Asko w6884w eco User manual

Operating Instructions
Washing Machine
ASKO W6884W ECO
Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years
to come. Scandinavian design combines clean lines, everyday functionality
and high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read the
operating instructions before using the machine. The operating instructions
also include information on how you can help protect the environment.
WARNING: Read the instructions before using the machine.

Before using your machine for the
first time 4
Transport protection 4
Packing material 4
Washer door 4
Language selection 4
Checking water hardness 4
Safety instructions 5
General 5
Installation 5
Overflow guard function 5
Recycling 5
Child safety 6
Keep an eye on children! 6
Description of the washing machine 7
Dispenser 8
Advice and tips before washing 9
Sorting your laundry 9
Clothing 9
Laundry labels 9
Laundry label symbols 9
Hot water connection 9
Unbleached linen 9
Advice and tips before washing 10
Wool 10
Rayon fibres and synthetic fibres 10
Reducing allergic reactions 10
Save time and energy 10
High water level 10
Detergents 10
Dyeing fabrics 10
Advice and tips before washing 11
Washing 12
Sort your laundry. 12
Turn on the main power switch 12
Open the washer door and load
the washing 12
Add detergent and fabric softener, as
required 12
Program selection 13
Selecting options 16
Close the washer door and press the
Start/Stop button 18
Once the program has finished 18
Settings 19
You can change the following settings 19
Child-safe 19
Door opening 19
Language 19
Temperature 19
Extra rinses 19
Hot water 19
Care and cleaning 20
Cleaning the trap and the drainage pump 20
Cleaning the detergent compartment 20
Cleaning the outside of the machine 20
Cleaning the inside of the machine
to avoid unpleasant smells 20
Rinse holes under the agitator 21
If you have hard water 21
Original instruction
2
Contents

Troubleshooting 22
The washer door will not open 22
The machine will not start 22
After power failure 22
Wet washing still in the machine 22
Error messages 23
Technical information 24
Information for test institute 24
Technical data 26
Transport protection 27
Installation 28
Positioning the washing machine 28
Adjusting the feet 28
Connection to water supply 28
Drainage connection 29
Electrical installation 29
Service 30
Before contacting the service division 30
Quick guide 32
3
Contents

4
Transport protection
Remove any transport protection devices before
installing the machine. See the "Transport
protection" chapter.
Packing material
Please sort waste materials in accordance with
local guidelines.
Washer door
• The washer door cannot be opened until
the machine is connected to the electricity
supply.
• To open the door manually, see "The washer
door will not open" in the "Troubleshooting"
chapter.
• The machine cannot be started when the
door is open.
• To open the washer door while a programme
is running, see "Close the door and press the
Start/Stop button" in the "Washing" chapter.
Language selection
You will be prompted to select the display
language when you have connected your
machine and start it for the first time. Do as
follows:
1. Turn the programme selector to choose from:
US English, English, Svenska, Dansk, Norsk,
Suomi, Français, Deutsch, Italiano, Espanol,
Русский, Nederlands.
2. Press Start/Stop once to save the setting.
Checking water hardness
The quantity of detergent needed depends,
amongst other things, on how hard the water
is. See the detergent pack for details. Phone
your local water company to check the water
hardness in your area.
NOTE!
Each machine is tested before leaving the
factory.
A small amount of water may remain in the drain
pump, though this does not affect quality or
damage the machine.
Before using your machine for the first time
See Quick guide on the last page

5
General
• Read the operating instructions and keep
them in a safe place.
• Installation should be carried out by qualified
ASKO technicians.
• The machine should only be used for
washing items as described in these
instructions. It is not intended for dry
cleaning.
• Use only detergent intended for machine
washing!
• Use only detergents and softeners for
machine wash. Manufacturer may not
assume responsibility for any damage and
eventual discolouring of gaskets and plastic
components as a consequence of incorrect
use of bleach and/or colouring agents.
• Never use detergents containing solvents,
since there is a danger of creating toxic
gasses which may damage the machine and
result in ignition or explosion.
• Remove any transport protection devices
before using the machine. See the "Transport
protection" chapter.
• Repairs and maintenance must be carried
out by a qualified professional.
• Damaged mains cables must only be
replaced by a qualified electrician.
• The machine is not designed to be used by
persons (even children) that are physically
or mentally handicapped or lack experience
and knowledge. Such persons must receive
instruction in how to use the machine or be
supervised by a person responsible for their
safety.
• Children must be watched to ensure they do
not play with the machine.
• In the enclosed plastic bag you will find a tool
for opening the washer door in emergencies.
Installation
See the "Installation" chapter.
Overflow guard function
If the machine’s water level rises above the
normal level, the overflow guard function begins
to pump water out and shuts offthe water
intake. If the water level has not dropped within
60 seconds, the program is terminated.
Transport/Winter storage
If the machine is to be transported or stored in
unheated premises where the temperature can
fall below freezing, do as follows:
• Empty the filter and the drainage pump. See
the "Care and cleaning" chapter.
• Shut offthe water to the washing machine,
loosen the supply hose to the intake valve
and let the water run out from the valve and
hose.
• After emptying the pump, a small amount of
water may remain in the machine. This does
not affect quality or damage the machine.
Recycling
This machine is manufactured and labelled
for recycling. In order to prevent injuries, the
machine must be made unusable once the
decision has been taken to dispose of it.
Contact your local authority for information
about where and how your machine can be
recycled correctly.
Safety instructions

6
Child safety
Keep an eye on children!
• Always close the door and start the
programme immediately once you have
added detergent.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• Young children should be supervised
to ensure that they do not play with the
appliance.
• Store detergent and fabric softener out of the
reach of children!
NOTE!
If this appliance is supplied from a cord
extensions set or electrical portable outlet
device, the cord extension ser or electrical
portable outlet device must be positioned so
that it is not subject to splashing or ingress of
moisture.
Activate child safety catch (for
detergent compartment)
On the inside of the detergent compartment is a
child safety catch.
Activated child safety
catch
Inactivated child safety
catch
When the child safety catch is activated you
must press the release button to pull out the
detergent compartment.

7
Description of the washing machine
1. Main power switch
2. Dispenser
3. Programme panel
4. Serial number plate (on inside of washer
door)
5. Drainage pump cover
6. Drainage pump (behind cover)
7. Washer door
1
75,6
23 4

8
Dispenser
14
5
6
23
1. Pre-wash
2. Main wash with liquid detergent.
Use the separator (A).
3. Main wash with powder detergent.
Do not use the separator.
4. Fabric softener
5. Release button
6. Child safety catch
A
B
C

9
Advice and tips before washing
Here are some tips that may help you before
washing.
Sorting your laundry
Sort items according to:
• how soiled they are
• colour
• material
Clothing
1. Do up zips and close Velcro straps so that
they don’t harm fabrics.
2. New coloured items may contain excess dye
and should therefore be washed separately
the first few times.
3. Turn delicate items inside out. This reduces
the risk of burling and fading.
4. Empty pockets and wash them inside out if
possible.
Laundry labels
Look at the item's laundry label. The table below
shows suitable wash programmes for different
materials and wash loads. Using modern
washing machines and detergents, for example
compact detergents, you can usually wash at
lower temperatures. It is a good idea to use trial
and error to find out what produces the best
results.
Laundry label symbols
Examples of washing instructions and recommended programs. Always follow the washing instructions
for each garment.
Laundry labels Material Program
Cotton, linen, white and light-coloured items. Everyday wash 60 °C to 90 °C
Cotton, linen, cotton/polyester. Light and dark-coloured garments. Quick 60 °C
Acrylic, viscose, modal, acetate, polyester, polyamide and
elastane. Light and dark-coloured garments.
Easy Care 40 °C
or
Wool, silk and other very delicate garments Wool/hand wash 30 °C to 40 °C
Hot water connection
Hot water intake has a positive effect on grease
stains and certain pigment stains, such as oil,
soot and coffee. Note however that difficult
protein stains with albumen content (blood,
milk, meat and fish) first need to be soaked in
cold water as they are difficult to dissolve at
temperatures above 40°C. For the best washing
results we recommend the Super wash option
and pre-soaking the stained items in cold water
before washing them in the machine.
Coloured cotton
Coloured cotton items with the washing
instruction 60°C should be washed at 60°C for
the first time in order to remove any excess dye.
If you do not do so, there is a risk that the colour
will run. Use detergent without bleach in order to
preserve the colour of the fabric.

10
Advice and tips before washing
Unbleached linen
Unbleached linen fabrics should be washed at
60 °C, using detergent containing no bleach
or optical whiteners. Heavily-soiled linen can
occasionally be washed at higher temperatures,
but not too often because the heat can destroy
the linen’s shine and strength.
Wool
These fabrics are labelled either machine wash
or hand wash. The Wool/hand wash program is
at least as gentle as washing by hand.
Wool is especially sensitive to processes such
as washing. If you do not wish to spin dry, you
can squeeze out the water using terry towels.
In this case select No spin. To find out how to
choose this setting, see the "Washing" chapter.
However, most garments can withstand a short
spin. Choose a short spin by selecting a spin
speed of 800 rpm or less.
Rayon fibres and synthetic fibres
Materials made of rayon fibres, such as viscose,
and some synthetic fibres are very delicate and
require much space so as not to crease. Only
half fill the drum when washing and choose a
spin speed of 800 rpm or lower.
NOTE!
Viscose and acetates are fragile when wet.
Reducing allergic reactions
The washing machine has a Super Rinse
option. Use this for people with sensitive skin,
such as those with allergies and small children.
Save time and energy
Use the Everyday wash program to save time
and energy. This program has a shorter main
wash than Normal, but is often sufficient for
lightly soiled washing.
High water level
If you want more water for the main wash and
rinses, you can use the High water level option.
This is automatically selected in the Wool/Hand
program.
Economy and efficiency
You can save energy by not using higher
temperature programs than necessary.
• Select Quick if you just need to freshen up
shirts or exercise clothes, for example. This
will save both water and energy.
• If you select a fast spin speed, this reduces
energy consumption when drying in a tumble
dryer or drying cabinet.
• Always wash with a full load when using
the Heavy, Everyday wash and Normal
programs.
• Avoid pre-washing. Modern machines and
detergents clean effectively without pre-
washing. Pre-washing is only necessary for
heavily soiled washing.
Detergents
Eco-labelled detergents are less harmful to the
environment.
Detergent overdosing does not give better
washing results; it merely causes a greater
impact on the environment; can also hinder the
wash performance.
Try to use less detergent, and increase only if
you are not satisfied with the results.

11
Dyeing fabrics
If you want to dye fabrics in the machine, select
the Everyday wash program with the Super
Rinse option. Select temperature according to
the dye manufacturer’s recommendations.
Choose a low spin speed if the fabric to be dyed
is a blended material such as polyester/cotton.
NOTE!
Add the dye directly to the washing drum – not
to the detergent compartment. After dyeing, you
should run the machine empty using the same
program. Use the normal amount of detergent.
NOTE!
Due to environmental concerns, we discourage
the use of strong chemicals. When using agents
for bleaching or stain removal, there is a risk
of rust (corrosion) and discolouration of the
machine.
Advice and tips before washing

12
Washing
1Sort your laundry.
See the "Advice and tips before washing"
chapter.
Place underwired bras in a laundry net.
Empty pockets. Coins, nails and the like can
cause damage to the machine and fabrics. See
the "Advice and Tips" section before washing.
2Turn on the main power
switch
3Open the washer door and
load the washing
If the washer door is closed, press the
Door opening button (key symbol). The door
opens once all water has drained from the
machine. Load the washing. The wash program
chart shows how much washing can be washed
with each program.
4Add detergent and fabric
softener, as required
The detergent packaging will have
recommendations for how much detergent you
should use.The machine holds 7 kg of washing.
If you only have a small amount of laundry in
the machine, you can reduce the amount of
detergent used.
Powder detergent
Pour the powder into the compartment for the
main wash, and pre-wash as well if desired.
Liquid detergent
When using a liquid detergent, observe the
detergent manufacturer's recommendations.
We recommend using a laundry ball with thick
detergents. In the main detergent compartment,
use the section wall (A) – see figure in the
section Dispenser. Add the detergent into the
front compartment of the detergent dispenser.
Wash ball or net
If you use a wash ball or net, place it directly
in the drum and select a program without pre-
wash.
NOTE!
Detergent overdosing does not give better
washing results; it merely causes a greater
impact on the environment; can also hinder the
wash performance.
Try using less detergent, and increase only if
you are not satisfied with the results.
Fabric softener
Pour the fabric softener into the
compartment with the symbol. Follow
the recommendations on the fabric softener
packaging.
NOTE!
Do not fill above the compartment’s maximum
fill level. Otherwise fabric softener will run in too
early, and will impair washing results.

13
Washing
5Program selection
You select a programme by turning
the programme selector. The selected
programme is shown in the display. Now use
the option buttons to select any options. See
chapter Selecting Options.
1.Auto
This program automatically adjusts the length
of the main wash and the number of rinses to
the amount and type of laundry loaded in the
machine.
2.Time program
This program adjusts itself to the specified time
frame or finish time. When using this program,
it is however important to select a temperature
and time suited to how soiled the laundry is. The
spin speed can be selected freely.
Specify the desired program time by pressing
+ or - on the Time button. The symbol for the
program lights beside the selected time.You can
choose a program time between 30 minutes and
3 hours. If you choose a 30-minute program time
the maximum wash temperature will be 30°C
3. Heavy
Program for heavily soiled laundry, with dirt
that needs to be fully dissolved before the
main wash. A pre-wash is used to do this. The
machine adapts the program time and water
consumption to the load size.
4. Normal
Program for normal to heavily soiled laundry,
whites and colours.You can select the
temperature freely, so follow the washing
instructions for each garment. 60°C is a good
temperature for heavily soiled cotton garments,
as well as for garments worn next to the
skin. Select 40°C if the laundry is less soiled.
The spin speed can be selected freely. The
machine adapts the program time and water
consumption to the load size.
5. Everyday wash
A standard program for lightly to moderately
soiled laundry. The temperature can be selected
freely, so follow the washing instructions for
each garment. Garments worn next to the skin
ought to be washed at 60°C. Very lightly soiled
laundry often comes clean already at 40°C.The
spin speed can be selected freely.
6. Quick
Fast program for laundry that just needs
freshening up. The program can be run at any
temperature, so follow the washing instructions
for each garment.
The lower the selected temperature, the shorter
the program time. Garments worn next to the
skin ought to be washed at 60°C. The spin
speed can be selected freely.
7. Easy Care
Program for synthetic, mixed fibre and easy
care cotton. The program has a high water
level and as such is also suitable for cushions,
quilted jackets and the like. Read the washing
instructions carefully and remember, for
example, that fabric softener must not be
used with the membranes found in some
outer garments. A washing temperature up to
60°C and a spin speed up to 1200 rpm can be
selected.

14
Washing
8. Synthetics
Program for delicate garments made of
synthetic fibre, mixed fibre, rayon and easy care
cotton. The maximum temperature is 60°C,
but follow the washing instructions for each
garment. Many synthetics will come clean at
40°C. Garments worn next to the skin ought to
be washed at 60°C. The maximum spin speed is
800 rpm.
9. Wool/hand wash
A gentle laundry program for wool, silk and
garments that should be washed by hand. The
highest temperature is 30°C. This program has a
short spin. The maximum spin speed is 800 rpm.
10. Rinse
This program performs one cold rinse cycle +
spin. Suitable for laundry that just needs to be
dampened and for cleaning cloths and mops.
11. Spin
Used to just spin the wash.
12. Drain
Used when you only want to drain the water
from the machine.

15
Washing
Program chart
Program Pre-wash Temp. °C Number of Rinses Spin Speed rpm Max. load (kg)
Water consumption
(approx. liter)
Energy consumption (approx. kWh) Programme time (approx. hrs and min.)
Hot 1) Cold 2) Sum 1)+2)
1. Auto
2. Time program
3. Heavy
X 90 5 1800 7 6 79 85 2,2 2:45
X 60 5 1800 7 6 69 75 1,2 2:40
4. Normal
60 2 1800 7 18 32 50 1,13 3:55
40 2 1800 7 18 32 50 0,47 3:40
5. Everyday wash 60 3 1800 7 18 42 60 1,1 1:40
6. Quick 40 2 1800 3,5 13 12 25 0,4 0:45
7. Easy Care 40 2 1200 3,5 12 48 60 0,6 1:40
8. Synthetics 40 3 800 3,5 13 17 30 0,4 1:20
9. Wool/hand wash 30 3 800 3,5 0 70 70 0,5 0:50
10. Rinse 1 1800 3,5 0 15 15 0,1 0:20
11. Spin 1800 3,5 0,1 0:15
12. Drain
1) Connection to Hot water, approx. 55 °C.
2) Connection to Cold water, approx. 15 °C.
Consumption data may vary from the given values depending on variations in water pressure, water hardness, water inlet temperature, room
temperature, fluctuations in the electricity, type and volume of the laundry and any extra options.
Adjustment of the displayed washing
time
Advanced technology allows the appliance
to sense the amount of laundry and add the
required amount of water during the washing
process. Depending on the washing load,
washing time can be longer or shorter and the
time displayed will be adjusted accordingly.
Moreover, displayed washing time may change
due to differences in inlet water temperature.
At low inlet water temperatures, washing time
can be longer; at higher temperatures, it can be
shorter.
Unevenly distributed laundry or lumps of
laundry in the washing machine drum can cause
problems such as vibration and noisy operation.
The appliance can sense such lumps and will
try to redistribute the laundry. Smaller loads
(e.g. one towel, one sweater, one bathrobe
etc.) or clothes made of materials with special
geometrical properties are virtually impossible
to distribute evenly across the washing machine
drum (slippers, large items etc.). This results
in several attempts to redistribute the laundry,
which in turn leads to longer program duration.

16
Washing
6Selecting options
You can select options to adjust the
wash programme to suit your own
specific requirements. The available options
depend on the selected programme. If the
option is available for the selected programme,
the symbol lights up when you press the button.
The machine will remember the options you
select for each programme (applies to Super
rinse, High water level and Super wash).You
can still change the selected options the next
time you select the same programme.
Temperature
• Select the temperature by pressing the -/+
buttons until the desired temperature is
displayed.
• You can select temperatures between
cold (-) and 90°C. By selecting cold, the
wash temperature will be the same as
the temperature of the water entering the
machine. For Wool/hand wash it is not
possible to select a temperature above 40°C,
when selecting Time program, Synthetics
and Easy Care the maximum temperature is
60 °C.
Spin
• Select the spin speed by pressing the -/+
buttons until the desired spin speed is
displayed.
• You can select speeds between 400 and
1400 rpm, (no spin) or No D (no drain).
The maximum spin speed varies according
to the program selected. The speed is shown
in the display.
• , means that the program does not include
a spin cycle and ends by draining.
• No D, No drain means that the program
does not include a spin cycle and ends
with the water from the final rinse still in the
machine. The washing will remain covered
by the water from the final rinse, stopping it
from getting creased. If you have selected
“No drain”, once the program has ended you
must select the Spin or Drain program to
drain the water from the machine before you
open the washer door.
Delayed start
When you select Delayed start the machine will
start 1-24 hours after you press the Start button.
This option cannot be used with Time program.
• Select Delayed start by pressing the + button
under the time display. Delayed Start is
shown for three seconds.
• By pressing the -/+ buttons under the time
display you can delay the start in whole
hours up to a maximum of 24 hours. The
symbol for Delayed start lights beside the
number of hours.
• Press Start, and the machine counts down
1 hour at a time and starts after the selected
delay.
If you change your mind and want to cancel
Delayed start, you must press and hold the Stop
button for three seconds.
NOTE!
Remember to press the Start button to start the
program.

17
NOTE!
Make sure the detergent compartment is
completely dry before you add detergent,
otherwise there is a risk that the detergent will
clump before the machine starts.
Super rinse
Use the Super rinse option if you want to
increase the number of rinses. The maximum
number of rinses is seven, and the number
of rinses varies depending on the selected
programme. Recommended for persons with
extremely sensitive skin and/or in areas with
very soft water.
Select Super rinse by pressing the button under
the symbol.
The symbol above the button lights when this
option is activated.
High water level
Use High water level if a garment’s laundry label
shows this symbol. High water level means that
additional water is used during the main wash
and rinse cycles.
• Select High water level by pressing the
button under the symbol.
• The symbol above the button lights when this
option is activated.
NOTE!
The machine takes in the additional water for
the High water level about 15 minutes after the
main wash has started.
Anti crease
Anti crease means that the drum will rotate for
three seconds per minute for two hours once
the wash programme has finished. This function
prevents the clothes from lying in the same
position and getting creased.
• Select Anti crease by pressing the button
under the symbol.
• The symbol above the button lights when this
option is activated.
Super wash
Super wash can be selected to better dissolve
difficult stains and heavy soiling on clothing.
This options adds a cold pre-wash and the
the wash time in cold water is extended by
approximately six minutes. The main wash time
is also extended.
• Select Super wash by pressing the button
under the symbol.
• The symbol above the button lights when this
option is activated.
Pre-soak
If the washing is stained, such as with blood, we
recommend Pre-soak.The washing will soak
in cold water for two hours before the wash
programme starts.
• Select Pre-soak by pressing the button under
the symbol.
• The symbol above the button lights when this
option is activated.
Washing

18
Washing
7Close the washer door and
press the Start/Stop button
NOTE!
A few seconds after you start a program the
washing machine will begin to fill with water
from both the hot and the cold supplies. If for
some reason no hot water is available, the
machine waits for one minute and then fills with
cold water only. The wash drum does not start
to rotate until it begins to fill with water.
Time remaining
The time remaining is shown in hours and
minutes. Once a program is selected, the
estimated program time is displayed. This
may differ from time to time depending on the
temperature of the water entering the machine
and the size of the load. If the program time is
longer than the previous wash with the same
program, "0:01" will be displayed until the
program finishes. This is normal! The next time
you use the program under similar conditions,
the estimated program time will be more
accurate.
To add or remove washing after the
program starts
If you want to add or remove items after
the program has started, you can stop the
program by pressing and holding the Door
opening button (key symbol) for three seconds.
When you restart the machine, add any extra
detergent needed and close the washer door.
The machine continues automatically from the
point where the program was interrupted.
Stopping or changing a programme
You can stop a program by pressing the Start/
Stop button for three seconds. "Stop" appears
in the display. To restart the machine, select a
new program, add any extra detergent needed
and press the Start/Stop button.
NOTE!
Do not open the detergent compartment while
the machine is running.
8Once the program has
finished
The text "Done" is shown on the display
for 2 minutes. The machine then turns off.
The washer door opens automatically once the
program has finished. If you want to deactivate
the automatic door opening function, see the
"Selecting settings" section.
• Remove the load.
If you have small children or pets at home, close
the washer door once you have removed the
laundry.
NOTE!
Upon completion of the washing cycle, close the
water faucet and unplug the mains cord.

19
Settings
You can change the following
settings:
• Child-safe
• Door opening
• Language
• Temperature
• Extra rinses
• Hot water
How to choose the settings:
1. Turn offthe machine using the main power
switch.
2. Press and hold the Door opening button
and then press the main power switch. Then
press the Door opening button 5 times within
10 seconds.
3. Select the setting you want to change by
turning the program selector.
4. Press the Door opening button once to select
the setting.
5. Change and save the setting as described
below.
6. Press Start/Stop to go to the program menu.
Child-safe
You can activate the Child-safe start option to
prevent children from starting the machine.
1. Turn the program selector and choose
"Child-safe On" or "Child-safe Off".
2. Press the Door opening button once to save
the setting.
You can temporarily deactivate Child-safe start
by pressing the Super Rinse button and the
minus button under Delayed Start at the same
time.
Child-safe start will be deactivated for three
minutes.
Door opening
The washer door opens automatically once the
program has finished. You can deactivate this
function if you would rather use the the Door
opening button to open the door.
1. Turn the program selector and select "Door
opening off" or "Door opening on".
2. Press the Door opening button once to save
the setting.
Language
1. Turn the program selector to choose from:
US English, English, Svenska, Dansk, Norsk,
Suomi, Français, Deutsch, Italiano, Espanol,
Русский, Nederlands.
2. Press the Door opening button once to save
the setting.
Temperature
1. Turn the programme selector to choose
between: °C and °F.
2. Press the Door opening button once to save
the setting.
Extra rinses
Upon delivery, your washing machine is set to
use three rinses in the Everyday wash program.
If you want to increase the number of rinses to
five for this program, do as follows:
1. Turn the program selector and select "Rinses
On" for five rinses or "Rinses Off" for three
rinses.
2. Press the Door opening button once to save
the setting.
Hot water
However, if you choose to connect your
ECO-machine to only the cold water it is
important that you shut offthe hot water
connection. Now select "Hot water Off". If your
machine is connected to both hot and cold
water, you should select "Hot water On".
1. Turn the program selector. Select "Hot water
Off" for a cold water connection or "Hot water
On" if the machine is connected to both hot
and cold water.
2. Press the Door opening button once to save
the setting.

20
Cleaning the trap and the drainage
pump
The washing machine has a trap where smaller
objects such as coins and hairpins can collect.
To clean the trap and the drainage pump, do as
follows:
1. Make sure the machine is empty of water
and switched offat the mains.
2. Open the door.
3. Unhook the drainage hose from the
connector inside the door and drain the water
into a suitable container, such as a shallow
bowl.
4. Turn the cover anti-clockwise to open the
pump. Remove the cover.
5. Remove any items and so forth from the
pump housing and the cover. Also check that
the pump blades right at the back rotate.
6. Screw on the cover, replace the drainage
hose on the hatch pin and close the hatch.
Cleaning the detergent
compartment
Pull out the detergent compartment using the
release button.
Rinse the compartment and scrub it clean. The
cover in the fabric softener compartment can be
removed.
NOTE!
Do not run the detergent compartment through
a dishwasher!
Cleaning the outside of the
machine
Clean the outside of the machine and the
program panel with a mild cleaner. Do not
use any solvents, as these can damage the
machine.
NOTE!
Do not hose down the machine with water!
Cleaning the inside of the machine
to avoid unpleasant smells
Modern detergents often allow clothes to be
washed at low temperatures. This means that
small deposits can build up in the machine.
These, in turn, may lead to unpleasant smells
developing.
To avoid this, we recommend running a 90 °C
wash programme once a month. When you do
this, use a small quantity of detergent. It is not
necessary to put any washing in the machine.
Care and cleaning
