishwasher is ready to start.
The Start/Stop start button has not been
pressed for long enough.
The dishwasher does not start.
Check.The door is not properly closed.
Check.A fuse/circuit breaker has been tripped.
Check.The plug is not plugged into the wall socket.
Check.The water tap is turned off.
Check.Overflow/leaks
Turn off the water tap. Pull out the plug and
call the service division.
A whirring sound (the drainage pump) is
heard from the dishwasher and does not stop
when the power is cut with the On/Left-on
mode button.
None, next time the program is run the cor-
rected time will be displayed.
The program is taking longer than estimated.1 minute appears in the display.
Loosen the drainage hose where it connects
to the sink unit's water trap. Check that no
debris has fastened. Is the cone-shaped part
of the pipe cut to an inner diameter of at least
14 mm?
Blocked drainage hose.Water remains in the dishwasher.
Check that the hose is free from kinks and
sharp bends.
Kink in drainage hose.
Clean the coarse and fine filters.The filters are blocked.
Ensure filter is completely locked with handle
pointing towards the door.
The filter is not locked in completely.
Clean the drainage pump. See the section
Care and cleaning.
Debris in the drainage pump.
Clean with washing-up brush and low foam-
ing cleaner.
Dirt around the seals and in corners.Bad odour in dishwasher.
Run a program with a higher temperature
about once a month.
Low temperature programs have been select-
ed for a prolonged period.
16

ActionPossible causesProblem
Fully load the dishwasher.The dishwasher is not fully loaded.The dishes are not dry enough.
Top up with rinse aid or increase the rinse
aid dosage. See the sections Before washing
for the first time and Settings.
Rinse aid needs topping up or dosage is set
too low.
Deactivate the TAB (3-in-1/ All-in-one deter-
gent) setting and top up the salt and rinse
aid.
3-in-1/All-in-one detergent is used and the
TAB (3-in-1/All-in-one detergent) setting is
activated.
Open the door a little once the program has
finished.
Check that the baskets are correctly posi-
tioned horizontally.
The baskets are not correctly positioned.Cannot close door.
Check that the dishes are not blocking the
baskets from sliding properly into place.
Wait a moment then try again.You have pressed the touch buttons too soon
after opening the door.
The touch buttons do not react when
pressed.
Clean with a dry or slightly damp cloth.Dirt on the touch buttons.
Open the door until the display lights up. Al-
ternatively, close the door and wait 30 sec-
onds. Then open the door again.
If this symbol appears on the display
the door is not open enough.
17

Technical information
Technical data
817-872 mmHeight:
596 mmWidth:
559 mmDepth:
52 kg1) Weight:
14 Place settings2) Capacity:
0.03–1.0 MPaWater pressure:
0.3–10 kp/cm2
3–100 N/cm2
See type plate.Electrical connection:
See type plate.Rated power:
1) Weight can vary due to different specifications.
2) In accordance with standard, AS/NZS 2007.
18

Installation
519
30-94
596
30
670
700
717
821*-872
133-183
9
559
1198
49
[mm]
*Remove locking nuts for an installed height of 820-821 mm.
Safety instructions
•Connections to electricity, water and drainage must be per-
formed by a qualified professional.
•Always follow applicable regulations for water, drainage and
electricity.
•An incorrect or flawed installation can result in higher consump-
tion of energy, water and detergent, which can result in in-
creased costs and poor dishwashing results. In order to min-
imise noise it is important that you follow the instructions.
•Take care during installation! Wear protective gloves! There
must always be two people!
•Before screwing the dishwasher into place, test the dishwasher
by running the Rinse & Hold program. Check that the dish-
washer fills with water and drains. Check also that none of the
connections leak.
WARNING!
Turn off the water supply when installing the dishwasher!
WARNING!
The plug must be disconnected or power to the socket turned
off while the work is carried out!
Transport protection for the door
Do not forget to remove the transport protection for the door when
unpacking the dishwasher.
2x
19

Suggested machine installations
The dishwasher can be installed built-in, completely freestanding
or partially built-in.
A. Built-in
The dishwasher is intended for installation under a worktop. The
recess dimensions are illustrated. Holes for wires/cables need
not be larger than 38 mm in diameter. Make sure the edges of
such holes are even to prevent damage to the drainage and inlet
hoses and the power cable.
560
*Remove locking nuts for an installed height
of 820-821 mm.
[mm]
B. Freestanding
A freestanding dishwasher must be fitted with anti-tip brackets.
This comprises two brackets, which are screwed into place as
illustrated.
The dishwasher is then pushed in so that the brackets engage
the rear feet. Now the dishwasher will not topple if pressure is
put on the open door. If the dishwasher is installed completely
on its own, side panels and a worktop must both be fitted. Acces-
sories can be purchased where you bought the dishwasher.
455-475
600
413
WARNING!
A completely freestanding dishwasher must be fitted with anti-
tip brackets.
C. Partially built-in
If the dishwasher is located so that one of its sides is visible, a
side panel must be fitted. Accessories can be purchased where
you bought the dishwasher.
Adjust the height and slide the
dishwasher into place
1 Start by measuring the height from the floor to the bottom
edge of the worktop.
2 Measure the height from the floor to the top edge of the dish-
washer.
3 Lean the dishwasher forwards a little and roughly adjust the
rear foot by turning the adjustment screw at the front clockwise
to raise and anticlockwise to lower the dishwasher (see illus-
tration below). Use a broad screwdriver or a socket screwdriv-
er.
4 Adjust the front feet by turning them clockwise to raise and
anticlockwise to lower the dishwasher.
24 mm
5 Check that there is an air gap of at least 3 mm between the
underside of the worktop and the top edge of the dishwasher.
6 Slide the dishwasher into place.
•Pull through the drainage and supply hoses when the ma-
chine is slid into place.
•Check that the hoses have no kinks or sharp bends, and
check that there is nothing that can damage the hoses.
20
